Weco Discovery 161MF User manual

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
WECO srl
Via S. Antonio, 22 - BELVEDERE
36056 TEZZE SUL BRENTA (VICENZA) ITALY
Tel.[phone] - Fax [phone]
www.weco.it - E-mail [e-mail]
Discovery 161MF
Discovery 161MF TP
GB
Instruction manual

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
2/23

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
3/23
CONTENTS
1INTRODUCTION............................................................................................................................................................................4
2INSTALLATION .............................................................................................................................................................................5
2.1 CONNECTIONS TO THE ELECTRICAL MAINS NETWORK ...........................................................................................................5
2.2 FRONT PANEL ..............................................................................................................................................................................5
2.3 REAR PANEL.................................................................................................................................................................................5
3PREPARING FOR MMA WELDING................................................................................................................................................6
3.1 PREPARING FOR TIG WELDING ..................................................................................................................................................7
3.2 PREPARING FOR MIG/MAG WELDING........................................................................................................................................8
3.2.1 WIRE SPOOL POSITIONING............................................................................................................................................................................... 8
3.2.2 POSITIONING THE WIRE IN THE WIRE FEEDER............................................................................................................................................... 8
3.2.3 CONNECTIONS TO SOCKETS............................................................................................................................................................................ 9
4COMMISSIONING........................................................................................................................................................................10
4.1 USER INTERFACE ......................................................................................................................................................................10
4.2 UNIT POWER-UP.........................................................................................................................................................................10
4.3 ALARMS MANAGEMENT.............................................................................................................................................................11
5WELDING SETTINGS ..................................................................................................................................................................11
5.1 TORCH TRIGGER MODES ..........................................................................................................................................................11
5.2 WELDING PARAMETERS............................................................................................................................................................12
6TECHNICAL DATA ......................................................................................................................................................................13
7SPARE PARTS............................................................................................................................................................................15
7.1 DISCOVERY 161MF.....................................................................................................................................................................15
7.2 DISCOVERY 161MF TP ...............................................................................................................................................................17
7.3 WIRE FEED MOTOR....................................................................................................................................................................19
7.4 WIRE FEEDER ROLLS ................................................................................................................................................................19
8ELECTRICAL DIAGRAM .............................................................................................................................................................20
8.1 DISCOVERY 161MF.....................................................................................................................................................................20
8.2 DISCOVERY 161MF TP ...............................................................................................................................................................21
8.3 TORCH CONNECTOR .................................................................................................................................................................22

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
4/23
1INTRODUCTION
IMPORTANT!
This handbook must be consigned to the user prior to
installation and commissioning of the unit.
Read the "General prescriptions for use" handbook supplied
separately from this handbook before installing and
commissioning the unit.
The meaning of the symbols in this manual and the associated
precautionary information are given in the "General
prescriptions for use”.
If the "General prescriptions for use" are not present, it is
mandatory to request a replacement copy from the
manufacturer or from your dealer.
Retain these documents for future consultation.
KEY
DANGER!
This pictogram warns of danger of death or serious injury.
This symbol identifies an action that occurs automatically as a
result of a previous action.
This symbol identifies additional information or a reference to a
different section of the manual containing the associated
information.
§
This symbol identifies a reference to a chapter of the manual.
NOTES
The figures in this manual are purely guideline and the images may
contain differences with respect to the actual equipment to which they
refer.
INTRODUCTION
The Discovery 161MF is a compact and heavy duty generator for
MIG/MAG welding.
The reduced weight and compact size allow it to be carried wherever
it is needed: it is designed to give you maximum power, reliability and
efficiency.
Wire reels of up to 200 mm in diameter can be mounted.
Sound alarm. A sound alarm has been provided to protect the power
generator: it blocks the primary inverter in the event that the average
welding current should exceed 160 A for more than 0.6 seconds.
Accessories that can be connected to the unit:
-Overcut device to protect the power source from power supply
voltage spikes that could damage the electrical components.
-Power source trolley.
-Spool gun torch.
The DISCOVERY 161MF power generators can be supplied together
with the 6 meters MIG SPOOL GUN torch with 1 kg D100 wire spools;
in the MIG welding mode they are able to weld SG2 solid wires, 0.6-
0.8 mm stainless steel wires, 0.6-0.8-1.0 mm aluminum wires and 0.9-
1.0 mm cored wires with or without gas shielding.
The SPOOL GUN torch features:
-A wire drawing motor with two rollers, one above the other, on the
torch.
-A spool support reel for 1 kg D100 wire spools.
-A 6 meters long torch.
Consult your dealer for an updated list of accessories and the latest
available new products.

