Webdyn WebdynSunPM User manual

WebdynSunPM
Supervision gateway for photovoltaic
installations
USER MANUAL

2
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
Contents
1Presentation........................................................................................................ 9
General description.................................................................................... 10
Operating principle..................................................................................... 10
The interfaces ............................................................................................ 11
Supported devices...................................................................................... 13
Product and accessory references............................................................. 13
Technical Specifications............................................................................. 14
1.6.1 General specifications........................................................................... 14
1.6.2 Technical specifications........................................................................ 15
1.6.3 Software specifications ......................................................................... 16
Safety instructions...................................................................................... 16
Regulation.................................................................................................. 17
2Installation and Maintenance............................................................................. 18
Prerequisite................................................................................................ 19
Unpacking.................................................................................................. 19
2.2.1 Content................................................................................................. 19
2.2.2 Identification.......................................................................................... 19
Assembly.................................................................................................... 21
2.3.1 Opening/closing the box ....................................................................... 21
2.3.2 Wall mounting....................................................................................... 21
Interface description................................................................................... 22
2.4.1 Product power supply ........................................................................... 22
2.4.1.1 External power supply.................................................................... 22
2.4.1.2 Battery............................................................................................ 23
2.4.2 Cellular Network.................................................................................... 23
2.4.2.1 Antenna.......................................................................................... 23
2.4.2.2 SIM card......................................................................................... 24
2.4.3 Indicators & buttons.............................................................................. 25
2.4.3.1 Power Button.................................................................................. 26
2.4.3.2 Factory Reset button...................................................................... 26
2.4.3.3 Power LED..................................................................................... 27
2.4.3.4 Activity LED.................................................................................... 27
2.4.3.5 Serial LED...................................................................................... 27
2.4.3.6 WAN LED....................................................................................... 27
2.4.4 Extension interface ............................................................................... 28
2.4.4.1 External memory medium (MicroSD) ............................................. 28
2.4.4.2 USB interface................................................................................. 28
2.4.5 Ethernet interface.................................................................................. 29
2.4.6 RS485/RS422 Serial interface.............................................................. 30
2.4.7 Input/Output interface ........................................................................... 33
2.4.7.1 Analog 0-10V or 4-20mA inputs ..................................................... 34
2.4.7.2 Digital ON-OFF/S0 (pulsed) inputs................................................. 35
2.4.7.3 Relay output................................................................................... 37
3Configuration..................................................................................................... 39
FTP/SFTP.................................................................................................. 44
3.1.1 Operating principle................................................................................ 44

3
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
3.1.2 Configuration files................................................................................. 45
3.1.2.1 Concentrator operation................................................................... 46
3.1.2.1.1 “<uid>_config.ini” file ................................................................. 46
3.1.2.1.2 “<uid>_var.ini” file...................................................................... 47
3.1.2.1.3 “<uid>_daq.csv” file................................................................... 49
3.1.2.1.4 “_sci.ini” file ............................................................................... 59
3.1.2.2 Connected device definition ........................................................... 60
3.1.2.2.1 Definition file naming................................................................. 61
3.1.2.2.2 Definition file content................................................................. 62
3.1.3 Updates ................................................................................................ 67
Embedded web interface............................................................................ 68
3.2.1 Devices................................................................................................. 70
3.2.1.1 Automatic device detection............................................................. 70
3.2.1.1.1 SunSpec device detection......................................................... 70
3.2.1.1.2 TIC device detection ................................................................. 74
3.2.1.1.3 SMA-Net device detection......................................................... 76
3.2.1.2 Manual device management .......................................................... 80
3.2.1.2.1 Add a device ............................................................................. 80
3.2.1.2.2 Deleting a device....................................................................... 84
3.2.1.2.3 Editing a device......................................................................... 85
3.2.1.2.4 Modifying the input/output configuration.................................... 86
3.2.1.2.5 Duplicating a device.................................................................. 89
3.2.2 Settings................................................................................................. 90
3.2.2.1 Concentrator................................................................................... 90
3.2.2.2 Serial.............................................................................................. 91
3.2.2.3 Networks ........................................................................................ 93
3.2.2.4 Modem ........................................................................................... 95
3.2.2.5 Servers........................................................................................... 99
3.2.2.6 Date & Time ................................................................................. 104
3.2.2.7 Password...................................................................................... 109
3.2.3 System................................................................................................ 110
3.2.3.1 Scripts .......................................................................................... 110
3.2.3.1.1 Importing a script..................................................................... 111
3.2.3.1.2 Enabling/Disabling a script...................................................... 113
3.2.3.1.3 Viewing the script log.............................................................. 113
3.2.3.1.4 Viewing the script.................................................................... 114
3.2.3.1.5 Exporting a script .................................................................... 115
3.2.3.1.6 Deleting a script ...................................................................... 115
3.2.3.2 Update.......................................................................................... 116
3.2.3.3 Rebooting the webdynSunPM...................................................... 117
Text message command.......................................................................... 118
3.3.1 “connect” connection command .......................................................... 118
3.3.2 “apn” modem configuration command ................................................ 119
3.3.3 “ftp” FTP configuration command........................................................ 119
3.3.4 “reboot” command............................................................................... 119
3.3.5 “status” command ............................................................................... 120
3.3.6 SunSpec “detect” command................................................................ 122
3.3.7 “factory” reset command ..................................................................... 123
4Operation......................................................................................................... 125
The FTP/SFTP server.............................................................................. 126

