BASIC OPERATION GUIDE
WebDT 390
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com
Copyright © 2011, DT Research, Inc. All Rights Reserved.
DT Research and WebDT are registered trademarks of DT Research, Inc.
INTRODUCTION
Thank you for acquiring the latest addion to
DT Research’s line of mobile tablets—the WebDT 390.
Featuring an IP54-rated, slim yet robust enclosure, the
two-pound WebDT 390 with 8.9”TFT display is powered by the Intel®Atom™ processor,
offering opmal combinaons of performance and power savings. An external baery
expansion opon provides approximately 3-4 hours of addional baery operaon for
up to eight hours of mobile usage.
The WebDT 390 is available with Windows®Embedded Standard 7, Windows®XP
Embedded, Windows®XP Pro for Embedded Systems, Windows®7 Pro or Linux operang
systems. Each soware operang system features web browser, client/server compung
soware, media player, accessories, and applicaons support.
PACKAGE CONTENTS
WebDT 390 with Internal Baery Pack, Stylus and Bumpers•
AC-DC Power Adapter with Power Cord•
Basic Operaon Guide•
Major opons, depending on configuraon:
Desktop Charging Cradle with DC-in Power Jack and Ethernet/ USB Ports•
Handstrap•
External External Baery Pack and Baery Charger Kit•
Vehicle/ Wall Mount Cradle•
5-System Gang Charger•
* If your WebDT 390 contains MSR, camera or scanner module, please refer to the POS module operaon guide
for detailed operaon.
BOG031811DT390ENG
SPECIFICATIONS
System
Processor Intel® Atom™ Z530, 1.6GHz
Memory (RAM) 1GB to 2GB DDR2 533MHZ
Storage 2GB to 16GB Internal Flash Module or 32GB to 128GB SSD
Operang Systems
Microso® Windows® Embedded Standard 7,
Windows® 7 Professional, Windows® XP Embedded,
Windows® XP Pro for Embedded Systems, or Linux
Display 8.9”LED-backlight screen with resisve touch;
outdoor-viewable opon
Display Resoluon 1024 x 600 (WSVGA)
Network Interface Wi-Fi 802.11a/b/g/n, 3G (Oponal)
Control Switch and Buons 1 power buon, 7 front buons and 1 trigger buon
Indicator 1 power/ baery status LED and 1 WLAN acve LED
Speaker/Microphone Built-in speaker; built-in internal microphone
Input/Output Ports 1 DC-in Jack; 1 USB 2.0 port;
1 Headphone-out Jack combined with microphone
Power
AC/DC Adapter Input: 100 – 240V AC; Output: 19V DC, 2.36A
Baery Pack Internal 7.4V, 3760mAh/ Oponal: External 7.2V, 3900mAh
Mechanical
Enclosure ABS + PC plascs
Stylus Non-electronic p
Protecve Grip Rubber
Dimensions (H x W x D) 7.7 x 10 x 1.25 in/ 196 x 256 x 32 mm
Weight 2.43 lbs/ 1.1 kg
Environmental
Water and Dust Resistance IP54
Vibraon and Shock Resistance MIL-STD-810G
Regulatory FCC Class B, CE, C-Tick, RoHS compliant
Temperature Operaon: 0°C - 40°C; Storage: -20°C - 60°C
Humidity 0% - 90% non-condensing
* Specificaons subject to change without noce.
