Weston REALTREE EDGE 73-0701-RE User manual

7 LB (3 L)CAPACITY
VERTICAL
SAUSAGE STUFFER
INSTRUCTIONS
MODEL NO. 73-0701-RE

-2-
ASSEMBLED
VERTICAL
STUFFER
30 mm 13 mm
40 mm 20 mm
5
1
2
34
6
7
8
9
10
11
12
Stuffer
Base
Stuffer
Sides
13
11
12

-3-
COMPONENT LIST
DIAGRAM PART
NUMBER DESCRIPTION
1 Handle
2 Plunger
3 Plunger Seal
4 Pressure Release Valve (3 Piece Set)
5 Stainless Steel Funnel Set (4 Funnels)
6 Stainless Steel Canister
7 Front Ring Nut
8 Canister Mounting Hardware Kit (4 Sets)
9 Plunger Shaft
10 Plunger Bolt
11 Gear Housing Cover with Hardware Kit
12 Gear Set
13 Rubber Foot (4 Piece Set)
Not Shown Realtree EDGE® Camo Cover
If any components of this unit are broken or the unit does not operate
properly, call Weston Brands, LLC Toll Free at
1-800-814-4895
Monday thru Friday 8:00am-5:00pm EST. Outside the U.S. call 1-216-901-6801

-4-
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Refer to them often and use them to instruct others.
WHEN USING APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED TO REDUCE THE RISK OF INJURY TO
PERSONS, INCLUDING THE FOLLOWING:
7. Be sure the Stuffer is stable during
use. All four feet should be secure on
a level surface. The Stuffer should not
move during operation.
8. Never operate the Stuffer with the
Gear Housing Cover open or removed.
9. Wear eye protection! Everyday
eye glasses are not safety glasses.
Safety glasses conform to ANSI Z87.1
requirements. Note: Approved safety
glasses have Z87 printed or stamped
on them.
10. Do not use while under inuence of
drugs or alcohol.
11. Household use only.
1. Read all instructions.
2. Check for damaged parts. Before
using the Stuffer, check that all parts
are operating properly and perform the
intended functions. Check for binding
of moving parts, mounting and any
other conditions that may affect the
operation.
3. Keep children away. Never leave the
appliance unattended. The Stuffer is
not a toy.
4. The Manufacturer declines any
responsibility in the case of improper
use of the Stuffer. Improper use of the
Stuffer will void the warranty.
5. Never store or leave the Stuffer at a
temperature lower than 32oF (0oC).
6. Repair must be done by an
authorized dealer. Use only factory
original parts and accessories.
Modication of the Stuffer will void the
warranty.
GEAR MOVEMENT
Fast Gear Shaft
With theHandle attached, turn
clockwise to raise thePlunger,
counter-clockwise
to lower the Plunger.
Slow Gear Shaft
With theHandle attached, turn
counter-clockwise to
raise thePlunger,
clockwise to lower thePlunger.

-5-
ASSEMBLY
PLUNGER ASSEMBLY
1. Slide the Plunger Seal onto the
Plunger (Figure 1).
2. Assemble the Pressure Release
Valve Kit onto the Plunger. From the
top of the Plunger, place the Washer
onto the Valve Hole, then insert the
Screw through the Washer and into the
Valve Hole. From the underside of the
Plunger, place the Spring onto the end
of the Screw, then place the Valve Cap
onto the end of the Screw and twist to
secure.
3. Screw the Plunger Bolt onto the
Plunger Shaft (Figure 2).
4. Place the assembled Plunger onto
the end of the Plunger Shaft (Figure 3).
STUFFER ASSEMBLY
5. Attach the Handle by sliding it onto
either the Fast or the Slow Gear (Figure 4).
6. Crank the Handle to bring the
Plunger to the top of the Stuffer.
Continued Next Page
Plunger
Seal
Plunger
Pressure
Release
Valve Kit
Screw
Washer
Spring
Valve Cap
Valve Hole
Plunger
Shaft
Plunger
Bolt
Handle
Fast Gear
Shaft
Slow Gear
Shaft
Plunger
Shaft
Plunger
Figure 1
Figure 2
Figure 3
Figure 4
