Weston PRO 2100 65-0101 User manual

VACUUM SEALERS
PRO 2100 65-0101 / PRO 2300 65-0201
DUE TO CONSTANT FACTORY IMPROVEMENTS, THE PRODUCT PICTURED MIGHT DIFFER
SLIGHTLY FROM THE PRODUCT IN THIS BOX.
65-0201 PICTURED

IMPORTANT SAFEGUARDS
COMPONENT LIST
PROTECTIVE TAPE
CLEANING INSTRUCTIONS
VACUUM CHAMBER SEALS
COOLING FAN
THERMAL OVERLOAD PROTECTOR
LIMIT SWITCH
OTHER CONSUMER SAFETY INFORMATION
POWER SUPPLY
CONTROL BUTTONS
OPERATING INSTRUCTIONS
PREPARING VAC BAGS FROM A ROLL
SERVICE INSTRUCTIONS
REPLACING THE FUSE
STORAGE LIFESPAN GUIDELINES
FOOD SAFETY
WARRANTY
REGLAS IMPORTANTES DE SEGURIDAD
LISTA DE COMPONENTES
CINTA PROTECTORA
INSTRUCCIONES DE LIMPIEZA
SELLOS DE LA CÁMARA DE VACÍO
VENTILADOR DE REFRIGERACIÓN
PROTECTOR DE SOBRECARGA TÉRMICA
INTERRUPTOR DE LÍMITE
OTRA INFORMACIÓN DE SEGURIDAD PARA EL CLIENTE
FUENTE DE ALIMENTACIÓN
BOTONES DEL CONTROL
INSTRUCCIONES DE FUNCIONAMIENTO
PREPARACIÓN DE BOLSAS AL VACÍO DE UN ROLLO
INSTRUCCIONES DE MANTENIMIENTO
REEMPLAZO DEL FUSIBLE
PAUTAS SOBRE LA VIDA EN ALMACENAMIENTO
SEGURIDAD DE LOS ALIMENTOS
INFORMACIÓN DE GARANTÍA WESTON
IMPORTANTES RÈGLES DE SÉCURITÉ
DESCRIPTION DE LA PIÈCE
RUBAN PROTECTEUR
INSTRUCTIONS DE NETTOYAGE
GARNITURE DU CANAL D’ASPIRATION
VENTILATEUR
LIMITEUR DE SURCHARGE
INTERRUPTEUR DE POSITION
AUTRES RENSEIGNEMENTS DE SÉCURITÉ AU CONSOMMATEUR
ALIMENTATION ÉLECTRIQUE
TOUCHES DE COMMANDE
MODE D’EMPLOI
FABRICATION D’UN SAC SUR MESURE AVEC UN ROULEAU
INSTRUCTIONS D’ENTRETIEN
REMPLACEMENT DU FUSIBLE
GUIDE DE CONSERVATION DES ALIMENTS EMBALLÉS
SÉCURITÉ ALIMENTAIRE
INFORMATION SUR LA GARANTIE
3
4-5
6
6
7
7
7
7
8
8
9
9-10
11
11-12
12
13
14
16
18
20-21
22
22
23
23
23
23
24
24
25
25-26
27
27-28
28
29
30
32
34
36-37
38
38
39
39
39
39
40
40
41
41-42
43
43-44
44
45
46
47
TABLE OF CONTENTS / ÍNDICE / TABLE DES MATIÈRES
2

