Westport PILOT3 User manual

PILOT3 Owner’s Manual
Westport Marine, Unit 2 Connaught Lane, Plymouth PL4 7BZ, UK
T: 07977 466160, e: [e-mail], www.westportmarine.co.uk
This manual has been compiled to help you to operate your craft with safety and
pleasure. It contains details of the craft, the equipment supplied or fitted, its systems,
and information on its operation and maintenance. Please read it carefully and
familiarise yourself with the craft before using it.
If this is your first craft, or you are changing to a type of craft you are not familiar with, for
your own comfort and safety, please ensure that you obtain handling and operating
experience before assuming command of the craft. Your dealer or national boating
association will be pleased to advise you of local sea schools or competent instructors.
PLEASE KEEP THIS MANUAL IN A SECURE PLACE AND HAND IT OVER TO THE
NEW OWNER WHEN YOU SELL YOUR CRAFT.
Owner’s Manual
PILOT3

PILOT3 Owner’s Manual
Page 2 of 11
CONTENTS
DECLARATION OF CONFORMITY..................................................................................3
Abbreviations....................................................................................................................4
Design Category D (D)....................................................................................................4
Seaworthiness and Crew Ability (W)..............................................................................4
Maintenance & Repairs (D).............................................................................................4
GENERAL INFORMATION ................................................................................................5
REGULAR INSPECTION (W) ............................................................................................5
HANDLING CHARACTERISITCS, TRIM, PERFORMANCE & STABILITY (D)............5
CRAFT MASS (C)................................................................................................................6
OPERATOR’S FIELD OF VISION (D) ...............................................................................6
SAFETY EQUIPMENT (W).................................................................................................7
RISK OF FLOODING (D)....................................................................................................7
RISK OF FIRE (D)...............................................................................................................7
GENERAL OPERATION.....................................................................................................7
Man-overboard Prevention & Recovery (C)..................................................................7
Bilge Pumping and Bailing (C)........................................................................................7
Main Deck Drainage (D)..................................................................................................7
Mooring, Anchoring & Towing (W).................................................................................8
Launching & Trailering (W).............................................................................................8
Lifting (D)..........................................................................................................................8
Outboard Engine (C)........................................................................................................8
Cleaning (C) .....................................................................................................................8
Winter Storage (C)...........................................................................................................9
Additional Manuals (C)....................................................................................................9
WESTPORT MARINE WARRANTY................................................................................10
Registration ....................................................................................................................10
Use..................................................................................................................................10
Limitation.........................................................................................................................10
Claims.............................................................................................................................10
Westport Marine Product & Warranty Registration Form ..............................................11

PILOT3 Owner’s Manual
Page 3 of 11
Recreational Craft Directive 94/25/EC
DECLARATION OF CONFORMITY
Craft Identification Number GBWPBP3_ _ _ _ _ _ _
Manufacturer Westport Marine
Brand Name PILOT3
Type of Craft Outboard Powered Open Decked Motorboat
Construction Material Fibre Reinforced Plastic
Maximum Design Category D
Maximum Persons Capacity 3
Maximum Engine Power 7.5 kw, (10hp)
Dimensions Length 4.45m
Beam 1.48m
Draught 0.19m
Assessment module A
Standards Applied General Requirements EN ISO 8666
Craft Identification Number EN ISO 10087
Builders Plate EN ISO 14945
Protection from Falling Overboard and
Means of Reboarding EN ISO 15085
Visibility from Steering Position EN ISO 11591
Owner’s Manual EN ISO 10240
Structure EN ISO 12215
Stability & Freeboard EN ISO 12217
Manufacturer’s Recommended Load EN ISO 14946
Anchoring, Mooring & Towing EN ISO 15084
Handling Characteristics EN ISO 11592
For noise and emissions, see outboard
engine manufactures Declaration of Conformity.
The Pilot3 Complies With All Relevant And Essential Safety
Requirements Of The Recreational Craft Directive (94/25/EC) And Other
Associated Directives.
Signature …………………..…………………………………
Name Charles Broughton
Position Managing Director, Westport Marine
Unit 2 Connaught Lane, Plymouth PL4 7BZ, UK
Date 04-01-2021

