Wellcare WE-167CPHD User manual

Soothing Heating Pad
Energy fills every cell | Self-healing
Instruction Manual
WE-167CPHD
Beruhigendes Heizkissen
Fült jede Zelle mit Energie |
Selbstheilung
Gebrauchsanleitung
Verzachtend
Verwarmingskussen
Vult elke cel met energie |
Zelfgenezend
Gebruiksaanwijzing
Coussin Chauant
Apaisant
Remplis chaque cellule d’énergie |
Autoguérison
Mode d’emploi

2
MODEL: WE-167CPHD
GB Soothing Heating Pad ………………… 03
Energy fills every cell | Self-healing
Instruction Manual
DE Beruhigendes Heizkissen ………………… 20
Fült jede Zelle mit Energie | Selbstheilung
Gebrauchsanleitung
NL Verzachtend Verwarmingskussen ………………… 39
Vult elke cel met energie | Zelfgenezend
Gebruiksaanwijzing
FR Coussin Chauant Apaisant ………………… 58
Remplis chaque cellule d’énergie |
Autoguérison
Mode d’emploi
WELLCARE CO., LTD.
16F, No. 738, Jhong Zheng Rd., Jhong He District, New Taipei City 235, Taiwan
Tel. [phone] Fax. [phone]
www.wellcare-global.com
CONTENT
B803.102-M0824

3
Explanation of symbols
Read instructions
Do not use when folded or creased
Do not pierce with needles
Not to be used by very young children
(0-3 years)
Do not dry clean
30°C extra gentle washing program
Do not bleach
Do not tumble dry
Do not iron
GB

4
Thank you for purchasing the Soothing
Heating Pad from Wellcare.
To enjoy the most comfortable
experience and the greatest satisfaction,
please take a few minutes to read this
instruction carefully before using this
product.
IMPORTANT SAFETY INSTRUCTIONS
RETAIN FOR FUTURE USE
KEEP CAREFULLY IN CASE IT IS NEEDED!
This heating pad is designed to be used for many
years if it is properly used. Read the instruction
carefully to prevent damage or danger caused
by incorrect use. Keep this instruction manual at
an easy-to-access location so you can refer back
when necessary.
If you let somebody else use this product, please
pass on this instruction manual as well and make
sure the user has read it before using.
GB

5
GB
B
C
61
34
5
A
8
7
2

6
4D DWF® Technology (please see fig. C)
This product utilizes WELLCARE’s recent and the most innovative
technology – 4D DWF®. While this technology pioneers in the flexible
heating industry, its production process is also the state of the art.
Our physical living environment consists of three dimensions, width,
length, and depth; hence, the term “3D”. As Wellcare introduces to you
the 4D DWF® technology, the “temperature” brought to you by dynamic
flow of warmth is the definition of the fourth dimension. 4D DWF®
employs concepts of breathing system which creates full-body heat
circulation for heat to disperse evenly, thoroughly, and quickly. The heat
is generated by heating elements, builds up and gathers around several
hundred uniquely designed circular holes. Through these holes, the heat
flows bi-directionally to create a gentle heat flow and the thermal energy
can flow rapidly to warm up human bodies.
There are many benefits of this innovative technology :
• Better breathability
• Rapid heating
• Higher temperature
• Uniquely designed holes to provide 360° warmth circulation
• Greater heat distributing area
• Eective heat transmission
• Strands of warmth flow retain air moisture
• Warmth kept at a constant temperature
• Energy saving
GB

7
BBC (BEST BED CLIMATE) DESIGN
What is BBC Design?
Many factors that can impact one’s sleeping quality, temperature is
one of them. There are more and more people consider that the right
temperature on the bed could lead to an ideal sleep. With that being said,
if we can create a comfortable and suitable environment, in other words,
the Best Bed Climate, then, it is more likely for us to fall asleep easier and
improve our sleep quality.
BBC (Best Bed Climate) design is originated from the elements of 4D
DWF (Dynamic Warmth Flow), breath, warmth, and nature. When the
product is switched on, cold and warm air circulates in and out each 4D
DWF circular hole, soothing warmth flow and better breathability are
created for people to have their optimal bed climate and enjoy a restful
sleep. Warmth is delivered to people’s body as natural as breathing air.
BBC Design Application
The timer function in all Wellcare electric heating products is with BBC
design, which is a function of automatic switch-o in 90 minutes, 2 hours
or 8 hours. With Wellcare’s natural prescription, you can enjoy every
sleep with healthy and rejuvenating energy especially for the busy you.
CONCEPT
Take a deep breath and take care of yourself.
Drawing the idea from breathing, the cell heating pad mimics the shape
of a cell to demonstrate the concept of cell building block. Each 360°
hole allows the cold and warm air to circulate in and out and combine with
the moisture in the air and forms strands of warmth flow as natural as
breathing air. You will instantly feel the peace and tranquility for natural
self-healing the moment you touch it.
Regardless you’re in a place of tranquility, or hustle and bustle, you’ll feel
content with solitude.
The loving warmth flow stays just for you. Take a deep breath and take
care of yourself.
GB

