Western Global FUELCUBE R2 User manual

Product Manual
Aboveground tanks for flammable
and combustible liquids
models: FCP250, FCP500, FCP1000 AND FCP1800 R2
fuelcube R2

NUMBER ONE IN
FUEL STORAGE
From a farm to a rock concert, our
customers have one thing in common.
They need a cost efficient, environmentally
secure and safe source of fuel that’s
reliable and ready to go.

Contents
Introduction .....................................................................................................................1
Description .......................................................................................................................2
Operation Acceptance ......................................................................................................3
Identification....................................................................................................................4
Specification.....................................................................................................................6
Safety ...............................................................................................................................7
Access & Security............................................................................................................12
Cabinet Overview ...........................................................................................................13
Century Of Gravity..........................................................................................................14
Lifting .............................................................................................................................18
Filling..............................................................................................................................19
Dispensing ......................................................................................................................20
Transporting ...................................................................................................................20
Stacking..........................................................................................................................21
Strapping Charts .............................................................................................................22
Maintenance ..................................................................................................................26
Recommended Inspection ..............................................................................................27
Inner Tank Removal........................................................................................................28
Torque Settings ..............................................................................................................31
Environmental................................................................................................................32
Troubleshooting .............................................................................................................33
Warranty........................................................................................................................34

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
1
Introduction
Thank you for choosing Western Global
Please read the contents of this manual before use.
•Ensure all operators are fully conversant with the procedures for lifting,
loading, positioning, filling, maintaining and use of the unit
•By understanding and following the information and procedures in this
manual, your tank will give you many years of safe use
•Certain information in this manual is governed by law and is subject to
change without prior notice. Great care has been taken to ensure that the
information is correct at the time of publication.
•However, the owner’s / user’s sole responsibility is to ensure that they and
the tank fully comply with all legal requirements. Western Global cannot
and will not accept any liability for any inaccuracy or incorrectly stated legal
requirements
•Western Global reserves the right to alter product specifications without
prior notice or obligation
Western Global Tanks are designed and approved under various Global /
International / National / Regional standards of safety 1
1Speak to your local / regional Western Global office for applicable standards.

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
2
Description
FCP – Static Fuel Tank
•The FCP range of fuel tanks have been designed to enable the safe storage of
Flammable & Combustible fluids
•The FCP can be used as an auxiliary fuel tank, feeding generators etc., and for
refuelling other equipment via a dedicated fuel pump
•All pipe work and pump systems are stored beneath a secure, lockable access
lid
•The FCP must be empty before transporting
•To aid both transporting and handling, the FCP is fitted with forklift pockets
(Lift empty only)
•Containment capacity equal to 110% of the primary tank’s capacity
•The design enables maintenance of the containment area without speciality
equipment
•The FCP has a comprehensive range of connection points to enable the
attachment of various fittings
•The FCP can supply fuel to multiple feed lines
•The FCP can be used to refuel independent equipment
•The FCP is listed and approved to UL142 & CAN/ULC-S601 Standard for Steel
Aboveground Tanks for Flammable and Combustible Liquids

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
3
Operation Acceptance
•The equipment provider should follow the general Safety Standards
•Anyone who will be using and/or maintaining the tank must read and
clearly understand ALL Safety, Usage and Maintenance information in
this manual
•Periodic reviews of SAFETY and OPERATION should be standard practice
for all your equipment
•A sign-off sheet is provided for your records, showing all personnel
working with the equipment
I have read and understand the information in the Operator’s Manual
and have been instructed in the operation of the equipment
Date Employee Signature Employer Signature

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
4
Identification
Each tank is supplied with 3 unique identification numbers.
1. Western Serial Number
2. Manufacturing Serial Number
3. UL/ULC Serial Number
1, Western Serial
Number
The Western Serial Number is located on the external of the tank (front or Side
near the cabinet area
2, Manufacturing
Serial Number
The tank number is positioned in the cab area and will be permanently attached
to the primary tank.

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
5
3, UL/ULC Serial
Number
The UL Plate is located on the external of the tank (front or Side near the cabinet
area
Record your serial numbers here
Western Data-plate Serial Number
Manufacturing Serial Number
UL/ULC Data plate Serial Number
Plant Number*
*Optional customer plant number

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
6
Specification
Capacities / Dimensions
Model
Capacity
Litres US Gallon Imp. Gallon
Nominal 95% Nominal 95% Nominal 95%
FCP250
955
907
252
240
210
200
FCP500
2058
1955
5448
516
453
430
FCP1000
3855
3662
1018
967
848
806
FCP1800 6991 6641 1847 1754 1538 1461
Model
Weight
KG
LBS
TARE
GROSS
TARE
GROSS
FCP250
397
1304
875
2875
FCP500 645 2600 1422 5732
FCP1000
1076
4738
2372
10466
FCP1800
1690
8331
3726
18367
Model
Dimension
Metric (mm) Imperial (Inch)
L W H L W H
FCP250
1164
1164
1288
46
46
51
FCP500
2212
1166
1288
87
46
51
FCP1000
2220
2320
1166
87
91
46
FCP1800 3969 2212 1166 156 87 46

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
7
Safety
Before using this equipment and to avoid personal injury, carefully
read and understand these instructions.