When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of re, electric shock, and/or injury to persons,
including the following:
1. Read all instructions.
2. ALWAYS DISCONNECT Vacuum
Sealer from power source before
servicing, changing accessories or
cleaning the unit.
3. Plug the Vacuum Sealer into a
standard 120 Volt, 60 Hz wall outlet.
Avoid using extension cords.
4. DO NOT USE the Vacuum Sealer
if the Power Cord, Plug or any other
parts are damaged. If the Power Cord
or the Vacuum Sealer is damaged,
call Customer Service. DO NOT
ATTEMPT TO REPLACE THE CORD.
Be sure to not allow the Power Cord to
drape into your work area. Check that
all parts are operating properly, and
perform the intended functions. Check
for any other conditions that may
affect the operation.
5. NEVER use any accessories or
parts from other manufacturers. Doing
so will VOID YOUR WARRANTY and
may cause re, electrical shock or
injury.
6. Reduce risk of unintentional
starting. Make sure the Power
Switch is in the “OFF” position before
attaching to the power source.
7. KEEP FINGERS CLEAR of the
Heat Sealing Bar and Seal Bar Tape
AT ALL TIMES, these areas become
HOT. Doing so may cause serious
injury.
8. DO NOT take this appliance
apart; doing so will VOID YOUR
WARRANTY and may result in
personal injury.
9. TO PROTECT AGAINST RISK
OF ELECTRICAL SHOCK: DO
NOT SUBMERGE THE VACUUM
SEALER INTO WATER OR LIQUID.
BE SURE THE VACUUM SEALER
IS DISCONNECTED FROM THE
POWER SOURCE BEFORE
CLEANING. Follow the “Cleaning
Instructions” in this booklet. NEVER
rinse appliance Vacuum Sealer under
tap.
10. NEVER LEAVE THE VACUUM
SEALER UNATTENDED. Be safe,
DISCONNECT the Vacuum Sealer
from power source before leaving
the work area. Close supervision is
necessary when any appliance is used
near children. This appliance is NOT to
be used by children.
11. DO NOT let the Power Cord hang
over edge of work surface.
12. Be sure the Vacuum Sealer is on
a stable work surface. Be sure all the
Vacuum Sealer Feet are stable.
13. DO NOT use the Vacuum Sealer
outdoors.
14. DO NOT use the Vacuum Sealer
while under the inuence of drugs,
medications or alcohol.
15. The Vacuum Sealer is ONLY
intended to be used with VACUUM
BAGS. For best results, only use the
recommended vacuum bags. DO
NOT USE HOUSEHOLD BAGS! Any
other uses of the Vacuum Sealer,
other than the uses described in this
booklet, could potentially damage the
appliance and void the warranty!
SAVE THESE INSTRUCTIONS 3
ENGLISH INSTRUCTIONS
IMPORTANT SAFEGUARDS

ENGLISH INSTRUCTIONS
4
Power Cord Port
3
2
STOP
MANUALSEAL
START
POWER
VACUUM
SEAL
COOL
1
4
5
6 / 11
7 / 10
8
Vacuum
Lid
12
Pro-Series Vacuum Sealer
Maintenance Kit Sold Separately
Model No. 08-0501-W
Power Cord
Storage
9
13
VACUUM
STOP
SEAL
COOL START
MANUAL SEAL
POWER
AUTOMATIC VACUUM SEAL
1. PLUG power cord into 120-Volt outlet
2. Turn the POWER SWITCH to the “ON” position
3. Place VACUUM BAG OPEN END into VACUUM CHAMBER (See Instruction Book for Details)
4. CLOSE LID – APPLY PRESSURE to HANDLE – push START button
5. The machine will VACUUM and SEAL automatically*
MANUAL SEAL MODE
MANUAL SEAL MODE is used to disengage the vacuum pump and engage the sealing function manually
1. Follow steps 1-4 of the Automatic Vacuum Seal Instructions
2. When the desired vaccum is reached, press the MANUAL SEAL BUTTON
3. The machine will begin sealing the bag*
* The Sealing Time is pre-set to 3 seconds. The Cooling Time is pre-set to 3 seconds.
THIS IS ONLY A QUICK REFERENCE GUIDE. THOROUGHLY READ AND UNDERSTAND
THE SUPPLIED INSTRUCTION MANUAL BEFORE USING THIS APPLIANCE.
QUICK REFERENCE GUIDE
PRO-2100
U.S. P atented
R e c on n e c t with Re a l F ood
VACUUM
SEALER

5
ENGLISH INSTRUCTIONS
COMPONENT LIST
If any components of this unit are broken, the unit does not operate properly or you
need a replacement instruction manual, visit us on the web at
WestonSupply.com
Or call Weston Brands, LLC Toll Free at 1-800-814-4895
Monday thru Friday 8:00am-5:00pm ET. Outside the U.S. call 001-216-901-6801
DIAGRAM NUMBER PART DESCRIPTION PART NUMBER
1 POWER CORD 08-0402
2 POWER INDICATOR SWITCH 65-0110
3 FUSE HOLDER 08-0404
4 10-AMP BUSS FUSE 08-0405
5 RUBBER FOOT (6) 08-0407
6 SEAL BAR HEATING ELEMENT WITH
SCREWS 08-0427
7 VACUUM LID SEAL BAR ASSEMBLY 08-0430
8 VACUUM LID HANDLE WITH SCREWS 08-0434
9 INTERNAL COOLING FAN 08-0444
10 10MM UPPER SEAL BAR TAPE
11 15MM LOWER SEAL BAR TAPE (2)*
*NOTE ONE EXTRA PIECE OF SEAL BAR TAPE IS
INCLUDED WITH THE ORIGINAL UNIT AS A SPARE.
08-0426
12 OVAL VACUUM CHAMBER SEAL (2) 08-0429
13 MAINTENANCE KIT
(SOLD SEPARATELY: INCLUDES 2
OVAL VACUUM CHAMBER SEALS, (1)
10MM UPPER SEAL BAR TAPE, (1)
15MM LOWER SEAL BAR TAPE
08-0501-W