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
5/23
2INSTALLATION
DANGER!
Lifting and positioning
Read the warnings highlighted by the following symbols in the
“General prescriptions for use”.
2.1 CONNECTIONS TO THE ELECTRICAL MAINS
NETWORK
The characteristics of the mains power supply to which the equipment
shall be connected are given in the section entitled “Technical data”
on page 13.
The machine can be connected to motorgenerators provided their
voltage is stabilised.
Connect/disconnect the various devices with the machine switched
off.
2.2 FRONT PANEL
1.
Negative pole welding socket.
2.
Positive pole welding socket.
3.
Polarity selector cable.
4.
EURO TORCH welding socket.
5.
Connector for logic signals of TIG torch.
2.3 REAR PANEL
1.
Connector for gas feed hose:
cylinder power source
2.
Welding power source ON/OFF switch.
3.
Power cable.
Total length (including internal part): 2,5 m
Number and cross section of wires: 3 x 2,5 mm2
Power plug type: Schuko
4.
(Only DISCOVERY 161MF TP version)
Led indicating excess voltage protection.
A built-in Total Protection Device saves the inverter components
from overvoltage and makes the unit suitable for use with
unstable power supply and motor-generators.
Wire feed motor power transformer fuse.
Type: Delayed acting (T)
Amperage: 800 mA
Voltage: 250 V
3
4
2
1
1
2
3
4
5

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
6/23
3PREPARING FOR MMA WELDING
1.
Set the welding power source ON/OFF switch to “O” (unit de-
energized).
2.
Plug the power cable plug into a mains socket outlet.
3.
Choose the electrode based on the type of material and thickness
of the workpiece to be welded.
4.
Insert the electrode in the electrode holder.
5.
Connect the electrode holder cable to the welding socket based on
the polarity requested by the type of electrode used.
6.
Connect the plug of the ground clamp to the welding socket on the
basis of the polarity required.
7.
Connect the earth clamp to the workpiece being processed.
DANGER!
Electric shock hazard!
Read the warnings highlighted by the following symbols in the
“General prescriptions for use”.
8.
Set the welding power source ON/OFF switch to “I” (unit
powered).
9.
Select the following welding mode on the user interface: MMA
10.
Set the required welding parameter values on the user interface.
The system is ready to start welding.
Preparing for MMA (polarity to basic electrode)

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
7/23
3.1 PREPARING FOR TIG WELDING
1.
Set the welding power source ON/OFF switch to “O” (unit de-
energized).
2.
Plug the power cable plug into a mains socket outlet.
3.
Connect the gas hose from the welding gas cylinder to the rear
gas socket.
4.
Open the cylinder gas valve.
5.
Connect the TIG torch plug to the EURO TORCH welding socket.
6.
Choose the electrode based on the type of material and
thickness of the workpiece to be welded.
7.
Insert the electrode in the TIG torch.
8.
Connect the plug of the polarity selector cable to the welding
socket on the basis of the polarity required.
9.
Connect the plug of the ground clamp to the welding socket on
the basis of the polarity required.
10.
Connect the earth clamp to the workpiece being processed.
11.
Set the welding power source ON/OFF switch to “I” (unit
powered).
12.
Select the following welding mode on the user interface: DC TIG
13.
Set the required welding parameter values on the user interface.
The system is ready to start welding.
Preparing for TIG (polarity for tungsten electrode)

