Wenshing WS-UHFRFIDANT4 User manual

12
902~928MHz 2W
UHF RFID Industrial Reader
Instruction manual
Content
Important event Parts Description
Model: WS-UHFRFIDANT4
123A
456B
789C
*0#D
123A
456B
789C
*0#D
Wiegand out
WiFi antenna port USB port RS-485 port
WAN port LAN port Power in
+ +
TNC Antenna port
d
b
c
a
e
fg
h
ijk l
RS-232 port
Keyboard
LCD display
abc
def
gh i
jk l
SD slot
Important event
Declaration
Warranty
Parts Description
Specification
Wi-Fi Specification
Accessory
Characteristic
Start Display
Instructions
Set up instruction
Rj-45 Connection
Wi-Fi Connection
Wiegand out Pin Identify (Data Output Interface)
RS-485 Pin Identify (Reserved Communication Interface)
Install the Fix Stand
CE Caution Note (European Union)
Administrative Regulations on Low Power Radio Waves Radiated Devices
FCC Consistent Declaration (U.S.A. Only)
1
1
1
2
3
3
4
4
4
5
5
8
8
8
9
9
11
11
12
This product is in general use for the equipment on the premise of the
development, design, manufacture. Do not use that require high security
purposes, such as machinery or medical,aviation equipment, machinery
and transport-related deaths are directly or indirectly relatedto the
system.
This product should be in this brochure by the instructions of the types
and rated voltage power under the current proper use.If violation of this
statement by the safety records of the supply operation, I am afraid our
company cannot afford any of the responsibility.
Do not self-decomposition, alteration, repair of the products also will
cause fire, electric shock, fault, and dangerous.In addition, their
decomposition, alteration, and repair the product, failure is not within
the scope of warranty.
The products are not waterproof, so please do not use and touch water.
Take off and on also please note. Rain, spray, drinks,steam, sweat may be
a failure.
Use of this product, please be sure to use according to the statement
recorded by the use of methods to operate.
Please do not violate particular attention to the matterreminded to use.
Please respect this statement recorded by the note. When consumers in
contravention of this statement recorded note of the operation, I am
afraid our company could not shoulder any responsibility.
Products are defective, the Company will be responsible for free to amend
the flaws, or to the same flawless product or its equivalent products in
exchange. However, the Company does not assume based on the
requirements of the flaw and loss responsibility.
The Company reserves the right to retain without notice to users of the
cases, the product of hardware / software (version upgrade) is with the
right to edit.
Declaration
This product meet different telecommunication regulation.
Warranty
The warranty time is within one year from purchased date. The
warranty scope are used in normal situation and none vandalism.
(Some function harmful out of warranty scope and Vandalism are
Un-warranty).
▶
▶
▶
▶
▶
▶
▶
▶

Frequency: USA(902~928MHz), China(920~925MHz)
Communication Protocol: EPC Class 1 Gen 2、ISO18000-6C、
IS18000-6A/B
Antenna: 4 Port TNC antenna output
Output Power: 2W (33dBm)
Communication Interface: RS-232、RS-485、Wiegand、Rj-45、
Wi-Fi、SD Card
Keyboard: 4X4
Reading Range: Able to reach 35 meter (depends on environment
tag size or function)
Display: 2.2”240x320 LCD Screen
Memory Device: Micro SD (32G extendable)
Wi-Fi: IEEE802.11b/g Wireless Standard
Working Voltage: 12V 2A
Operating Temperature: -10°C to +60°C
Size: 160 x 150 x 47.7 mm
5
3
6
4
Specification
Start Display
WWW.RF.NET.TW
RFID Reader
A= Device Menu
B= RFID Enable
C= RFID Disable
#= Device Info
PackageNo=
2014-12-15
09:25:33
F/W Ver : V002
Set up instruction
Press A to enter the Device Menu
System normal
Press A to the menu, enter six digit password (default password: 888
888) press # to delete error and re-enter the menu (Figure 1). Enter
the menu (Figure 2), when there is no indication over 5 min. it'll
automatically jump back to the menu or press D to exit.
