Westar WSS55010 User manual

WSS5O1O
Version 2.1
Installation
Manual

Table of Contents
Section 1 - System Introduction
1.1 Specifications ....................................................................... 1
1.2 Additional Devices ............................................................... 2
1.2.1 Keypads ............................................................................... 2
1.2.2 WSS5108 Eight Zone Expander Module ............................. 2
1.2.3 WSS5132-RS Wireless Receiver Module ............................ 2
1.2.4 WSS5204 Power Supply Output Module ............................. 3
1.2.5 WSS5208 Eight Low Current Output Module ...................... 3
1.2.6 WSS5580 Module ................................................................. 3
1.2.7 WSS5928 Audio Interface Module ...................................... 3
1.2.8 WSS5400 Printer Module ..................................................... 3
1.2.9 LINKS 1000 Cellular Communicator .................................... 4
1.2.10 Cabinets ............................................................................... 4
1.2.11 Backplates ........................................................................... 4
1.3 Out of the Box ...................................................................... 4
Section 2 - Getting Started
2.1 Installation Steps .................................................................. 5
2.2 Terminal Descriptions .......................................................... 6
2.3 Keybus Operation and Wiring ............................................. 7
2.4 Current Ratings - Modules and Accessories ...................... 8
2.5 Assigning Zones to Zone Expanders .................................. 8
2.6 Keypad Assignment ............................................................. 9
2.6.1 How to Assign Keypads ...................................................... 9
2.7 Enable Supervision .............................................................. 9
2.8 Removing Modules ............................................................ 10
2.9 Zone Wiring ........................................................................ 10
2.9.1 Normally Closed (NC) Loops ............................................. 10
2.9.2 Single End Of Line (EOL) Resistors .................................. 11
2.9.3 Double End of Line (DEOL) Resistors ............................... 11
2.9.4 Fire Zone Wiring - 4 wire Smoke Detectors ....................... 11
2.9.5 Fire Zone Wiring - 2 wire Smoke Detectors ....................... 12
2.9.6 LINKS Supervisory ............................................................. 12
2.9.7 LINKS Answer .................................................................... 12
Section 3 - Keypad Commands
3.1 Access Codes .................................................................... 13
3.2 Arming ................................................................................ 13
3.2.1 Stay Arming ........................................................................ 13
3.2.2 Away Arming ...................................................................... 13
3.3 Disarming ........................................................................... 14
3.4 [ ] Commands .................................................................. 14
[] [1] Zone Bypass/Reactivate Stay/Away Zones .......... 14
[] [2] Trouble Display ...................................................... 14
[] [3] Alarm Memory ....................................................... 16
[] [5] Programming Access Codes ................................ 16
[] [6] User Functions ....................................................... 17
[] [7] Output Functions ................................................... 18
[] [8] Installer Programming ........................................... 18
[] [9] Arming Without Entry Delay .................................. 18
3.5 Function Keys .................................................................... 18
Section 4 - How to Program
4.1 How to Enter Installer Programming .................................. 19
4.2 Programming Decimal Data ............................................... 19
4.3 Programming HEX Data ..................................................... 19
4.4 Programming Toggle Option Sections ............................... 20
4.5 Viewing Programming ........................................................ 20
4.5.1 LED Keypad ....................................................................... 20
4.5.2 LCD Keypad ....................................................................... 20
i
Section 5 - Program Description
5.1 Zone Definitions ................................................................. 21
5.2 Zone Attributes ................................................................... 23
5.3 Communicator - Dialing ..................................................... 24
5.4 Communicator - Phone Numbers ...................................... 24
5.5 Communicator - Account Identifier Code/DLS Panel
ID Code .............................................................................. 24
5.6 Communicator - Reporting Formats .................................. 24
5.6.1 SIA (Level 1) ....................................................................... 24
5.6.2 Pager Format ...................................................................... 25
5.7 Communicator - Reporting Codes..................................... 25
5.7.1 Zone Alarm ......................................................................... 25
5.7.2 Zone Restoral ..................................................................... 25
5.7.3 Closings.............................................................................. 25
5.7.4 Openings ............................................................................ 25
5.7.5 Tampers .............................................................................. 26
5.7.6 Priority/Emergency ............................................................. 26
5.7.7 Maintenance ....................................................................... 26
5.7.8 Test Transmissions ............................................................. 27
5.7.9 Wireless Maintenance ........................................................ 27
5.7.10 Miscellaneous .................................................................... 27
5.7.11 Up and About Timer ........................................................... 27
5.8 Downloading ...................................................................... 27
5.9 PGM Outputs ...................................................................... 28
5.9.1 PGM Output Options.......................................................... 28
5.9.2 WSSFOB PGM Pulse Timer ............................................... 30
5.10 Telephone Line Monitor (TLM) ........................................... 30
5.11 Siren Supervision ............................................................... 30
5.12 Test Transmission ............................................................... 30
5.13 Fire, Auxiliary, Panic Keys ................................................. 31
5.14 Entry/Exit Delay Options .................................................... 31
5.15 Event Buffer ........................................................................ 31
5.15.1 Viewing the Event Buffer through the LCD Keypad .......... 31
5.15.2 Stored Events ..................................................................... 32
5.16 Swinger Shutdown ............................................................. 32
5.17 Transmission Delay ............................................................ 32
5.18 Keypad Backlighting.......................................................... 33
5.19 Arming/Disarming Options ................................................ 33
5.20 Bell Output Options ........................................................... 33
5.21 Keypad Lockout ................................................................. 33
5.22 Keypad Blanking ................................................................ 33
5.23 Loop Response .................................................................. 33
5.24 LINKS 1000 Cellular Communicator .................................. 33
5.24.1 Using the LINKS as a Backup Communicator .................. 34
5.25 Wireless Expansion ............................................................ 34
5.25.1 Supervision of Wireless Zones .......................................... 34
5.26 WSS5580 Module ............................................................... 34
5.27 On-Site Printer .................................................................... 35
5.28 Audio Interface Module ..................................................... 35
5.29 Default (Factory) ................................................................ 35
5.29.1 Factory Default Main Panel (Hardware) ............................ 35
5.29.2 Factory Default Main Panel (Software) and other
Modules .............................................................................. 35
5.30 Installer Lockout ................................................................. 36
5.31 Walk Test (Installer) ............................................................ 36
5.31.1 Buzzer Walk Test Mode ..................................................... 36
5.31.2 Bell/Buzzer Walk Test Mode .............................................. 36
5.31.3 To end the Installer Walk Test with no communications ... 36
5.31.4 To end the Installer Walk Test with communications ......... 36

