Westward GO-4 INTERCEPTOR.IV User manual

GO-4 INTERCEPTOR.IV
SPACE SAVING - ERGONOMICAL - EFFICIENT
TAILORED DESIGN - RETURN ON INVESTMENT - DOMESTICALLY BUILT
THE URBAN UTILITY VEHICLE
A new and improved
OPERATOR’S MANUAL
© Westward Industries Ltd. 2017

Contact Westward Industries for Manuals and Documentation. Do not copy.
Title Page
GENERAL INFORMATION 2
SAFETY 4
CONTROLS AND GUAGES 5
OPERATION 13
SERVICE AND MAINTENANCE 18
SPECIFICATIONS 34
INDEX
WARRANTY SERVICE 35
OWNERS OBLIGATION & RESPONSIBILITY 36
REPORTING SAFETY DEFECTS 40
The description and specications contained in the operator’s manual were in aect at the time the
manual was approved for printing. Westward Industries Ltd. has the right to discontinue models at
any time, or change specications or design, without notice and without incurring obligation.
39
TABLE OF CONTENTS

2
GENERAL INFORMATION
The Westward Industries GO-4 is poweredby a 998cc 3-cylinder water cooled engine.
The engine power is transferred to the drive wheels by a four speed automatic
transmission.
Vehicle Identi tion Number
The decal is located on the front inside left post.
V.I.N.#
VIN #
Contact Westward Industries for Manuals and Documentation. Do not copy.

3
General Information – cont’d
Engine Number
Is stamped right on the cylinder head cover. It is advised upon deliver to record this number with your
permanent record les.
Engine No.
Vehicle Emission Control Information Decal
Is located front of the engine cab.
Engine Number
Sticker
Contact Westward Industries for Manuals and Documentation. Do not copy.

4
SAFETY
CAUTIONS and WARNINGS
Throughout the operator’s manual, you will nd Cautions and Warnings.
Warnings remind you to be especially carefulto avoid personal injury.
Cautions are provided to prevent you from making an error, which could damage the
vehicle and possibly cause personal injury.
Safety Reminders
1. Make sure the GO-4 operator has read the manual and understands it.
2. Do not let children operate vehicle.
3. This vehicle is to carry one person ONLY. No riders!
4. Use a seat belt for optimum safety. - It's the Law!
5. Keep both hands on steering wheel whenever possible.
6. Keep legs and arms in the vehicle when it is in motion.
7. Always shut o engine when vehicle is being refueled.
8. Never smoke when refueling or servicing vehicle.
9. Always dim headlights when approaching people or other vehicles.
10. Never make sudden turns or stops when not necessary.
11. NOTE: The cornering ability of three-wheeled vehicles is not as great as that of similar 4 –
wheeled units. A warning buzzer will sound if the vehicle is operating on too much of a slope or
if a corner is taken at too high a rate of speed.
12. Always keep within load limits and never overload it.
13. Always run the vehicle in open areas with plenty of fresh air to prevent carbon monoxide
poisoning.
14. Always slow down before you turn and when travelling over rough areas.
15. Always signal lane changes and turns.
16. Always wear a helmet where law states such as required.
NOTE: The GO-4 is classed as a motorcycle.
Operating Precautions for the Catalytic Converter
1. Use only unleaded fuel in your vehicle.
2. Do not park the vehicle near or over ammable objects such as gas.
3. Do not operate engine at high idle speeds for long periods of time while in “P” or “N”
4. Do not allow your vehicle to run empty of fuel.
5. Do not operate the vehicle when there are signs of engine malfunctions, such as misre or
noticeable loss of power to the engine.
6. Do not coast with engine o.
7. Do not go down steep grades in gear with ignition o.
8. Do not modify or tamper with emission control system. Let a qualied technician do the
adjustments.
Contact Westward Industries for Manuals and Documentation. Do not copy.