Mobile POS Tablet

WebDT 390
ENGLISH 23ENGLISH
Buon Funcons (with Windows XP Operang System)
BUTTON ACTION
Programmable
Programmable, launch so(on-screen) keyboard (default)
Launch SAS (Secure Aenon Sequence)
Generate Ctrl+Alt+Del keys to invoke the security windows defined under Windows XP
Programmable,
Change display orientaon (portrait/ landscape) (default)
Programmable, system ulity menu (default)
Programmable,
As scanner trigger when equipped with the scanner module
Power on,
Push/release typically enters Standby mode, or Push/release exits Standby mode or
restarts device (soware dependent)
Push and hold (over 4 seconds) invokes hardware shutdown
The WebDT 390 (with Windows XP Operang System)
Baery/Power LED
Wireless LEDMicrophone
Stylus
Buon ManagementWireless Network Sengs
Calibraon
Power/Baery LED Status:
Blue indicates the baery is 25% to 100% charged•
Blinking blue indicates the baery is charging•
Orange indicates that the baery is between 11% to 25%•
Blinking Orange indicates that the baery is below 10%•
Precauons
Always exercise care when operang and handling the WebDT 390.
•
Do NOT apply excessive pressure to the display screen.
•
We recommend using the Stylus provided to keep the screen clean.
•
Avoid prolonged exposure of the display panel to any strong heat source. Wherever
•
possible, the WebDT 390 should face away from direct light to reduce glare.
If the AC-DC power adapter is used to recharge or power the device, do NOT use any
•
AC-DC adapter other than the one provided with the device or acquired from the
manufacturer or its partners.
In the unlikely event that smoke, abnormal noise, or strange odor is present,
•
immediately power offthe WebDT 390 and disconnect all power sources. Report the
problem to your device provider immediately.
Never aempt to disassemble the WebDT 390, as this will void the warranty.
•
THE WebDT 390
Basic Features
The WebDT 390 wireless tablet integrates a bright and responsive touch display, 1 USB
port, and embedded networking elements such as wireless LAN or oponal 3G. The
primary device is complemented by a suite of accessories, including baery expansion,
docking cradles, and carrying cases, for a comprehensive user experience.
A WebDT 390 typically integrates an 802.11a/b/g/n wireless LAN (WLAN) adapter that
may connect to other wireless devices or access points. If your WebDT 390 does not
come with such a network adapter, please consult your device provider to establish the
desired network connecvity.
1
8
9
2 3
4
5
6
8
9
7
Input/ Output Ports
Headphone Jack
USB Port
DC Power Input
A
C
B
A
B
C
1234567
Baery and Power Meter

WebDT 390
ENGLISH 45ENGLISH
OPERATION
Internal Baery
Warning!
The Internal baery pack should only be replaced by an authorized WebDT service
representave. Please contact your product and/or service provider for internal baery
replacement service.
Powering ON and OFF
To acvate the WebDT 390, push and quickly release the Power Buon. The display will
come on in a few seconds. To put the WebDT 390 in Standby mode, push and quickly
release the Power Buon. To turn the WebDT 390 offfor extended storage, power off
the device safely using any soware funcon that “shuts down computer”provided in
the soware operang system.
NOTE: The baery packs shipped with your device may be low in power—please use
the AC-DC adapter with the WebDT 390 when seng up the device for the first me to
fully charge the internal baery pack. You may charge the external baery pack with it
aached to the WebDT 390, or with the oponal external baery charger kit.
NOTE: When the baery pack(s) is (are) charging, the blue-colored Baery LED should
blink slowly. If plugging in the AC-DC adapter does not trigger this blinking acvity
and the LED stays dark, the baery pack(s) may have been drained substanally. Try
unplugging/ replugging the AC-DC adapter to the WebDT 390 a few mes to acvate the
charging process.
NOTE: To conserve power, use (push and quick release) the Power Buon to put the
device in “Standby”mode while not in use. Pushing briefly on the same buon will wake
up the system within seconds.
NOTE: Avoid using the Power Buon (“hold 4+ seconds”feature) to turn offthe
device—this form of hardware shutdown is intended to be a means of recovery from
device lockups, and not as normal operaon.
Start Up
If the power up (from Standby or otherwise) is successful, the appropriate interface will
be displayed aer a launch sequence of several seconds. The wireless LAN connecon
may take 10-15 seconds to be established.