4
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
4.1.1 The configuration “CONFIG”............................................................... 129
4.1.2 “DEF”, the definitions .......................................................................... 130
4.1.3 “DATA”................................................................................................ 131
4.1.3.1 TIC header ................................................................................... 132
4.1.3.2 Input/Output (IO) header .............................................................. 132
4.1.3.3 Device header (Modbus, inverters) .............................................. 133
4.1.3.4 Data.............................................................................................. 133
4.1.4 “ALARM” alarms ................................................................................. 136
4.1.5 “CMD” commands............................................................................... 138
4.1.6 “SCRIPTS”.......................................................................................... 138
4.1.7 “BIN” update........................................................................................ 138
4.1.8 “LOG”.................................................................................................. 139
4.1.8.1 Connection logs............................................................................ 139
4.1.8.2 Script logs..................................................................................... 142
4.1.8.3 SunSpec detection logs................................................................ 142
4.1.8.4 System logs.................................................................................. 144
The MQTT/MQTTS server ....................................................................... 144
4.2.1 Configuration....................................................................................... 144
4.2.2 Operation............................................................................................ 144
5Update............................................................................................................. 145
Using the web interface............................................................................ 146
Using FTP/SFTP...................................................................................... 146
6Tools & diagnostics ......................................................................................... 148
Diagnostics............................................................................................... 149
Tools ........................................................................................................ 149
7Support............................................................................................................ 150
8FAQ................................................................................................................. 152
9APPENDICES................................................................................................. 159
Appendix A: “_config.ini” file..................................................................... 160
Appendix B: Time zone list....................................................................... 168

5
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
Glossary
Name
Description
2G
Second Generation
Second generation (2G) digital standard for cell phones including GSM, GPRS
and EDGE.
3G
Third Generation
Third generation (3G) digital standard for cell phones including UMTS, HSPA,
HSPA+ and DC-HSPA+.
AES
Advanced Encryption Standard
Symmetrical encryption algorithm.
APN
Access Point Name
The name of the access point the gateway uses to connect to the Internet via
a mobile connection.
CSV
Comma-separated values
Open text format representing tabulated data in the form of values
separated by semi-colons. This format makes it easy to use data with
spreadsheet software such as Excel.
DNS
Domain Name System
Distributed computer service used to translate Internet domain names to IP
addresses.
FTP
File Transfer Protocol
Communication protocol used to exchange files over a TCP/IP network.
HTTP
HyperText Transfer Protocol
Client-server communication protocol developed for the Web.
IMEI
International Mobile Equipment Identity
Number used to uniquely identify each modem
IMSI
International Mobile Subscriber Identity
Unique number stored in the SIM card used by a cell phone network to
identify a user.