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
8/23
3.2 PREPARING FOR MIG/MAG WELDING
3.2.1 WIRE SPOOL POSITIONING
1.
Open the unit side door to gain access to the spool compartment.
2.
Unscrew the cap of the spool holder.
3.
Choose the wire on the basis of the workpiece thickness and
material type.
4.
Fit the spool in the spool holder, ensuring it is located correctly.
5.
Adjust the spool holder braking system by tightening/loosening the
screw in such a way that the wire feed force is not excessive and
when the spool stops rotating no excess wire is released.
6.
Refit the plug.
3.2.2 POSITIONING THE WIRE IN THE WIRE FEEDER
1.
Lower the wire feeder pressure devices.
2.
Raise the wire feeder pressure arms.
3.
Check that the feed rolls are suitable for the wire gauge.
(See § 7.4 page 19.)
The diameter of the roll groovemust be compatible with the
diameter of the welding wire.
The roll must be of suitable shape in relation to the composition of
the wire material.
The groove must feature a "U" profile for soft materials
(Aluminium and its alloys, CuSi3).
The groove must be "V" shaped for harder materials (SG2-SG3,
stainless steels).
4.
Feed the wire between the wire feeder rolls and insert it into the
MIG/MAG TORCH connector plug.
5.
Make sure the wire is located correctly in the roll grooves.
6.
Close the wire feeder pressure arms.
7.
Adjust the pressure system so that the arms press the wire with a
force that does not deform it while also ensuring constant feed rate
without slipping.

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
9/23
8.
Close the spool compartment door in the side of the unit.
3.2.3 CONNECTIONS TO SOCKETS
1.
Set the welding power source ON/OFF switch to “O” (unit de-
energized).
2.
Plug the power cable plug into a mains socket outlet.
3.
Connect the gas hose from the welding gas cylinder to the rear
gas socket.
4.
Open the cylinder gas valve.
5.
Connect the MIG/MAG torch plug to the EURO TORCH welding
socket.
6.
Connect the plug of the ground clamp to the welding socket on
the basis of the polarity required.
7.
Connect the plug of the polarity selector cable to the welding
socket on the basis of the polarity required.
8.
Connect the earth clamp to the workpiece being processed.
9.
Set the welding power source ON/OFF switch to “I” (unit
powered).
10.
Select the following welding mode on the user interface:
MIG/MAG
11.
Feed the wire through the torch until it protrudes from the tip,
pressing button on the unit's user interface.
The advancement speed is adjustable by means of the POT1
potentiometer.
12.
Select the torch trigger procedure on the user interface.
13.
Set the required welding parameter values on the user interface.
The system is ready to start welding.
Preparing for MIG/MAG

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
10/23
4COMMISSIONING
4.1 USER INTERFACE
The picture shows the adjustment panel of MIG/MAG welding
parameters, accessible by opening the wire feeding unit door.
CODE
SYMBOL
DESCRIPTION
L1
This LED illuminates to show an anomaly in the operating conditions.
See § 4.3 ALARMS MANAGEMENT page 11.
L2
This LED comes ON when the machine is switched on.
L3
This LED illuminates to confirm the presence of power on the output sockets.
L5
This LED illuminates to show that the following welding mode is selected: 2 stroke procedure MIG/MAG
L6
This LED illuminates to show that the following welding mode is selected: 4 stroke procedure MIG/MAG
L7
This LED illuminates to show that the following welding mode is selected: MMA
L8
This LED illuminates to show that the following welding mode is selected: 2 stroke procedure TIG DC
S1
MIG/MAG mode: this button activates wire feed to insert it through the MIG/MAG torch.
S2
L4
MIG/MAG mode: when the corresponding led is on it means the inductance is high and a soft welding arc is obtained;
when the led is off it means the inductance is low and a dry welding arc is obtained.
S3
This button selects the welding mode.
POT1
MIG/MAG mode: the potentiometer sets the value of the following parameter: WIRE FEED RATE
POT2
MIG/MAG mode: the potentiometer sets the value of the following parameter: WELDING VOLTAGE
MMA mode, TIG mode: the potentiometer sets the value of the following parameter: WELDING CURRENT
POT3
MIG/MAG mode: the potentiometer sets the value of the following parameter: POST-GAS
4.2 UNIT POWER-UP
Set the welding power source ON/OFF switch to “I” to switch on the unit.
First power-up or power-ups following a RESET procedure
The welding power source sets up for welding with the factory presets.
Subsequent power-ups
The welding power source sets up for welding in the latest stable welding configuration that was active at the time of power-off.

