1.1 EcoDesign Overview
1.1 EcoDesign Overview
This document provides information about the OpenFlex Data24 related to its manufacturing and operation,
and instructions for secure data deletion and disassembly.
1.2 OpenFlex Data24 EcoDesign Specifications
Product Type Online Data Storage Product
Manufacturer's Name Western Digital
Manufacturer's Registered Trade Name Western Digital®
Manufacturer's Registered Trade Address 5601 Great Oaks Parkway
San Jose, CA 95119
USA
Product Model Number DCS0010
Starting Year of Manufacture 20201
PSU efficiency at 20%, 50%, 100%
of rated output power
20% load = 93.01%
50% load = 94.31%
100% load = 92.02%
Power Factor at 50% Rated Load Level Minimum Power Factor (at 50%) = 1.0
Declared Operating Condition Class A2
Neodymium Content in HDDs N/A
Cobalt Content in Batteries N/A
1.3 Secure Erasing a Storage Device
This task provides instructions for performing a Secure Erase on an OpenFlex Data24 storage device using
NVMe-CLI.
Before you begin: The Secure Erase feature provides the following options for securely erasing the storage
device:
•No Secure Erase – initializes the number of storage pools on the device
•User Data Secure Erase – deletes the mapping table and all user content present on the device
•Crypto Secure Erase – deletes the encryption key, making the data unrecoverable
This procedure assumes prior knowledge of the device names that will be deleted.
Step 1 : From a terminal, use NVMe-CLI to issue a format command to the target drive. Use the --ses
command modifier with a value set to 2 (crypto secure erase).
nvme format /dev/<device ID> --namespace-id=1 --ses=2
1. This value is the original date of product manufacture. For the specific manufacture date of your platform, check the
agency label attached to the platform. There will be a 4 digit date code on that label.
2

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Note: Crypto Secure Erase may not be available on all drives.
Step 2 : Verify data cannot be accessed by attempting reads to the drive. The data that exists on the
drive will no longer be accessible, because the encryption key has been deleted.
1.4 Chassis Disassembly
This procedure provides instructions for disassembling an OpenFlex Data24 Chassis.
Table 1: Replacement Procedure Info
Required Tools # of People Required
•T7 Torx screwdriver
•T8 Torx screwdriver
•T10 Torx screwdriver
•Tweezers or needle-nose pliers
(recommended)
•2 for removal of the Chassis from the rack
•1 for the disassembly of the Chassis
Step 1 : Follow the instructions for removing the enclosure from the rack (see the Chassis Disassembly
section of the OpenFlex Data24 User Guide).
Step 2 : Place the OpenFlex Data24 on an ESD-safe work surface, and ensure ESD safety equipment is
installed and working properly.
Step 3 : Uninstall the Drive Assemblies.
a. At the front of the enclosure, press the release button on the front of a Drive Assembly. The
release handle will rotate outward:
Figure 1: Drive Assembly Release Button and Handle Operation
3

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
b. Pull down slightly on the release handle to unseat the Drive Assembly. Then pull the handle
to remove the Drive Assembly from the enclosure:
Figure 2: Drive Assembly Removal
c. Repeat these steps to remove the remaining Drive Assemblies.
Step 4 : Uninstall the Power Supply Units (PSUs).
a. At the rear of the enclosure, grasp the ring handle of a Power Supply Unit (PSU) with your
index finger, and use your thumb to press the latch release with a pinching motion:
Figure 3: Power Supply Unit (PSU) Release Latch Operation
b. Pull the Power Supply Unit (PSU) out of its slot:
4

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 4: Power Supply Unit (PSU) Removal
c. Repeat these steps to remove the remaining Power Supply Unit (PSU).
Step 5 : Uninstall the IO Modules (IOMs).
a. Unlock an IO Module (IOM) by turning its thumbscrew counterclockwise until the threads are
disengaged. The location of the thumbscrew is shown in the following image:
Figure 5: IO Module (IOM) Thumbscrew Operation
b. Pull the release handle down until the IO Module (IOM) is unseated from its slot:
5