6
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
IP
Internet Protocol
Message protocol in charge of addressing and sending TCP packets over the
network.
Lua
Script language. See http://www.lua.org/ for more details.
Modbus
Modbus is a communication protocol routinely used by industry to dialogue
with industrial equipment over a network. See http://www.modbus.org/ for
more details.
MQTT
Message Queuing Telemetry Transport
Publish-subscribe messaging protocol based the TCP/IP protocol.
MQTTS
Secure Message Queuing Telemetry Transport
NTP
Network Time Protocol
Protocol used to synchronise the local concentrator clock with a time
reference via a computer network.
DIN rail
Standard 35 mm metal rail used in racked industrial control equipment in
Europe.
RSSI
Received Signal Strength Indication
Reception power level measurement of a signal issued by a radio antenna.
RTU
RTU mode is an RS422/485 hard-wired bus for Modbus.
S0
Standardised pulse from meters (water, gas, electricity, etc.) as per the NF
EN 62053-31 standard
SFTP
SSH File Transfer Protocol
Communication protocol using a secure SSH communication protocol. Its use
is similar to FTP.
IS
Information System
Server with which the concentrator exchanges (configuration, data, alarms,
etc.)
Sunspec
Open communication protocol for inverters based on Modbus and compliant
with the SunSpec alliance standards (See https://sunspec.org/for more
details).
TCP
Transmission Control Protocol
An Internet-based connection-oriented protocol that provides data packet
segmenting services that the IP protocol sends over the network. This
protocol provides a reliable data transfer service. See also IP.

7
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
TCP/IP
Transmission Control Protocol/Internet Protocol
A set of network protocols that provide interconnection services between
computers of different hardware architectures and operating systems.
TCP/IP includes standards for communication between computers and
conventions for network interconnection and routing.
TIC
Customer remote information
Digital data output from ERDF meters that permanently broadcasts the
managed contractual parameters as well as the consumption magnitudes
measured by the meter.
UDP
User Datagram Protocol
Non connection-oriented protocol of the TCP/IP model transport layer. This
protocol is very simple because it does not provide error checks (it is not
connection-oriented...).
UTF-8
Universal Character Set Transformation Format1 - 8 bits
Computer character encoding designed to encode all the characters from the
‘Universal encoded character set”

8
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
Notes on this manual
This guide describes all the WebdynSunPM product characteristics.
Its purpose is to help operators install and configure their WebdynSunPM and to allow
operators to include collected data in their IS.
This manual is split into six separate sections:
➢Section 1: General presentation
➢Section 2: Installation
➢Section 3: Configuration
➢Section 4: Operation
➢Section 5: Tools & diagnostics
➢Section 6: FAQ
Scope
This technical description is valid for WebdynSunPM concentrators as from hardware version
V1 and software version V3.0.0.
Target group
This guide is intended for all people involved in photovoltaic system supervision, in particular
people in charge of local or remote installation maintenance, as well as for the developers of
portals designed to use the sent data.
We recommend calling on specialised and trained persons to install and commission the
WebdynSunPM. Please get in touch with your sales contact ([email protected]) to obtain
the list of partner portals.
Change history
Version
Content
V2.05
Manual creation

9
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
1Presentation

10
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
General description
The WebdynSunPM is a concentrator designed to monitor all types of photovoltaic
installation. It is used to collect, analyse, monitor and control the on site devices.
The collected information (data, parameters, etc.) is formatted before being sent to an
Information System (IS). The concentrator provides the security and confidentiality of the
exchanged information.
The automation of certain local actions, for example injection or self-consumption is managed
using customisable scripts embedded in the concentrator.
Operating principle
The WebdynSunPM concentrator can be fully integrated into photovoltaic installations.
Devices such as inverters, sensors (pyranometers, temperature sensors, etc.), meters,
displays, circuit breakers or relays can be connected to the concentrator using its many
available interfaces. Information readings and device control are carried out by the
WebdynSunPM continuously. The data is regularly formatted and uploaded to an FTP server
and/or sent to an MQTT server using the modem or an Ethernet connection. The concentrator
manages the SFTP and MQTTS protocols to secure exchanges with the servers. The
WebdynSunPM can be configured by simply sending text message commands, but also using
the embedded web pages.
Specific scripts can be created for installations requiring specific functions.