CONTROLS AND GAUGES
1. Fan Speed
2. Temperature Light Indicator
3.
4. Speedometer
5. Hourmeter
6. Fuel Gauge
7.
8. Park Brake/ Brake Warning Light
9. High Beam Indicator Light
10. Turn Signal Lights (L, R)
11. Oil Pressure Light
12. LTI (Lateral Thrust Indicator)
13. Auxiliary Switches (two)
14. Vents
15. Hazard Switch
16. Check Engine Light
17. O/D Light Indicator
18. Low Fuel Indicator
19. Battery Light Indicator
20. Temperature Control
1
4
12
20
15
31 31
5
6
14
910 2
17
18 19 816
Contact Westward Industries for Manuals and Documentation. Do not copy.
11
No Longer in Use
No Longer in Use

6
Controls and Gauges – cont’d
All controls and gauges are located on the dash.
Ignition Switch (4 positions)
a. Accessory Position: Allows use of various instruments and accessories without the engine
running. Option lights, dome light, radio.
b. Position: Prevents all electrical powered accessories and engine from running except hazard
warning asher and allows key to be removed
c. On Position: This allows all accessories and engine to be run.
The key is automatically returned to this position after starting the GO-4
d. Start Position: Hold key in start to engage starter, upon engine starting release key.
Important: Do not turn the key to “start” position with engine running.
Severe damage can result to the starter drive and ring gear.
Note: If GO-4 does not start within 15 seconds, turn key to the position, then try again in 30 seconds.
Damage may occur to starter if it is run continuously for an extended period of time.
Contact Westward Industries for Manuals and Documentation. Do not copy.

7
Controls and Gauges – cont’d
Note:The GO-4 will start only when the transmission is in Park or Neutral.
Gear Selector
The gear selector is located to the left handside of thedriver’sseat. When shiftingfromPark or Neutral to
anygear, hold foot on brake.Use the thumb button on the side ofgear selector torelease from “P” or “R”.
When the transaxle is in Park, the push buttonwill pop out automatically, locking the lever in the Park
position. In this position the gear selector cannot be moved unless the button is pushed in.
“P” (Park)position: use only when thevehicle has come to a complete stop.
WARNING: When the above is not followed, extreme damage to the
transmission can occur. “P” should not be used as a
brake.
“R”(Reverse) position: Use for backing up vehiclefrom
a stop. Note: A back up alarm (if equipped) will sound
when the transmission is in “R”.
“N”(Neutral) position: For standing (brakesapplied).
“D” (Drive) position: For normal driving this
transmission will shift automatically through the four
forwardgear sequence.
“2”position: manually select when power is needed to
go up steephills, a braking assistwhen goingdown hills
“L” position: Manuallyselectwhen climbing up or
down very steep hills or for bettercontrol on slick
surfaces.
Parking Brake
Pull up to engage.Depress button onend of handle and
push lever down toreleaseparking brake. Brake light on
dash will come onwhen parking brake is engaged.
Contact Westward Industries for Manuals and Documentation. Do not copy.

8
Controls and Gauges – cont’d
Foot Throttle
Pushpedal to operate throttle. Idle position is when pedal
returns to the top.
Note: The GO-4’s engine high idle comes on
automatically upon cold start. As the engine reaches
normal operating temperature the high idle device will
come
Brake Pedal
When pedal is depressed, the vehicle’s brakes are applied and
vehicle will slow down to a stop.
Doors
The doors slide on tracks to ease opening and closing. The window can be opened separately from inside
(eg. To provide ventilation)withou ting door operation and safety.
Door: Open door by pulling on red handle and slide door back on
its tracks. Close door by pushing on black handle and allowing
door to travel forward until click is heard.
Window: Pull back black handle and slide window ba rst
notch (vent position) orback until it locks in the fully open
position.
Speedometer/Odometer
The speedometer indicates the forward speed of the vehicle.
This is shown in MPH by large number and km/h (kilometers per
hour)by the smallnumbers. The odometer indicates the total
distance (in miles) the vehicle hasdriven.
Hourmeter
Records the number of hours that the vehicle has run and is important if your vehicle operates at slow
speeds and idles a good portion of its daily operation . It is a better indicator when maintenance items
should be carried out, (eg. oil an changes.)
Fuel Gauge
Records the fuel level in the tank; Tank capacity is 9.0 US gal,
34 liters.
Contact Westward Industries for Manuals and Documentation. Do not copy.