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
11/23
4.3 ALARMS MANAGEMENT
This LED illuminates if an incorrect operating condition occurs.
Tab. 1 - Alarm messages
MEANING
EVENT
CHECKS
Overheating alarm
Indicates tripping of the welding power source
thermal protection.
All functions disabled.
Exceptions:
-cooling fan.
Leave the unit running so that the overheated
components cool as rapidly as possible.
When the unit has cooled, the welding power
source will reset automatically.
-Make sure that the power required by the
welding process is lower than the maximum
rated power output.
-Check that the operating conditions are in
compliance with the welding power source
data plate specifications.
-Check for the presence of adequate air
circulation around the welding power source.
Overcurrent alarm
Indicates tripping of the welding power source
current surge protection.
All functions disabled.
Exceptions:
-cooling fan.
An audible signal will sound (buzzer).
Muting the audible signal:
-in torch trigger procedure 2T, release the
torch trigger.
-in torch trigger procedure 4T the alarm
mutes automatically after 5 seconds.
Exit the alarm state by performing one of the
following actions:
-press any button.
-switch the power source off.
-Check that the programmed arc voltage
value is not too high in relation to the
thickness of the work to be welded.
5WELDING SETTINGS
5.1 TORCH TRIGGER MODES
2 STROKE LIFT-ARC TIG WELDING (2T)
1.
Touch the workpiece with the torch electrode.
2.
Press (1T) and keep the torch trigger pressed.
3.
Slowly lift the torch to strike the arc.
The welding current reaches the preset value, by way of a up slope time, if programmed.
4.
Release (2T) the trigger to start the weld completion procedure.
The current reaches the end current value in the time set in the down slope time parameter.
The arc is extinguished.
Gas delivery continues for the time set in the post gas parameter.
2 STROKE MIG/MAG WELDING (2T)
1.
Bring the torch up to the workpiece.
2.
Press (1T) and keep the torch trigger pressed.
The wire advances at the approach speed until making contact with the work.
The arc strikes and the wire feeder accelerates to the set feed rate value.
3.
Release (2T) the trigger to start the weld completion procedure.
Gas flow continues for the time set in the post gas parameter (adjustable time).
4 STROKE MIG/MAG WELDING (4T)
1.
Bring the torch up to the workpiece.
2.
Press (1T) and release (2T) the torch trigger.
The wire advances at the approach speed until making contact with the work.
The arc strikes and the wire feeder accelerates to the set feed rate value.
3.
Press (3T) the trigger to start the weld completion procedure.
Gas flow continues until the torch trigger is released.
4.
Release (4T) the torch trigger to start the post gas procedure (adjustable time).

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
12/23
5.2 WELDING PARAMETERS
PARAMETER
MIN
DEFAULT
MAX
WELDING CURRENT
5 A
-
140 A
MIG/MAG WELDING VOLTAGE
14.2 V
-
22.0 V
WIRE FEED RATE
0.5 m/min
-
16.0 m/min
POST GAS
0.0 s
-
3.0 s
WELDING CURRENT
Output current value during welding.
POST GAS TIME
Time of post gas delivery when the welding arc is extinguished.
This is useful when welding at high current values or with materials
that oxidise readily to cool the weld pool in an uncontaminated
atmosphere.
In the absence of specific requirements the value should generally be
kept low.
Consequences of a higher value:
-More effective pickling (improved appearance of workpiece at the
end of the welding pass).
-Higher gas consumption.
Consequences of a lower value:
-Lower gas consumption.
-Oxidation of electrode tip (more difficult arc strike).
MIG/MAG WELDING VOLTAGE
The parameter sets the welding voltage in MIG/MAG mode.
WIRE FEED RATE
The parameter sets the output wire feed rate.

