Weco Cruiser Power Pulse User manual

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322T
Power Pulse 402T
502T
Instruction manual
ENG
Translation of original instructions

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
2
WELD T H E W O R L D
ENGLISH

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
3
WELD T H E W O R L D
ENGLISH
INDEX
1 INTRODUCTION.......................................................................................................................................... 4
1.1 INTRODUCTION.......................................................................................................................................... 5
2 INSTALLATION .......................................................................................................................................... 6
2.1 CONNECTIONS TO THE ELECTRICAL MAINS NETWORK...................................................................... 6
2.2 FRONT PANEL............................................................................................................................................. 6
2.3 REAR PANEL............................................................................................................................................... 7
2.4 PREPARING FOR MMA WELDING............................................................................................................. 8
2.5 PREPARING FOR TIG WELDING ............................................................................................................... 9
3 USER INTERFACE .................................................................................................................................... 10
4 UNIT POWER-UP ...................................................................................................................................... 13
5 RESET (LOAD FACTORY SETTINGS)..................................................................................................... 14
6 SET-UP (INITIAL SET-UP OF THE WELDING POWER SOURCE) ......................................................... 15
7 ALARM MANAGEMENT ........................................................................................................................... 18
8 MMA WELDING ........................................................................................................................................ 21
8.1 TIG WELDING/GOUGING - FIRST LEVEL MENU.................................................................................... 21
8.2 MMA /GOUGING WELDING -SECOND LEVEL MENU............................................................................. 22
8.3 MMA WELDING - SPECIAL FUNCTIONS ................................................................................................. 24
9 TIG WELDING ........................................................................................................................................... 25
9.1 TIG WELDING - FIRST LEVEL MENU ...................................................................................................... 25
9.2 TIG WELDING - SECOND LEVEL MENU ................................................................................................. 30
9.3 TIG DC WELDING - SPECIAL FUNCTIONS MENU ................................................................................. 32
10 TORCH TRIGGER PROCEDURE ............................................................................................................. 35
10.1 2 STROKE SPOT - Q-SPOT FUNCTION .................................................................................................. 43
11 JOBS MANAGEMENT .............................................................................................................................. 48
11.1 SAVING A JOB ........................................................................................................................................... 48
11.2 DELETING A JOB ...................................................................................................................................... 49
11.3 LOADING A JOB ........................................................................................................................................ 50
11.4 SELECTING JOBS USING THE TORCH BUTTONS ................................................................................ 51
12 TECHNICAL DATA .................................................................................................................................... 51
12.1 CRUISER 322T – POWER PULSE 322T .................................................................................................. 52
12.2 CRUISER 402T – POWER PULSE 402T .................................................................................................. 53
12.3 CRUISER 502T – POWER PULSE 502T .................................................................................................. 54
13 ELECTRICAL DIAGRAM .......................................................................................................................... 55
13.1 CRUISER 322T - POWER PULSE 322T ................................................................................................... 55
13.2 CRUISER 402/502T - POWER PULSE 402/502T ..................................................................................... 61
13.3 “REMOTE 1” CONNECTOR ...................................................................................................................... 66
13.4 “IR” CONNECTOR ..................................................................................................................................... 66
13.5 TORCH CONNECTOR (front panel) .......................................................................................................... 66
13.6 REMOTE CONTROL CONNECTOR ......................................................................................................... 66
14 SPARE PARTS .......................................................................................................................................... 67
14.1 CRUISER 322T - POWER PULSE 322T ................................................................................................... 67
14.2 CRUISER 402/502T - POWER PULSE 402/502T ..................................................................................... 69

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
4
WELD T H E W O R L D
ENGLISH
1 INTRODUCTION
IMPORTANT!
This handbook must be consigned to the user prior to installation and commissioning of the unit.
Read the "General prescriptions for use" handbook supplied separately from this handbook before
installing and commissioning the unit.
The meaning of the symbols in this manual and the associated precautionary information are given in
the "General prescriptions for use”.
If the "General prescriptions for use" are not present, it is mandatory to request a replacement copy
from the manufacturer or from your dealer.
Retain these documents for future consultation.
LEGEND
DANGER!
This pictogram warns of danger of death or serious injury.
WARNING!
This pictogram warns of a risk of injury or damage to property.
CAUTION!
This pictogram warns of a potentially hazardous situation.
INFORMATION
This pictogram gives important information concerning the execution of the relevant operations.
 Thissymbolidentiesanactionthatoccursautomaticallyasaresultofapreviousaction.
 Thissymbolidentiesadditionalinformationorareferencetoadi󰀨erentsectionofthemanual
containing the associated information.
§ Thissymbolidentiesareferencetoachapterofthemanual.
*1 The symbol refers to the associated numbered note.
NOTES
Theguresinthismanualarepurelyguidelineandtheimagesmaycontaindi󰀨erenceswithrespectto
theactualequipmenttowhichtheyrefer.

