Whale AK1005 Assembly Instructions

INSTALLATION & USER INSTRUCTIONS
Thank you for purchasing this Whale® product.
For over 70 years Whale has led the way in the design and manufacture of freshwater, bilge and waste management systems including plumbing, taps, showers and
pumps, for low voltage applications. The company and its products have built a reputation for quality, reliability and innovation backed up by excellent customer service.
Grey Waste Tank - Service Kits
The Grey Waste Tank enables the user to manage all grey waste on board easily, through one skin fi tting. The Intelligent Control sensor integrated into the tank lid
provides automatic operation of the grey waste pump. The sensor will detect water in the grey waste tank at a pre-determined level, and will automatically activate the
grey waste pump. When the tank is emptied, the switch will automatically turn the grey waste pump off . The 2 sensor models include a second sensor which can be
used to control a second grey waste pump. It is factory set to activate at a higher water level and will provide additional pumping capacity during periods of high infl ow to
the grey waste tank. Alternatively, the second sensor can be wired to a high level alarm, warning of a high water level within the grey waste tank.
Read the following carefully before installation.
WARNING: Please note that incorrect installation may invalidate warranty.
To the Fitter:
Check that the product is suitable for the intended application, follow these installation instructions and ensure all relevant personnel read the points listed below. Also
ensure that these operating instructions are passed on to the end user. The manufacturer cannot be held responsible for claims arising from incorrect installation,
unauthorised modifi cation or misuse of the product.
To the User:
Read the following instructions carefully.
The Grey Waste Tank is designed to collect grey shower waste water. If it is intended for use for any other purpose or with any other liquid, it is the user’s responsibility
to ensure that the tank and switch are suitable for the intended use and, in particular, that the materials are fully compatible with the liquids to be used. The integrated
Intelligent Control sensor is designed to operate at 12V d.c or 24V d.c. only. The sensor is suitable for use with pumps operating with current up to 20A, and is
recommended for use with Whale Gulper® 220 or Gulper® 320 grey waste pumps.
• With all applications, it is important that a system of safe working practice is applied to installation, use and maintenance. Ensure the electric supply is turned off and
that the waste water system is drained before installation.
• The Grey Waste Tank is designed for the storage of grey waste water in recreational marine vessels. Your warranty may be invalidated if the product is used
in other applications or outside the remit of the standards quoted on the packaging/product literature.
• WARNING: Installation must be carried out by a qualifi ed electrician. Improper wiring can cause a fi re resulting in injury or death. Suggested wiring information (Figure
1A and Figure 1B) is given as a guide only, and wiring must comply in accordance with the applicable electrical standards. Appropriate size fuses or circuit breakers
must be installed.
AK1005 / AK1006 / AK1007 / AK1008
1. SPECIFICATION
2. PRINCIPLES OF OPERATION
3. TO THE FITTER & TO THE USER
4. APPLICATION
5. WARNINGS
Model Grey Waste Tank - Service Kits
Product
Codes AK1005 AK1006 AK1007 AK1008
No. of Sensors 12
Voltage 12V d.c. / 24V d.c.
Electrical
Connections Tinned wire ends 1 x Deutsch DT06-3S-P012
2 x Deutsch
DT06-3S-P012 Tinned wire ends
Materials Seals: EPDM/Neoprene, Monprene®
Lid: Glass Filled Polypropylene, ABS, Polyurethane
Grey Waste Tank with Integrated Intelligent Control - Service Kits
Pump Model Recommended Automotive Fuse
Size (Amps)
Gulper 220 (12V dc) 5
Gulper 220 (24V dc) 2.5
Gulper 320 (12V dc) 10
Gulper 320 (24V dc) 5
Gulper IC (12V dc) 10
Gulper IC (24V dc) 5

Wiring: See Figure 1A or Figure 1B. For AK1006 and Ak1007 see also Figure 1C.
Instructions for Use
Once installed, turn on shower or tap to fi ll grey waste tank. Ensure the pump is operating and waste water is being removed from the tank. Note: If using a seacock,
ensure it is open before use.
QTY: 1 Grey Waste Lid with integrated sensor(s)
6. PARTS
7. INSTRUCTIONS FOR INSTALLATION
8. MAINTENANCE
Figure 1A Wiring Diagram - For Single Sensor Models Figure 1B Wiring Diagram - For Double Sensor Models
Figure 1C AK1006 / AK1007
Figure 2A AK1005 / AK1006 Figure 2B AK1007 / AK1008
For best performance, the sensor faces on the lid must be cleaned from debris/residue regularly, at least every 3 months. See Figure 3. Do not use an abrasive
cleaner.
Figure 3 Cleaning / Maintenance
The lid is not a serviceable part. The yellow cover must not be removed and doing so will invalidate warranty.
It is advisable to have an annual check on all plumbing and fi ttings to prevent leaks and blockages.
connect to grey waste pump
connect to high level alarm
or secondary grey waste pump
connect to gre
y
Primary sensor wires -
Connect to Grey Waste Pump
Primary sensor wires -
Connect to Grey Waste Pump
Secondary sensor wires -
Connect to high level alarm or
secondary Grey Waste Pump
Position Wire
A Positive from battery
B Not Used
C Positive to pump
C
B
A

The system must be fully drained, including the contents of the grey waste tank. If water is allowed to freeze in the system, serious damage to the plumbing, pump
and/or accessories may occur. Failures of this type will invalidate the warranty.
We hereby declare, under our sole responsibility, that the enclosed equipment complies with the provisions of the following EC Directives.
Electromagnetic Compatibility Directive 2004/108/EC on the approximation of the laws of the Member States relating to electromagnetic compatibility.
CE mark affi xed: May 2017
Basis on which conformity is declared - The above equipment complies with the protection requirements of the EMC Directive.
Standards applied
2013/53/EU Recreational Craft Directive
ISO10133:2012 Extra-low voltage DC Installation
EN55014-1:2006 EMC Emissions
EN55014-2:1997+A2:2008 EMC Immunity
EN28846 :1993 Ignition Protection
Richard Bovill
Engineering Director
9. TROUBLESHOOTING
Problem Possible Cause Potential Solution
Sensor fails to operate pump
No power to sensor Check power supply, leads and connections
Fuse has blown Replace fuse
Dirt/debris has covered sensor Carefully remove the lid from the tank, and clean debris
from the sensor faces - Figure 3
Pump is faulty Replace pump
Sensor is faulty Replace tank lid (see table Specifi cation for appropriate
service kit)
Sensor is operating pump continuously
Dirt/debris has covered sensor Carefully remove the lid from the tank, and clean debris
from the sensor faces - Figure 3
Tank not emptying water Check water supply level and pressure relief settings are
appropriate for the system
Incorrect wiring Check wiring Figures 1A / 1B
Sensor is faulty Replace tank lid (see table Specifi cation for appropriate
service kit)
Pump is faulty Remove pump and check non-return valve and remove any
debris. Replace non-return valve if necessary