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
13/23
6TECHNICAL DATA
Directives applied
Waste electrical and electronic equipment (WEEE)
Electromagnetic compatibility (EMC)
Low voltage (LVD)
Restriction of the use of certain hazardous substances (RoHS)
Construction standards
EN 60974-1; EN 60974-5; EN 60974-10 Class A
Conformity markings
Equipment compliant with European directives in force
Equipment suitable in an environment with increased hazard of electric shock
Equipment compliant with directive WEEE
Equipment compliant with directive RoHS
Supply voltage
1 x 230 Va.c. ± 15 % / 50-60 Hz
Mains protection
16 A Delayed
Zmax
This equipment complies with IEC 61000-3-12 provided that the maximum permissible system impedance is
less than or equal to 36 mΩ at the interface point between the user's supply and the public system. It is the
responsibility of the installer or user of the equipment to ensure, by consultation with the distribution network
operator if necessary, that the equipment is connected only to a supply with maximum permissible system
impedance less than or equal to 36 mΩ.
Dimensions ( L x D x H )
460 x 230 x 325 mm
Weight
12.6 kg
Insulation class
B
Protection rating
IP23S
Cooling
AF: Air-over cooling (fan assisted)
Maximum gas pressure
0,5 MPa (5 bar)
Motor speed
0.5 - 16.0 m/min
Wire spool: (dimensions/weight)
200 mm / 5 kg
Static characteristic
MMA
Drooping characteristic
TIG
Drooping characteristic
MIG/MAG
Flat characteristic
Current and voltage adjustment range
MMA
5 A / 20.2V - 140 A - 25.6 V
TIG
5 A / 10.2 V - 140 A - 15.6 V
MIG/MAG
5 A / 14.2 V - 160 A - 22.0 V
Welding current / Working voltage
MMA
35 % (40° C)
140 A - 25.6 V
60 % (40° C)
120 A - 24.8 V
100 % (40° C)
100 A - 24.0 V
TIG
40 % (40° C)
140 A - 15.6 V
60 % (40° C)
130 A - 15.2 V
100 % (40° C)
110 A - 14.4 V
MIG/MAG
30 % (40° C)
160 A - 22.0 V
60 % (40° C)
120 A - 20.0 V
100 % (40° C)
100 A - 19.0 V
Maximum input power
MMA
35 % (40° C)
5.4 kVA
60 % (40° C)
4.6 kVA
100 % (40° C)
3.7 kVA
TIG
40 % (40° C)
3.6 kVA
60 % (40° C)
3.2 kVA
100 % (40° C)
2.6 kVA
MIG/MAG
30 % (40° C)
5.5 kVA
60 % (40° C)
3.7 kVA
100 % (40° C)
3.0 kVA
Maximum supply current
MMA
35 % (40° C)
23.5 A
60 % (40° C)
20.0 A
100 % (40° C)
16.0 A
TIG
40 % (40° C)
15.7 A
60 % (40° C)
13.9 A
100 % (40° C)
11.3 A
MIG/MAG
30 % (40° C)
24.0 A
60 % (40° C)
16.1 A
100 % (40° C)
13.0 A

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
14/23
Maximum effective supply current
MMA
35 % (40° C)
13.9 A
60 % (40° C)
15.5 A
100 % (40° C)
16.0 A
TIG
40 % (40° C)
9.9 A
60 % (40° C)
10.8 A
100 % (40° C)
11.3 A
MIG/MAG
30 % (40° C)
13.1 A
60 % (40° C)
12.5 A
100 % (40° C)
13.0 A
No-load voltage (U0)
MMA
91 V
TIG
91 V
MIG/MAG
91 V
Reduced no-load voltage (Ur)
MMA
10 V
TIG
10 V
MIG/MAG
10 V

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
15/23
7SPARE PARTS
7.1 DISCOVERY 161MF