ii
For the Record .............................................................................. 37
WSS5010 - Zone 1-32 Assignment ............................................. 38
Keypad Programming
[000] Keypad Assignment ............................................................. 39
Basic System Programming
Zone Definitions ............................................................................. 39
[001]-[003] Zone 1-24 Definitions ................................................. 39
[004] Zone 25-32 Definitions ......................................................... 40
[005] System times ........................................................................ 40
[006] Installer’s Code ..................................................................... 40
[007] Master Code ......................................................................... 40
[009]-[011] WSS5010 PGM Output Programming ........................ 40
[012] Keypad Lockout Options ..................................................... 41
[013]-[015] System Option Codes ................................................. 41
Advanced System Programming
Zone Attribute Defaults .................................................................. 42
Zone 1-32 Attributes ...................................................................... 42
[160] Maximum Dialing Attempts to Each Phone Number ........... 43
[161] Post Dial Wait for Handshake ............................................... 43
[162] Delay Between Dialing Attempts ......................................... 43
[170] Cross Zone Timer ................................................................. 43
[171] Up and About Timer ............................................................. 43
[172] WSSFOB PGM Pulse Timer .................................................. 43
Communicator Programming
[301] First Telephone Number ....................................................... 43
[302] Second Telephone Number .................................................. 43
[310] Account Identifier Code / DLS Panel ID Code .................... 43
[360] First Telephone Number Dialing Options ............................. 43
[361] First Telephone Number LINKS Backup Dialing Options .... 44
[365] Second Telephone Number Dialing Options ....................... 44
[370] Communication Variables..................................................... 44
[380] First Communicator Option Code ........................................ 44
[390] LINKS Preamble (Telephone Number) ................................. 44
Downloading Programming
[401] First Downloading Option Code ........................................... 45
[402] Downloading Computer’s Telephone Number ( 32 Digits) .. 45
[403] Downloading Access Code.................................................. 45
[404] Number of RIngs to Answer ................................................. 45
[405] Answering Machine Double-call Timer ................................ 45
[490] Initiate PC-LINK (Direct Connect Local Download) ............ 45
Module Programming
[801] RS232 Module (WSS5400) Programming ............................ 46
[804] WSS5132 Wireless Expansion Programming ...................... 46
Special Installer Functions
[902] Module Supervision Enable/Reset ....................................... 49
[903] View Module Supervision Field ............................................ 49
[904] Wireless Module Placement Test ......................................... 49
[980] Installer Buzzer Walk Test Mode Begin ............................... 49
[981] Installer Buzzer/Bell Walk Test Mode Begin ........................ 49
[982] Installer Walk Test Mode End (No Communications) .......... 49
[983] Installer Walk Test Mode End (Communications) ................ 49
[990] Installer Lockout Enable ....................................................... 49
[991] Installer Lockout Disable ...................................................... 49
[995] Restore WSS5580 Factory Default Programming ................ 49
[996] Restore WSS5132-RS Factory Default Programming .......... 49
[997] Restore WSS5400 Factory Default Programming ................ 49
[998] Restore WSS5928 Factory Default Programming ................ 49
[999] Restore Factory Default Programming ................................ 49
Programming LCD Keypads
How to Program the WSS5500 Keypad ......................................... 49
Appendix A - SIA Format ............................................................. 52
Appendix B - Pager Format ......................................................... 53
WSS5010 Control Panel Hookup Diagram................................. 54

1
System Introduction
S E C T I O N 1
1.1 Specifications
Control Panel Specifications
Flexible Zone Configuration:
• 8 Fully Programmable Zones
• 37 Access Codes: 32 User, 1 System Master, 2 Master and 2 Duress
• Expandable to 32 Zones
• Hardwired expansion available using the WSS5108 Eight Zone Expansion Module
• Wireless expansion available using the WSS5132-RS Wireless Zone Expansion Module (up to 32
wireless zones, 900MHz, True Spread Spectrum Technology, Fully Supervised)
• Normally Closed, Single EOL or Double EOL zone supervision
• 2-Wire Smoke Zone
• 27 Zone Types, 8 Programmable Zone Options
Audible Alarm Output:
• Supervised Bell Output (current limited at 3 amps), 12 VDC
• Steady or Pulsed Output
EEPROM Memory:
• Will not lose programming or system status on complete AC and Battery failure
Programmable Outputs:
• Up to 14 Programmable Voltage Outputs, 26 programmable options
• One High Current (300 mA) PGM output with 2 wire smoke detector capability on main panel
• Maximum Loop Current is 1.5 mA when the 2-wire smoke detector configuration is used
• One Low Current (50 mA) PGM output on main panel
• Eight Additional Low Current (50 mA) PGM outputs available using the WSS5208 module
• Four High Current (1 Amp) PGM outputs Available Using the WSS5204 module
• 1 WSS5204 Output Fully Supervised for Siren Output
Powerful 1 Amp Regulated Power Supply:
• 500 mA Auxiliary Supply, 12 VDC
• Positive Temperature Coefficient (PTC) components replace fuses
• Supervision for loss of AC Power, Low Battery
• Internal Clock Locked to AC Power Frequency
Power Requirements:
• Transformer = 16.5 VAC, 40VA • Battery = 12 volt 4 Ah minimum rechargeable sealed lead acid
Remote Keypad Specifications:
• 2 Different Keypads Available: • Connect up to 8 Keypads
- WSS5508 8 Zone LED Keypad • Four Wire (Quad) Connection to Keybus
- WSS5500 LCD Alphanumeric Keypad • Built in Piezoelectric Buzzer
Digital Communicator Specifications:
• Supports SIA Format • Event Initiated Personal Paging
• 2 Programmable Phone Numbers • 1 Account number
• Supports LINKS 1000 Cellular Communication • DTMF and Pulse Dialing
• DPDT Line Seizure • Anti-jam Feature
• Split Reporting of Selected Transmissions to Each Telephone Number
System Supervision Features
The WSS5010 continuously monitors a number of possible trouble conditions including:
• AC Power Failure • Trouble by Zone • Fire Trouble
• Telephone Line Trouble • Low Battery Condition • Bell Output Trouble
• Loss of Internal Clock • AUX Power Supply Fault • Tamper by Zone
• Failure to Communicate • Module Fault (Supervisory or Tamper)
False Alarm Prevention Features
• Audible Exit Delay • Audible Exit Fault • Urgency on Entry Delay
• Quick Exit • Swinger Shutdown • Recent Closing Transmission
• Communication Delay

