LX3V-4AD
1 WECON TECHNOLOGY CO., LTD.
1. Introduction
The LX3V-4AD special module has four input channels. The input channels receive analog
signals and convert them into a digital value. This is called an A/D conversion; the maximum
resolution is 16 bits.
The selection of voltage or current based input/output is by user wiring. Analog ranges of -10 to
10V DC (resolution: 5mV), and/or 4 to 20mA, -20 to 20mA (resolution: 20µA) may be selected.
Data transfer between the LX3V-4AD and the LX3V main unit is by buffer memory exchange.
There are 32 buffer memories (each of 16 bits) in the LX3V-4AD.
LX3V-4AD consumes 5V voltage from LX3V main unit or active extension unit, 90mA current of
power supply.
2. Dimensions
① Extension cable and connector
② COM LED: Light when communicating
③ Power LED: Light when connect to 24V
④ State LED: Light when normal condition
⑤ Module name
⑥ Analog signal output terminal
⑦ Extension module interface
⑧ DIN rail mounting slot
⑨ DIN rail hook

LX3V-4AD
2 WECON TECHNOLOGY CO., LTD.
3. Terminal layouts
4. Installation
4.1 Environment specification
Item
Specification
Environmental specifications (excluding
Same as those for the LX3V main unit

Please use crimp terminals as indicated on the
graph.

The tightening torque should be applied 5 to 8
Kg.cm.
1) The analog input is received through a
twisted pair shielded cable. This cable should
be wired separately from power lines or any
other lines which may induce electrical noise.
2) If a voltage ripple occurs during input, or
there is electrically induced noise on the
external wiring, connect a smoothing
capacitor of 0.1 to 0.47µF, 25V.
3) If you are using current input, connect the V+
and I+ terminals to each other.
4) If there is excessive electrical noise, connect
the FG frame ground terminal with the
grounded terminal on the LX3V-4AD.
5) Connect the ground terminal on the
LX3V-4AD unit with the grounded terminal
on the main unit. Use class 3 grounding on
the main unit, if available.

LX3V-4AD
3 WECON TECHNOLOGY CO., LTD.
following)
Dielectric withstand voltage
500VAC, 1min (between all terminals and
ground)
4.2 Power supply specification
Item
Specification
Analog circuits
24V DC ± 10%, 55mA (external power supply from main unit)
Digital circuits
5V DC, 90mA (internal power supply from main unit)
4.3 Performance specification
1) Analog Inputs
Voltage Input
Current input
Items
Either voltage or current input can be selected with your choice of input terminal.
Up to four input points can be used at one time.
Analog input
range
DC -10V to +10V (input resistance:
200kΩ).
Warning: this unit may be damaged by
input voltage in excess of ±15V
DC -20mA to +20mA (input resistance:
250Ω).
Warning: this unit may be damaged by
input currents in excess of ±32mA.
Digital
output
12-bit conversion stored in 16-bit 2’s complement form
Maximum value:+2047 Minimum value:-2048
Analog
accuracy
±1% (for the range of -10V to +10V)
±1% (for the range of -20mA to +20mA)
Conversion
speed
15ms/channel (Normal speed), 6ms/channel (High speed)
2) Analog Inputs continued...
Preset 0 (-10V to +10V)
Preset 1 (+4mA to +20mA)
Preset 2 (-20mA to +20mA)
Note:

LX3V-4AD
4 WECON TECHNOLOGY CO., LTD.
Preset ranges are selected by an appropriate setting in buffer memory of the analog block.
Current/Voltage input selection must match the correct input terminal connections.
3) Miscellaneous
Item
Description
Isolation
Photo-couple isolation between analog and digital circuits. DC/DC converter isolation
of power from LX3VCPU.
No isolation between analog channels.
4.4 Allocation of buffer memories (BFM)
BFM
Description
*#0
Channel initialization, default=H0000
*#1
Channel 1
Contains the number of samples (1 to 4096) to be used for an
averaged result.
The default setting is 8-normal speed. High speed operation can be
selected with a value of 1.
*#2
Channel 2
*#3
Channel 3
*#4
Channel 4
#5
Channel 1
These buffer memories contain the averaged input values for the
number of samples entered for the channel in buffer memories #1 to
#4 respectively.
#6
Channel 2
#7
Channel 3
#8
Channel 4
#9
Channel 1
These buffer memories contain the present value currently being
read by each input channel.
#10
Channel 2
#11
Channel 3
#12
Channel 4
#13-#14
Reserved
#15
Selection of A/D
conversion
speed please
refer to note 2
When set to 0, a normal speed is selected of 15m/s.ch (default)
When set to 1, a high speed is selected of 6m/s.ch
#16-#19
Reserved
*#20
Reset to Defaults and Preset. Default = 0
*#21
Offset, Gain Adjust Prohibit.
Default = (0, 1) Permit
*#22
Offset, Gain
Adjust
b7
b6
b5
b4
b3
b2
b1
b0
G4
O4
G3
O3
G2
O2
G1
O1
*#23
Offset Value Default = 0