PILOT3 Owner’s Manual
Page 4 of 11
GENERAL NOTES
Abbreviations
The following abbreviations have been used:
(D): DANGER
(W): WARNING
(C): CAUTION
Design Category D (D)
This craft has a design category ‘D’ designated “Sheltered Waters”: Designed for voyages
on sheltered coastal waters, small bays, small lakes, rivers and canals when conditions up
to, and including, wind force 4 and significant wave heights up to, and including, 0.3 m may
be experienced, with occasional waves of 0.5 m maximum height, for example from passing
vessels.
This craft should not be used in areas and conditions exceeding those of category D. This
craft should only be operated at speeds suitable to the prevailing conditions and experience
of crew and should not be operated at higher speeds in adverse sea conditions.
Seaworthiness and Crew Ability (W)
Regardless of the craft’s seaworthiness and its certified RCD design category, protection
from freak sea and wind conditions cannot be guaranteed. The ability, experience and
fitness of all the crew should therefore be taken into consideration before using the craft.
As a minimum, ensure that the anticipated wind and sea conditions do not exceed the design
category of your boat and that you and your crew are able to handle the boat in these
conditions. All crew should receive suitable instruction/training particularly with regards to
location and operation of safety equipment.
Maintenance & Repairs (D)
Always use trained and competent people for maintenance, repairs or modifications. Contact
your dealer prior to undertaking any modifications as they may affect the safety
characteristics of the craft, endangering your own safety and invalidating any warranties.
Please note that any change in the disposition of masses aboard may significantly affect the
stability, trim and performance of your boat.

PILOT3 Owner’s Manual
Page 5 of 11
Length
4.45
m
Design Category
D
Beam
1.48
m
Max. No. People
3
Draught
0.19
m
Max. Load (excl. engine)
285
Kg
Max. Power
10.0 (7.5)
Hp (kw)
Boat Mass (excl. engine)
180
Kg
Max. Speed
15.0
knots
Trailering Mass
290
Kg
GENERAL INFORMATION
REGULAR INSPECTION (W)
Regular inspections should be carried out prior to use and should include at least the
following:
Ensure transom & deck drains are closed, secure and in good condition.
Check the fuel hose and connections for leaks, general wear and chaffing.
Check the steering and engine controls, ensuring free and full movement.
Ensure the secure mounting and operation of the outboard motor, referring to
separate outboard motor manufacturers manual.
HANDLING CHARACTERISITCS, TRIM, PERFORMANCE & STABILITY (D)
Small craft are susceptible to significant changes in trim, (fore & aft) and heel, (port &
starboard) for relatively minor movements of onboard masses.
Arrange crew and store gear/equipment securely to ensure that your craft has level trim and
heel prior and during use, bow down trim should be avoided otherwise the boat might turn
unexpectedly.

PILOT3 Owner’s Manual
Page 6 of 11
Avoid sudden changes in speed and direction unless in an emergency. High speed and
sudden steering movements, especially in high seas, may result in loss of control of the boat
and excessive heeling angles. Always consider your own driving skill, your speed, direction
and environmental conditions.
Observe the recommendations on the manufacturer’s plate concerning the maximum
permitted number of passengers, weight of loads and maximum design conditions.
Water should not be allowed to collect in the main deck area as this can reduce
performance, stability and cause adverse trim and heel conditions. All water should be
bailed directly overboard.
Do not operate this craft with an engine of rated power greater than 7.5KW, (10hp). The
craft should only be operated at higher speeds in calm conditions, not exceeding 15 knots.
As the sea state and wind conditions worsen speed should be reduced to a level that avoids
slamming, is comfortable for the crew and is at a level that the operator is confident in
controlling.
Do not operate at maximum speed in congested high traffic waterways or in weather and sea
conditions of reduced visibility, high winds or large waves. Reduce speed and wake as a
courtesy and as a safety consideration to yourself and others. Observe the speed limit and
no wake zones.
Observer the right-of-way as defined by the Rules of the Road and required by COLREG.
Always be certain to have sufficient distance to stop or manoeuvre if required to avoid
collisions.
DANGER: OPERATING THE BOAT AT HIGHER SPEEDS IN ADVERSE SEA AND WIND
CONDITIONS CAN DAMAGE THE BOAT, CAUSE SERIOUS INJURY AND INVALIDATE
WARRANTIES.
CRAFT MASS (C)
A maximum total load has been used for assessing stability and buoyancy comprising:
Crew mass (3) 225 kg
Provisions & personal effects 30 kg
Outboard engine 45 kg
Portable fuel tank and fuel 15 kg
Anchoring, mooring & miscellaneous 15 kg
Maximum total load 330 kg
The stability of this boat has been assessed assuming that:
In the light craft condition it has a mass of (incl. engine) 240 kg
The maximum recommended outboard engine mass is 45 kg
OPERATOR’S FIELD OF VISION (D)
Operator vision from the aft seat can be obstructed by high trim angles of the craft and other
factors caused by one or more of the following variable conditions:
Loading and load distribution
Speed & rapid acceleration