S Y S T E M I N T R O D U C T I O N
2
Additional Features
• Keypad Activated Alarm Output and Communicator Test
• Keypad Lockout
• Audio Capability using the WSS5928 Audio Interface Module which allows local intercom and Central
Station 2-Way Listen in.
• All modules connect to the system via a four wire Keybus up to 1000’/330m from main panel
• Event Buffer can be printed using WSS5400 RS232 Serial Interface module
• Supports the WSS5580 Voice Prompt Module with Automation/Lighting Control
• 128 Event Buffer, Time and Date Stamped
• Upload/Download Capability
1.2 Additional Devices
1.2.1 Keypads
A maximum of eight (8) keypads can be connected to the control panel and can be any combination of
the following listed.
WSS5508 WSS5500
8 zone LED keypad with function keys LCD keypad with function keys
1.2.2 WSS5108 Eight Zone Expander Module
Eight zone expander module can be used to increase the number of zones on
the system. Up to 3 modules can be connected to increase the system zones to
a maximum of 32. (See WSS5108 Installation Instructions.)
1.2.3 WSS5132-RS Wireless Receiver Module
The WSS5132-RS Wireless Receiver module can be used to connect up to 32
wireless devices. All devices are spread spectrum, 900 MHz, fully supervised
and use standard ‘AAA’ or ‘AA’ alkaline batteries
(See Section 5.25 “Wireless
Expansion”). (See WSS5132-RS Installation Manual.)
Additional wireless devices are available:
WSSPIR WSSSMK WSSSLX WSSPNC WSSFOB
WSSPIR Wireless Motion Detector
The wireless Motion Detector can be used in conjunction with the WSS5132-RS Wireless Receiver to
include wireless space protection. The unit comes with four ‘AAA’ batteries .
WSSUTX/SLX Wireless Universal Transmitter
The wireless Universal Transmitter can be used in conjunction with the WSS5132-RS Wireless Receiver
module to add wireless door or window contacts. The Universal Transmitter comes with three ‘AAA’
batteries and has built-in contacts. The unit also provides terminals for connecting hardwire contacts
.
WSSSMK Wireless Smoke Detector
The wireless Smoke Detector can be used in conjunction with the WSS5132-RS Wireless Receiver to
include wireless fire (smoke) protection. The unit comes with six ‘AA’ batteries.
WSSPNC Wireless Panic Pendant
The wireless Panic Pendant can be used in conjunction with the WSS5132-RS Wireless Receiver to
include a mobile panic zone.
WSSFOB Wireless Key Fob
The wireless Key Fob can be used in conjunction with the WSS5132-RS Wireless Receiver as a portable unit
which can arm and disarm the system as well as activate PGM outputs and send emergency transmissions.
1.2.4 WSS5204 Power Supply Output Module

S Y S T E M I N T R O D U C T I O N
3
The WSS5204 can provide up to 1 Amp of additional power for modules or
devices connected to the control panel. The module requires a 16.5 volt AC 40
VA transformer and 4 AH battery. In addition, the module provides 4 program-
mable high current voltage outputs. Each output is individually programmable
with 26 different output options available
(See Section 5.9 “PGM Outputs”).
(See WSS5204 Installation Instructions.)
1.2.5 WSS5208 Eight Low Current Output Module
Adds eight low current outputs (50 mA) to the control. Each output is individu-
ally programmable with 26 different output options available (See Section 5.9
“PGM Outputs”). (See WSS5208 Installation Instructions.)
1.2.6 WSS5580 Module This WSS5580 module will turn any touch tone phone into a fully functional
keypad. The module also includes a built-in interface to control up to 32 line
carrier type devices for lighting and temperature control
(See Section 5.26
“WSS5580 Module”). For more information, see the WSS5580 Installation Manual.
1.2.7 WSS5928 Audio Interface Module (This device is not UL Listed)
The WSS5928 Audio Interface module is a simple way to incorporate paging,
intercom, baby listen-in and door answer to the WSS5010 control panel. The
module also has talking and listening-in capability for the central station
(See
Section 5.28 “Audio Interface Module”).
Four additional devices are available:
WSS5923 WSS5923 EXT WSS5923 EXT/R WSS5904
WSS5923 Intercom Audio Station
(This device is not UL Listed)
The WSS5923 Intercom Audio Station can be used in conjunction with the WSS5928 Audio Interface Module .
WSS5923 EXT Door Box Audio Station (This device is not UL Listed)
The WSS5923 EXT Door Box Audio Station can be used in conjunction with the WSS5928 Audio Interface
Module .
WSS5923 EXT/R Door Box Audio Station (This device is not UL Listed)
The WSS5923 EXT/R Door Box Audio Station can be used in conjunction with the WSS5928 Audio
Interface Module. The Door Box contains a relay so the normal door bell can be used instead of the
internal one generated by the WSS5928 module.
WSS5904 Central Station Talk / Listen Module (This device is not UL Listed)
The WSS5904 Central Station Talk / Listen module can be used in conjunction with the WSS5928 Audio
Interface Module
.
1.2.8 WSS5400 Printer ModuleThis WSS5400 Printer Module will allow the panel to print out all events that
occur on the system to any serial printer. All events will be printed with the time,
date and the event that occurred
(See Section 5.27 “On-site Printer”).
1.2.9 LINKS 1000 Cellular Communicator (This device is not UL Listed)

S Y S T E M I N T R O D U C T I O N
4
The LINKS 1000 Cellular Communicator provides an efficient, cost-effective
method for adding cellular back up. The unit comes in its own cabinet with
antenna and requires a separate battery and transformer
(See Section 5.24
“LINKS 1000 cellular communicator”).
1.2.10 Cabinets
Several different cabinets are available for the WSS5010 modules:
WSS5002C Cabinet
Cabinet to house the WSS5010 main control panel and also the WSS5204 Power Supply Output Module.
Dimensions 213mm x 235mm x 78mm / 8.4” x 9.25” x 3” approximately.
WSS5004C Cabinet
Cabinet to house the WSS5580 Module and WSS5400 Printer Module. Dimensions 229mm x 178mm x
65mm / 9” x 7” x 2.6” approximately.
WSS5001C Cabinet
Cabinet to house the WSS5108 Zone Expander Module and the WSS5208 Eight Low Current Output
Module. Dimensions 153mm x 122mm x 38mm / 6” x 4.8” x 1.5” approximately.
WSS5001CP Cabinet
Plastic cabinet to house the WSS5108 Zone Expander Module, WSS5132-RS Wireless Receiver Module
and the WSS5208 Eight Low Current Output Module. Dimensions 146mm x 105mm x 25.5mm / 5.75” x
4.2” x 1” approximately.
WSS5132C Cabinet
Cabinet to house the WSS5132-RS Wireless Receiver Module. Dimensions 165mm x 143mm x 38mm /
6.5” x 5.625” x 1.5” approximately.
CMC-1 Attack Resistant Enclosure
Listed enclosure for local installations where attack resistance is required. Dimensions 288mm x 298mm
x 78mm / 11.3” x 11.7” x 3” approximately.
1.2.11 Backplates
There are two different backplates available for keypads to locate an Audio Station next to the keypad:
WSS55BP1 Backplate This backplate is to be used when an Audio Station is to be located next to
a keypad. Dimensions 208mm x 115mm x 18mm / 8.2” x 4.5” x 0.25”
approximately.
WSS55BP2 Backplate This backplate is to be used when an Audio Station is to be located next
to a keypad. In addition the backplate will allow you to mount a WSS5108
Zone Expander Module or the WSS5208 Eight Low Current Output
Module. Dimensions 208mm x 115mm x 18mm / 8.2” x 4.5” x 0.7”
approximately.
1.3 Out of the Box
You should find the following equipment included in your system. Verify each of the components is included:
• one WSS5010 main control cabinet (WSS5002C)
• one WSS5010 main control circuit board
• one Installation Manual
• one hardware pack consisting of:
- 5 plastic circuit board standoffs - 16 5600 ohm (5.6K) resistors
- 1 2200 ohm (2.2K) resistor - 1 1000 ohm (1K) resistor
- 16V 40VA transformer - ULF siren
- RJ-31X telephone block and cord - Battery, 12V, 4 Ah
Note: In order to complete the installation, a keypad(s) must also be used.