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
16/23
N°
CODE
DESCRIPTION
1
005.0001.0008
BELT
2
011.0000.0181
COVER PLATE
3
015.0001.0001
HEAT SINK L= 107mm
4
015.0001.0002
HEAT SINK L= 50 mm
5
012.0001.0000
INTERNAL FRAMEWORKS
6
050.0006.0001
POWER BOARD
7
046.0002.0006
ELECTRICAL INSULATION
8
012.0001.0007
NYLON BASE
9
045.0005.0006
SHUNT
10
011.0010.0005
FRONT PROTECTION PLATE
11
050.5052.0000
LOGIC FRONT PANEL
12
014.0002.0008
KNOB WITH POINTER
13
021.0001.0229
FIXED SOCKET
14
021.0001.2021
CAPILLARY TUBE FOR EURO CONNECTOR
15
021.0001.0029
MOVABLE PLUG
16
050.0001.0042
AMPHENOL CONN. BOARD
17
010.0006.0033
FRONT PLASTIC PANEL
18
040.0003.1080
TERMAL SWITCH 80° C
19
021.0001.2001
COUPLING EURO
20
002.0000.0021
WIRE FEED MOTOR
21
041.0006.0001
AUXILIARY TRANSFORMER
22
016.0009.0001
RUBBER FOOT
23
011.0010.0007
LOWER COVER
24
011.0010.0008
INTERNAL SUPPORT PLATE
25
015.0001.0027
HEAT SINK L= 75 mm
26
032.0002.2003
ISOTOP DIODE
27
011.0010.0004
MOTOR PROTECTION PLATE
28
050.0001.0021
MOTOR BOARD
29
011.0010.0003
SPOOL SUPPORT PLATE
30
011.0006.0050
SPOOL SUPPORT
31
040.0006.1420
FUSE CARRIER
32
050.0001.0033
DOUBLER BOARD
33
011.0010.0006
REAR PROTECTION PLATE
34
010.0006.0034
COMPLETE REAR PLASTIC PANEL
35
017.0001.5542
SOLENOID VALVE
36
013.0007.0200
REAR PANEL
37
045.0000.0007
CABLE CLAMP
38
045.0002.0001
NEOPRENE CABLE
39
011.0002.0018
SOLENOID VALVE PLATE
40
040.0001.0001
BI-POLE SWITCH
41
050.0001.0003
SNUBBER BOARD
42
011.0006.0001
SLIDE CLOSURE
43
012.0000.0001
SPOOL COVER
44
003.0002.0002
FAN
45
011.0000.0201
DOOR PLATE
46
010.0007.0001
POWER TRANSFORMER
47
011.0006.0006
PLASTIC HINGE
48
021.0001.2011
BRASS GUIDE FOR EURO CONNECTOR
49
002.0000.0284
SCREW CAP FOR SPOOL SUPPORT
50
045.0006.0062
DIODE-POWER CABLE BRACKET
51
045.0006.0063
DIODE-PLANAR TRANSFORMER BRACKET
N°
CODE
DESCRIPTION
021.0000.0003
COMPLETE KIT FOR GAS CONNECTORS
1
016.5001.0822
SLEEVE HOSE ADAPTER FOR RUBBER HOSE
2
016.0007.0001
HOSE CLAMP Ø= 11-13
3
016.5001.0823
NUT 1/4
4
021.0004.3360
AMPHT3360-001 M/5V. VOL. CONNECTOR
5
021.0001.2021
CAPILLARY TUBE FOR EURO CONNECTOR

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
17/23
7.2 DISCOVERY 161MF TP