LX3V-4AD
5 WECON TECHNOLOGY CO., LTD.
*#24
Gain Value Default = 5,000
#25-#28
Reserved
#29
Error status
#30
Identification code K2010 (12-bit resolution)
Identification code K2011 (16-bit resolution)
#31
Hardware version
In buffer memory locations (BFM’s) marked with an “*” data can be written from the PC using
the TO command.
For buffer memories (BFM’s) without “*”mark, data can be read to the PC using the FROM
command.
Before reading from the analog special function block, ensure these settings have been sent to
the analog special function block. Otherwise, the previous values held in the analog block will
be used.
Offset (intercept): The analog input value when the digital output becomes 0.
Gain (slope): The analog input value when the digital output becomes +1000.
Note
1) Channel Selection
Channel initialization is made by a 4 character HEX number HOOOO in buffer memory BFM #0.
The least significant character controls channel 1 and the 4 character controls channel4.
BFM#0
Analog input
Digital output
Resolution
Offset/Gain
Constant
0
-10V~10V
-2000~2000
5 mV
0/5000
1000
1
4mA~20mA
0~1000
16µA
4000/20000
1000
2
-20mA~20mA
-1000~1000
20µA
0/20000
1000
3
Disabled
/
/
/
/
4
-10V~10V
-10000~10000
1mV
0/5000
10000
5
4 mA ~20mA
0~10000
1.6µA
4000/20000
10000
6
-20mA~20mA
-10000~10000
2.0µA
0/20000
10000
Example: H3310
CH1: Preset range (-10V to +10V).
CH2: Preset range (+4mA to +20mA).
CH3, CH4: Channel OFF.
2) Analog to Digital Conversion Speed Change

LX3V-4AD
6 WECON TECHNOLOGY CO., LTD.
By writing 0 or 1 into BFM #15 of the LX3V-4AD, the speed at which A/D conversion is
performed can be changed.
However the following points should be noted: To maintain a high speed conversion rate, use
the FROM/TO commands as seldom as possible.
NOTES:
When a conversion speed change is made, BFM #1-#4 are set to their default values
immediately after the change. This is regardless of the values they held originally. Bear this in
mind if a speed change will be made as part of the normal program execution.
3) Adjusting Gain and Offset values
Formula for Gain/Offset: Digital output= (Analog input-Offset)*Constant/ (Gain-Offset)
a) When buffer memory BFM #20 is activated by setting it to K1, all settings within the analog
special function block are reset to their default settings. This is a very quick method to
erase any undesired gain and offset adjustments.
b) If (b1, b0) of BFM #21 is set to (1, 0), gain and offset adjustments are prohibited to prevent
inadvertent changes by the operator. In order to adjust the gain and offset values, bits (b1,
b0) must be set to (0, 1). The default is (0, 1).
c) Gain and offset values of BFM #23 and #24 are sent to non-volatile memory gain and offset
registers of the specified input channels. Input channels to be adjusted are specified by the
appropriate G-O (gain-offset) bits of BFM #22.
Example:
If bits G1 and O1 are set to 1, input channel 1 will be adjusted when BFM #22 is written to
by a TO instruction.
d) Channels can be adjusted individually or together with the same gain and offset values.
e) Gain and offset values in BFM #23 #24 are in units of mV or µA. Due to the resolution of
the unit the actual response will be in steps of 5mV or 20µA.
4) Status Information BFM #29
Bit devices of BFM #29
ON
OFF
b0: Error
When any of b1 to b4 is ON. If
any of b2 to b4 is ON, A/D
conversion of all the channels is
stopped
No error
b1: Offset/gain error
Offset/Gain data in EEPROM is
corrupted or adjustment error.
Offset/Gain data normal
b2: Power source abnormality
24V DC power supply failure
Power supply normal

LX3V-4AD
7 WECON TECHNOLOGY CO., LTD.
b3: Hardware error
A/D converter or other
hardware failure
Hardware normal
b10: Digital range error
Digital output value is less than
-2048 or more than +2047
Averaging is normal. (between
1 and 4096)
b11: Averaging error
Number of averaging samples is
4097 or more or 0 or less
(default of 8 will be used)
Averaging is normal. (between
1 and 4096)
b12: Adjust prohibit
Prohibit-(b1, b0) of BFM #21 is
set to (1, 0)
Permit-(b1, b0) of BFM #21 is
set to (0,1)
NOTE:
b4 to b7, b9 and b13 to b15 are undefined.
5) Identification Code BFM #30
The identification (or ID) code number for a Special Function Block is read using the FROM
command.
This number for the LX3V-4AD unit is K2011 or K2010.
The user’s program in the PC can use this facility in the program to identify the special function
block before commencing data transfer from and to the special function block.
NOTE:
Values of BFM #0, #23 and #24 are copied to EEPROM memory of the LX3V-4AD. BFM #21 and
BFM #22 are only copied when data is written to the gain/offset command buffer BFM #22.
Also, BFM #20 causes writing to the EEPROM memory. The EEPROM has a life of about 10,000
cycles (changes), so do not use programs which frequently change these BFMs.
Because of the time needed to write to the EEPROM memory, a delay of 300 ms is required
between instructions that cause a write to the EEPROM. Therefore, a delay timer should be
used before writing to the EEPROM a second time.
5. Defining gain and offset
Gain determines the angle or slope of the calibration line, identified at a digital value of 1000.
(a) Small gain: Large steps in digital readings
(b) Zero gain: Default is 5V or 20mA.
(c) Large gain: Small steps in digital readings.

