Westinghouse GHL95 Manual

DIMENSION AND INSTALLATION GUIDE
510mm
58mm
(built-in height)
860mm
A minimum B minimum
830mm
470mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL95/795 Current as at Jul 2007
Note: Electrical connection
Requires 240V 10AMP power outlet
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm above
the bench top.
These models are supplied
with 10Amp plug and lead
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
gas cooktop
MODELS: GHL95, GHL795

DIMENSION AND INSTALLATION GUIDE
535mm
58mm
(built-in height)
600mm
A minimum
B minimum
570mm
490mm
Gas supply
connection
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
Note: Electrical connection
GHL12 models require a
240V/10A power outlet.
GHL11 models do not require
an electrical connection.
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL11/12 Current as at Jul 2007
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
GHL12 is supplied with
10Amp plug and lead
gas cooktop
MODELS: GHL11, GHL12

DIMENSION AND INSTALLATION GUIDE
535mm
58mm
(built-in height)
600mm
A minimum
B minimum
570mm
490mm
Gas supply
connection
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
Note: Electrical connection
GHL12 models require a
240V/10A power outlet.
GHL11 models do not require
an electrical connection.
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL11/12 Current as at Jul 2007
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
GHL12 is supplied with
10Amp plug and lead
gas cooktop
MODELS: GHL11, GHL12

DIMENSION AND INSTALLATION GUIDE
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
535mm
58mm
(built-in height)
600mm
A minimum
B minimum
570mm
490mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL16/17/765 Current as at Jul 2007
Note: Electrical connection
Requires 240V 10AMP power outlet
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
These models are supplied
with 10Amp plug and lead
gas cooktop
MODELS: GHL16, GHL17, GHL765

DIMENSION AND INSTALLATION GUIDE
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
535mm
58mm
(built-in height)
600mm
A minimum
B minimum
570mm
490mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL16/17/765 Current as at Jul 2007
Note: Electrical connection
Requires 240V 10AMP power outlet
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
These models are supplied
with 10Amp plug and lead
gas cooktop
MODELS: GHL16, GHL17, GHL765

DIMENSION AND INSTALLATION GUIDE
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
542mm
58mm
(built-in height)
600mm
A minimum
B minimum
570mm
490mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL26 Current as at Jul 2007
Note: Electrical connection
Requires 240V 10AMP power outlet
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
These models are supplied
with 10Amp plug and lead
gas cooktop
MODEL: GHL26

DIMENSION AND INSTALLATION GUIDE
520mm
58mm
(built-in height)
890mm
A minimum B minimum
830mm
470mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL46 Current as at Jul 2007
Note: Electrical connection
Requires 240V 10AMP power outlet
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
These models are supplied
with 10Amp plug and lead
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
gas cooktop
MODEL: GHL46

DIMENSION AND INSTALLATION GUIDE
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
510mm
58mm
(built-in height)
860mm
A minimum B minimum
830mm
470mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL90 Current as at Jul 2007
Note: Electrical connection
Not required
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
gas cooktop
MODEL: GHL90

DIMENSION AND INSTALLATION GUIDE
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
58mm
(built-in height)
510mm
860mm
A minimum B minimum
830mm
470mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL92 Current as at Jul 2007
Note: Electrical connection
Requires 240V 10AMP power outlet
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
These models are supplied
with 10Amp plug and lead
gas cooktop
MODEL: GHL92

DIMENSION AND INSTALLATION GUIDE
510mm
58mm
(built-in height)
860mm
A minimum B minimum
830mm
470mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL95/795 Current as at Jul 2007
Note: Electrical connection
Requires 240V 10AMP power outlet
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm above
the bench top.
These models are supplied
with 10Amp plug and lead
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
gas cooktop
MODELS: GHL95, GHL795

DIMENSION AND INSTALLATION GUIDE
* Minimum height of non-combustible surface is 150mm
NOTE: All appliances must be installed to Australian Standard AS5601
minimum distance to
combustible vertical surface minimum distance to non-combustible vertical surface*
A 135mm 50mm
B 120mm 50mm
535mm
58mm
(built-in height)
600mm
A minimum
B minimum
570mm
490mm
Gas supply
connection
© 2007 Electrolux Home Products Pty Ltd
WDIMGHL16/17/765 Current as at Jul 2007
Note: Electrical connection
Requires 240V 10AMP power outlet
cooktop dimensions
building-in cut-out dimensions
Walls around cooktop
must be heat resistant for
temperatures up to 90oC
to a height of 150mm
above the bench top.
These models are supplied
with 10Amp plug and lead
gas cooktop
MODELS: GHL16, GHL17, GHL765
