Quick Start Guide
Websense V10000
Rack Documentation Cable/Ties PacketTray
Left Rail
Right Rail
Cable-management Arm
Bezel (faceplate)
See the Rack Installation Instructions included in the
Rack Hardware kit.
V10000 Getting Started Guide
www.websense.com/V10000/gsg/
Also available on the Documentation disk.
Online Support and Contact Information
www.websense.com/support/
Serial Port Connection
OR
Keyboard/Monitor Connection
Connect a terminal or terminal server to the
serial port.
Connect a monitor, keyboard, and mouse to
the V10000, either directly or through a KVM
(keyboard/video/mouse) switch.
1. Plug each power supply into an appropriate power source.
2. Press power button on front of V10000.
3. Check these indicators:
1. Insert right tab into slot on V10000.
2. Press left tab in firmly until bezel snaps into place.
3. V10000 can be locked using keys included with bezel.
(optional)
Contact Websense Technical Support if any indicators are not illuminated correctly.
Cat 5E cables (or better) are required. Do not use crossover network cables.
Front
• Powerbuttonisilluminated.
• HarddriveLEDsaregreen.
Rear
• TopandbottomLEDsforeachpowersupplyaregreen.
• NICLEDsaregreen.
• Systemstatusindicator(LEDleftofpowersupplies)issolidblue.
Plan your deployment before setting up the V10000. See the
back of this guide for a deployment overview.
Contact Websense Technical Support if any items are missing.
Rail Kit
2
1. V10000 Command Line: Configure V10000 Controller
interface (C) via firstboot script.
2. V10000 Console: Log on via browser to configure remaining
network interfaces.
3. Windows Server 2003: Install Websense Manager, Log
Server, and optional components.
4. Websense Manager: Log on via browser to enter
subscription key, update Master URL Database, configure
NetworkAgent,andcustomizepolicies.
5. Websense Content Manager: Log on to the proxy via browser
to enter subscription key and download proxy databases.
See the V10000 Getting Started guide online for detailed
instructions.
EthernetCables(4) Power Cable Clips (2)Power Cables (2)
Recovery Disk Documentation Disk Diagnostic Disk
Accessory Kit
1
Support & Resources
4
2
5
6
7
3
1
Connect Input Device
Rack Installation
Connect Power
Install Bezel (optional)
Configuration Overview
Connect Network Cables
Verify Contents
Before you begin...

Network Configuration Reference SheetV10000 Deployment Overview
You can deploy one or more V10000 appliances on your network. The diagram below illustrates a basic V10000
deployment. A separate computer with Windows Server 2003 is required for running Websense Manager, Log Server and
Microsoft SQL Server. See the V10000 Getting Started guide for details.
* P2 is optional and may be connected to the router or the switch. See the V10000 Getting Started guide for details.
** ConnecttheNinterfacetoaspan,monitor,ormirrorportontheswitch.
Websense Content Manager
Password (default): adminUser Name (default): admin
https://<C interface IP address>:8081
URL:
Websense Manager
Password (default): adminUser Name (default): WebsenseAdministrator
https://<Manager IP address>:9443/mng
Also used for Websense Content Manager
URL:
Policy Server IP:
Subscription Key:
SQL Server IP:
Internet
Firewall
ClientsWindows Server 2003
Router
Switch
*
**
V10000 Configuration
Hostname:
V10000 Controller Interface (C)
Network Agent Interface (N)
Websense Content Gateway Interfaces (P1 & P2)
P1
IP Address:
IP Address:
IP Address:
Subnet Mask:
Subnet Mask:
Subnet Mask:
P2
IP Address:
Subnet Mask:
V10000 Console Access
User Name (default): admin
https://<C interface IP address>:9447/
URL:
Default Gateway:
Default Gateway:
Primary DNS:
Primary DNS:
Secondary DNS:
Secondary DNS:
Tertiary DNS:
Tertiary DNS:
Default Gateway:
Primary DNS:
Secondary DNS:
Tertiary DNS:
Above settings apply to P1 and P2