9
Controls and Gauges – cont’d
Warning and Indicator Lights
Battery Warning Light: If this light is displayed when the engine is running, you may have a
problem with your charging system. This display will also stay on while the key is in RUN until the engine
is started.
Brake System Warning Light: Red warning light has two functions:
1. Park brake warning light. This indicates when the parking brake is applied when the engine is
started. Release the parking brake fully before moving vehicle. The light should go o when the
parking brake is released.
2. Brake uid level warning light. This warning light is still on even when the parking brake is
completely released. It may indicate low brake uid level in the reservoir.
If the warning light stays on:
1. Make sure parking brake is full released.
2. Carefully stop your vehicle. Put in “P” Park andapply emergency brake.
3. With engine stopped, check uid level and ow. Checkall brake components for leaks.
4. If any leaks are found, if warning light continues to stay on, or the brakes do not operate properly
do not drive vehicle.
5. Have your vehicle towed to an authorized dealer for a full brake examination. Let them do the
necessary repairs.
WARNING: Driving your vehicle with improperly operating brakes can cause severe damage to your
vehicle and possible injury to the operator.
Check bulb operation: the warning light glows when the ignition key is in start position and should go out
when the brake is released and engine is started.
Headlight High Beam Indicator Light: The blue indicator light comes on when the headlights are
on and in the high beamposition.
Turn Signal Indicators: Lights when left or right turn signal is engaged.
Panel Lights:Lights on instrument panel display gauges atnight. They operate when the headlights are
switched on.
Low Fuel Light: This light indicates the vehicle is running low on fuel.
Contact Westward Industries for Manuals and Documentation. Do not copy.

10
Controls and Gauges – cont’d
Temperature Warning Lights : These lights indicate the temperature of the engine coolant. A blue
temperature light will come on when the vehicle is started. This indicates that the engine is cold and
should be driven slowly. If the engine gets too warm a red temperature light will come on. At this point make
Oil Pressure Warning Light : The red oil pressure light indicates the low oil pressure in the engine.
Auxiliary Switches
The illuminated rocker switches operate the following
options:
- Roof-mounted work light(s).
- Work lights or other customer installed options
Heater Controls
Fan Speed: The four-speed heater control switch is located on
the right side of the dash. Turn
clockwise
to increase fan speed.
Heat/Cold : Temperature is controlled by pulling control for
more heat. Push in to reduce heat. This control is located
on the left side of the dash.
Defrost/Vent: Direction of air is manipulated by opening or closing
of the lowerdash vents. Close the vents for full defrost.
Air Conditioner: Activate the optional air conditioning by pushing
the middle of the fan speed control button. The AC light will illuminate
when air conditioning is engaged.
Contact Westward Industries for Manuals and Documentation. Do not copy.

11
Controls and Gauges – cont’d
Steering Column Controls
Light Switch/Turn Signal : The multifunction lever is on the left hand side of the steering wheel.
Turn Signals : Pull lever down until it latches to signal a left turn and push it up for a right turn.
The indicator lights on the instrument panel will indicate a left or right turn. When the turn is
rutehtfI.lan signrutehtlecnaclliwleehwgnireetsehtetelpmoc n signal continues to pull
the turn signal switch back to OFF position.
Dimmer Switch: To change your headlamp from low to high beam, push the lever away from you,
until it latches and release. The blue high beam indicator on the dash glows when the headlamps
are on high beam. To change your headlamp from high to low beam, pull the lever toward you and
release. Flash to Pass: Pull the lever toward you and hold to momentarily turn on the high beam.
Lights: Rotate the knob on the end of lever to the st position. This activated the clearance,
parking, license, and taillights. Turn knob to second position to activate headlights, license, and
taillights.
Daytime running lights: Once the vehicle is running the daytime running lights automatically
come on. These however should not be used for night driving.
Tilt Adjustment: Tilt steering with a lever on the right side lower steering column. Pull the lever out from the center
section.
Wiper Control: Located on the right hand side of the steeringcolumn. Move stalk down to select wiper
speed. When the wiper is on the INT (intermittent) setting, rotate knob on end of stalk to select desired
intermittent setting.
Dome Light: Located on the ceiling in compartment. Push switch on dome light to illuminate it. Push
again to shut it
Wi
p
er Control
Light Switch/
Turn Signal
Contact Westward Industries for Manuals and Documentation. Do not copy.