Getting Started
S E C T I O N 2
5
The following sections provide a complete description of how to wire and configure devices and zones.
2.1 Installation Steps
The following steps are provided to assist with the installation of the panel. It is suggested that you read
over this section briefly to get an overall understanding of the order of installation. Once this is done
carefully work through each step. Working from this plan will help reduce problems and reduce the
overall installation time required.
Step 1 Create a Layout
Draw a rough sketch of the building and include all alarm detection devices, zone expanders, keypads
and all other modules that are required.
Step 2 Mounting the Panel
Locate the panel in a dry area, preferably located near an unswitched AC power source and the incoming
telephone line.
Before attaching the cabinet to the wall be sure to press the five circuit board
mounting studs into the cabinet from the back.
Complete all wiring before applying AC or connecting the battery
.....
Step 3 Wiring the Keybus
(Section 2.3)
Wire the Keybus to each of the modules following the guidelines provided.
Step 4 Assigning Zones to Zone Expanders
(Section 2.5)
If zone expander modules are being used the modules must be configured so the panel knows which
zones are assigned to each expander. Follow the guideline provided to assign zones to expanders.
Step 5 Zone Wiring (Section 2.9)
Power down the control panel and complete all zone wiring. Follow the guidelines provided in Section 2.9
to connect zones using normally closed loops, single EOL resistor, double EOL resistors, Fire zones and
Keyswitch Arming zones.
Step 6 Completing Wiring
Complete all other wiring including bells or sirens, phone line connections, ground connections or any
other wiring necessary. Follow the guidelines provided in Section 2.2 “Terminal Descriptions”.
Step 7 Power up the Control
Once all zone wiring and Keybus wiring is complete, power up the control panel.
The panel will not power up if only the battery is connected.
Step 8 Keypad Assignment (Section 2.6)
Keypads must be assigned to different slots to be properly supervised. Follow the guideline provided in
Section 2.6 to assign keypads.
Step 9 Enabling Supervision (Section 2.7)
After all modules have been wired to the Keybus, supervision must be enabled. Once supervision is
enabled, the panel will be able to indicate module communication faults. Follow the guidelines provided
in Section 2.7.
Step 10 Programming the System (Sections 4 and 5)
Section 4.0 provides a complete description of how to program the panel. Section 5.0 contains complete
descriptions of the various programmable features, what options are available and how the options function.
The Programming Work Sheets should be filled out completely before attempting to program the system.
Step 11 Testing the System
Test the panel completely to ensure that all features and functions are operating as programmed.

G E T T I N G S T A R T E D
6
2.2 Terminal Descriptions
AC Terminals - AC
The panel requires a 16.5 volt, 40 VA transformer. Connect the transformer to an unswitched AC source
and connect the transformer to these terminals.
Do not connect the transformer until all other wiring is complete
.....
Battery Connection
The battery is used to provide back up power in the event of an AC power failure and to provide
additional current when the panel demands exceed the power output of the transformer, such as when
the panel is in alarm.
Do not connect the battery until all other wiring is complete .
Connect the RED battery lead to the positive of the battery, the BLACK battery lead to the negative.
Auxiliary Power Terminals - AUX+ and GND
These terminals provide up to 500 mA of additional current at 12 VDC
(rated 11.6 - 12.6 V DC for UL residential
applications)
for devices requiring power. Connect the positive side of any device requiring power to the
AUX+ terminal, the negative side to GND. The AUX output is protected; if too much current is drawn from
these terminals (wiring short) the panel will temporarily shut off the output, until the problem is corrected.
Bell Output Terminals - BELL+ and BELL-
These terminals provide up to 3 Amps of current at 12 VDC (rated 11.6 - 12.6 V DC for UL residential
applications)
(with stand-by battery; 700 mA continuous) for powering bells, sirens, strobes or other
warning type equipment. Connect the positive side of any alarm warning device to BELL+, the negative
side to BELL–. The BELL output is protected; if too much current is drawn from these terminals (wiring
short) the BELL fuse will open.
The Bell output is supervised. If no alarm warning device is being used connect a 1000 ohm resistor
across BELL+ and BELL– to prevent the panel from displaying a trouble condition
(See Section 3.4 “[ ]
Commands, [ ] [2]”).
If an alarm warning device is being used, connect the 1000 ohm resistor at the end
of the line across the last device.
Keybus Terminals - RED, BLK, YEL, GRN
The Keybus is used by the panel to communicate with modules and by modules to communicate with the
panel. Each module has four Keybus terminals that must be connected to the four Keybus terminals on
the panel. For more information,
see Section 2.3 “Keybus Operation and Wiring”.
Programmable Outputs - PGM1 and PGM2
Each PGM output is an open collector switch to ground. That is, when the PGM output is activated by the
panel the terminal will switch to ground.
PGM1 can sink up to 50 mA of current to activate LEDs or a small buzzer. Connect the positive side of the
LED or buzzer to AUX+, the negative side to PGM1. If more than 50 mA of current is required a relay must
be used. Refer to the following diagram:
PGM2 operates similar to PGM1.
Zone Input Terminals - Z1 to Z8
Each detection device must be connected to a zone on the control. It is suggested that each zone have
one detection device however it is possible to wire multiple detection devices to the same zone.
For zone wiring specifics,
see Section 2.9 “Zone Wiring” .

G E T T I N G S T A R T E D
7
Telephone Connection Terminals - TIP, RING, T-1, R-1
If a telephone line is required for central station communication or downloading connect an RJ-31X jack in
the following manner:
• RING - Red Wire ........ Incoming line from • R-1 - Grey Wire .......... Outgoing line to
• TIP - Green Wire telephone company • T-1 - Brown Wire house telephone(s)
Ensure the plugs and jacks meet the dimension, tolerance and metallic plating requirements
of 47 C.F.R. Part 68, SubPart F
.....
For proper operation there must be no other telephone equipment connected between the
control panel and the telephone company facilities
.....
2.3 Keybus Operation and Wiring
The Keybus is used by the panel to communicate with all modules connected and by the modules to talk to
the panel. The RED and BLK terminals are used to provide power while YEL and GRN are clock and data.
The 4 Keybus terminals of the panel must be connected to the 4 Keybus terminals or wires of
all modules.
The following conditions apply:
• Keybus should be run in minimum 22 gauge quad (0.5mm), two pair twist preferred
• the modules can be home run to the panel, connected in series or can be T-tapped
• any module can be connected anywhere along the Keybus, you do not need a separate Keybus wire
run for keypads, zone expanders etc.
• no module can be more than 1,000'/330m (in wire length) from the panel
• shielded wire is not necessary unless wires are run in an area that may present excessive RF noise or
interference
Example of Keybus Wiring
B
C
A
PANEL 500’
500’
150’
150’
B
C
A
PANEL 500’
500’
150’
150’
NOTE: Module (A) is wired correctly as it is within 1,000'/330m of the panel, in wire distance.
Module (B) is wired correctly as it is within 1,000'/330m of the panel, in wire distance
Module (C) is NOT wired correctly as it is further than 1,000'/330m from the panel, in wire distance.