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
5
WELD T H E W O R L D
ENGLISH
1.1 INTRODUCTION
ThisprofessionalandruggedweldingpowersourceforDCMMAandTIGweldingwithexceptionalarc
characteristicsisdesignedtooperateinharshenvironmentalconditionsintheeldsofprofessional
maintenance,shipyardsando󰀨shore,buildingconstructionandheavyfabrication.
TheARCAIRfunctionallowsperfectde-seamingwithcarbonelectrodesofupto10mmindiameter.
Upto6mmdiameterelectrodeweldingispossibleinMMA.
InMMAweldingtheHotStartandArcForcefunctionsareadjustableandtheyallowimprovedarcstrik-
ing,aatterbeadandmoreuniformweld.
TheAntiStickingfunctionmakesitpossibletodetachtheelectroderapidlyfromtheworkpieceinthe
eventofaccidentalsticking.
Theparameterspre-setintheDCTIGpulsedsynergiccurvesimplifyweldingbyregulationexclusively
of the current.
ThecurrentisadjustablealsofromtheUp-Downtorch.
Thesimplyandintuitiveinterfaceallowshighprecisionadjustmentswith50storableprograms.
Thewiderangeof adjustable pulsed frequency incombinationwiththecomplementaryparameters
(basecurrentanddutycycle)makesitpossibletoweldinslowandfastpulsedmode.
Thankstoitsmodularconguration,thepowersourcecanbeconguredforMIG/MAGweldingbyadd-
ingawirefeedunit,extension,and,ifrequired,acoolingunitandpowersourcetransporttrolley.
Fan. Thefanisturnedononlyduringwelding,attheendoftheweldingprocessitremainsonfora
xedperiodoftimeaccordingtoweldingconditions.
 Thefanisnonethelesscontrolledbyspecicthermalsensorsthatguaranteeacorrectcoolingof
the machine.
Accessories/ancillary devices that can be connected to the unit:
-UP/DOWNtorchortorchwithpotentiometertoadjusttheweldingcurrentfromadistance.
-Manualremotecontrollerforremoteadjustmentoftheweldingcurrent.
-Foot-pedalremotecontrollerforTIGtorcharcstrikingandremoteadjustmentofweldingcurrent.
 ThemaximumandminimumvalueoftheTIPweldingcurrentcanbesetusingtheremotecontrol
pedal.Ifbothremotecontrolsareconnected,theremotecontrolpedaltakesprecedenceover
theTIGUp/Downorpotentiometertorch.
- Liquid cooler group for TIG torches.
-Powersourcetrolley.
Consultyourdealerforanupdatedlistofaccessoriesandthelatestnewproductsavailable.

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
6
WELD T H E W O R L D
ENGLISH
2 INSTALLATION
DANGER!
Lifting and positioning
Read the warnings highlighted by the following symbols in the “General prescriptions for use”.
2.1 CONNECTIONS TO THE ELECTRICAL MAINS NETWORK
Themainspowersupplyfeaturestowhichtheequipmentshouldbeconnectedaregiveninchapter“12
TECHNICAL DATA” at page 48.
Themachinecanbeconnectedtomotorgeneratorsprovidedtheirvoltageisstabilised.
Connect/disconnectthevariousdeviceswiththemachineswitchedo󰀨.
2.2 FRONT PANEL
1
7
8
2 3 4 5 6
○ Connectorforgasfeedhose:Torchpowersource[Item1].
○ ConnectorforlogicsignalsofTIGtorch[Item2].
○ Remotecontrollerconnector[Item3].
○ TIGTORCHweldingsocket[Item4].
○ Negativepoleweldingsocket[Item5].
○ Positivepoleweldingsocket[Item6].
○ WeldingpowersourceON/OFFswitch.Item7].
○ MainsprotectionONLED[Item8].ThisLEDilluminatesifanincorrectoperatingconditionoccurs:
• absenceofaphaseinthepowersupplyline.

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
7
WELD T H E W O R L D
ENGLISH
2.3 REAR PANEL
1 2 3
5
8
9
4
6 7
○ Auxiliarypowersupplytransformersafetyfuse[Item1].
• Type: Delayed acting (T)
• Amperage: 2 A (3.15 A for 322T)
• Voltage: 500 V a.c.
○ Signalsconnectorforautomaticapplication[Item2].
○ Pre-heatersupplysocket(OPTIONALon322T)[Item3].
 Thesocketisinternallyprotectedbyaself-resettingfuse.
• Powersockettype:Schuko
• Maximumpower:130W
• Voltage: 230 V a.c.
○Connector for gas feed hose:
• cylinderpowersource
○ Coolergrouppowerfeedingconnector[Item5].
• Voltage: 400 V a.c.
• Current output: 1.0 A
• IP protection rating: IP20 (cap open) / IP66 (cap closed)
DANGER!
High voltage!
If the socket is not connected to any devices always close cap 1
○ Connectorforconnectiontotheprogrammer.[Item6].(Programmingconnectorforthe"frontal
logic"circuitboard).Youcanupdatethesoftwareoftheequipmentusingtheprogrammingkit.
○ Connectorofthebundleofcablesforconnectingthepowersourcetotheremotecontroldevice.
[Item7].
○ Powercable[Item8].
• Total length (including internal part): 5,0 m
10