12
Controls and Gauges – cont’d
Seat
Adjust the seat by pulling up on the lever and than
push or pull on seat until desired position obtained.
Release lever. The seat back can also be adjusted
by lifting the lever on the righthand side of the seat
close to the back. Do not put pressure on the seat
back while attempting to lift lever as this could bind
the system.
Seat Belt
The lap/shoulder belt should be used atall times
when the vehicle is in motion.
To fasten seat belt:
1. Grasp the buckle end and tongue plate.
2. Slowly pull out the tongue plate section.
3. Insert the tongue plate into the open end of
the buckle. A noticeable click will indicate
the seat belt is securely locked.
Unfasten seat belt:
1. Push button on buckle end to release.
2. The tongue end will automatically return to
resting position along side seat.
Note: To help decrease the possibility or severity of
injury in sudden stops and accidents, buckle up at
all times when using your vehicle. Position the belt,
low on the hips and make sure it always is snug.
Use the seat belt at all times when the vehicle is in
operation.
Contact Westward Industries for Manuals and Documentation. Do not copy.

13
OPERATION
WARNING: Do not exceed payload capacity given on vehicle nameplate or permit passengers any
place on the vehicle.
•A three-wheeled vehicle is not as stable as a four-wheeled vehicle while cornering, particularly
while on a down hill grade. Pay attention to the LTI warning which will sound if maximum lateral
“G” force is exceeded.
•Place heavy loads forward of rear axles. Unbalanced or top heavy loads can cause vehicle upset.
•Wear a helmet.
•Do not start your vehicle in a closedgarage or other enclosed areas. Exhaust fumes can be toxic.
Always open the garage door before you start the engine.
Before you start your vehicle, do the following:
1. Make sure you buckle your safety belt. See Seat Belt in the Controls and Gauges section of the
manual for more details.
2. Make sure the gearshift selector is in Park and the parking brake is set before you turn the key.
Starting the Vehicle: Further information on engine starting is provided in this section.
1. Adjust the seat for easy access to switches and controls.
2. Adjust mirrors for a clear rear view both right and left mirrors.
3. Fasten seat belt.
4. Put key in ignition.
5. Turn key to start vehicle.
6. Use accelerator after vehicle has started.
7. Step on brake pedal.
8. Place gear selector into desired gear.
9. Release parking brake.
Note: Vehicle will not start if the transmission is not in “P” or “N”.
Stopping and Leaving Vehicle:
1. Stop unit fully with brake pedal.
2. Place gear selector lever in “P”.
3. Apply parking brake.
4. Turn ignition switch to OFF position and remove key.
Note: When leaving the vehicle on an uphill or downhill grade, the vehicle should be “curbed” (front wheel
positioned and pointed towards the curb so that the downhill momentum of the vehicle, should it roll, will
force the tire against the curb).
Contact Westward Industries for Manuals and Documentation. Do not copy.

14
Operation – cont’d.
Starting the Engine
When starting the fuel-injected engine, avoid pressing down on the accelerator. Use the accelerator only
when you have problems getting your vehicle started. See Starting a Cold Engine for detailsabout when
to use the accelerator while you start your vehicle.
IMPORTANT: Do not park, idle or operate your vehicle in tall, dry grass or other dry ground areas. The
high heatgenerated by engine and emissions components (eg catalyticconverter) could starta ground re.
1. Turn the key to the ON position. All the warning lights, except the Brake Warning Light, should
light up. If any of them do not light up, have the bulb and circuit checked. When the engine starts,
the lights should go out.
2. The key must be in the START position, which cranks the engine, to test the Brake Warning
Light. If the Brake Warning Light does not light up, have the bulb and circuit checked.
3. When you release the parking brake, the Brake Warning Light should go o.
Starting a Cold Engine
During extremely cold weather, let the engine idle for about one minute after starting. By doing this, you
will allow the engine oil to begin to warm and lubricate engine parts before putting load on them.
WARNING: Do not let your vehicle idle too long. If it idles for more than 10 minutes, the high
temperatures in the exhaust system can cause damage especially if your vehicle idles at high speeds.
1. Turn the key to START until the engine starts. Do not press the accelerator.
Do not hold the key in the START position for more than 15 seconds at a time or you
could damage the starter.
2. Release the key as soon as the engine starts. Do not hold the key in START position after the
engine starts because you could damage the starter.
3. If the engine does not start on your rst try, turn the key to OFF. Wait 10 to 12 seconds so that
you do not ood the engine. Then begin again.
4. If the engine does not start after two tries, press the accelerator about ¼ of the way to the oor.
Then try again.
5. If the engine still does not start, push the accelerator to the oor and hold it while you turn the
key. Turn the key to START and hold it for up to 15 seconds. Then if the engine does notstart,
turn the key to OFFand wait two minutes before you try again.
Contact Westward Industries for Manuals and Documentation. Do not copy.