G E T T I N G S T A R T E D
8
2.4 Current Ratings - Modules and Accessories
In order for the WSS5010 system to operate properly, the power output capabilities of the main control
and expansion devices must not be exceeded. Use the data presented below to ensure that no part of
the system is overloaded and cannot function properly.
System Outputs (all 12 VDC)
• WSS5010
+AUX: 500 mA. Includes one keypad. Subtract for each additional keypad, expansion module and
accessory connected to VAUX or Keybus.
BELL: 700 mA. Continuous Rating.
3.0 A. Short Term. Available only with stand-by battery connected.
• WSS5204
VAUX: 1.0 A. Continuous Rating. Subtract for each device connected.
3.0 A. Short Term. Available only with stand-by battery connected.
• WSS5208
VAUX: 250 mA. Subtract for each device connected. Subtract the total load on this terminal from the
WSS5010 VAUX/Keybus output.
• WSS5108
VAUX: 100 mA. Subtract for each device connected. Subtract the total load on this terminal from the
WSS5010 VAUX/Keybus output.
WSS5010 Device Ratings (@ 12 VDC)
• WSS5500 LCD Keypad: 50 mA; 100mA max. • WSS5580 Module: 150 mA
• WSS5508 LED Keypad: 45 mA; 70mA max. • WSS5928 Audio Interface Module: 65 mA
• WSS5108 Zone Module: 35 mA • WSS5923 Intercom Audio Station: 20 mA
• WSS5204 Output Module: 20 mA • WSS5923 EXT Door Box Audio Station: 20 mA
• WSS5208 Output Module: 50 mA • WSS5923 EXT/R Door Box Audio Station: 35 mA
• WSS5132-RS Wireless Module: 125 mA • WSS5400 Serial Printer Module: 62 mA
Other Devices
Read the manufacturer’s literature carefully to determine the maximum current requirement (during
activation or alarm) and use this value for loading calculations. Do not allow connected devices to exceed
the system capabilities during any possible operational mode.
2.5 Assigning Zones to Zone Expanders
The main panel contains zones 1 to 8. Additional zone expanders may be added to increase the number
of zones on the system. Each zone expander consists of two groups of 4 zones and each group must be
configured to assign the specific zones to the expander. This is done by setting the jumpers located on
the expander to the proper settings.
Before a zone expander will work properly the jumpers must be set so the panel can deter-
mine the correct zone assignment
.....
The following are the jumper settings for different zone assignments:
Expander Zones Jumpers System Zones Assigned
Group A (Zones 1-4) J1 J2 J3
Group B (Zones 5-8) J4 J5 J6
ON ON ON Zones Disabled
OFF ON ON Zones Disabled
ON OFF ON Zones 9 - 12
OFF OFF ON Zones 13 - 16
ON ON OFF Zones 17 - 20
OFF ON OFF Zones 21 - 24
ON OFF OFF Zones 25 - 28
OFF OFF OFF Zones 29 - 32
The following is a diagram of the zone expander and where the jumper switches are located.
There are two sets of jumpers, one set for the first 4 zones of the expander and one set for
the other 4 zones
.....

G E T T I N G S T A R T E D
9
In the above diagram the jumpers settings shown indicate the first group of four zones of the expander
will be zones 9 to 12 and the second group of 4 zones will be 13 to 16.
A group of zones can be disabled if they are not required for the installation.
If a tamper switch is not incorporated, theTAM terminal should be connected to BLK.
2.6 Keypad Assignment
There are 8 available slots for keypads. WSS5508 keypads by default are always assigned to slot 1 while
the WSS5500 is always assigned to slot 8. Keypads can each be assigned to a different slot (1 to 8)
which offers two advantages. The panel can supervise the keypad connection to indicate a trouble
condition if it is removed.
2.6.1 How to Assign Keypads
All keypad assignment must be done individually on each keypad on the system
.....
To assign a keypad to a slot, enter the following:
Step 1 — Press [ ] [8] [Installer Code] to enter Installer Programming.
Step 2 — Press [000] for Keypad Programming
Step 3 — Press [0] for Slot Assignment
Enter a two digit number to specify the system and slot assignment.
1st digit Enter 1
2nd digit Enter 1 to 8 for Slot Assignment
Press the [#] key twice to exit programming. Continue this procedure at each keypad until all have been
assigned to the correct slot.
Multiple LCD keypads must not occupy the same supervisory slot. At least one LCD keypad
must occupy slot 8 for downloading purposes. Do not assign more than one LCD keypad to
slot 8.
2.7 Enable Supervision
Once all the Keybus connections have been made, supervision must be enabled so the panel can
indicate a trouble if a module is removed from the system.
To enable supervision, enter the following at any keypad:
Step 1 - Press [ ] [8] [Installer Code] to enter Installer Programming.
Step 2 - Press [902] to enable supervision. The panel will automatically search for all modules on the
system. Once the search (it will take about 1 minute) is complete enter the following to confirm
the modules on the system.
Step 3 - Press [903] to display all modules.

G E T T I N G S T A R T E D
10
Zone lights will be turned on according to what modules the panel has found on the system. The LCD
keypad will allow you to scroll through the modules. Refer to the following chart:
Light [1] ....... Keypad 1 present Light [13] ....... Zones 25 to 28 present
Light [2] ....... Keypad 2 present Light [14] ....... Zones 29 to 32 present
Light [3] ....... Keypad 3 present Light [15] ....... N/A (not used)
Light [4] ....... Keypad 4 present Light [16] ....... N/A (not used)
Light [5] ....... Keypad 5 present Light [17] ....... Module WSS5132-RS present
Light [6] ....... Keypad 6 present Light [18] ....... Module WSS5208 present
Light [7] ....... Keypad 7 present Light [19] ....... Module WSS5204 present
Light [8] ....... Keypad 8 present Light [20] ....... Module WSS5400 present
Light [9] ....... Zones 9 to 12 present Light [21] ....... Module WSS5928 present
Light [10] ....... Zones 13 to 16 present Light [22] ....... N/A
Light [11] ....... Zones 17 to 20 present Light [23] ....... N/A
Light [12] ....... Zones 21 to 24 present Light [24] ....... WSS5580 module present
If a module is connected but does not show as being present, it may be due to any of the following
reasons:
• it is not connected to the Keybus
• if there is a Keybus wiring problem
• if the module is more than 1,000'/330m from the panel
• if the module does not have enough power
• if the WSS5132-RS does not have any devices added
2.8 Removing Modules
If a module is no longer required on the system the panel must be told to no longer supervise the module. To
do this remove the module from the Keybus and perform the Enable supervision function again (
See Section
2.7 “Enable Supervision”). The panel will see the module has been removed and will no longer supervise it.
2.9 Zone Wiring
There are several different ways in which zones may be wired, depending on the programming options
selected.
Any zone defined as Fire, 24 Hour Links Supervisory and Links Answer (See Section 5.1
“Zone Definitions”) will automatically require a single End of Line (EOL) resistor regardless
of which type of zone wiring supervision is selected
.
When reconfiguring the zone supervision from a non-default setting, such as DEOL to EOL/
NC to DEOL/disabling zones 1-8 while open or in trouble, the system should be powered
down completely and powered up again.
2.9.1 Normally Closed (NC) Loops
Wire all zones according to the following diagrams:
2 NORMALLY CLOSED
CONTACTS WITH
NO END OF LINE
RESISTOR
ANY Z
TERMINAL ANY COM
TERMINAL
NORMALLY CLOSED
CONTACT;
NO END OF LINE
RESISTOR
ANY Z
TERMINAL ANY COM
TERMINAL
This option can only be selected if Normally Closed (NC) detection devices or contacts are
being used .