11
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
The interfaces
Devices
WebdynSunPM
Operation
0
1
5
3
0
Sensors
Meters
Inverters
Displays
Circuit breakers
Relays, etc.
Web Server
Scripts
Data
management
Troubleshooting
Text message
Server
MQTT
Server
FTP
2G/3G modem
Ethernet
Configuration/
Maintenance

12
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
12-24 V power supply terminal block
2 Ethernet ports (LAN 1 and LAN 2)
4 0-10 V or 4-20 mA analog inputs
1 Relay output
Indicators:
•Power: 12-24 V power supply status
•Activity: Product status
•Serial1, Serial2, Serial3:
•Tx: Data sent on the RS485/RS422 serial port
•Rx: Data received on the RS485/RS422 serial port
•WAN: Connection status
Power button
Micro SD card slot
3 Digital inputs (ON-OFF or pulsed S0)
1
2
3
4
5
6
7
8
11
8
7
5
2
13
3
4
6
12
9
10
1
3

13
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
3 RS485/RS422 ports
SIM card holder
Modem SMA antenna connector
USB port (for extension)
RESET button
Supported devices
The WebdynSunPM is compatible with all devices that include one of the supported protocols.
Partial list of the supported protocols:
Inverter protocol
Physical interface
Specifications
SMA-net
RS485/RS422 2 wires
100 max
Modbus TCP
Ethernet
254 max
Modbus RTU
RS485/RS422 2 wires or 4
wires
247 max
Power-One Aurora
RS485/RS422 2 wires
100 max
TIC
USB (cable optional)
1 max
Currently, much inverter equipment runs using Modbus.
The concentrator accepts all Modbus RTU and TCP devices.
Product and accessory references
Product:
References
Descriptions
WG0517-A01
WebdynSunPM (Europe and India)
Accessories:
References
Descriptions
AC1601-01
USB / TIC extension 1 modulated input
9
10
11
12
13

14
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
AC1601-02
USB / TIC extension 1 non-modulated input
AC1101-01
4-20 mA ambient temperature sensor
AC1101-02
Modbus ambient temperature sensor
AC1102-01
4-20 mA surface temperature sensor
AC1401-01
Class C pyranometer
AC1402-01
3 m pyranometer cable
AC1403-01
20 m pyranometer cable
AC1201-01
Modbus slave 8 ON-OFF inputs / 6 relay outputs
AC1201-02
Modbus slave 16 ON-OFF inputs
AC1301-01
Single phase electricity meter
AC1301-02
Single phase electricity meter with relay
AC1302-01
Three phase electricity meter
AC1302-02
Three phase electricity meter with relay
AC1001-01
Irradiation and temperature sensor & 3m Modbus cable
AC1002-01
Irradiation sensor
Technical Specifications
1.6.1 General specifications
Specifications
Descriptions
Power supply
+12V 700mA (some functions are not
supported on 12V)
or
+24V 350mA
Battery
650mAh 3.7V, Lithium-polymer
Consumption
P: 5 W
Pmax: 10W
Dimensions
155x 106 x 58mm
9 DIN rail modules
Box
RoHS compliant
DIN EN 60715 TH35
DIN VDE 0470-1
DIN 43880 size 1

15
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
REACH compliant
VBG 4
IEC 529
Non leak tight
Fixing
DIN rail
Weight
0.330 kg
Operating temperature
-5 °C / +40 °C
Storage temperature
Storage: -20 °C / +85 °C
Humidity
25 - 75 %
Pollution rating
2
Certification
RED
ROHS
REACH
Regulation
: CE marking created in the framework
of European technical harmonisation
legislation. It is mandatory for all products
covered by one or more European
regulatory texts (directives or regulations)
: Symbol indicating that the waste must
be collected via a specific channel and must
not be disposed of as household waste.
: Symbol indicating that the product
must be recycled.
1.6.2 Technical specifications
Specifications
Descriptions
Memory capacity for data
DDR3 SDRAM: 512 Mb
Flash eMMc: 8 Gb in total (50Mb max per
defined device)
SD card
MicroSD MMC/SD/SDIO (up to 32 Gb)
Cellular Interface Modem
GSM/GPRS/EDGE/3G modem
•2G (EDGE, GSM, GPRS): B1 and B8
•3G (HSPA): B1 and B8
Antenna: External SMA
SIM format
Standard SIM (mini SIM) 2FF format
1.8V compatible
Ethernet interface
2 10/100 Mbits/s ports available
USB interface
1 USB2.0 port
Serial interface
3 RS485/RS422 ports
Input/Output interface
4 analog 0/10V or 4/20mA inputs