15
Operation – cont’d
NOTE: If you consistently start your vehicle in subzero temperatures, park your vehicle in a garage or use
the engine block heater (if so equipped). Your dealer can provide information on block heater installation.
Starting a Warm Engine
1. Follow the steps under “Starting”
2. Turn the key to START until the engine starts. Do not use the accelerator until the engine is
running. Do not hold the key in the START position for more than four seconds at a time so that
you do not ood the engine.
3. If the engine does not start within four seconds, turn the key to the OFF position. Wait 10 or 12
secondsso that you do not ood the engine. Then begin again.
4. If the engine still does not start:
a. Press the accelerator all the way to oor. Hold it. Do not pump the pedal.
b. Turn the key to START.
c. Release the key when the engine starts.
d. Release the accelerator gradually as the engine starts.
Engine Cranks but Does Not Start
WARNING: If you detectanabnormally strong smell of gas, do not try to start your vehicle. You could
injure yourself or others. Get out of your vehicle and call a towing service or the localre department.
Exhaust Fumes
Carbon monoxide is colorlessand odorless. It is present in exhaust fumes. Take precautions to avoid its
dangerous eects.
WARNING: Never idle the engine in closed areas. Never sit in parked or stopped vehicle for more than a
short period of time. Exhaust gases,particularly carbon monoxide, may build up. These gases are harmful
and could kill you.
If you smell exhaust fumes of anykind inside your vehicle, have your dealer inspect and x your vehicle
immediately. Do not drive the vehicle if you smell exhaust fumes.
Contact Westward Industries for Manuals and Documentation. Do not copy.

16
Operation – cont’d
Refueling
WARNING : Use only unleaded fuel,damage to the pollution control system and catalytic converter will
occur if leaded fuel is used. Donot use fuel system cleaning agents.
engine and do not smoke while refueli re or explosion may occur.
Filler Cap
Alwaysensure thatth ller cap is in place and tight
while operating this vehicle.
To remove cap, turn counterclockwise.
To install cap, turn clockwise until a click(s) is heard.
Fuel Type
Use only unleaded fuel with anoctane rating of at least
87. If your vehicle doesn’t performwell, switch to
another fuel. If thisdoesn’t cure the problem see yourelcihevruoyfI.naicinhcetecivrestnegarorelaed4-OG
is damaged because of incorrect fuel, your warranties
maynot apply.
NOTE : Higher-octane fuel is allowed. If a lower octane fuel is used it can cause apersistent and heavy
pinging,which can cause severe damage to engine.
Your vehicle may experience slight ‘engine knock’when driving up steep hillsor when you accelerate.
See your GO-4 dealer if your vehicle:
1. Still ‘knocks’ heavily under all driving conditions.
2. Vehicle ‘knocks’ lightly while you are driving at cruising speed on level ground.
Running Out of Gas : If your vehicle runs out of gas, try to stop on level ground. Add at least two
gallons to start aga
Contact Westward Industries for Manuals and Documentation. Do not copy.
turn the ignition to START for an extended time (not more than 15 seconds) before the fuel system starts to
pump gas from the tank to the engine.

17
Operation – cont’d
Tire Pressure Decal
Shows proper tire in ation rates depending on load for your GO-4. The information for in ation rates is
found on the VIN decal located on the front dash.
The tire in on pressure for front is 32psi and for the rear is 32 psi.
Towing
Tow the vehicle only on dollies (turn slowly and carefully) or on decks of trucks or trailers.
IMPORTANT: Failure to follow towing procedures may cause severe damage to critical vehicle parts.
Contact Westward Industries for Manuals and Documentation. Do not copy.