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
18/23
N°
CODE
DESCRIPTION
1
005.0001.0008
BELT
2
011.0000.0181
COVER PLATE
3
015.0001.0001
HEAT SINK L= 107mm
4
015.0001.0002
HEAT SINK L= 50 mm
5
012.0001.0000
INTERNAL FRAMEWORKS
6
050.0006.0001
POWER BOARD
7
046.0002.0006
ELECTRICAL INSULATION
8
012.0001.0007
NYLON BASE
9
045.0005.0006
SHUNT
10
011.0010.0005
FRONT PROTECTION PLATE
11
050.5052.0000
LOGIC FRONT PANEL
12
014.0002.0008
KNOB WITH POINTER
13
021.0001.0229
FIXED SOCKET
14
021.0001.2021
CAPILLARY TUBE FOR EURO CONNECTOR
15
021.0001.0029
MOVABLE PLUG
16
050.0001.0042
AMPHENOL CONNECTOR BOARD
17
010.0006.0033
FRONT PLASTIC PANEL
18
040.0003.1080
TERMAL SWITCH 80° C
19
021.0001.2001
COUPLING EURO
20
002.0000.0021
WIRE FEED MOTOR
21
041.0006.0001
AUXILIARY TRANSFORMER
22
016.0009.0001
RUBBER FOOT
23
011.0010.0007
LOWER COVER
24
011.0010.0008
INTERNAL SUPPORT PLATE
25
015.0001.0027
HEAT SINK L= 75 mm
26
032.0002.2003
DIODE
27
011.0010.0004
MOTOR PROTECTION PLATE
28
050.0001.0021
MOTOR BOARD
29
011.0010.0003
SPOOL SUPPORT PLATE
30
011.0006.0050
SPOOL SUPPORT
31
040.0006.1420
FUSE CARRIER
32
050.0001.0043
DOUBLER-OVERCUT BOARD
33
011.0010.0006
REAR PROTECTION PLATE
34
010.0006.0034
COMPLETE REAR PLASTIC PANEL
35
017.0001.5542
SOLENOID VALVE
36
013.0007.0200
REAR PANEL
37
045.0000.0007
CABLE CLAMP
38
045.0002.0001
NEOPRENE CABLE
39
011.0002.0018
SOLENOID VALVE PLATE
40
040.0001.0001
BI-POLE SWITCH
41
050.0001.0003
SNUBBER BOARD
42
011.0006.0001
SLIDE CLOSURE
43
012.0000.0001
SPOOL COVER
44
003.0002.0002
FAN
45
011.0000.0201
DOOR PLATE
46
010.0007.0001
POWER TRANSFORMER
47
011.0006.0006
PLASTIC HINGE
48
021.0001.2011
BRASS GUIDE FOR EURO CONNECTOR
49
002.0000.0284
SCREW CAP FOR SPOOL SUPPORT
50
045.0006.0062
DIODE-POWER CABLE BRACKET
51
045.0006.0063
DIODE-PLANAR TRANSFORMER BRACKET
N°
CODE
DESCRIPTION
021.0000.0003
COMPLETE KIT FOR GAS CONNECTORS
1
016.5001.0822
SLEEVE HOSE ADAPTER FOR RUBBER HOSE
2
016.0007.0001
HOSE CLAMP Ø= 11-13
3
016.5001.0823
NUT 1/4
4
021.0004.3360
AMPHT3360-001 M/5V. VOL. CONNECTOR
5
021.0001.2021
CAPILLARY TUBE FOR EURO CONNECTOR

Discovery 161MF
Discovery 161MF TP
Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
19/23
7.3 WIRE FEED MOTOR
N°
CODE
DESCRIPTION
1
002.0000.0364
PRESSURE ARM COMPLETE
2
002.0000.0257
FIXING ARM COMPLETE
3
002.0000.0231
MOTOR COIL
4
002.0000.0217
COMPLETE INLET GUIDE
5
002.0000.0363
FEED PLATE
6
002.0000.0232
DISTANCE RING
7
002.0000.0106
FEED ROLL
8
002.0000.0227
FIXING CAP
7.4 WIRE FEEDER ROLLS
D = 40 mm
d = 22 mm
N°
CODE
WIRE DIAMETER
GROOVE TYPE
7
0.6 - 0.8
002.0000.0106
V groove
Solid wire
0.8 - 1.0
002.0000.0109
0.8 - 1.0
002.0000.0111
U shape
Aluminium wire
1.0 - 1.2
002.0000.0114

Cod.006.0001.0420
21/06/2019 v2.14
ENGLISH
Discovery 161MF
Discovery 161MF TP
20/23
8ELECTRICAL DIAGRAM
8.1 DISCOVERY 161MF
