Westomatic Primo Compact Instruction sheet

FRESH MILK
INSTALL, CLEAN & FILL
COMPACT
COMPACT

INSTALL MILK FRIDGE
External Dimensions Fridge:
W230xD420xH455mm
External Dimensions Total:
W530xD515xH600mm
Capacity Milk Fridge:
4litres/8pints fresh milk
Noise Emission: <70dB
Weight: 19kg (Total: 57kg)
The milk fridge is designed to
work in combination with the
Primo Compact:

Parts Included:
Milk Fridge
Power cable
Milk container with lid
2 x keys
Milk hose
Measuring Jug
Safety Instructions
OPTIONAL: Ingredient Box
PN: 1057339
Check the contents:
NB: The machine will have been set up to your specifications and tested at Westomatic
HQ prior to install. All parts have been assembled on the machine. The QR code inside
the machine gives access to the We:Support pages with technical information.

Clean milk fridge,
place hose in
milk container,
place in machine
and close door
Connect milk
hose to milk
output - feed
hose through
into fridge
Move fridge
into place next
to the Primo
Compact
Remove green
cover from the
nozzle on the
side of the
machine
Place the Fridge
on a level surface
Min Clearances:
Rear: 50mm
Ensure the
protective
plastic is
removed from
the top

Connect fridge to
a 230V mains
power socket -
ensure supply has
minimum 45W
Machine is ready
to use
Switch the Fridge
on using button
on the front

Parts Needed:

FRESH MILK CLEANING:
The Fresh Milk Fridge must be
cleaned every day
The Primo will remind you to
clean the fridge at a pre-set
time each day - the machine
won't work unless this is done
These instructions show the
steps for Cleaning the Fresh Milk
Fridge:

Before you
start - wash
hands or wear
gloves
Open the milk
cooler, remove
the hose and
wipe clean
Clean the
canister with
dishwasher
detergent
Rinse with
thoroughly
clean water
Ensure you
clean the lid
thoroughly with
detergent too
Empty the milk
canister

FRESH MILK LINE CLEANING:
Westomatic Milk Line Cleaner
Measuring Jug
Fresh Water
Cleaning wipes
These instructions show the
steps for Cleaning the Fresh Milk
Lines:
For this process you will need:

On the
touchscreen:
Select the
machine menu
Select CLEAN
MILK SYSTEM
Follow machine
instructions
Open fridge,
remove hose
and wipe, press
NEXT on
screen
Fill a measuring
jug with 500ml
of clean water
Use 30ml of
Westomatic
Milk Line
cleaner. Press
NEXT on screen
Before you
start - wash
hands or wear
gloves

11
Place the hose in
the jug and press
NEXT on the
screen
Place container
under the outlet -
Hot water is
dispensed - press
NEXT on screen
Empty the
container
System cleans
the lines - This
takes about 4
minutes
Replace
container back
under outlet
and press NEXT
on screen
12
Remove and
clean hose, and
press NEXT on
screen

14
16
15
13
17
Clean the
measuring jug
with dishwasher
detergent
Fill measuring
jug with 1 litre
of clean water
System cleans
the lines - This
takes about 4
minutes - Hot
water dispensed
Place the hose
in the jug, and
press NEXT on
the screen
Remove the
container,
press NEXT on
the screen
18
The cleaning
process is stored
HACCP cleaning
schedule. Press X
to continue

20
22
21
19
23
Clean the milk
container with
dishwasher
detergent
Place milk
container back
into fridge with
hose
Clean drip tray
using a damp
cloth
Clean drip tray
and cover
behind
Machine is
ready to use

FRESH MILK FILLING:
Ensure the Fresh Milk Fridge
and lines are clean
Clean the Fridge before every
refill
Clean the Lines daily after use
These instructions show the steps
for Filling the Fresh Milk Fridge:

Press menu to
start
Select Fill Milk,
the system will
start filling,
follow on screen
instructions
Open fridge,
remove milk
container and
lid
Fill the
container with
cold milk - max
8 pints/4 litres
Press NEXT
Replace the lid
on the
container, and
the line into the
container
Before you
start wash your
hands
thouroughly

11
Place Fridge back
into machine,
close the door
and press NEXT
Place empty
container under
the outlet - press
NEXT on screen
Remove the
container -
press NEXT
The machine
will flush and
fill the milk
system.
The milk
system is ready
to use. Press X
(close) to go to
recipe menu
12
All drinks with
fresh milk are
available to use