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
8
WELD T H E W O R L D
ENGLISH
• Numberandcrosssectionofwires:4x6mm2(4 mm2on 322T)
• Powerplugtype:notsupplied
○ Socketforconnectingthepowercablebetweenthepowersourceandtheremotecontroldevice
[Item9].
○(Only PowerPulse322/402/502T)Connectorforconnectiontotheprogrammer[Item10].Pro-
grammingconnectorforthe“pulsed”circuitboard.Youcanupdatethesoftwareoftheequipment
usingtheprogrammingkit.
2.4 PREPARING FOR MMA WELDING
1. SettheweldingpowersourceON/OFFswitchto“O”(unitswitchedo󰀨).
2. Plugthepowercableplugintoamainssocketoutlet.
3. Choosetheelectrodebasedonthetypeofmaterialandthicknessoftheworkpiecetobewelded.
4. Insert the electrode in the electrode holder.
5. Connecttheelectrodeholdercabletotheweldingsocketbasedonthepolarityrequestedbythe
type of electrode used.
6. Connecttheplugofthegroundclamptotheweldingsocketonthebasisofthepolarityrequired.
7. Connecttheearthclamptotheworkpiecebeingprocessed.
DANGER!
Electric shock hazard!
Read the warnings highlighted by the following symbols in the “General prescriptions for use”.
8. SettheweldingpowersourceON/OFFswitchto“I”(unitpowered).
9. Selectthefollowingweldingmodeontheuserinterface:MMA
10.Settherequiredweldingparametervaluesontheuserinterface.
Whentheremotecontroller[RC]isconnectedandtherelativelockingscrewistightened,welding
currentcanbeadjustedusingtheremotecontroller.
Thesystemisreadytostartwelding.
REAR VIEW FRONT VIEW
(polarity to basic electrode)
RC

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
9
WELD T H E W O R L D
ENGLISH
2.5 PREPARING FOR TIG WELDING
NOTE: For the cooler to power source assembly procedure refer to the cooler instruction man-
ual.
1. SettheweldingpowersourceON/OFFswitchto“O”(unitde-energized).
2. Plugthepowercableplugintoamainssocketoutlet.
3. Connectthegashosefromtheweldinggascylindertothereargassocket.
4. Openthecylindergasvalve.
5. Choosetheelectrodebasedonthetypeofmaterialandthicknessoftheworkpiecetobewelded.
6. Insert the electrode in the TIG torch.
7. Connectthetorchplugtotheweldingsocketonthebasisofthepolarityrequiredbythetypeof
electrode in question.
8. Connecttheplugofthegroundclamptotheweldingsocketonthebasisofthepolarityrequired.
9. Connectthegashosefromtheweldingtorchtothefrontgassocket.
10.ConnecttheweldingtorchconnectortotheTIGtorchsignalsconnector.
11.Connecttheearthclamptotheworkpiecebeingprocessed.
12.SettheweldingpowersourceON/OFFswitchto“I”(unitpowered).
13.Selectthefollowingweldingmodeontheuserinterface:DCTIG
14.Pressthetorchtriggerwiththetorchwellclearofanymetalparts.Thisservestoopenthegas
solenoidvalvewithoutstrikingtheweldingarc.
15.Usetheowcontrolvalvetoadjusttheowofgasasrequiredwhilethegasisowingout.
16.Settherequiredweldingparametervaluesontheuserinterface.
Whentheremotecontrolpedalisconnectedandtherelativelockingscrewistightenedtheweld-
ingcurrentwillvaryinrelationtothepressureexertedonthepedal.
Thesystemisreadytostartwelding.
REAR VIEW FRONT VIEW
(polarity for tungsten electrode)
RC

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
10
WELD T H E W O R L D
ENGLISH
3 USER INTERFACE
Cruiser 322T - Power Pulse 322T
L1
L2
L15
L34
L35
L36
L37
L16
L17
L18
L19
L20 L21
L22
L23
L24
L25
L26
L27
L3
L4 L5
S1 S2 S3 S4
L29
L28 S5 S6
L6 L7 L8 L9 L11L10 L12 L13 L14 E1
D1 D2
L31
L30
L32
L33
Cruiser 402-502T - Power Pulse 402-502T
L1
L2
L15
L38
L35
L36
L37
L16
L17
L18
L19
L20 L21
L22
L23
L24
L25
L26
L27
L3
L4 L5
S1 S2 S3 S4L29
L28 S5 S6
L6 L7 L8 L9 L11L10 L12 L13 L14 E1
D1 D2
L31
L30
L32
L33
L34
CODE SYMBOL DESCRIPTION
L1 ThisLEDilluminatestoconrmthepresenceofpowerontheoutputsockets.
L2
S T OP
ThisLEDilluminatestoshowananomalyintheoperatingconditions.
L3
JOB
IlluminatestoshowthatapreviouslysavedJOBhasbeenloaded.

