Wenshing TX-F03 User manual

http://www.wenshing.com.tw ; http://www.rf.net.tw
TX-F03 Instruction Manual P.1
WENSHING®© TX-F03
Wireless Remote Controller/Transmitter (RF ASK)
TX-F03 is switch controlled by programmer. By RF wireless technology, can
reach the distance about reach 80~120m if work with WENSHING remote
control receiver. The feature of RF wireless technology, do not need the
direction to use; and its special frequency 371.5MHz can avoid most of the
interference.
By working with the remote control receiver, it can use in many purpose. Such
as electronic lock, garage door, home alarm security system, auto control
system and etc.

http://www.wenshing.com.tw ; http://www.rf.net.tw
TX-F03 Instruction Manual P.2
Content
Important Event................. ........ ..... ..............................................................3
Declaration …………………... ..………………………………………………...3
Warranty…………………………..... ...…………………………………………3
Un-warranty Scope Description…………... ...…………………………………3
Contact Us………………………………... ...……………………………………3
Spec....... ....... ... ... ... ... ... ... ... .................... .. ....... .......................................4
Material....... ............................. .. ... ... ... ... ... ... .... .......................................4
Function...... ............................. .. ..... ... ... ... ... ... .. .......................................4
CE Statement (European Union)……………………. .. ..……………………..5
FCC Statement (U.S.A. Only)…………………………….…….. ...……………5

http://www.wenshing.com.tw ; http://www.rf.net.tw
TX-F03 Instruction Manual P.3
Important Event
This product is in general use for the equipment on the premise of the development,
design, manufacture. Do not use that require high security purposes, such as
machinery or medical, aviation equipment, machinery and transport-related deaths
are directly or indirectly related to the system.
This product should be in this brochure by the instructions of the types and rated
voltage power under the current proper use. If violation of this statement by the
safety records of the supply operation, I am afraid our company cannot afford any
of the responsibility.
Do not self-decomposition, alteration, repair of the products also will cause fire,
electric shock, fault, and dangerous. In addition, their decomposition, alteration,
repair the product, failure is not within the scopeof warranty.
The products are not waterproof, so please do not use and touch water. Take off
and on also please note. Rain, spray, drinks, steam,sweatmay be a failure.
Use of this product, please be sure to use according to the statement recorded by
the use of methods to operate. Please do not violate particular attention to the
matter reminded to use.
Please respect this statement recorded by the note. When consumers in
contravention of this statement recorded note of the operation, I am afraid our
companycould not shoulder any responsibility.
Products are defective, the Company will be responsible for free to amend the
flaws, or to the same flawless product or its equivalent products in exchange.
However, the Company does not assume based on the requirements of the flaw
and loss responsibility.
The Company reserves the right to retain without notice to users of the cases, the
product of hardware / software(version upgrade) is with the right to edit.
Declaration
This product provides different frequency for user selection to meet different
telecommunicationregulation and FCC/CE on different countries.
Warranty
The warranty time iswithin one year from purchased date. The warranty scopeare
used in normal situation and none vandalism. (Somefunction harmful out of warranty
scopeand Vandalism are Un-warranty).
Un-warranty Scope Description
Becausethe natural disaster,accident or human factor to causethe bad damage.
Violate the product instruction manual to causethe damage of the products.
The improper assemblecauses damage.
The products usedthe unsanctioned accessoryto causedamaged.
Overstep the allowed used environment to causethe products damaged.
Contact Us
WENSHING ELECTRONICSCO.,LTD.
No.82, Chong DeSt. 11054 Shin Yi Dist,Taipei, Taiwan
Tel: [phone]
Fax: [phone]

http://www.wenshing.com.tw ; http://www.rf.net.tw
TX-F03 Instruction Manual P.4
Spec
Frequency range: 371.5MHz
Channel spacing: ±250KHz
Material
Material
Specification
Color
Casing
ABS
Black
Button
3
Orange
Battery
DC 12V,23A
-----
Size
60*40*12mm
-----
Function
Push the button"ON", it will be opened.
Push the button "CLOSE",itwill be closed.
Push the button" STOP",it will be stopped.

http://www.wenshing.com.tw ; http://www.rf.net.tw
TX-F03 Instruction Manual P.5
CE Caution Note (European Union)
Symbol of it accords with EMC regulation (89/336 / EEC) to represent this device,
and the low-voltage regulation of European Union (73/23/EEC). It represents to follow
the following standard regulations of European Union (The bracket is a reciprocal
international standard reciprocal international standard and regulation).
EN60950/A11: 1997/(IEC 60950/A4: 1996),The ones that includes information
scienceand technology of apparatus of e-commercesafe.
EN55024: 1998 (IEC 1000-4-2, 1000-4-3, 1000-4-4, 1000-4-5, 1000-4-6,
1000-4-8, 1000-4-11) -' scientific and technological apparatus of information - The
characteristic of interfere avoided - Restrain and test method '
Chapter 2 -Static release (ESD) Demand
Chapter 3 -Radiate the staticfield demand
Chapter 4 -The electron is transmitted/ produced and washed (EFT) fast
Demand.
Chapter 5 -surgedemand
Chapter 6 -Resistancedemandcausedin field of wireless frequency.
Chapter 8 -Magnetic field demand of electric frequency.
Chapter 11 –Shortly cut off the demand of making a variation with the voltage
transiently under the voltage.
EN 55022:1998/(CISPR 22:1997) ,Class B, ' “To assess information scientific and
technological apparatus wireless restriction and way of interfering with the
characteristic.”
FCC Consistent Declaration ( U.S.A. Only)
Attention: FCC rule regulation, modified and changed mustallowed by WENSHING
Electronics company,otherwise that would make you operate this apparatus invalid.
This apparatus adopted test, according to chapter 15 that FCC regulation, accord with
Class B digital restrictions of device. These limits are designed to provide reasonable
protection, avoid to having harmful interference at home’s environment.
This device may have radiated wireless frequency energy. If don’t allow the instruction
manual, then may will interfere wireless communication. However, there is no any way
to guarantee, it will not be interfered in particular installed. If this device really causes
harmful interference, (It could be confirmed by turning on or off this device.) Advise
you to try to usethe following ways modifying the interference situation.
Relocation receiving antenna or altering its direction.
Increase the distancebetween device and receiver.
Please connectthis device to the outlet in the circuitdifferent from the receiver.
The following manuals is published by Federal Communications Commission,
they mustbe helpful to all users.
How to Identify and Resolve Radio-TV Interference Problems.(This manual can
be obtained by relevant departments of publication of the U.S. government.)
Government Printing Office,Washington D.C.,20402. Stock No. 004-00398-5