G E T T I N G S T A R T E D
11
2.9.2 Single End Of Line (EOL) Resistors
Wire all zones according to the following diagrams:
NORMALLY CLOSED
CONTACT WITH
5600 ΩEND OF LINE
RESISTOR
ANY Z
TERMINAL ANY COM
TERMINAL
NORMALLY OPEN
CONTACTS WITH
5600 ΩEND OF LINE
RESISTOR
ANY Z
TERMINAL ANY COM
TERMINAL
ANY Z
TERMINAL ANY COM
TERMINAL
2 NORMALLY OPEN
CONTACT AND
2 NORMALLY CLOSED
CONTACT WITH
5600 ΩEND OF LINE
RESISTOR
1 NORMALLY OPEN
CONTACT AND
1 NORMALLY CLOSED
CONTACT WITH
5600 ΩEND OF LINE
RESISTOR
ANY Z
TERMINALANY COM
TERMINAL
This option can be selected if either Normally Closed (NC) or Normally Open (NO) detection
devices or contacts are being used .
2.9.3 Double End of Line (DEOL) Resistors
Double EOL loops allow the panel to determine if the zone is in alarm, tampered or faulted. Wire the zones
according to the following diagram:
ANY Z
TERMINAL ANY COM
TERMINAL
ALARM
CONTACT
DOUBLE EOL CIRCUIT
1 NORMALLY CLOSED
CONTACT WITH
5600ΩEND OF LINE
RESISTORS
This option can be selected only if Normally Closed (NC) detection devices or contacts are
being used
.
Only one NC contact can be connected to each zone.The connection of multiple detection
devices or contacts on one loop is not allowed .
The following chart shows the status of the zone under certain conditions:
Loop Resistance ................................... Loop Status
5600Ω(contact closed) ........................ Secure
11200Ω(contact open) ........................ Violated
0Ω(shorted wire, loop shorted) ........... Fault
Infinite (broken wire, loop open)........... Tamper
2.9.4 Fire Zone Wiring - 4 wire Smoke Detectors
All zones defined as Fire
(See Section 5.1 “Zone Definitions”) must be wired according to the following
diagram:
For a complete description of how fire zones operate, see Section 5.1 “Zone Definitions”.

G E T T I N G S T A R T E D
12
2.9.5 Fire Zone Wiring - 2 wire Smoke Detectors
If PGM2 has been programmed for 2 Wire Smoke Detector connection (See Section 5.9 “PGM Output”),
the detectors must be wired according to the following diagram:
+
Ω
+
-
For a complete description of how fire zones operate, see Section 5.1 “Zone Definitions”.
If PGM2 is programmed for 2 wire smoke support, Jumper J1 on the main board must be removed.
2.9.6 LINKS Supervisory (Shall not be used on UL certificated systems)
If the LINKS 1000 cellular communicator is being used a zone may be configured for LINKS Supervisory
(See Section 5.1 “Zone Definitions”) . If the LINKS 1000 experiences a trouble it will violate the zone,
causing the panel to report the event to central station.
The zone programmed as LINKS Supervisory ALWAYS requires a single EOL resistor (5.6K) and must be
wired according to the following diagram:
2.9.7 LINKS Answer (Shall not be used on UL certificated systems)
If the LINKS 1000 cellular communicator is being used a zone may be configured for LINKS Answer to
allow downloading to be performed in the event of phone line failure.
When the LINKS receives a phone call it will activate the RING terminal on the LINKS circuit board. This
terminal can be used to violate a zone programmed as LINKS Answer
(See Section 5.1 “Zone
Definitions”)
, causing the panel to seize the phone line and begin communication with the downloading
computer.
The zone programmed as LINKS Answer ALWAYS requires a single EOL resistor (5.6K) and must be
wired according to the following diagram:
Do not make this connection without direction from WestarTechnical Support.

Keypad Commands
S E C T I O N 3
13
All keypads provide complete information and control of the alarm panel. The panel can be completely programmed
via any keypad on the system. LED keypads provide function indicator lights and individual zone indicator lights for
the alarm circuits. The LCD keypad provides function indicator lights and word descriptions for zone status.
The following sections describe how to arm, disarm and perform other keypad functions.
3.1 Access Codes
The panel has a total of 37 Access Codes available.
Access Codes [01] to [32] .. User Codes 1 to 32
Access Code [33] .............. Duress Code
Access Code [34] .............. Duress Code
Access Code [40].............. System Master Code
Access Code [41] .............. Master Code
Access Code [42] .............. Master Code
System Master Code
The System Master Code Not ChangeableSystem Master Code Not Changeable
System Master Code Not ChangeableSystem Master Code Not Changeable
System Master Code Not Changeable option can be used to lock in the code. This will prevent the
user from being able to change the System Master Code. If they attempt to change the code the keypad
will sound a long error beep. The System Master Code can be used to arm or disarm the system and
perform any keypad function.
If the code is lost it can be reprogrammed through Installer Programming.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
System Master Code Not Changeable ......... Section [015], Option [4]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
System Master Code..................................... Section [007]
Master Codes
By default the Master Codes are not programmed. They must be programmed by the System Master Code.
Once programmed, a Master Code can perform the same basic system functions as the System Master
Code. In addition, it can be used to program the 32 User Codes and 2 Duress Codes on the system.
Duress Codes
By default Duress Codes are not programmed. They must be programmed by the System Master Code or
Master Code. Once programmed if the Duress Code is used, the panel will activate a silent Duress alarm
(See Section 5.7 “Communicator - Reporting Codes”) .
User Codes
By default the 32 User Codes are not programmed. They must be programmed by the System Master
Code or Master Code. Once programmed the User Code can be used to arm or disarm the system. In
addition, each User Code can be enabled or disabled for bypass ability (See Section 3.4 “[ ]
Commands, [ ] [1] Zone Bypass”)
and for accessing the system by the WSS5580.
3.2 Arming
The system cannot be armed unless the ‘Ready’ light is on. If the ‘Ready’ light is not on make sure all
protected doors and windows are secure and stop movement in areas covered by motion detectors.
If the ‘Ready’ light is on, press the ‘Stay’ or ‘Away’ key for 2 seconds.
The Arming Keys Require Access Code option can be used so that an access code is needed after
using the STAY/AWAY arming keys. This would be used in conjunction with Closings Enabled in the
Dialing Options..
..
.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Arming Keys Require Access Code.............. Section [015], Option [3]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Closings Enabled .......................................... Section [360], Option [6]
3.2.1 Stay Arming
The system will be armed with all interior Stay/Away type zones Bypassed so that users can remain in the
premises while armed. The perimeter zones will be armed.
3.2.2 Away Arming
The system will be armed with all interior Stay/Away type zones Active. If motion is detected on the Stay/
Away type zones, the alarm sequence will begin.