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
11
WELD T H E W O R L D
ENGLISH
CODE SYMBOL DESCRIPTION
L4
HF
Illuminationshowsthatthefollowingfunctionhasbeenactivated:HIGHFREQUENCYARC
STRIKE (HF)
L5
VRD
Illuminationshowsthatthefollowingfunctionhasbeenactivated:VRD(reducedoutputvolt-
age).
Theno-loadvoltagebetweenthe welding socketsisswitchedfromU0toUr (see technical
data).
L6 Illuminatestoindicateavalueinthefollowingunitofmeasurement:AMPERES
L7
HOLD
Illuminatestoshowthelastvoltageandcurrentvaluesmeasuredduringwelding.
Thevalueappearsonthefollowingdisplays:D1-D2
TheLEDswitcheso󰀨whenanewweldingprocedureisstarted,orwhenanyofthewelding
settingsismodied.
L8 Illuminatestoindicateavalueinthefollowingunitofmeasurement:VOLTS(V)
L9
mm
Illuminatestoindicateavalueinthefollowingunitofmeasurement:MILLIMETERS(mm)
L10 Illuminatestoindicateavalueinthefollowingunitofmeasurement:AMPERES(A)
L11 Illuminatestoindicateavalueinthefollowingunitofmeasurement:SECONDS(s)
L12 Illuminatestoindicateavalueinthefollowingunitofmeasurement:HERTZ(Hz)
L13
KHz
Illuminatestoindicateavalueinthefollowingunitofmeasurement:KILOHERTZ(KHz)
L14 Illuminatestoindicateavalueinthefollowingunitofmeasurement:PERCENTAGE(%)
L15
QST
WhenthisLEDilluminatesthefollowingparametercanbeset:Q-START
L16
DYN arc
WhenthisLEDilluminatesthefollowingparametercanbeset:DYNAMICARC
L17 WhenthisLEDilluminatesthefollowingparametercanbeset:MULTITACK
L18 WhenthisLEDilluminatesthefollowingparametercanbeset:STARTINGCURRENT(%/A)
L19 WhenthisLEDilluminatesthefollowingparametercanbeset:SLOPEUP(s)
L20 WhenthisLEDilluminatesthefollowingparametercanbeset:WELDINGCURRENT(A)
L21 WhenthisLEDilluminatesthefollowingparametercanbeset:SECONDCURRENTB-LEVEL
(%)
L22 WhenthisLEDilluminatesthefollowingparametercanbeset:BASECURRENT(A)
L23 WhenthisLEDilluminatesthefollowingparametercanbeset:PEAKTIME(s)
L23+L24 When this LED illuminates the following parameter can be set: PULSED CURRENT
FREQUENCY(Hz/kHz)