PILOT3 Owner’s Manual
Page 7 of 11
Transition from displacement to planning mode
Sea conditions
Rain & spray
Darkness & fog
Electrical Lighting
Persons or movable gear in the operator’s field of vision
The International Regulations for Preventing Collisions at Sea (COLREGS) and the rules of
the road require that a proper lookout be maintained at all times and observance of right of
way. Observance of these rules is essential.
SAFETY EQUIPMENT (W)
Be sure, before you start your boating, that you have the required safety equipment onboard,
such as:
Life jackets
Fire extinguisher
Flares
Anchor and line
Means of signaling (high powered torch)
Bailer
Oars or alternative means of propulsion
RISK OF FLOODING (D)
All small boats are susceptible to flooding. Ensure that deck hatches are kept closed while
underway and opened only for access while stopped.
Ensure that any water collecting in the boat is immediately bailed overboard.
RISK OF FIRE (D)
Fuel and electrics onboard small boats present an inherent fire risk.
Always remove the portable fuel tank from the boat and fill in a well ventilated area, away
from the risk of ignition.
Ensure that any wiring is correctly installed and in good condition.
GENERAL OPERATION
Man-overboard Prevention & Recovery (C)
Care should always be taken when moving around small boats. Crew should restrict
movements to the working deck area and remain seated at all times while aboard. Avoid
sudden changes in speed and direction unless in an emergency.
Bilge Pumping and Bailing (C)
It is the responsibility of the owner/operator to have at least one bailer/draw bucket on board,
secured against accidental loss.
Main Deck Drainage (D)
The deck drain is only intended for use ashore to drain wash down or rain water into the
bilges and out through the transom drain.

PILOT3 Owner’s Manual
Page 8 of 11
WARNING: THE MAIN DECK DRAIN PLUG SHOULD BE KEPT CLOSED AT ALL TIMES
WHEN AFLOAT.
Mooring, Anchoring & Towing (W)
Always moor your boat with care even in sheltered moorings, as weather conditions can
change rapidly.
Prior to launching, mooring or anchoring it is recommended that all lines & fenders be
prepared and attached to the boat, as required, prior and in good time to the operation to be
undertaken. Always plan ahead and assess any potential difficulty, ensuring that your crew
are fully aware of your intentions and their responsibilities.
It is the owner’s/operators responsibility to ensure that mooring lines, tow lines and anchor,
chain & line are adequate for the vessel’s intended use. The breaking strength of all
lines/chains shall in general not exceed 5.0 KN (80% of the minimum breaking strength of
the deck cleats).
Owners should consider and practice the making fast of a tow line, in a manner that shall
allow the tow to be release while under load, ensuring that they are fully prepared in the
event of an emergency.
Always tow or be towed at a slow speed. Never exceed the hull speed of a displacement
craft when being towed.
Launching & Trailering (W)
Ensure that the centre rollers of the trailer bear the keel of your boat in a correct way, and
adjust the lateral bearing to avoid any movement. Do not forget to fasten the tie down
straps. Do not load the craft when trailering.
New owners/operators should seek instruction/guidance on launching and recovery from the
dealer or local sea school/powerboat instructor. Do not attempt launching/recovery without
adequate instruction.
Lifting (D)
Adjust the location and length of lifting strops to ensure the craft is horizontal when being
lifted. Provide protection between the strops and the craft. Do not use warp to lift the craft.
Do not load or stand under the craft while being lifted.
Outboard Engine (C)
Refer to the engine manual. Always flush the cooling system with fresh water after use.
Cleaning (C)
Keep your boat clean and tidy. This enhances comfort and safety and increases the boats re-
sale value. The fuel consumption of a motor boat is significantly affected by the cleanliness
of the hull and engine parts beneath the surface of the water.
Use as few cleaning agents as possible, do not discharge waste agents into the water, and:
Clean your craft preferably on land
Avoid scratching of the hull, use a high-pressure water machine
Do not use abrasive cleaning or polishing methods
Do not use solvents or aggressive detergent
Always rinse down after use