16
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
3 digital ON-OFF or pulsed S0 inputs (class A or B)
1 relay output
Webdyn does not supply any SIM cards. Please contact an M2M operator that
supports the 2G and 3G networks.
Connectivity data:
RF band
Emission frequencies
Max Power
UMTS B1
1922 Mhz - 1978MHz
22.5 dBm(+-1.5dB)
UMTS B8
882 Mhz - 913 MHz
22.5 dBm(+-1.5dB)
E-GSM 900
880 Mhz - 915 MHz
33 dBm (+-2dB GSM,GPRS)
DCS 1800
1710 Mhz - 1785 MHz
30 dBm (+-2dB GSM,GPRS)
1.6.3 Software specifications
Specifications
Protocols/Formats
Embedded server
HTTP
Server communication protocol (IS)
•FTP
•SFTP
•MQTT
•MQTTS (generic and compatible with
AWS IoT, Azure IoT and Google Cloud IoT)
Modbus
•RTU
•TCP
Clock synchronisation
NTP
File format for the server (IS)
•CSV for FTP/SFTP
•JSON for MQTT/MQTTS
Safety instructions
Follow all the safety instructions in this guide.
Failure to follow these instructions can damage equipment and endanger people.
Electric connection:
•All wiring work must be carried out by a specialised qualified electrician.
•Please follow all the safety instructions featured in the manufacturer’s device
documentation.

17
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
The WebdynSunPM product can be damaged by electrostatic discharges (ESD)
Class 3 equipment: the device operates on safety extra-low voltage (SELV) (50V
maximum). The voltage reduction must be obtained using a safety transformer
providing safe galvanic isolation between primary and secondary.
This equipment is not suitable for use on premises that may host children.
Do not install the equipment near a heat source or at a height greater than 2m.
To clean the product, only use a slightly damp cloth to gently clean and wipe the
surfaces.
Never use aggressive chemical agents or solvents that could alter the plastic material
or corrode the metal parts.
It is essential to leave a 20 cm empty space around the antenna to optimise the
Modem cell sensitivity.
Regulation
The product is compliant with the European directives according to the EU declaration of
Conformity available from Webdyn or from the web site: www.webdyn.com
Recycling:
The nationally enacted European directives covering batteries and waste electric
and electronic equipment govern the actions required to limit the negative impact
of the end of product life.
These products are collected separately. Use an authorised battery collection and processing
centre or contact Webdyn.

18
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
2Installation and Maintenance

19
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
Prerequisite
As the WebdynSunPM concentrator’s role is to send the data it collects to an IS, installation
requires knowledge of the concentrator but also of the IS it will upload its data to.
The following elements are required to guarantee a proper installation:
-To have this user manual to hand.
-To have a screwdriver suitable for the connector types available on the
WebdynSunPM.
-To have knowledge of the parameters to connect to the IS information system.
It is also strongly recommended to have the elements described below for any
intervention on site and to install the product.
-To have a SIM card with an activated M2M subscription (data and text messages
(optional)) and knowledge of the supplier’s APN. The SIM card call number can be
useful.
-Use a remote antenna if radio or cellular modem reception is deteriorated.
-To have a PC for the product configuration or update using the concentrator’s Web
interface
Unpacking
2.2.1 Content
The standard version of the WebdynSunPM concentrator is delivered with:
•an angled SMA antenna for the modem (taped to the back of the product)
•a battery (already in place in the product)
2.2.2 Identification
The commercial reference is composed as follows:
•WG0517-A01: WebdynSunPM Europe and India version
Each product is labelled with the following information:

20
USER MANUAL –WebdynSunPM
Version 2.05
préliminaire
This label is accessible on the top of the product:
The product CE label on the back of the box:
Commercial reference
Product serial number
Date of manufacture
WG0517-A01
WW/Y
Y
MAC: 00:05:F3:00:00:00
WFFVVAAHHHHHH
MAC address
WG0517-A01
WW/
YY
MAC: 00:05:F3:00:00:00
WFFVVAAHHHH
HH
