WFS TNT-10 User manual

INSTRUCTION MANUAL
MODEL #: TNT-10
Double check the tent poles are secure in the eyelets.
All stakes are secured into the ground.
Rainfly is securely attached to rings.
FINAL CHECK LIST
ONLINE VIDEO
WORLDFAMOUSSPORTS.COM
[phone]
(833) WFS-1234
For any questions or concerns please call our toll free customer service line.
Please watch our online video for further help.
SCAN ME

IMPORTANT
PARTS
ASSEMBLY
AB
C D E
PARTS IDENTIFICATION:
A.
B.
C.
D.
E.
Treat your tent seams with waterproofing. Set up your tent at home before your first camping trip. A dark campsite is no place
to learn how to assemble your WORLD FAMOUS SPORTS tent. Read assembly instructions with care. When selecting a
campsite, make sure you find a flat area with good drainage free from all sharp objects. Protect your investment.
Tent ........(1)
Rainfly ........(1)
Shock Corded Fiber Glass Poles.. (6)
(4 regular, 2 curved rainfly poles)
Steel Poles........ (8)
Tent stakes ........ (6)
This product can expose you to chemicals including Diethylhexyl Phthalate,
which is known to the state of California to cause cancer, birth defects, or
other reproductive harm. For more info go to: www. P65Warnings.ca.gov
1
3
2
STEP 1: Unfold and spread the tent out on a clear
camp area. Remove all stones and sharp objects.
STEP 2: Assemble all shock corded poles/ steel
poles by unfolding and slipping shafts together.
STEP 3: Lay the two longer poles assemblies across the
tent to form an “X” across the tent. Run the assembled pole
sections through the sleeves and insert the poles through the
“red” color coated prong attached to the tent.
2
52
STEP 5: To erect the tent, insert the “white” color coated
steel pole into the “white” color coated side of the prongs on
the corners of the tent. Then insert the pin and ring attached
on the corner of the tent into the open metal ferrule at the end
of the pole assembly to secure the tent(repeat for all 4 corners)
STEP 6: Fasten the tent clips to the pole assembly
for further security.
6
4
STEP 4: Insert the “yellow” color coated steel pole into
the “yellow” color coated side of the prongs on both sides
of the tent. (repeat for both sides)
6
6
5 2
STEP 9: Securely attach the rainfly to each leg of the tent with
the plastic hook, then insert tent Stake into the ground through the
small pin and ring on each corner of the tent and middle of bottom.
6
7
STEP 7: Slide the remaining fiber glass poles through the
orange sleeves located on the top of the tent and secure them
in the prong with the “green” coated tape to erect the roof.
STEP 8: Insert the remaining steel poles through
the “green” color coated prong to secure the middle of
the tent. (Repeat for both sides)
89
8
5