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
8
General
•If there is anything you do not understand, contact your supplier for advice
•The unit must be operated by authorised personnel only
•This unit must not be moved, filled, maintained, or operated by persons who
are under the influence of alcohol or drugs, tired or unwell
•You MUST perform a risk assessment before using this equipment to ensure
your safety and the safety of others
•Wear the correct Personal Protective Equipment for the task you are
performing
•Do not wear loose jewellery or clothing that may get in the way or become
trapped in the mechanism
•Inspect the unit before use, if there is any doubt about its condition, DO NOT
USE IT
•Do not smoke – No naked flames near the tank
•Please follow all necessary National and Regional Fire Safety Codes, and other
Installation Codes as applicable in your region/country of use.
No Smoking No Open Flames Authorised Access Only
Wear Safety Glasses Wear Safety Helmet Wear Ear Protection
Wear Safety Shoes Wear Safety Gloves Wear Coveralls
NOTE: Please check with the local authority for any further site
requirements or regional legislation. A full risk assessment may be
required

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
9
Limitations of use
•The FCP is designed for the safe storage of noncorrosive, stable flammable
and combustible liquids that have a specific gravity not exceeding 1.0 in
aboveground applications
•UL 142 and CAN/ULC-S601 listed tanks are intended for installation by a
variety of installation codes, including NFPA 30, NFPA 30A, NFPA 31, NFPA
37, NFPA 1 NFCC PART-4, CSA B138, CSAB139 and the International Fire
Code.
•The FCP is not suitable for use underground
Safe practice
The storage, transportation and dispensing of Flammable & Combustible fluids are
governed by law and the user/operator has sole responsibility to ensure that any
such rules and regulations are abided by.
Earthing point
•The unit is fitted with an earthing point. This can be found on the bottom
frame of the unit
•Used to protect against static electricity build-up, this should be connected
to a suitable earthing point, by a qualified electrician, when in use

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
10
Venting
Each unit has 2 common vents installed; these are installed in the Cab Area of the
tank.
IMPORTANT: Do not operate the unit if these vents are damaged or
missing
•2” Pressure Vacuum Vent – Allows movement of air into the unit at low
pressure during the pumping process and allows air out of the unit at a higher
pressure to stop an overpressure of the internal tank
•¼” Roll over Vent – Allows free flow air into and out of the tank at all times,
this low volume vent will fully close if the tank is accidentally inverted or
turned on its side
•For static installation follow local regional, state and national Fire Safety
Codes and other governing Installation Codes for the Normal and Emergency
Venting equipment and appurtenances.
1. 2” Pressure / Vacuum Vent
2. ¼” Breather Vent

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
11
All tanks come with the provision to install a UUL2583-compliantemergency vent,
the dedicated port will be indicated on each tank.
Vent size
FCP250 – 3”
FCP500 – 4”
FCP1000 – 5”
FCP1800 – 6”

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
12
Access & Security
Access to the Cab Area
•The cabinet hatch is constructed of heavy-duty steel, care should be taken
when opening or closing
•The cabinet hatch should be kept closed when the FCP is not being used, to
protect the fittings and containment area from weather conditions.
Access to Containment
•The primary tank can be removed from the containment to allow easy
inspection
Security
•The FCP is fitted with a range of connections to enable the supply of
Flammable & Combustible fluids. All the connections are housed behind the
cabinet hatch, which can be locked using a suitable security padlock

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
13
Cabinet Overview
Standard Unit
1. 1” Feed
2. 3” Fill Point
3. 3 x 1.5” Spare Ports
4. 2” Pressure / Vacuum Vent
5. ¼” Roller Over Vent

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
14
Century Of Gravity
FCP250 Centre of Gravity 2
Center Of Gravity
2Based on empty tank.

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
15
FCP500 Centre of Gravity 3
Centre Of Gravity
3Based on empty tank.

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
16
FCP1000 Centre of Gravity 4
Centre Of Gravity
4Based on empty tank.

WM045 FCP250, 500, 1000, 1800 R2 v3 EN
17
FCP1800 Centre of Gravity 5
Centre Of Gravity
5Based on empty tank.