K E Y P A D C O M M A N D S
14
3.3 Disarming
To disarm the panel enter the premises through the designated entry/exit door. The keypad will emit a
steady beep to warn that you must disarm the system. During the last 10 seconds of entry delay the panel
will pulse the keypad beeper on and off rapidly to warn the entry delay is about to expire. Enter a valid
Access Code at the keypad. If an error is made press the Clear function key or the [#] key, then enter the
code again. When a correct code is entered the keypad will turn off the ‘Armed’ light and stop the keypad
buzzer. If an alarm occurred while the panel was armed the ‘Memory’ light and the zones which caused
the alarm will be flashing. Press the [#] key to return the keypad to the Ready state.
3.4 [ ] Commands
[] [1] Zone Bypass/Reactivate Stay/Away Zones
The [ ] [1] keypad command can be used to bypass individual zones. It can be used if the user wants to
have access to an area while the system is armed or to bypass a defective zone (bad contact, damaged
wiring) until service can be provided.
The system can be armed with a bypassed zone. A bypassed zone will not cause an alarm.
Bypass Status Displayed will indicate on the keypads, while armed, that there are zones that have been
manually bypassed on the system.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Bypass Status Displayed………………………..Section [015] Option [8]
Code Required for Bypass
(required for UL Listed systems) is enabled therefore an access code will
be required to enter the Bypass mode. Only user codes with the Bypass attribute enabled will be able to
bypass zones
(See Section 3.4 “[ ] Commands, [ ] [5]“) .
Zones can only be bypassed when the system is disarmed.
To bypass a zone:
1. Enter [ ] [1] [Access Code]
2. The keypad will flash the ‘Bypass’ light and turn on the zone lights for any zones already bypassed.
3. Enter the 2 digit zone number to bypass the zone.
4. The keypad will turn on the zone light.
5. Press [#].
All zones that were lit when the [#] key was pressed are now bypassed. The ‘Bypass’ light will be on
steady to indicate zones are bypassed.
To un-bypass a zone:
1. Enter [ ] [1] [Access Code].
2. The keypad will flash the ‘Bypass’ light and turn on the zone lights for any zones already bypassed.
3. Enter the 2 digit zone number to un-bypass the zone.
4. The keypad will turn off the zone light.
5. Press [#].
All zones that were lit when the [#] key was pressed are now bypassed. If no zones were lit, the ‘Bypass’
light will be off and no zones will be bypassed.
When the system is disarmed all manually bypassed zones will be un-bypassed.
Reactivate Interior
If the system is armed in the Stay mode (See Section 3.2 “Arming”), the [ ] [1] command can be used to
reactivate the Stay/Away zones.
[][2] Trouble Display
The panel constantly monitors itself for several different trouble conditions. If a trouble condition is
present the ‘Trouble’ light will be on steady and all keypads will beep twice every 10 seconds.
Bell Squawk on Trouble will sound the bell twice every 10 seconds in conjunction with the keypad
buzzer, and will be silenced when a key is pressed on the keypad.
The trouble beep can be silenced by pressing any key on any keypad.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Bell Squawk on Trouble ................................. Section [014], Option [2]

K E Y P A D C O M M A N D S
15
To view trouble conditions:
1. Press [ ] [2].
2. The keypad will flash the ‘Trouble’ light and light zones to indicate which trouble conditions are
present.
A description of the various troubles are as follows:
Trouble [1] - Service Required
This light will be on if any of the following trouble conditions are detected by the control panel; Low
Battery, Bell Circuit Trouble, General System Trouble, General System Tamper, General System
Supervisory, WSS5204 Low Battery and WSS5204 AC Failure.
If a ‘Service Required’ trouble is present press [1] to determine the specific trouble present. The following
is a list of the specific ‘Service Required’ trouble conditions:
• Light [1] - Low Battery
The main panel backup battery is low. The trouble will be generated if the battery drops below 11.5
volts under load and will restore when the battery charges over 12.5 volts.
• Light [2] - Bell Circuit Trouble
The panel will indicate this trouble if the Bell fuse is blown or the panel senses an open condition on the
bell circuit
(See Section 5.11 “Siren Supervision”) .
• Light [3] - General System Trouble
This trouble will be present if the WSS5204 Power Supply module has an AUX failure, WSS5204 Output
#1 Trouble, or a printer connected to the WSS5400 Printer module has a fault (off-line).
• Light [4] - General System Tamper
This trouble will be indicated if a Tamper Zone violation on any module is detected.
• Light [5] - General System Supervisory
This trouble will be indicated if the panel loses communication with any module connected to the Keybus
(See Section 2.7 “Enable Supervision”) . The event buffer will log a detailed description of the event.
A Keybus fault will also cause this trouble to be displayed. A Keybus fault will occur if one of the data lines
(yellow or green wire) is shorted to ground.
• Light [6] - Not Used
• Light [7] - WSS5204 Low Battery
The WSS5204 module has a low backup battery.
• Light [8] - WSS5204 AC Failure
The WSS5204 module has lost AC power.
Trouble [2] - AC Failure
This trouble indicates that AC power is no longer being supplied to the control unit. If it is required to
communicate this to a monitoring station, enable Maintenance Alarms and Maintenance Restorals in
Section [360] options [7] and [8] respectively. To inhibit reporting of short duration power outages, a
delay can be programmed in section [370].
Trouble [3] - Telephone Line Trouble
The telephone connection to the control unit is continuously monitored. If there is a problem with the
telephone connection, a trouble will be indicated after the delay programmed in section [370]. If the
system has a LINKS 1000, this trouble can be reported to a monitoring station by enabling Maintenance
Alarms and Maintenance Restorals in Section [361] options [7] and [8] respectively.
Trouble [4] - Failure to Communicate (FTC)
If the communicator fails in an attempt to communicate with any of the programmed telephone numbers,
this trouble will be generated. If a later attempt is successful, the FTC reporting code, enabled by
Maintenance Restorals in Section [360] options [8], will be transmitted along with any other unreported
events that occurred while the panel was not able to communicate.
Trouble [5] - Zone Fault (including Fire Zone)
This trouble will be indicated if any zone on the system is in a trouble condition, i.e. it could not provide an
alarm to the panel if required to do so. When a trouble condition occurs, the keypad(s) will start to beep.
Press [5], while in Trouble mode, to view which zones have a trouble condition. If 2-wire smoke detectors
are being used, a trouble on that zone will be indicated by the “Fire” LED.
Trouble [6] - Zone Tamper
This trouble is only generated by zones configured for Double End-of-Line Resistor Supervision or
wireless zones. This trouble is generated when a tamper condition is present. When a tamper condition
occurs, the keypad(s) will start to beep.
Press [6], while in Trouble mode, to view which zones have a tamper condition.