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
12
WELD T H E W O R L D
ENGLISH
CODE SYMBOL DESCRIPTION
L24 WhenthisLEDilluminatesthefollowingparametercanbeset:BASETIME(s)
L25 WhenthisLEDilluminatesthefollowingparametercanbeset:SLOPEDOWN(s)
L26 WhenthisLEDilluminatesthefollowingparametercanbeset:/STARTINGCURRENT(%/A)
L27 WhenthisLEDilluminatesthefollowingparametercanbeset:POST-GAS(s)
L28
REMOT E
Illuminatestosignalactivationofaconnectedremotecontrolunit,ifavailable.
L29 This LED indicates that the current reference setting is imposed by the remote controller.
L30 Illuminationshowsthatthefollowingfunctionhasbeenactivated:4strokeB-levelprocedure+
highfrequencyarcstrike(HF).
L31
SPOT
Illuminationshowsthatthefollowingfunctionhasbeenactivated:2strokespotprocedure(Q-
SPOT).
L32 Illuminationshowsthatthefollowingfunctionhasbeenactivated:2strokeprocedure.
L33 Illuminationshowsthatthefollowingfunctionhasbeenactivated:4strokeprocedure.
L34 ThisLEDilluminatestoshowthatthefollowingweldingmodeisselected:MMA
L35 ThisLEDilluminatestoshowthatthefollowingweldingmodeisselected:TIGDCCONTINUOUS
L36 ThisLEDilluminatestoshowthatthefollowingweldingmodeisselected:PULSEDDCTIG
L37
SYN
ThisLEDilluminatestoshowthatthefollowingweldingmodeisselected:SYNERGICPULSED
DC TIG
Whenthisison,itmeansthatthesynergicmodeisactiveandthattheoperatorcansetjustthe
weldingcurrentwhiletheotherparametersareautomaticallyregulatedbythemachine.The
synergyisoptimisedbyanglewelding.
L38 AI
R
This LED illuminates to show that the following welding mode is selected: GOUGING
ELECTRODE (Only on 402-502)
D1
Datasetting:Thedisplayshowstheacronymoftheparametertobeset.
Welding:Thedisplayshowsthee󰀨ectiveamperesvalueduringwelding.
HOLDfunction:Thedisplayshowstheaveragecurrentvaluemeasuredovertheentirewelding
period(excludingthestartingandendingramps).
D2
Datasetting:Thedisplayshowsthevalueoftheselectedparameter.
Welding:Thedisplayshowsthee󰀨ectivevoltageduringweldingoperations.
HOLDfunction:Thedisplayshowstheaveragevoltagevaluemeasuredovertheentirewelding
period(excludingthestartingandendingramps).
S1
Press the button to select the parameter to be set.
Possiblechoices:Q-START-DYNAMICARC-MULTITACK
AC TIG mode: Press the button to select the parameter to be set.
Possiblechoices:MIXAC-EXTRAFUSION-ACFREQUENCY–ACBALANCE-ELECTRODE
DIAMETER
S2
Menu
Pressandrelease:thebuttonselectstherstlevelmenuparameters.
Holddownfor3seconds:thebuttonopensthesecondlevelmenu.Wheninthemenu,press
and release the button to select the parameters.
Keepthebuttonpressedwhilepoweringonthepowersource:thebuttonopenstheSETUP
menu.

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
13
WELD T H E W O R L D
ENGLISH
CODE SYMBOL DESCRIPTION
S3 Press and release: the button opens the JOBs upload menu.
Holddownfor3seconds:thebuttonopenstheJOBssaveanddeletemenu.
S4
Pressandrelease:thebuttonenablesthedevicetoreceivetheweldingcurrentcontrolsignal
from a remote controller.
Holddownfor3seconds:thebuttonactivatesaconnectedremotecontroller,ifavailable,which
isthenusedtomanageallfunctionsoftheweldingpowersourcefromadistance.
S5 TIG DC / TIG AC mode: This button selects the torch trigger procedure.
MMAmode:PressthebuttontoshowtheselectedelectrodetypeforMMAwelding.
S6 Thisbuttonselectstheweldingmode.
E1 Datasetting:Theencodersetsthevalueoftheselectedparameter.
Welding:Theencodersetsthevalueofthefollowingparameter:WELDINGCURRENT
4 UNIT POWER-UP
SettheweldingpowersourceON/OFFswitchto“I”toswitchontheunit.
FX.XThemessageappearsonthefollowingdisplay:D2.
x.x=softwareversion
Firstpower-uporpower-upsfollowingaRESETprocedure
Theweldingpowersourcesetsupforweldingwiththefactorypre-sets.
Subsequentpower-ups
Theweldingpowersourcesetsupforweldinginthelateststableweldingcongurationthatwasactive
atthetimeofpower-o󰀨.

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
14
WELD T H E W O R L D
ENGLISH
5 RESET (LOAD FACTORY SETTINGS)
L1
L2
L15
L38
L35
L36
L37
L16
L17
L18
L19
L20 L21
L22
L23
L24
L25
L26
L27
L3
L4 L5
S1 S2 S3 S4L29
L28 S5 S6
L6 L7 L8 L9 L11L10 L12 L13 L14 E1
D1 D2
L31
L30
L32
L33
L34
rEC PAr
A C A
B
ACTIVATION/
SELECTION ACTIVATIONEXIT
SETTING
Theresetprocedureinvolvescompleterestorationofthedefaultvalues,parametersandmemoryset-
tings set in the factory.
Theresetprocedureisusefulinthefollowingcases:
- Toomanychangesmadetotheweldingparameterssouserndsitdi󰀩culttorestoredefaults.
- Unidentiedsoftwareproblemsthatpreventtheweldingpowersourcefromfunctioningcorrectly.
PARTIAL RESET
Theresetprocedureinvolvesrestorationoftheparametervaluesandsettings,exceptthefollowing
settings:
- Settings of the SETUP menu.
- SavedJOBS.
TOTAL RESET
Theresetprocedureinvolvescompleterestorationofthedefaultvalues,parametersandmemoryset-
tings set in the factory.
Allmemorylocationswillberesetandhenceallyourpersonalweldingsettingswillbelost!
A
○ SettheweldingpowersourceON/OFFswitchto“O”toswitchtheunito󰀨.
○Keeping both the S1 and S6 buttonspressed,set thegeneratorpowersource
switchto“I”toturnontheequipment[ SIMULTANEOUS ACTIONS]
- rEC PAr: Themessageappearsonthefollowingdisplays: D1-D2.
B○Select encoder E1 withthefollowingsetting: rEC PAr (partial) or rEC FAC (total).

