Wharfedale Pro Crystal-4.2 User manual

CRYSTAL 4 SERIES
Crystal-4.1
Crystal-4.2
Crystal-4.3
Crystal-4.4
Crystal-4.C
User's Manual

IMPORTANT SAFETY INFORMATION
This symbol indicates that there are important operating and maintenance
instructions in the literature accompanying this unit.
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
1
BEFORE INSTALLING THIS PRODUCT READ ALL THESE INSTRUCTIONS!
Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.
Before making any connections, switch all the units in your system o at the mains.
Set the volume control at minimum when you switch on your system or change sources and turn the level up
gradually.
DO NOT use your amplier at full volume.
Ensure that all loudspeakers in the system are correctly wired.
DO NOT subject your loudspeakers to excessive cold, heat, humidity or sunlight.
Loudspeakers should not be placed directly facing other hi- units, or share the same shelf or cabinet.
DO NOT place heavy objects on top of loudspeakers.
Some manufacturers forbid the placing of objects on top of their TV sets. Check your TV handbook before
installing the speaker directly on your TV set. Consult your TV dealer if you are in any doubt.
DO NOT connect speaker terminals to the mains supply.
DO NOT dismantle the loudspeaker. There are no user serviceable parts inside it and you will void the warranty.
Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in
anyway, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Caution: Changes or modications not expressly approved by the manufacturer could void the user’s authority to
operate this device.
Unpacking
After taking out the top packing piece, lift the loudspeakers from the carton. Do NOT lift a loudspeaker out using
the protective bad. After unpacking remove all the protective bags from the loudspeakers and store or dispose
of them safely.
The Crystal-4.3 and Crystal-4.4 are heavy. If you are unsure of your ability to unpack and manoeuvre them safely,
get someone to help you.
Check all items after unpacking. If any item is missing or damaged, immediately contact your Wharfedale dealer.
Retain the packaging. If you dispose of the packing, follow all recycling regulations in your area.

2
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
Preparing The Crystal-4.3 and Crystal-4.4 Loudspeakers
Place a soft cloth on the oor to protect the speaker.
Invert the loudspeaker and place it on the cloth.
Thread a locking nut two-thirds of the way up the
spike. Thread each spike assembly into a spike mount.
Tighten nger tight so that spike is secure but not
locked in place.
Levelling The Loudspeaker
Invert the loudspeaker and place int carefully on the
oor. If the oor is not perfectly level you will nd that
one spike is o the ground. Starting with this spike,
unscrew it so that it touches the oor. Move the other
spikes in and out so until the speaker is level front and
back and sideways. Now tighten the nuts to lock the
spikes rmly in position.
Spike Seats: A set of spike seats is provided for
sensitive oors. Place a seat under each spike before
you level the speakers.
Caution: Spikes Are Sharp
Make sure that there are no wires or hidden obstacles
that could be damaged by the spikes in the
immediate operational area of the speakers. NEVER
drag a loudspeaker on its spikes. Always lift it. If the
item is heavy get assistance.
Attaching The Spikes

3
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
Positioning Stereo Loudspeakers
The Crystal-4.3 and Crystal-4.4 are oor standing. We
suggest they are positioned at least 200mm from
the rear walls and 700mm from the side walls, facing
slightly inwards. The Crystal-4.1 and Crystal-4.2 maybe
stand or wall mounted or placed on a rigid shelf.
The bass extension will improve if smaller speakers
are operated closer to the rear walls. If the
loudspeakers are placed too close to the walls the
bass will increase but maybe boomy and indistinct. If
the loudspeakers are placed away from the
walls, the inward angle maybe increased by up to
40%, but this may restrict the width of the optimum
listening position.
A rule of thumb is that the listener should be as far
from the loudspeakers as they are from each other.
The speakers should be ideally positioned so that the
treble units are roughly at ear level to a seated listener.
As personal taste plays a large role, experiment
with dierent congurations and play a wide range
of programmes before nalising the position of your
speakers.

4
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
Positioning Home Cinema Loudspeakers
5.1 Positioning
Place the front speakers as shown. Front loudspeakers
should be placed away from the walls for best results.
Angling the speakers inward slightly will improve
stereo images but too extreme an angle will impair
the movie sound.
All the speakers with the exception of the Crystal-4.
C must be placed at least 450mm from a CRT TV. Flat
panels are unaected.
The Crystal-4.C centre speaker can be placed above
or below the TV screen.
Subwoofer room positioning is not critical but we
recommend that it is placed in front of the listening
seat. Never operate the subwoofer within 450mm of a
conventional TV screen.
The surround speakers should be placed above and
behind the listening seat. They may be mounted on
the side walls or on the rear walls but always behind
a listener. Do not operate them within 450mm of a
conventional CRT TV.
If the distance between the side walls is too great, you
could use a second pair of stand mounted or oor
standing loudspeakers, as the surround loudspeakers
placed as shown in the drawing opposite.
7.1 Positioning
If you are using a 7.1 system, the back loudspeakers
must be at least 1 metre behind the listening seat.
Wall Monting Positions
If you arewall mounting the centre and eects
loudspeakers we recommend that they be mounted
as shown.
The Crystal-4.1 has integral speaker mounts. To wall
mount the Crystal-4.C we recommend that you
consult your dealer to advise you on a suitable wall
bracket.
Wall mounting the centre loudspeaker below the
screen is not recommended unless the screen is
mounted signicantly above eye level. Consult your
TV user guide for preferred placement options.

