Westinghouse PON663 Manual

DIMENSION AND INSTALLATION GUIDE
© 2007 Electrolux Home Products Pty Ltd
WDIMPON/GON Current as at Jul 2007
oven and cut-out dimensions
cabinet construction
For the best integration within a kitchen, install this appliance in a standard 600mm wide cupboard that
gives a ush t with the surrounding cupboard fronts (Figure 1). A 20mm recess is ideal. It can also be
installed using a proud t with the surrounding cupboard (Figure 2).
Note: Your appliance must be mounted on a at surface for the full width and depth of the product.
Figure 1 – ush t (top view) Figure 2 – proud t (top view)
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
A
C
B
561mm
595mm
mounting holes
595mm
547mm
20mm
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
Inll panel recessed 20mm
from external cabinet/door
to accommodate for a ush t
type of fit A (width) B (height) C (depth)
Flush t (mm) 600 600 581 min.
Proud t (mm) 565 590 560 min.
C = from face of cabinet/door to rear of enclosure.
Connection: All electric models require hardwire connection
models load
PON663, PONS663 2.3kW
PON667 3.0kW
PON668, PON781, PON783 3.1kW
Gas models require a standard 240V/10A power outlet
NOTE: Side opening models PONS663 and PONS667 are
supplied congured for left hand hinge door.
The door is reversible at installation
single underbench oven
MODELS: PON663, PON667, PON668, PONS663, PONS667, PON781, PON783, GON474, GON476

DIMENSION AND INSTALLATION GUIDE
© 2007 Electrolux Home Products Pty Ltd
WDIMPPN776/778 Current as at Jul 2007
oven and cooktop dimensions
and cut-out dimensions
cabinet construction
For the best integration within a kitchen, install this appliance in a standard 600mm wide cupboard
that gives a ush t with the surrounding cupboard fronts (Figure 1). A 20mm recess is ideal. It can
also be installed using a proud t with the surrounding cupboard (Figure 2).
Note: Your appliance must be mounted on a at surface for the full width and depth of the product.
Figure 1 – ush t (top view) Figure 2 – proud t (top view)
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
A
588mm 485mm
C
B
561mm
595mm
mounting holes
595mm
547mm
20mm
605mm 505mm
45mm
(built-in height)
type of fit A (width) B (height) C (depth)
Flush t (mm) 600 600 581 min.
Proud t (mm) 590 565 560 min.
C = from face of cabinet/door to rear of enclosure.
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
Inll panel recessed
20mm from external
cabinet/door to
accommodate for a
ush t
Note: a minimum gap of 40mm must be maintained between the top of the underbench oven and the
bottom of the cooktop to ensure adequate ventilation and space for the interconnection lead.
600mm
28mmmin.
Side view
Note: a 40mm min.
recommended air gap
below cooktop base for
this type of installation
Connection: All electric models require
hardwire connection
models load
PPN778 9.5kW
PPN776 8.7kW
combination oven and cooktop
MODELS: PPN776, PPN778

DIMENSION AND INSTALLATION GUIDE
© 2007 Electrolux Home Products Pty Ltd
WDIMPDN/PXN/GXN Current as at Jul 2007
oven and cut-out dimensions
cabinet construction
For the best integration within a kitchen, install this appliance in a standard 600mm wide cupboard
that gives a ush t with the surrounding cupboard fronts (Figure 1). A 20mm recess is ideal. It can
also be installed using a proud t with the surrounding cupboard (Figure 2).
Note: Your appliance must be mounted on a at surface for the full width and depth of the product.
Figure 1 – ush t (top view) Figure 2 – proud t (top view)
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
Inll panel recessed 20mm
from external cabinet/door
to accommodate for a ush t
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
min. 650mm
A
mounting holes
mounting holes
595mm
B
C
547mm
20mm
888mm
566mm
type of fit A (width) B (height) C (depth)
Flush t (mm) 600 893 581 min.
Proud t (mm) 565 885 560 min.
C = from face of cabinet/door to rear of enclosure.
Connection: All electric models require hardwire connection
models load
PDN790, PXN698 5.3kW
PXN688 4.5kW
Gas models require a standard 240V/10A power outlet
separate grill wall oven & duo oven
MODELS: PDN790, PXN698, PXN688, GXN650