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
15
WELD T H E W O R L D
ENGLISH
C
○Exit with conrmation
- Press the S3 button.
- Waitforthememoryclearproceduretoterminate.Thisactionwillautomaticallyclosethe
menu.
○Exit without conrmation
- Press any button (except S3).
- Thisactionwillautomaticallyclosethemenu.
6 SET-UP (INITIAL SET-UP OF THE WELDING POWER SOURCE)
L1
L2
L15
L38
L35
L36
L37
L16
L17
L18
L19
L20 L21
L22
L23
L24
L25
L26
L27
L3
L4 L5
S1 S2 S3 S4L29
L28 S5 S6
L6 L7 L8 L9 L11L10 L12 L13 L14 E1
D1 D2
L31
L30
L32
L33
L34
AC
B
SEt UP
ACTIVATION/
SELECTION
EXIT
SETTING
A
○ SettheweldingpowersourceON/OFFswitchto“O”toswitchtheunito󰀨.
○Holding the S2
Menu
buttondown,turnthepowersourceswitchto“I”tostarttheequipment.
[ SIMULTANEAOUS ACTIONS]
- SEt UP:Themessageappearsforafewsecondsonthefollowingdisplays:D1-D2.
- Coo Aut: The messageappearsonthefollowingdisplays:D1-D2.
○Use the S2
Menu
,buttontoscrollthroughthesettingstobemodied.
B○Using the encoder E1 ,editthevalueoftheselectedsetting.
C
○Exit with conrmation
- Press any button (except S2)forexampleS3 .
- Thisactionwillautomaticallyclosethemenu.

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
16
WELD T H E W O R L D
ENGLISH
Tab. 1 - Setup settings
ACRONYM SETTING MIN DEFAULT MAX
Coo COOLER ACTIVATION Aut Aut oFF
St.C. STARTING CURRENT %%A
F.Cu. FINAL CURRENT %%A
HF.C. HF CURRENT 20 A SYn 250 A
HF.t. HF TIME 0.5 s 2.0 s 3.0 s
PUL. TYPEOFPULSEDCURRENT SLo. FA. FA.
P.A. PILOT ARC oFF on on
E.C.C. CONTACT COMMAND EXPANSION oFF oFF Ir
E.r.C. ENABLE READ CURRENT oFF on on
StS SPECIAL TORCH STROKE oFF oFF 2
F.r.C. UP CURRENT 2 2 9
- Coo [COOLER ACTIVATION GROUP]
○ ON=Thecoolerisalwaysrunningwhenthepowersourceisswitchedon.Thismodeispreferable
forheavydutyandautomaticweldingprocedures.
○ OFF=Thecoolerisalwaysdisabledbecauseanair-cooledtorchisinuse.
○ AUT=Whentheunitisswitchedonthecoolerisswitchedonfor15s.Duringweldingprocedures
thecoolerrunsconstantly.Whenweldingisterminatedthecoolercontinuestorunfor90s+a
numberofsecondsequivalenttotheaveragecurrentvalueshownusingtheHOLDfunction.
Torch loading
WARNING!
Make sure the torch in use is correctly sized in relation to the welding current required and for
the available and selected cooling type. This prevents the risk of burns to which the operator is
potentially exposed, potential faults, and irreversible damage to the torch and the system.
If a torch is installed or replaced while the unit is running, the circuit of the newly installed torch
must be lled with coolant to avoid the risk of damage to the torch in the case of high voltage arc
strikes without any liquid in the circuit.
Power-up with operation of the cooler set to "ON" or "AUT" mode
○ Acheckisperformedautomaticallyofthepresenceofliquidinthecoolingcircuitandthecooler
isswitchedonfor15seconds.
○ Ifthecoolantcircuitisfull,thepowersourcesetsupinthemostrecentstableweldingcongura-
tion.
○ Ifthecoolantcircuitisnotfull,allfunctionsareinhibitedandtherewillbenooutputpowerpresent.
AL. Coo.:Themessageappearsonthefollowingdisplays: D1-D2.
 Pressanybuttontorepeatthecheckingprocedureforanadditional15seconds.
If the problem persists, rectify the cause of the alarm.
Power-up with operation of the cooler set to "OFF"
Operation of the cooler and the cooler alarm are disabled.
Weldingisperformedwithoutliquidcoolingofthetorch.
Torch change-over with operation of the cooler set to "ON"
Press and release the torch trigger.
Thisservestostartthecoolerfor15secondstollthetorchcoolingcircuit.