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 6: IO Module (IOM) Release Handle Operation
c. Use the handle to pull the IO Module (IOM) out of the enclosure:
Figure 7: IO Module (IOM) Removal
d. Repeat these steps to remove the remaining IO Module (IOM).
Step 6 : Remove the rear chassis cover.
a. Using a T7 Torx screwdriver, remove the sixteen (16) screws securing the rear chassis cover:
6

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 8: Rear Chassis Cover Screw Locations
b. Remove the rear chassis cover by lifting it from the back and sliding it toward the rear of the
Chassis:
Figure 9: Removing the Rear Chassis Cover
Step 7 : Remove the fan cover.
a. Using a T7 Torx screwdriver, remove the two (2) screws securing the fan cover:
7

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 10: Fan Cover Screw Locations
b. Remove the fan cover by pressing inward on the latches and lifting the cover away from the
Chassis:
Figure 11: Fan Cover Latches Operation
8

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 12: Fan Cover Removal
Step 8 : Remove the fan backflow guard.
a. Using a T8 Torx screwdriver, remove the six (6) screws securing the fan backflow guard:
Figure 13: Fan Backflow Guard Screw Locations
b. The fan backflow guard is a single piece of flexible material; remove it by lifting it away from
the Chassis:
9

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 14: Fan Backflow Guard Removal
Step 9 : Remove the System Fan modules.
a. Each System Fan module has a rounded notch and a rectangular notch with a retaining clip.
Place your thumb and index finger into the notches, squeeze to release the tension clip, and
pull upward on the System Fan module to remove it from the Chassis:
Figure 15: System Fan Latch Operation
10

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 16: System Fan Module Removal
b. Repeat these steps to remove the remaining System Fan modules.
Step 10 : Remove the Rack Ears and front system LED PCBA.
a. Using a T10 Torx screwdriver, remove the three (3) screws holding each cover to its rack ear
(6 screws total):
Figure 17: Rack Ear Cover Screw Locations
b. Pull each cover away from its rack ear to remove it:
11

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 18: Rack Ear Cover Removal
c. The left rack ear has a system LED PCBA mounted to it. Using a T7 Torx screwdriver, remove
the two (2) screws holding the PCBA to the rack ear:
Figure 19: Front System LED PCBA Screw Locations
d. On the PCBA, open the connector and separate the LED cable from the PCBA. Remove the
PCBA and leave the LED cable in place.
12

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 20: Front System LED PCBA Removal
e. Using a T7 Torx screwdriver, remove the four (4) screws securing each rack ear to the Chassis
(8 screws total). The screws are accessed from inside the left and right drive bays:
Figure 21: Rack Ear Screw Locations
f. Remove each rack ear:
13

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 22: Rack Ear Removal
Step 11 : Remove the top cover assembly.
a. Using a T7 Torx screwdriver, remove the fourteen (14) screws holding the top cover assembly
to the Chassis:
Figure 23: Top Cover Assembly Screw Locations
b. Lift the top cover assembly to remove it from the Chassis:
14

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 24: Top Cover Assembly Removal
Step 12 : Remove the rear system LED PCBA.
a. The rear system LED PCBA is located behind an access panel on the center divider of the
IO Module (IOM) compartment. Using a T7 Torx screwdriver, remove the three (3) screws
holding the panel to the Chassis:
Figure 25: Rear LED Access Panel Screw Locations
b. Pull the bottom of the panel outward, and then pull the panel down to remove it from the
Chassis:
15

EcoDesign Disclosures 1. EU EcoDesign Disclosures
1.4 Chassis Disassembly
Figure 26: Rear LED Access Panel Removal
c. Using a T7 Torx screwdriver, remove the two (2) screws holding the rear system LED PCBA to
the Chassis:
Figure 27: Rear System LED PCBA Screw Locations
d. On the PCBA, open the connector and separate the LED cable from the PCBA. Remove the
PCBA and leave the cable in place:
16