DIMENSION AND INSTALLATION GUIDE
© 2007 Electrolux Home Products Pty Ltd
WDIMPDN/PXN/GXN Current as at Jul 2007
oven and cut-out dimensions
cabinet construction
For the best integration within a kitchen, install this appliance in a standard 600mm wide cupboard
that gives a ush t with the surrounding cupboard fronts (Figure 1). A 20mm recess is ideal. It can
also be installed using a proud t with the surrounding cupboard (Figure 2).
Note: Your appliance must be mounted on a at surface for the full width and depth of the product.
Figure 1 – ush t (top view) Figure 2 – proud t (top view)
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
A
C
B
mounting holes
mounting holes
595mm
547mm
20mm
725mm
566mm
type of fit A (width) B (height) C (depth)
Flush t (mm) 600 731 581 min.
Proud t (mm) 565 723 560 min.
C = from face of cabinet/door to rear of enclosure.
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
Inll panel recessed 20mm
from external cabinet/door
to accommodate for a ush t
Connection: All electric models require hardwire connection
models load
PGN657 4.1kW
PGN659 4.9kW
Gas models require a standard 240V/10A power outlet
separate grill underbench oven
MODELS: PGN659, PGN657, GGN475

DIMENSION AND INSTALLATION GUIDE
oven and cut-out dimensions
© 2007 Electrolux Home Products Pty Ltd
WDIMPDN794 Current as at Jul 2007
min. 650mm
547mm
20mm
mounting holes
mounting holes
595mm
1081mm
A
B
C
561mm
type of fit A (width) B (height) C (depth)
Flush t (mm) 600 1086 581 min.
Proud t (mm) 565 1078 560 min.
C = from face of cabinet/door to rear of enclosure.
cabinet construction
For the best integration within a kitchen, install this appliance in a standard 600mm wide cupboard that gives
a ush t with the surrounding cupboard fronts (Figure 1). A 20mm recess is ideal. It can also be installed
using a proud t with the surrounding cupboard (Figure 2).
Note: Your appliance must be mounted on a at surface for the full width and depth of the product.
Figure 1 – ush t (top view) Figure 2 – proud t (top view)
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
565mm
Cupboard doorCupboard door
20mm
9mm clearance required
600mm
Cupboard door
Cupboard door
Inll panel recessed 20mm
from external cabinet/door
to accommodate for a ush t
Connection: Requires hardwire connection.
Total load 6.2kW
double wall oven
MODEL: PDN794

DIMENSION AND INSTALLATION GUIDE
© 2007 Electrolux Home Products Pty Ltd
WDIMPON/GON Current as at Jul 2007
oven and cut-out dimensions
type of fit A (width) B (height) C (depth)
Flush t (mm) 600 600 581 min.
Proud t (mm) 565 590 560 min.
C = from face of cabinet/door to rear of enclosure.
cabinet construction
For the best integration within a kitchen, install this appliance in a standard 600mm wide cupboard
that gives a ush t with the surrounding cupboard fronts (Figure 1). A 20mm recess is ideal. It can
also be installed using a proud t with the surrounding cupboard (Figure 2).
Note: Your appliance must be mounted on a at surface for the full width and depth of the product.
Figure 1 – ush t (top view) Figure 2 – proud t (top view)
894mm
Cupboard doorCupboard door
20mm
9mm clearance required
900mm Cupboard doorCupboard door
894mm
Cupboard doorCupboard door
20mm
9mm clearance required
900mm Cupboard doorCupboard door
Inll panel recessed 20mm
from external cabinet/door
to accommodate for a ush t
894mm
Cupboard doorCupboard door
20mm
9mm clearance required
900mm Cupboard doorCupboard door
A
CB
855mm
894mm
474mm
545mm
20mm
Connection: Requires hardwire connection. Total load 2.9kW
900mm oven
MODEL: POH967S