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
17
WELD T H E W O R L D
ENGLISH
- St.C. [STARTING CURRENT]
○ Thevalueofthisparametercanbesetasapercentageoftheweldingcurrentorasanabsolute
valueexpressedinAmperes.
F.C. [FINAL CURRENT]
○ Thevalueofthisparametercanbesetasapercentageoftheweldingcurrentorasanabsolute
valueexpressedinAmperes.
- HF.C. [HF CURRENT]
○ ThisparameterestablishesthecurrentvalueduringHFdischarge.Thevalueofthisparameter
canbesetasanabsolutevalueorinSYN.
○ WithSYNsettingtheHFcurrentvalueiscalculatedautomaticallyonthebasisofthepre-setweld-
ingcurrentvalue.
Consequences of a higher value:
• Arcstrikingisfacilitated,evenonverydirtyworkpieces.
• Riskofpiercingexcessivelythingaugeworkpieces.
- HF.t. [HF TIME]
○ Thisparameterdenesthemaximumhighfrequency(HF)arcstrikeduration.
- PUL. [TYPE OF PULSED CURRENT]
○ SLo.=Thissettingenablesslowpulsedmode.Thepeaktimeandbasetimeareset.
○ FA.=Thissettingenablesfastpulsedmode.Thefrequencyandduty-cycleareset.
- P.A. [PILOT ARC]
○ Thefunctionenablestheoutputofalowcurrentbetweenthe1stand2ndtimesofthetorchtrig-
gertoshieldthemaskinadvanceandavoidtheriskofblindingashbackcausedbythewelding
current.
- E.C.C [CONTACT COMMAND EXPANSION]
○ on=ThefunctionenablestheemissionoftheARC-ONandALARMsignalsviathesignalconnec-
tors for automatic applications (IR).
○ Ir=Thefunctionenablesthecommunicationwitharobotinterfaceboardviathesignalconnector
forautomaticapplications(IR).WhentheIrfunctionisenabled,TIG2strokeHFweldingcanbe
performed,only.MMAmodecannotbeselected,aremote-controlunitcannotbeselected(wire
feeder), UP/DOWN torch cannot be used.
- E.r.C.[ENABLE READ CURRENT]
○ Thisfunctionallowsfortherealweldingcurrentdisplaytobeenabledordisabled.
- StS [SPECIAL TORCH STROKE]
○The parameter changes the torch trigger operating mode.
• oFF: indicates standard operation.
• 1:speciesthe4TB-levelmanagementvariant.Allowsthetransitiontothesecondarywelding
currentbypressingandholdingdowntheUPorDOWNbutton;whenthebuttonisreleased,
theprimarycurrentisrestored.WithvariantoFFselected,theUP/DOWNbuttonsaredisabled
for all procedures.
• 2:speciesthedownslopemanagementvariant.Byreleasingthetorchtriggerduringthethird
stroke(3S)thedownslopeisstoppedandthenalcurrentisimmediatelydeliveredwithout
havingtogothroughtheentireslopetime.
- F.r.C. [COMMAND TYPE PEDAL]

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
18
WELD T H E W O R L D
ENGLISH
○The parameter selects the type of pedal used:
• RC02 standard pedal type
• RC09 special pedal type. This type of pedal recognises the pressure applied to the foot pedal
orthetorchbutton,switchingautomaticallyfrominternaladjustmenttoexternalcontrolusing
the pedal.
- I.UP [UP CURRENT]
○ WhentheparameterissettoON,themaximumvalueoftheweldingcurrentthatcanbesetwith
theUP/DOWNtorchisthecurrentsetbytheencoderinthefrontpaneloftheweldingpower
source.WhentheparameterissettoOFF,themaximumvalueoftheweldingcurrentthatcanbe
setwiththeUP/DOWNtorchisthemaximumcurrentthatcanbesuppliedbytheweldingpower
source.
7 ALARM MANAGEMENT
S T OP
This LED illuminates if an incorrect operating condition occurs.
Analarmmessageappearsonthefollowingdisplay:D2.
Tab. 2 - Alarm messages
MESSAGE MEANING EVENT CHECKS
AL. HEA.
In start-up phase Appears for 2-3 seconds
Overheating alarm
Indicates tripping of the welding
powersourcethermalprotection.
Leavetheunitrunningsothatthe
overheated components cool as
rapidly as possible.
When the unit has cooled, the
welding power source will reset
automatically.
All functions disabled.
Exceptions:
• Cooling fan.
• Cooler(ifswitchedon).
• Make sure that the power re-
quiredbytheweldingprocessis
lower than the maximum rated
poweroutput.
• Check that the operating con-
ditions are in compliance with
theweldingpowersourcedata
platespecications.
• Checkforthepresenceofade-
quate air circulation around the
weldingpowersource.
Phase missing alarm
Indicates the absence of a phase
inthepowersupplyline.
The message appears at the
same time as the mains protection
activationLEDswitcheson.
All functions disabled.
Exceptions:
• Cooling fan.
• Check if the equipment power
supply line has all the phases.
If the problem persists:
• qualied technical personnel
are required for repair/mainte-
nancejobs.