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Delete
Please input
Password
2014-12-15
09:25:33
F/W Ver : V002
******
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Delete
1=Output
2=Baudrate
3=Setup
4=Time set
5=Update F/W
6=Antenna
7=Distance
8=Mode
Wi-Fi Specification
2.4GHz 802.11b/g/n,compatible
Support IEEE 802.3、IEEE 802.3u
WiFi Client/AP/Router Mode
Support wps/wds
The range of baudrate: 1200~500000bps
Support transparent transmission mode
Support multiple security authentication-mechanisms:
WEP64/WEP128/ TKIP/ AES
WEP/WPA-PSK/WPA2-PSK
Support wireless roam
Support multiple network protocols:
Support two config methods:Serial/WEB
Characteristic
Parameter Min Type Max Unit Condition
Operating Condition
Operating Temperature Range -30 +70 ℃
Operating Supply Voltage 12 V
Current Consumption
Standby mode 190 mA
Operating mode 1200 mA 2W Peak
RF Characteristic
Frequency Range 902 928
Output Power 15 33
MHz
dBm
Other
Display 2.2” TFT 240*320 Display
Button 4 * 4 Keyboard
Working mode FHSS
Antenna Four Antenna
Read prompt Buzzer
Support Area Taiwan、USA、China、Korea
Instructions
Figure 1 Figure 2
1=Output
Press 26 or 34 to set up output data, press B to the last page; Enter 1
and long press C (do not save) to the last page; Enter 1 and press D
(save) to standby mode (Figure 3).
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Delete
Select Output
2014-12-15
09:25:33
F/W Ver : V002
1.Wiegand 26
2.Wiegand 34
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Delete
Select Rate
2014-12-15
09:25:33
F/W Ver : V002
1=115200
2=57600
3=38400
4=19200
5=9600
6=230400
2=Baudrate
Set up RS-232 and RS-485 interface, press B to the last page; Enter
2 and long press C (do not save) to the last page; Enter 2 and press
D (save) to standby mode (Figure 4).
3=Setup
Set up password, reset Wifi, RFID and voice, press B to the last page
Enter 3 and long press C (do not save) to the last page; Enter D
(save) to the home screen (Figure 5).
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Delete
Setup
2014-12-15
09:25:33
F/W Ver : V002
1=Set Password
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Pre
Set Time
2014-12-15
09:25:33
F/W Ver : V002
YYYY-MM-DD
2=Reset Netword
3=RFID Setup
0000-00-00
00:00:00
4=Time set
Set up date and time as order: year-month-date-hour-minute-second
press B to the last page; Enter 4 and long press C (do not save) to
last page; Enter 4 and press D (save) and back to home screen
(Figure 6).
5=Update F/W
（Not Functioning）
Accessory
Power Adopter 12V 2A *1 Fix Stand *2 Instruction Manual *1
4=Control Buzzer
Press B to start scan
Press C to stop scan
Press # to display Device Info
Tag Reading Frequency
Date
Time
Version
Figure 3 Figure 4
Figure 5 Figure 6

910
78
6=Antenna
Set up Antenna Mode
Enter 6 and press B to the last page; Enter 6 and long press C (do not
save) to the last page; Enter 6 and press D (save) to the home
screen (Figure 7).
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Delete
Select Antenna
2014-12-15
09:25:33
F/W Ver : V002
1=Single mode
Single=1~4 ANT
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Delete
Distance
1=ANT1
Input 1~4 to
Change Distance
2=ANT2
3=ANT3
4=ANT4
7=Distance
Set up Signal Strength
Enter 6 and press B to the last page; Enter 6 and long press C (do not
save) to the last page; Enter 6 and press D (save) to the home
screen (Figure 8).
8=Mode
Enter 8 and press B to the last page; Enter 6 and long press C (do not
save) to the last page; Enter 6 and press D (save) to the home
screen (Figure 9).
WWW.RF.NET.TW
RFID Reader
A= Menu B= Enter
C= Back D= Exit
* = Next #= Delete
Data Format
2014-12-15
09:25:33
F/W Ver : V002
1=EPC
Output
2=TID
3=EPC+TID
Rj-45 Connection
1. Set up Dynamic IP on PC, insert the LAN Port on the Reader.
2. Open browser and enter ,User Name: admin http://192.168.16.254
Password: admin. The internet set up is adjustable.