K E Y P A D C O M M A N D S
16
Trouble [7] - Zone Low Battery
This trouble is generated when an RF device reports a low battery condition to the control unit. Press [7]
while in Trouble mode to view which RF zones have a low battery. Press [7] to view which One Way
keypad has a low battery and press [7] again to view which wireless key has a low battery.
Trouble [8] - Loss of System Time
This trouble occurs when the control unit is powered up and the internal clock has not been set. Setting
the time with User Function [ ] [6] [Master Code] [1] will clear this trouble.
[] [3] Alarm Memory
The ‘Memory’ light will be on if any alarm occurred during the last armed period or if an alarm occurred
while the panel was disarmed (24 hour zones).
To view alarm memory:
1.Press [ ] [3].
2.The keypad will flash the Memory light and light up zone lights to indicate alarm or tamper conditions
that occurred during or since the last armed period.
When the panel is armed the ‘Memory’ light will go out.
If the alarm memory is cleared, the events can be viewed in the event buffer.
[] [5] Programming Access Codes
There are 37 Access Codes available. They are as follows:
Access Code [01] to [32] . User Codes 1 to 32
Access Code [33] ............. Duress Code
Access Code [34] ............. Duress Code
Access Code [40] ............. System Master Code
Access Code [41] ............. Master Code
Access Code [42] ............. Master Code
All Access Codes have the ability to arm/disarm the system and activate the PGM Outputs using the[ ]
[7] [1] [Access Code] and [ ] [7] [2] commands
(See Section 3.4 “[ ] Commands, [ ] [7]”) .
Additional Access Code Attributes are also programmable. Attributes determine what abilities the code
will have. The programmable attributes are as follows:
• Pager Communications • Zone Bypassing
• Day Zone Reset • Phone Access on WSS5580
User Codes - Access Codes [01] to [32]
Each User Code can be programmed to have the ability to bypass zones and access the system through
the WSS5580.
“Master code” attributes cannot change. By default, each code has the attributes of the code
used to program it.
Duress Codes - Access Codes [33] and [34]
When a Duress Code is used to perform any function the panel will report a Duress Reporting Code (See
Section 5.7 “Communicator - Reporting Codes”)
.
Master Codes - Access Codes [41] and [42]
Master Codes can program additional User Codes and the Duress Codes.
System Master Code - Access Code [40]
By default the System Master Code is enabled to perform any keypad function. This code can be used to
program all User Codes as well as the Master Codes and Duress Codes.
If the Master Code Not Changeable option is enabled the System Master Code can only be changed
using Installer Programming.
How to program Access Codes:
Programming Access Codes is a two step process. First the Code must be programmed followed by the
Code Attributes.
1.Enter [ ] [5] [Master Code]. The keypad will flash the ‘Program’ light and turn on the zone light for any
code already programmed.
2.Enter the 2 digit number for the code you want to program. The corresponding zone light will flash.
3.Enter a 4 digit code. The zone light will turn on steady.
4.Continue with steps 2 and 3 until all codes are programmed.
Do not press [ ] or [#] when programming the 4 digit code.
When programming Duress Codes or Master Codes no zone light will flash.
After all the Codes have been programmed press the [#] key to return to the Ready mode.

K E Y P A D C O M M A N D S
17
How to program Access Code Attributes:
“Master Code” attributes cannot change. By default, each code has the attributes of the code
used to program it.
1.Enter [ ] [5] [Master Code]. The keypad will flash the ‘Program’ light and turn on the zone light for any
code already programmed.
2.Press [9] to enter the Attribute mode. The keypad will turn on the ‘Ready’ light and turn off the armed
light.
3.Enter the 2 digit number for the code you want to program Attributes for. Zone lights [1] to [4] will be on
or off. Refer to the following chart:
Zone Light 1 - ON - Pager Communications enabled
Zone Light 2 - ON - Day Zone Reset enabled
Zone Light 3 - ON - enable zone bypass
Zone Light 4 - ON - Phone Access through WSS5580 enabled
4.Enter [1] to [4] to turn the zone lights ON or OFF.
5.Continue with steps 2 and 3 until all code attributes are programmed.
After all the codes and attributes have been programmed press the [#] key to exit Access Code Programming.
How to erase Access Code:
Select the code to be erased and press [ ].
[] [6] User Functions
This keypad command can be used to program several different functions. The following are the items
programmable:
[1] - Time and Date
[2] - System Test
[3] - User Call-Up (Downloading)
[4] - [7] For future use
To program User Functions:
1.Press [ ] [6] [Master Code]. The keypad will flash the ‘Program’ light.
2.Press the number [1] to [7] for the item to be programmed.
• [1] - Time and Date
The time and date must be accurate for the Test Transmission function to work properly. In addition the
event buffer time and date stamps all events.
- Enter the time: hour and minute, using 24-hour format [HH MM]. (00:00 to 23:59)
- Enter the date: month, day and year [MM DD YY].
All entries must be 2 digits. For example, eight o’clock in the morning would be [08] hours
and [00] minutes, and January would be month [01].
• [2] - System Test
When [2] is pressed the panel will perform the following:
- sound the alarm output for two seconds
- light all lights on the keypad
- sound the keypad buzzer for two seconds
- test the main panel battery
- send a System Test Reporting code, if programmed
(See Section 5.7 “Communicator - Reporting
Codes”) .
SystemTest will not activate any Fire outputs.
• [3] - User Call-Up (Downloading)
When [3] is pressed the panel will call the downloading computer
(See Section 5.8 “Downloading”) .
• [4] - [7] For future use
Additional Features are available using on the LCD keypad. These features do not have
numbers assigned. Use the arrow keys (< >) to scroll through the [ ] [6] menu and press the
[] key to select the following commands.
View Event Buffer
The 128 Event Buffer can be viewed through any LCD keypad (See Section 5.15.1 “Viewing the Event
Buffer Through the LCD Keypad”)
.
Brightness Control
When this option is selected the keypad will allow you to scroll through 10 different backlight level
options. Use the arrow keys (<>) to scroll to the desired backlight level and press the [#] key to exit.