Cod. 006.0001.1680
09/06/2020 V.2.10
Cruiser 322/402/502T
Power Pulse 322/402/502T
19
WELD T H E W O R L D
ENGLISH
MESSAGE MEANING EVENT CHECKS
AL. Coo.
Cooler alarm
Indicates insu󰀩cient pressure in
the torch liquid cooling circuit.
All functions disabled.
Exceptions:
• Cooling fan.
The alarm message persists on
thedisplayuntiltherstoperation
is performed on the user interface.
Signalling of the alarm depends
onthefollowingsettings:
• Coo=on:thealarmissignalled
if the cooling unit is connected
tothepowersourceandifitis
running.
• Coo= oFF:thealarm isnever
signalled,irrespectiveofthecir-
cumstances.
• Coo=Aut:thealarmissignalled
if the cooling unit is connected
tothepowersourceandifitis
running.
• Check that the connection to
the cooler is correct.
• Check that the "O/I" switch is
setto"I"andthatitilluminates
whenthepumpisrunning.
• Check that the cooler is lled
withcoolant.
• Check that the cooling circuit
is liquid tight, notably the torch
hoses, the fuse and the internal
connections of the cooler.
CAn Err.
CAN BUS alarm
Indicates a problem on the CAN
communication.
Remove the cause of the alarm
and press any key to exit the
alarm.
All functions disabled.
Exceptions:
• cooling fan.
• cooler(ifswitchedon).
• Checkthattheconnectingcable
betweenpowersourceandwire
feederis intact andmake sure
the connectors are securely
tightened.
• Check that the IR-01 board is
poweredon.
• CheckthestatusoftheLEDson
board IR.
• Checkthatthecablingbetween
IR and the generator is correctly
connected.
• Switcho󰀨themachineandthen
switchitonagain.
• If the problem persists:
• qualied technical personnel
are required for repair/mainte-
nancejobs.
E. 04 Alarm, no-load voltage failure
All functions disabled.
Exceptions:
• Cooling fan
• Check to ensure the welding
torchisnotrestingonthework-
piece connected to ground.
• Check that when the power
source is switched on there
is no short circuit between the
sockets(voltagemustbegreat-
erthan/equivalenttoUr).
If the problem persists:
• Qualied technical personnel
are required for repair/mainte-
nancejobs.
E. 05
Torch button alarm
Indicates that when the power
source was powered up a short
circuitwas detected onthe torch
trigger input.
When the unit has cooled, the
welding power source will reset
automatically.
All functions disabled.
Exceptions:
• Cooling fan.
• Make sure the torch trigger is
not pressed, jammed, or short
circuiting.
• Make sure the torch and torch
connector are intact.

Cod. 006.0001.1680
09/06/2020 V.2.10 Cruiser 322/402/502T
Power Pulse 322/402/502T
20
WELD T H E W O R L D
ENGLISH
MESSAGE MEANING EVENT CHECKS
E. 06
Mode alarm
It indicates that the combination
withmodeselectionpinsdoesnot
match any settable mode.
Toexit the alarm,setthe correct
conguration.
All functions disabled.
Exceptions:
• cooling fan.
• cooler(ifswitchedon).
• Make sure that the selected
modeisactuallyavailable.
E. 08
Job missing alarm
Indicates that the combination
set by the robot for the interface
board program/job selection pins
doesnotmatchanysavedjob.
Toexit the alarm,setthe correct
conguration.
All functions disabled.
Exceptions:
• cooling fan.
• cooler(ifswitchedon).
• Checktomakesurethatthese-
lectedjobactuallyexists.
E. 69
Software compatibility error
Indicates that the welding power
sourcehasasoftwareversionthat
isnotcompatiblewiththeremote
device connected to it (remote
controller,wirefeedunit).
All functions disabled.
Exceptions:
• Cooling fan.
• Updatetheremotedevicesoft-
ware.
• Contact support
E. 97
Indicates that the robot has trans-
mitted a request to disable the
weldingunitfunctions
All functions disabled.
Exceptions:
• cooling fan.
• cooler(ifswitchedon).
• Thecauseofthealarmlieswith
the robot.
E. 98 The error code indicates problems
regarding the IR-02 board..
All functions disabled.
Exceptions:
• cooling fan.
• cooler(ifswitchedon).
• Qualied technical personnel
are required for repair/mainte-
nancejobs.