8
The appliance is not intended for medical use in
hospitals.
• Please read carefully and follow the instructions.
• Examine the appliance frequently for signs of
wear or damage. If there are such signs or if
the appliance has been misused or does not
work, return it to the supplier before switching
it on again.
• Do not use this appliance if there is visible
damage.
• Use the appliance only as described in this
instruction manual.
• Before connecting the device to the power
supply, please ensure that the supply voltage
stated on the rating plate is compatible with
your mains supply.
• The appliance must not be used when folded
or crumpled.
• Do not use the appliance for persons who
cannot move without help, small children,
persons who cannot feel heat, or animals.
Persons who can feel heat to some extent may
only use the appliance with supervision.
• This appliance must not be used by persons
insensitive to heat and other very vulnerable
persons who are unable to react to overheating.
• If the mains cable of the product is damaged,
it must be replaced by the manufacturer, its
customer service department or qualified
persons to prevent hazards.
• Do not treat this appliance as a sheet or tuck
it in the mattress.
GB

9
• Do not pierce the appliance with needles, safty
pins or other sharp objects.
• Do not tug, twist or make sharp bends to the
cables.
• Do not carry or unplug the appliance by pulling
its mains cable.
• Do not expose the controller or the mains cable
to moisture or liquids.
• Do not use this appliance when it is damp or
wet and only use it in dry environments.
• Do not sit on the heating pad.
• Avoid sharp bending or bundling of the heating
pad.
• The cable and control unit of the appliance can
give rise to risks of entanglement, strangulation,
tripping or treading if not correctly arranged.
The user shall make sure that excess ties and
electric cords shall be arranged in a safe way.
• While the heating pad is switched on,
- Do not place any large or heavy objects on it
such as suitcases, etc.
- Do not place any sources of heat on it such
as hot water bottles, heating pads.
- Due to the components in the controller will
make it slightly warm, never let the controller
to be covered or placed on the heating pad,
pillows and the like or lie on the electric
mattress heater.
• Do not fold the heating pad when it is hot.
• This appliance is only designed to warm up
the human body. Do not use it on pets or
GB

10
other animals.
• Caution! Never fall asleep while the appliance is
in operation.
• When the appliance will be used for an
extended period (falling asleep), the
temperature setting should be adjusted to the
lowest level (setting 1) for continuous use to
avoid overheating on the same body part,
which may lead to burns to the skin.
• Prolonged use can cause burns to the skin.
• Children should be supervised to ensure that
they do not play with the appliance.
• Children below the age of three (0~3) are not
allowed to use this device due to their inability
to react to overheating.
• This device may not be used by young children
over the age of three (3) unless the control
unit has been pre-set by a parent or guardian
and unless the child has been adequately
instructed on how to operate the control unit
safely.
• The appliance can be used by children older
than 3 years and younger than 8 years under
supervision and with the control always set to
minimum temperature value.
• This appliance may be used by children over the
age of eight (8), and persons with reduced
physical, sensory or mental capabilities or
lack of experience or knowledge if they have
been supervised or instructed concerning use
of the appliance in a safe way and understand
the hazards involved.
GB

11
• Cleaning and user maintenance shall not be
made by children without supervision.
• If you have any concerns about health issues,
please consult with your doctor before using
the appliance.
• Do not use the heating pad on parts of the
body that are swollen, injured or inflamed.
• If you experience any pain or discomfort while
using the appliance, stop using it immediately.
• If you use a pacemaker, please consult your
doctor and the manufacturer of the pacemaker
before using this product due to the EMF
(electromagnetic fields) emanated from this
electric product may interfere with functions of
your pacemaker under certain circumstances.
• When the heating pad is not in use :
- Set the slide switch on the controller to
setting “0” (OFF)
- The plug should be removed from the wall
socket and the heating pad should be
stored in a dry place, without additional
weight on it.
- The plug-in connector should be removed
from the heating pad to avoid damages
caused by twist or bend of the cable.
• When the appliance will not be used for a
period of time, we recommend that you store it
in the original packaging.
- Allow it to cool down before folding and the
storage.
- Do not crease the heating pad by placing
items on top of it during storage.
GB

