WFS 733 Manual

SET UP INSTRUCTIONS FOR :
Style: 733
When you are Ready To Set up your Tent
-Select a level campsite clear of rocks and other
hard or sharp objects.
-Do not set up your tent under trees.
-For best results in windy conditions, do not
position the door of tent into the wind.
Layout & Positioning of
Tent, Pole Assembly
-Layout and position tent with door facing
desired direction. (illus. 1)
-Unzip door
--Stake down tent corners only, using the
rings at the end of stake loops. (illus.2)
Keep the floor taut.
-Assemble frame poles by interlocking
shock corded poles..
-Inert the poles diagonally into pole
sleeves. The center of the poles should
cross forming an “X” in the middle of tent
(illus.1)
Connect Frame to Tent
-Insert one end of main tent pole onto
pin of pin & ring system, at tent
corner.(illus.3)
-Go to opposite end of pole and
gradually apply pressure to the pole
forming an arch until you are able to
insert the pin into the pole.
-Repeat for second pole.(illus.4)
Illus. 4
Tent frame set-up
(2) Main Tent
Poles
(2) Rainfly
Poles

Attach Tent to Frame
Using Frame Clips
-Attach frame clips along the edges of
tent to frame poles. (illus. 5 and 6 )
-Make any adjustments to the tent
corner stakes that are needed.
Illus. 5
Frame Clips
Illus. 6
Assambled tent without rainfly
Attach Rainfly
Assemble rainfly pole by interlocking
shock-corded pole.
-Insert rainfly pole into reinforced
pockets located at the center edges of
the underside of rainfly.(illus.7 and 8)
-Attach underside of rainfly to the rainfly
pole. (illus.8)
-Drape rainfly over tent frame, pole side
down. Rainfly pole should point out over
door and rear window.
-Connect the four elastic loops with “S”
hooks,(found at the rainfly corners) to
the four rings at the corners of the tent.
-Secure rainfly with attachments located
on underside of fly (illus. 9)
IMPORTANT: TREAT YOUR TENT SEAMS S/WATERPROOFING
Set up your tent at home before your first camping trip. A dark campsite is no place to learn how to
assemble your WORLD FAMOUS SPORTS tent. Read assembly instructions with care. When selecting a
campsite, make sure you find a flat area with good drainage free from all sharp objects. Protect your
investment.