Wi-Fi Connection
1. Search SSID as serial-Wifi's through Wi-Fi. Password=12345678
2. Open browser and enter ,User Name: adminhttp://192.168.16.254
Password: Admin. The internet set up is adjustable.
Wiegand out Pin Identify (Data Output Interface)
From left to right is RS-485 D+、5V、WG+、RS-485 D-、GND、
WG- (Figure 10).
RS-485 Pin Identify (Reserved Communication Interface)
From left to right is 5V、5V、RS-485 D+、RS-485 D-、GND、GND
(Figure 11).
RS-485 D+ 5V WG+ RS-485 D- GND WG-
RS-485 D+5V RS-485 D- GND5V GND
Install the Fix Stand underneath the device, then tighten the screw
(Figure 12, 13).
Figure 11
123A
456B
789C
*0#D
123A
456B
789C
*0#D
Figure 12
Figure 13
Install the Fix Stand
Figure 7 Figure 8
Figure 9
Figure 10

11
Attention: FCC rule regulation, modified and changed must allowed by
WENSHING Electronics company, otherwise that would make you operate
this apparatus invalid. This apparatus adopted test, according to chapter 15
that FCC regulation, accord with Class B digital restrictions of device. These
limits are designed to provide reasonable protection, avoid to having harmful
interference at home's environment.
This device may have radiated wireless frequency energy. If don't allow the
instruction manual, then may will interfere wireless communication. However,
there is no any way to guarantee, it will not be interfered in particular installed.
If this device really causes harmful interference, (It could be confirmed by
turning on or off this device.) Advise you to try to use the following ways
modifying the interference situation.
Relocation receiving antenna or altering its direction.
Increase the distance between device and receiver.
Please connect this device to the outlet in the circuit different from the
receiver.
The following manuals is published by Federal Communications
Commission, they must be helpful to all users.
How to Identify and Resolve Radio-TV Interference Problems. (This manual
can be obtained by relevant departments of publication of the U.S.
government.)
Government Printing Office, Washington D.C., 20402. Stock No. 004-
00398-5
Notice: The changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance
requirements, no change to the antenna or the device is permitted. Any
change to the antenna or the device could result in the device exceeding the
RF exposure requirements and void user's authority to operate the device.
Symbol of it accords with EMC regulation (89/336 / EEC) to represent this
device, and the low-voltage regulation of European Union (73/23/EEC).
It represents to follow the following standard regulations of European Union
(The bracket is a reciprocal international standard reciprocal international
standard and regulation).
EN 60950/A11: 1997/(IEC 60950/A4: 1996),The ones that includes
information science and technology of apparatus of e-commerce safe.
EN 55024: 1998 (IEC 1000-4-2, 1000-4-3, 1000-4-4, 1000-4-5, 1000-4-6,
1000-4-8, 1000-4-11) -' scientific and technological apparatus of information -
The characteristic of interfere avoided - Restrain and test method
Chapter 2 -Static release (ESD) Demand
Chapter 3 -Radiate the static field demand
Chapter 4 -The electron is transmitted / produced and washed (EFT) fast
Demand.
Chapter 5 -surge demand
Chapter 6 -Resistance demand caused in field of wireless frequency.
Chapter 8 -Magnetic field demand of electric frequency.
Chapter 11 –Shortly cut off the demand of making a variation with the
voltage transiently under the voltage.
EN 55022:1998/(CISPR 22:1997) ,Class B, ' “To assess information scientific
and
technological apparatus wireless restriction and way of interfering with the
characteristic.”
CE Caution Note (European Union)
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
FCC Consistent Declaration (U.S.A. Only)
12
Administrative Regulations on the Low Power Radio Waves Radiated Devices
Article 12
Without permission granted by the DGT, any company, enterprise, or user is not
allowed to change frequency, enhance transmitting power or alter original
characteristic as well as performance to a approved low power radio-frequency
devices.
Article 14
The low power radio-frequency devices shall not influence aircraft security and
interfere legal communications; If found, the user shall cease operating
immediately until no interference is achieved.
The said legal communications means radio communications is operated in
compliance with the Telecommunications Act.
The low power radio-frequency devices must be susceptible with the interference
from legal communications or ISM radio wave radiated devices.