18
SERVICE AND MAINTENANCE
Engine Service
Routine service can be done by opening the rearcargo box lid using the latch. Forward of the cargo box is
an access cover for checking uid levels; coolant, engine oil and transaxle.
Improved access to the engine/transaxle is provided by removing the rear cargo box.
1. Open box lid by unlocking rear latch.
2. Unscrew and withdraw ‘wing nut stud’ that axes cargo box to frame.
3. You and another person lift the rear of the cargo box slightly, slide backward, and remove.
Re-install cargo box using opposite procedures of disassembly.
Air Cleaner Element
The air cleaner element is a dry type air cleaner. It is chemically treated, pleated paper-air-ltering element
which permits air ow through the air induction system, ltering out unwanted dust, dirt, and debris.
Replace air lter every 30,000 miles (1000 hours). Replace every 15,000 miles (500 hours) or whichever
comes rst under severe operating conditions.
Access to air lter is done by:
1. Remove the cargo box (or slide rearward for access) as above.
2. Release the two latches on air cleaner housing cover.
3. Lift the air cleaner housing cover and air cleaner element.
4. Remove the air cleaner element.
5. To install, reverse the removal procedure.
Engine Oil
Proper amount of oil in the engine is important for safe operation. Check every time you add fuel to your
vehicle. For accurate reading make sure the vehicle is on a level surface and the oil is warm.
Check oil
1. Turn o engine after the oil is warm (2-3 minutes of running).
2. Locate the oil dipstick, on the side of engine.
3. Pull out dipstick, wipe clean and replace.
4. Pull out dipstick once again and read it. If the oil level is below the letter “F” or reads at 0.8L, add
oil until it reads at the line below “F”.
Adding Oil
1. Locate the oil ller cap on top of engine. Remove it.
2. Add desired amount of oil.
3. Let it sit a couple of minutes and recheck oil (as above) to insure proper level.
4. Replace ller cap.
Choosing the Right Viscosity Grade
You must consider the temperature in which you drive your GO-4. If you regularly drive in
temperatures that are below 100 F (38 C), use SAE 5W-20/GF4&SM oil. If you drive regularly at
temperatures above 100 F (38 C), use SAE 10W30 oil. If you regularly drive in temperatures that
are below 20 F (-10 C), use SAE 5W20 oil.
Service and Maintenance – cont’d
Contact Westward Industries for Manuals and Documentation. Do not copy.

19
Oiland Filter Change Intervals
The engine oil and engine oil in the GO-4 should be changed every 6,000 miles (8,000 Km)
or every 12 months under the Normal Maintenance Schedule.
However, if the use of the GO-4 includes:
1. Extended periods of idlingor low speed driving.
2. Operating in gritty or industrial conditions.
3. Majority of operation is in stop and go city tra, or short trips (less than 10 minutes).
4. Operation in sub-freezing temperatures.
Then engineoil and ed everyegnahcebdluohs 2,000 miles (4,000 Km) or 6 months
wh
*Please note: Any GO-4 used for parking patrol, security, tra c and or law enforcement must follow maintenance
under severe usage conditions.
OilChange
1. Drain oil by removing the oil cap and drain plug while the engine is warm.
2. Replace the drain plug tightly after the oil has been thoroughly drained.
3. the engine with new oil to the “F” level marked on the dipstick.
4.
Oil Filter
lter with a suitable wrench.
2. Use a clean rag to wipe of the mounting surface on
the engine.
3. Apply a small amount of new engine oil on to the
bber
4. Instal lter and hand tighten. Do not use a
wrench.
5. Start th e engine and inspect arolter
mark if necessary.
Oil Filter
Oil Filler cap
Oil Dipstick
Oil Capacity
Total: 3.2L (3.38USqt, 2.81 Impqt)
Oil pan: 2.7L (2.85USqt, 2.37 Impqt)
2.9L (3.06USqt, 2.55 Impqt)
Contact Westward Industries for Manuals and Documentation. Do not copy.