PILOT3 Owner’s Manual
Page 9 of 11
Winter Storage (C)
Refer to the engine manual for winterising the engine, otherwise generally include the
following:
Remove, charge and store the battery in a dry, ventilated place protected from frost
Remove the fuel tank and store in a suitable area away from the boat
Grease the steering gear
Remove all water from the craft and protect it from rain, preferably stored inside
Inspect all areas, fixtures & fittings replacing any doubtful components
When storing the boat on a trailer, the fastening straps must be loosened. If the engine is still
mounted, its weight must be supported. During the period of storage, heavy loose items such
as the battery and fuel tank should be removed.
If stored outdoors, cover the boat with a non-transparent tarpaulin. Ensure, however, that the
boat has sufficient ventilation. The tarpaulin and its fastening ropes will chafe the surface of
the boat if they flap and move in the wind, so fasten them with care. When storing outdoors,
make sure that an excessive amount of snow or puddles can not accumulate on top of the
tarpaulin. Storing the boat on its side is not recommended.
Additional Manuals (C)
Any additional equipment, fixtures and fittings should have their instructions/manuals stored
with this manual and passed on to any subsequent owners.

PILOT3 Owner’s Manual
Page 10 of 11
WESTPORT MARINE WARRANTY
Westport Marine Ltd manufacturer’s warranty extends for 12 months and is subject to the
following conditions:
Registration
1. On completion of the sale of a new Westport Marine boat a Product & Warranty
Registration Form must be completed & returned to Westport Marine Ltd, including
Boat model, Hull number, Outboard model and frame number, full customer & Dealer
details, date of sale, type of usage, etc. The Warranty will only be valid on receipt of
the completed form which can be found at the end of the Owners Manual supplied
with every boat, or on request from Westport Marine Ltd.
2. The warranty will commence from the date that the boat was sold new, by Westport
Marine (or by appointed Dealer). In the case of a Westport or Dealer demonstration
boat the warranty will commence from the date the vessel was first launched as a
demonstration boat, prior to Delivery or Dealer Sale.
Use
1. Westport Marine boats have been designed and manufactured for domestic use only
and as such warranty is limited to domestic use and does not cover any boat
engaged in commercial use, activity or application. The warranty will cease from the
time that the boat is first engaged in any such type of commercial use or service.
2. The following exclusions will further render any warranty void and unenforceable:
willful damage or neglect including, but not limited to, failure to follow manufacturers’
instructions for maintenance and use of the boat; non-adherence to the Owners
Manual issued with each new boat sale; non-adherence to our Engine Power and
Speed guide as published on our website and in our boat brochures; commercial use
of the Vessel.
Limitation
1. Westport Marine limits its warranty to make good any defect or fault due to the
process used to manufacture the boat.
2. It is the responsibility of the boat owner to return the boat to Westport Marine,
Plymouth, before any warranty work can be undertaken.
3. It is the owner’s responsibility to maintain insurance cover for his boat and equipment
while it is at Westport Marine or their appointed contractor’s premises.
4. All warranty work must be undertaken by Westport Marine or their approved
contractor. No liability will be accepted for any work undertaken by the owner or their
appointed contractor on the boat at any time.
5. The warranty period is not extendable.
Claims
1. Claims must be made in writing directly to Westport Marine Limited at the earliest
possible time. Warranty cover can only be accepted from the date that any such
claim notification is received by Westport Marine.
2. Westport Marine will endeavor to respond to any claim in a considered, professional
and timely manner. Full disclosure of the claim will hasten the procedure and should
include the following: clear and concise summary of the issue of concern,
photographs, usage history, engine hours, maintenance, boat condition, storage
location & history, etc. Any information proved to be false or misleading will render
any warranty claim void and unenforceable.

PILOT3 Owner’s Manual
Page 11 of 11
Westport Marine Product & Warranty Registration Form
This form must be completed & returned to Westport Marine as a condition of the boat warranty.
Product Details
Boat Model & Accessories fitted
Hull Identification Number
(found on transom)
Main Outboard - Model & Type
(see owners manual)
Main Outboard - Frame Number
(see owners manual)
Propeller: Number blades, diameter & pitch,
(found on propeller hub)
Auxiliary Outboard - Model & Type
(see owners manual)
Auxiliary Outboard - Frame Number
(see owners manual)
Type of Use (delete as appropriate)
Domestic / Commercial
Trailer: Manufacturer & Model
Customer Details
Name
Address
Postcode
Telephone Number
E-mail Address
Dealership Details
Dealer Stamp/Details
Dealer Code
Dealer Signature & Date
signature
date
Date of First Launch (demo-
boats)
Date of Customer Purchase