12
- Store it in a dry place away from any liquids
or sources of heat.
• This heating pad must be used with the type of
the controller that is marked on the rating label
only.
ITEMS INCLUDED IN THE PACKAGE
1 Heating Pad
1 Controller with Cable and Plug-in Connector
1 Instruction Manual
1 Service Instruction
1 Membership Card
DESCRIPTION OF THE DEVICE AND
CONTROLLER (please see fig.A)
1. Mains cable with plug
2. Controller
3. APS (Active Protection System) with 3-colored
LED display (on both sides)
4. Slide switch for ON, OFF and temperature
settings (1, 2, 3, 4)
5. Type of the controller
6. Detachable plug-in connector
7. Connection box
8. Heating pad
GB

13
METICULOUSLY SELECTED FABRICS
Creating warmth flow with 4D DWF holes through
cosy fleece side, and the other side with fluy baby
fleece provides comfort and relaxation.
PREPARING FOR USE
(please see fig.B)
The heating pad can be placed on parts of the
body, such as shoulder, back, abdomen, calf and
other parts where warmth is needed.
1. Always make sure the heating pad (8) is without
any folds, creases or ruck-up.
2. Join the detachable plug-in connector (6) to
the connection box (7).
3. Make sure the controller (2) is not covered by
the sheet, pillow or any objects.
4. Plug the mains cable (1) to the wall socket.
5. To enjoy instant warmth, please put the 4D DWF
circular holes side on your body.
6. Unplug the appliance from the wall socket
when it is no longer in use.
SWITCHING ON
Before each time you use the heating pad, please
make sure it is not bundled, folded or creased
before it is switched on.
Connect the heating pad only to 230 VAC. Switch it
on by using the hand-operated slide switch (4) and
there will be 3 times of beep sound (beep–beep–
GB

14
beep) to ensure the product has been operated
correctly. The warm-up time for this heating pad
is 7 - 10 minutes approximately.
In order to warm up the appliance faster, it is
recommended to initially set the heating pad at
the highest temperature setting.
Temperature settings :
4
= maximum warmth
2-3 = moderate warmth
1
= minimum warmth
0
= OFF
APS (Active Protection System) – 3-Color LED
This product is equipped with APS (Active
Protection System) (3) technology which detects
errors on the operation or component failures.
By the 3-color LEDs (3) which can be seen from
both sides of the controller (2) and the beep
sound, APS can help you to operate the product
easily and safely.
• Green – Your heating pad has reached the
desired temperature level
• Orange – Your heating pad is heating up to
reach the desired temperature level
Due to the temperature variation in dierent
environments (room, bed, etc.), APS LED may
change between green and orange colors within
seconds which indicates continuous heating when
the product is in use. Under this circumstance,
please note the product is functioning properly
GB

15
and normally.
• Red light and Beep Sound – Possible
malfunction or overheating, switch o the
appliance immediately.
In the following situations, the red light and beep
sound will come on to indicate warning :
• When the power is on but detachable plug-in
connector (6) is not connected properly: there
will be beep sound every second with the red
light on. Please connect the detachable plug-
in connector (6) to the connection box (7) and
switch on the controller again.
• When the critical components are damaged:
there will be continuous beep sound with the
red light on. Please disconnect the mains cable
from wall outlet immediately.
• When the heating wires or other components
are broken and the device cannot work
anymore : there will be beep sound every
second with the red light on.
• When the heating pad (8) is folded or covered
by objects, such as pillows and blankets, which
cause an overheating concern, the device will
beep every 2 seconds with the red light on.
Please switch the heating pad o and make
sure the pad is flat and/or remove the objects
that are on top of the pad. You may switch the
heating pad back on again after the pad cools
down.
The warnings mentioned above cannot cover
all defective situations as the damages on some
components will not lead to red light or beep
sound.
GB

16
TURBO HEATING
The product is with a turbo heating function for user
to feel warmth within 7-10 minutes after it is switched
on.
TIMER FUNCTION
Now you can enjoy the pleasant warmth. This product
will be switched o automatically after about 90
minutes. In order to put the product into operation
again, you must set the slide switch (4) to setting ‘0’
first. After about 5 seconds, you can switch it again.
CAUTION
Do not use the appliance when it is folded, creased, tucked in or drawn
together or it may lead to overheating or shutdown.
The electronic components inside the controller may cause the controller
slightly warm when the product is in use. Therefore, the controller must not
be covered or placed on top of any heating sources when it is in operation.
You should not gauge the product’s temperature by hands because the
skin on your body is more sensitive than hands. The temperature may feel
lukewarm by hand but could be unpleasantly hot to your body.
The repairs to the product may only be undertaken by qualified persons
by using original replacement parts. Repairs carried out by unqualified
persons may cause substantial risk to the user.
T
GB