Configuring the WebDT 390
The device may be configured using the ulies and methods dictated by the soware
operang system. The WebDT 390 should be configurable for various properes such as
user profiles, network features, and several system elements.
Calibraon
The touch display for the WebDT 390 is calibrated before shipping. In the event that the
calibraon has been modified or is unsasfactory, the respecve calibraon rounes
(e.g., PenMount (PM) for Windows XP) to calibrate the touch interface may be used.
Such applicaons are typically executed through touch input via Stylus or through mouse
click via a USB mouse.
Wireless Networking
Wireless LAN
The WebDT 390 is oen delivered with an embedded (user-inaccessible) 802.11a/b/g/n
WLAN adapter equipped with a hidden custom antenna.
T
•hrough the support of typical WLAN adapters, the WebDT 390 should be able to
detect all 802.11 access points in the vicinity for you to select the access point of
your choice for connecon.
T
•he SSID and WEP/WPA/WPA2 (if enabled) parameters on the WebDT 390 and
the access points have to match. The SSID is case-sensive and it is recommended
that you enable WEP/WPA/WPA2 encrypon (or advanced alternaves) for secure
access.
W
•hen WEP/WPA/WPA2 is enabled, you may need to consult your network admin-
istrator or your networking equipment literature to properly configure associated
sengs such as Authencaon mode, etc.
R
•efer to the access point operang manuals for seng up the 802.11 access points.
!

WebDT 390
ENGLISH 67ENGLISH
Buon Management
Where supported by soware, many of the hard buons on the WebDT 390 are
programmable to perform a funcon of the user’s choice. The excepon is the Power
Buon and the SAS Buon. To acvate the buon re-assignment applicaon, invoke the
Buon Manager applicaon, e.g., in Windows XP Embedded.
Brightness Control
Where supported by device firmware and soware, a hard buon may be engaged to
manipulate the display brightness. Press the System Menu buon (Buon 7) on the front
of the WebDT 390. The System screen will display a Brightness control secon with up
and down arrows that can be acvated with the stylus.
Baery and Power Management
The WebDT 390 is equipped with an internal 3760mAh Li-Ion baery pack that is
capable of supporng approximately 3 - 4 hours of connuous operaon. With the
internal baery and an external baery pack that clips (hot-pluggable) onto the back
of the device, the maximum period of connuous operaon will be approximately 6 - 8
hours. The period between baery recharges can be significantly lengthened by pung
the device into Standby mode through the Power Buon (see Buons Funcon Table)
whenever the device is not in use. Depending on the operang soware, the WebDT 390
may also be configured to enter various power-saving modes via the Power Buon or
through med entry.
Desktop Cradle
The WebDT 390 is complemented by an oponal Desktop Cradle for support, pass-
through charging, and connecon to a range of USB peripherals, including keyboard and
mouse. The Cradle offers the following interfaces: a DC-in port for the AC-DC adapter,
an Ethernet port, and USB ports. Always seat the WebDT 390 securely onto the cradle.
The cradle must be powered by the AC-DC adapter for the Ethernet and USB ports to
funcon. The baery packs on the WebDT 390 may be recharged by connecng the
AC-DC adapter directly to the DC-in port on the WebDT 390 or through the DC-in port on
the Desktop Cradle while the WebDT 390 is docked to the Cradle.
USING THE WebDT 390
Memory & Storage configuraon
The WebDT 390 is available with 1GB or 2GB memory configuraons. Storage opons
currently range from: 2GB to 16GB flash memory or 32GB to 128GB SSD.
Peripherals Support
Through its USB ports, the WebDT 390 supports a wide range of USB-based peripherals.
These peripherals are applicable for soware installaon, applicaons storage, data
storage, and system soware recovery and updates. The WebDT 390 is also compable
with custom mountable cradle opons. These securable and mountable cradles provide
an interface to VESA mounts and arms, and to ports that may include USB, Ethernet and
pass-through power.