LX3V-4AD
8 WECON TECHNOLOGY CO., LTD.
Offset is the “Position” of the calibrated line, identified at a digital value of 0.
(d) Negative offset.
(e) Zero offset: Default is 0V or 4mA.
(f) Positive offset.
Offset and gain can be set independently or together. Reasonable offset ranges are -5 to +5V or
-20mA to 20mA, and gain values 1V to 15V or 4mA to 32mA. Gain and offset can be adjusted by
software in the LX3V main unit (please refer to program example 2).
Bit device’s b1, b2 of the gain/offset BFM #21 should be set to 0, 1 to allow adjustment.
Once adjustment is complete these bit devices should be set to 1, 0 to prohibit any further
changes.
Channel initialization (BFM #0) should be set to the nearest range, i. e. voltage/current etc.
6. Example program
6.1 basic program
In the following example channels CH1 and CH2 are used as voltage inputs. The LX3V-4AD block is
connected at the position of special function block No.0. Averaging is set at 4 and data registers D0
and D1 of the PC receive the averaged digital data.

LX3V-4AD
9 WECON TECHNOLOGY CO., LTD.
Note
1) The FROM code for the special function block at position “0" is read from BFM #30 of that block
and stored at D4 in the main unit. CMP is compared to check the block is a LX3V-4AD, if OK M1
is turned ON.
2) TO code: The analog input channels (CH1, CH2) are setup by writing H3300 to BFM #0 of the
LX3V-4AD
3) The number of averaged samples for CH1 and CH2 is set to 4 by writing 4 to BFM #1 and #2
respectively.
4) The operational status of the LX3V-4AD is read from BFM #29 and output as bit devices at the
LX3V main unit. If there are no errors in the operation of the LX3V-4AD, then the averaged data
BFM’s are read.
5) In the case of this example BFM #5 and #6 are read into the LX3V main unit and stored at D0
and D1. These devices contain the averaged data for CH1 and CH2 respectively.
6.2 Using gain and offset in a program
The gain and offset of the LX3V-4AD can be adjusted using push-button switches on the input
terminal of the PC. It can also be adjusted using software settings sent from the PC.
Only the gain and offset values in the memory of the LX3V-4AD need be adjusted. A voltmeter or an
ammeter for the analog input is not needed. A program for the PC will be needed however.
The following is an example of changing the offset value on input channel CH1 to 0V and the gain
value to 2.5V.
The LX3V-4AD block is in the position of block No.0 (i.e. closest to the LX3V main unit).

LX3V-4AD
10 WECON TECHNOLOGY CO., LTD.
Example: Adjusting gain/offset via software settings
7. Diagnostics
7.1 Preliminary checks
1) Check whether the input wiring and/or extension cables are properly connected on LX3V-4AD
analog special function block.
Adjustment start
(H0000)->BFM#0 (initialize input
channels). Enter the instructions on the
left and RUN the PC
(K1)->BFM#21. BFM#21 must be set to
permit with (b1, b0)=(0,1)
(K0)->BFM#22 (offset/gain adjusts).
Reset adjust bits
(K0)-> BFM#23 (offset)
(K2500)-> BFM#24 (gain)
(H0003)->BFM#22(offset/gain adjusts).
3=0011 i.e. O1=1, G1=1. Therefore
channel 1 is adjusted.
Adjustment ends.
(K2)-> BFM#21. BFM#21 gain/offset
adjust prohibit

LX3V-4AD
11 WECON TECHNOLOGY CO., LTD.
2) Check that the LX3V system configuration rules have not been broken, i.e. the number of
special function blocks does not exceed 8 and the total system I/O is equal or less than 256 I/O.
3) Ensure that the correct operating range has been selected for the application.
4) Check that there is no power overload on either the 5V or 24V power sources, remember the
loading on a LX3V main unit or a powered extension unit varies according to the number of
extension blocks or special function blocks connected.
5) Put the LX3V main unit into RUN.
7.2 Error checking
If the LX3V-4AD special function block does not seem to operate normally, check the following
items.
Check the status of the POWER LED.
Lit: The extension cable is properly connected.
Otherwise: Check the connection of the extension cable.
Check the external wiring.
Check the status of the “24V” LED (top right corner of the LX3V-4AD).
Lit: LX3V-4AD is OK; 24V DC power source is OK.
Otherwise: Possible 24VDC power failure, if OK possible LX3V-4AD failure.
Check the status of the “A/D” LED (top right corner of the LX3V-4AD).
Lit: A/D conversion is proceeding normally.
Otherwise: Check buffer memory #29 (error status). If any bits (b2 and b3) are ON, then this is
why the A/D LED is OFF.
Version: V3.0.1
Date: April 2019
