Quick Start Guide
Warranty
One year against manufacturer defect.
Westcott’s warranty obligations for this product are limited to the terms
set forth below: The F.J. Westcott Co. (“Westcott") warrants this Westcott
branded product against defects in materials and workmanship under
normal use for a period of ONE (1) YEAR from the date of retail purchase
by the original end-user purchaser (“Warranty Period"). If a defect arises
and a valid claim is received within the Warranty Period, at its option and
to the extent permitted by law, Westcott will either (1) repair the defect at
no charge, using new or refurbished replacement parts, or (2) exchange
the product with a product that is new or which has been manufactured
from new or serviceable used parts and is at least functionally equivalent
to the original product. This Limited Warranty applies only to products
manufactured by or for Westcott that can be identified by the “Westcott”
trademark, trade name, or logo affixed to them.
This warranty does not apply: (a) to damage caused by accident, abuse,
misuse, flood, fire, earthquake or other external causes; (b) to damage
caused by operating the product outside the permitted or intended uses
described by Westcott; (c) to a product or part that has been modified
to alter functionality or capability without the written permission of
Westcott.
Please contact Westcott’s Repair Department for a Return Authorization
Number “RMA" prior to requesting warranty service. This RMA must be
clearly written on the outside of the box to the left of the shipping label.
Items sent in without pre-authorization or that do not fall under the ONE
(1) YEAR limited warranty will be returned at the expense of the sender.
Register this product at fjwestcott.com/warranty
Repair Dept.: 800-886-1689 / 419-243-7311 (International)
E-Mail: INFO@FJWESTCOTT.COM SUBJECT: ATTN: REPAIR DEPT.
Shipping: F.J. Westcott Co, 1425 Holland Rd, Maumee, OH 43537
©F.J. WESTCOTT CO. ALL RIGHTS RESERVED.
Gear setup:
(2) APOLLO STRIPS (#2337)
(2) APOLLO GRIDS (#2473)
(1) 6' x 7' BLACK/WHITE
COLLAPSIBLE BACKDROP (#6772)
(1) COLLAPSIBLE BACKGROUND
STAND (#1103)
©ERIK VALIND
Setup uSaGe
SMART DESIGN
The Apollo Grid is uniquely designed with
detached corners. Once the grid is attached to
the Apollo, this feature allows you to quickly
adjust positioning to provide a more taught
and secure fit.
SETUP
1. When using the grid with the front diffusion
panel, attach the diffusion panel first,
placing it as far back on the loop tape as
possible. This will ensure sufficient room is
available to attach the grid.
2. Remove grid from protective carry case.
3. Open by fanning it out in all directions until
it forms the shape of your Apollo.
4. Starting at the top of your Apollo, secure
the grid in place using the hook-and-loop
tape. Start in the middle and work your
way towards the right and left side.
5. Repeat Step 3 on the remaining sides.
6. Once attached, adjust the corners to pull
the grid taught.
USAGE
A grid is an essential accessory for any lighting
system. It’s purpose is to limit the light spread
to 40-degrees, while altering the shape and
intensity of the light output.
CONTAINS: [1] 40-degree Grid [1] Travel Case
28" Medium
Apollo™Grid
#2471
43" Apollo™
Orb Grid
#2472
16" x 30" Apollo™
Strip Grid
#2473
ESSENTIAL SPEEDLITE ATTACHMENT
adjustable shoe mount bracket
#5015
ORIGINAL 28" APOLLO OWNERS
If your 28" Apollo is older than one year,
you may have the original model that has a
fixed front diffusion panel. This model requires
modifications in order for grids to attach that
may void manufacturer warranty.
