Weber Summit Series Guide

56433 02/08/11 AA
NOTE: Grills illustrated may have slight differences than model purchased.
THIS PROCEDURE SHOULD ONLY BE PERFORMED BY AN AUTHORIZED
WEBER-STEPHEN PRODUCTS LLC SERVICE TECHNICIAN
WARNING: GENUINE WEBER-STEPHEN REPLACEMENT PARTS MUST BE USED FOR ANY REPAIR OR REPLACEMENT.
YOUR ACTIONS, IF YOU FAIL TO FOLLOW THIS PRODUCT WARNING, MAY CAUSE A FIRE, AN EXPLOSION, OR
STRUCTURAL FAILURE RESULTING IN SERIOUS PERSONAL INJURY OR DEATH AS WELL AS DAMAGE TO PROPERTY.
(WILL VOID ALL WARRANTY PROTECTION.)
 DANGER: BEFORE PERFORMING ANY WORK MAKE SURE THE GAS SUPPLY IS TURNED OFF AT THE SOURCE.
FAILURE TO FOLLOW DANGERS, WARNINGS AND CAUTIONS CONTAINED IN THIS INSTRUCTION SHEET MAY CAUSE A
FIRE OR AN EXPLOSION RESULTING IN SERIOUS PERSONAL INJURY OR DEATH AS WELL AS DAMAGE TO PROPERTY.
SIDE BURNER ASSEMBLY
REPLACEMENT INSTRUCTIONS
Side Burner
ASSeMBLY
repLAceMent
BEFORE STARTING: Make sure lid
is closed and casters are locked to
prevent grill from moving.
12
Side Burner cOMpOnent reMOVAL Side Burner GAS Line reMOVAL
A) Lift side burner lid.
B) Remove all side burner components from top of side burner assembly.
A) Remove quick-disconnect side burner gas line from side burner assembly,
which is located under side burner table.
Side Burner Grate
Side Burner Cap
Side Burner Ring
and Head
Control Knob
Side Burner
Lid Bumper

3
4
5
Side Burner ASSeMBLY reMOVAL
Side Burner iGniter reMOVAL
Side Burner iGniter reinStALLAtiOn
TOOLS NEEDED: - PHILLIPS
TOOLS NEEDED: - FLAT HEAD
A) Remove screws that secure side burner assembly to side burner table (1)
with a Phillips head screwdriver.
B) Lift and remove side burner assembly (2) from side burner table.
A) Under side burner assembly. Remove side burner igniter wires (1) from
side burner igniter.
B) Press in left clip of side burner igniter (2), using a flathead screwdriver
until it releases from side burner assembly.
C) Press in right clip of side burner igniter (3), using your thumb until it
releases from side burner assembly.
D) Remove igniter assembly out of
side burner assembly.
A) Reinstall side burner igniter assembly (1) in side burner assembly.
B) Flip side burner assembly over. Reinstall side burner igniter wires (2) onto
side burner assembly.
WARNING: All gas controls and supply valves should be in
the OFF position.
Make sure black wire is connected between igniter and electrode.
Make sure white wire is connected between igniter and grounding clip.
Spark should be a white/blue color,
not yellow.
A) Black — igniter wire (2)
B) White — ground wire (3)
1
2
1
2
6
Side Burner ASSeMBLY inStALLAtiOn
TOOLS NEEDED: - PHILLIPS
A) Lift side burner lid. Install side burner assembly (1) into side burner table.
B) Install screws that secure side burner assembly to side burner table (2)
with a Phillips head screwdriver.
2
1
2
1
1
2 3
1
2
3
•REPLACEMENTPARTINSTALLATION

78
Side Burner cOMpOnent reinStALLAtiOn Side Burner GAS Line reinStALLAtiOn
A) Place all side burner components onto top of burner assembly.
B) Close side burner lid.
A) Reinstall quick-disconnect side
burner gas line onto side burner
assembly, which is located under
side burner table.
Side Burner Grate
Side Burner Cap
Side Burner Ring
and Head
Control Knob
Side Burner
Lid Bumper
 WARNING: Make sure all control knobs are turned to the OFF position before reconnecting gas supply and
operating grill. Your actions, if you fail to follow this Product Warning, may cause a fire, an explosion, or structural
failure resulting in serious personal injury or death as well as damage to property.
9cHecK FOr GAS LeAKS
 DANGER
Do not use an open flame to check for gas leaks. Be sure
there are no sparks or open flames in the area while you
check for leaks. Sparks or open flames will result in a fire or
explosion, which can cause serious bodily injury or death and
damage to property.
You will need: a soap and water solution and a rag or brush to apply it.
A) Mix soap and water.
B) Turn on the gas supply at the source.
C) Check for leaks by wetting the fittings with the soap and water solution and
watching for bubbles. If bubbles form, or if a bubble grows, there is a leak.
D) When leak checking is complete, turn gas supply off at the source and rinse
connections with water.
Check:
A) Side burner pipe fitting-to-side burner cup (1).
B) Side burner pipe fitting-to-side burner valve connections (2).
 WARNING: If there is a leak at connection (1 or 2),
retighten fitting with a wrench and recheck for leaks
with soap and water solution. If a leak persists
after re-tightening the fitting, turn OFF the gas.
DO NOT OPERATE THE GRILL. Failure to follow
dangers, warnings and cautions contained in this
Instruction sheet may cause a fire or an explosion
resulting in serious personal injury or death as
well as damage to property. Contact the Customer
Service Representative in your area using the contact
information on our web site.
Log onto www.weber.com®.
Gas Sources:
NGLP
45
12
3
C) Side burner quick-disconnect connections (3).
D) LP: Regulator hose-to-cylinder connections (4).
E) NG: Hose-to-quick-disconnect gas line connections (5).
WARNING: If there is a leak at connections (3, 4 or 5), turn
OFF the gas. DO NOT OPERATE THE GRILL. Failure to follow
dangers, warnings and cautions contained in this Instruction
sheet may cause a fire or an explosion resulting in serious
personal injury or death as well as damage to property.
Contact the Customer Service Representative in your area
using the contact information on our web site.
Log onto www.weber.com®.
When leak checks are complete, turn gas supply OFF at source and rinse
connections with water.

 PROPOSITION 65 WARNING: HANDLING THE BRASS MATERIAL ON THIS PRODUCT EXPOSES YOU TO LEAD, A CHEMICAL
KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
(WASH HANDS AFTER HANDLING THIS PRODUCT.)
 WARNING: All repairs to gas carrying, gas burning, igniter or structural components must be performed by an
authorized Weber-Stephen Products LLC service technician.
These parts may be gas carrying, gas burning, igniter or structural components. Please contact Weber-Stephen Products LLC, Customer
Service Department for Genuine Weber-Stephen Products LLC replacement part(s) information.
 WARNING: Do not attempt to make any repair to gas carrying, gas burning, igniter or structural components
without contacting Weber-Stephen Products LLC, Customer Service Department.Your actions, if you fail to follow
this Product Warning, may cause a fire, an explosion, or structural failure resulting in serious personal injury or
death as well as damage to property.
WEBER-STEPHEN PRODUCTS LLC
Customer Service Center
1890 Roselle Road, Suite 308
Schaumburg, IL 60195
1-800-446-1071 (USA ONLY)
www.weber.com®
 WARNING: Make sure all parts are assembled and hardware is fully tightened before operating the grill.Your
actions, if you fail to follow this Product Warning, may cause a fire, an explosion, or structural failure resulting in
serious personal injury or death as well as damage to property.