17
CLEANING AND CARE
This heating pad (8) is machine washable.
• Before cleaning the heating pad (8), always unplug
the product from the wall socket first. Let the
heating pad cool down.
• Disconnect the plug-in connector (6) from the
connection box (7). Put the cable and the controller (2) to a dry place
where will not contact with water or other liquids.
• To clean the controller (2), use a dry, lint-free cloth. Do not use any
chemical or abrasive cleaning detergents.
• Please note that the heating pad should not be dry-cleaned, wrung
out, machine-dried, pressed or ironed or bleached.
• Small marks on the heating pad can be removed with a damp cloth.
• Set washing machine to a gentle washing cycle at 30 °C, the heating
pad should only be washed together with other textiles. Use a mild
washing detergent for delicate fabrics and dose it according to the
manufacturer’s instructions.
• Always use a laundry bag for better protection of the holes and fabric.
• For dark color products, always wash separately.
• After washing, reshape the heating pad (8) to its original dimensions
while it is still damp, and lay the heating pad flat on a moisture-
absorbent towel, mat or clothes horse to dry it.
• Do not use pegs or similar items to attach the heating pad to the
clothes horse, they may damage the heating pad.
• Please note that excessive washing will wear out the heating pad. For
this reason, the heating pad should only be washed a maximum of 10
times throughout its entire life.
• Only use the heating pad when it is complete dry.
• Never switch on the appliance to dry it.
GB

18
DISPOSAL
This appliance must not be disposed together with
domestic waste but at a suitable local collection or
recycling point. Please dispose of the appliance in
accordance with Directive on Waste Electrical and
Electronic Equipment (WEEE). If there is any
question, please contact the municipal authority
for more information about disposal in your area.
WARRANTY
Please note Wellcare provides two-year limited warranty for this
product. Wellcare warrants that this product will be free from defects in
materials and workmanship for a period of two years beginning on the
date of purchase.
During the two-year period beginning on the date of purchase,
Wellcare will replace defective products covered under this limited
warranty. Please note a clear copy of the purchase receipt for the
product is required. To request limited warranty service, please return
the defective product to the store where you purchased it with the
clear copy of purchase receipt within the limited warranty period. The
replacement product will assume the remaining limited warranty of the
original product.
We advise you to call our helpdesk for any problems regarding the
product before returning it to the store where you purchased it.
However, please note that our limited warranty does not cover any
damage due to shipment of the products to you and external causes,
including accident, abuse, misuse, problems with electrical power, usage
STORAGE
If the heating pad will not be used for a long time, we highly
recommend :
• Remove the plug-in connector from the connection box.
• Always let the appliance to cool down first before folding and
storing it.
• Store it in the original packaging and put it in a dry place.
• Do not put any object on the top of the appliance.
GB

19
not in accordance with product instructions, failure to perform reasonable
maintenance, problems caused by use of parts and components not
supplied by Wellcare, and problems caused by unauthorized repair of
Wellcare’s product. Furthermore, our limited warranty does not cover any
damage due to the defects known to exist by you when you purchase the
product.
This limited warranty gives you specific legal rights, and you may also
have other rights that vary from country to country (or jurisdiction to
jurisdiction). Wellcare’s responsibility for malfunctions and defects in
product is limited to replacement as set forth in this limited warranty
statement. All express and implied warranties for the product,
including but not limited to any implied warranties of any conditions of
merchantability and fitness for a particular purpose, are limited in duration
to the limited warranty period set forth above and no warranties, whether
express or implied, will apply after such period. Wellcare does not accept
liability beyond the remedies set forth in this limited warranty statement
or liability for indirect, incidental or consequential damages.
Model : WE-167CPHD
Size : 34 (W) x 52 (L) CM
Voltage : 230V~ 50Hz
Watts : 100W
TECHNICAL DATA
GB

20
Zeichenerklärung
Lesen Sie die Anweisungen
Nicht benutzen, wenn gefaltet oder
zerknittert
Nicht mit Nadeln durchbohren
Nicht für Kleinkinder geeignet
(0-3 Jahre)
Nicht chemisch reinigen
Extra Schonwasch-gang mit 30°C
Nicht bleichen
Nicht im Trockner trocknen
Nicht bügeln
DE