5
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
Left Surround
Left Back
90º
110º
135º
150º
22º 30º
LFE
Centre
Right Back
Right Front
Left Front
Right Surround
(Single back channel
for 6.1sound)
Doby Labs Recommended 7.1 Placement
Wall Mounting The Crystal-4.1 Loudspeakers
The crossover terminal panel of the Crystal-4.1
loudspeaker is provided with an integral keyhole slot
for wall mounting. Wall mounting should be carried
out by licensed sound contractors or technicians
with appropriate qualications and experience. All
installations and wiring should comply with the
standards laid down by the competent authority
in the country and place of installation. Before you
attempt wall or ceiling mounting, ensure the surface
is stable and strong enough to support the weight of
the speaker and mounting hardware.
You will need 1 No.8 screw and matching wall plug
to attach each loudspeaker to the wall. These are
the responsibility of the installer who should supply
suitable xings for this purpose.
Drill one 6mm hole in the wall at a suitable height o
the oor. Fix a suitable No 8 round head screw rmly
into each hole using appropriate wall plugs. Leave
a stub of 7mm protruding from the wall. Align the
keyhole slot in the crossover panel over the screw
head and carefully lower the unit onto the screw.
Remove the loudspeakers from the wall ready for
connection. After connection they can be re-installed
on the wall.

6
Connecting Your Loudspeakers
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
40mm
8mm
Terminal Panels
All the loudspeakers are connected to the amplier
via a twin terminal connecting panel. The positive
terminal is located at the right of the panel and is
coded red, the negative terminal is coded black.
Cable Preperation:
Prepare a suitable length of loudspeaker cable for
each unit. Split the twin cores to a depth of about
40mm. Carefully strip the insulation from each
end, leaving about 8mm of bare wire. If the cable is
stranded, lightly twist together any loose strands.
Threading Cable
Unscrew a terminal. Thread the bared end of each
cable through the hole in the bottom of the terminal
post. Ensure that there are no loose strands which
may touch adjacent terminals. Retighten the terminal
securely.
Amplier – Speaker Connections:
Audio cable is polarised, with two cores of dierent colours, or often a coloured tracer or identication rib. We
suggest that you connect the coloured / striped wire to the red, positive terminals of your AV amplier. This will
ensure that all the loudspeakers are connected the correct way round and avoid set-up problems.
Connect each loudspeaker to the correct channel of your amplier or AV processor taking care to connect
the red (+) positive terminal of the speaker to the red, positive (+) terminal of the speaker output terminal of the
amplier and similarly with the black, negative (-) terminal. Use the connection diagrams on the next page to
help you.

7
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
Connecting Your Loudspeakers
T
F
EL
T
NOR
FTH
GI
R
T
NO
R
F
STEREO AMPLIFIER
ROOM PLACEMENT
R
L
RL
Stereo Connection
CENTRE
LL
RC
R
RIGHT LEFT
SURROUND LEFTSURROUND RIGHT
ROOM PLACEMENT
To Subwoofer
LR
C
SL SR
5 Channel Connection
7 Channel Connection

8
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
Setting Up A Stereo System
Ensure that the listening seat is central to the loudspeakers.
Play some music with which you are familiar. Adjust the speakers for the optimum performance. You will nd that
a few degrees more or less ‘toe in’ can eect the sound dramatically.
The sound should be well balanced with a rm bass. If the sound lacks denition or the bass is indistinct, the
Setting Up An AV System
Please read the relevant sections of your AV amplier manual and familiarise yourself with the various
issues. If you are unsure, consult your dealer for help.
Most digital AV processors require you to specify the size of speakers in all operational channels. These are
usually ‘Large’ or ‘Small’. Set all the bookshelf speakers to ‘Small’. This will direct all the bass in the system to the
subwoofer for clean, deep and louder bass. The oorstanding loudspeakers should be set to ‘Large’. It is normal
for a centre and eects speakers to be set to ‘Small’. Set the ‘Subwoofer’ option n the processor to ‘On’. If there is
no subwoofer in the system set all the speakers to ‘Large’ and set the subwoofer to ‘O’.
When the loudspeaker settings are nalised, put the AV amplier into its ‘Test’ mode (see your processor
instruction) and adjust the levels until all channels are equally loud.
Troubleshooting
IF YOUR LOUDSPEAKERS ARE NOT WORKING SATISFACTORILY, PLEASE WORK THROUGH THE TABLE BELOW BEFORE CONTACTING YOUR
DEALER FOR ASSISTANCE. BEFORE INVESTIGATING A PROBLEM, SWITCH OFF THE SYSTEM AT THE MAINS
Symptom Possible Cause
No Sound System not switched on; Speaker cables shorting terminals out; wrong source selected
Sound lacks bass content
Bass reproduction is indistinct
Front loudspeakers out of phase. Check all system connections and rectify.
Subwoofer not switched onl Subwoofer phase incorrected; Subwoofer crossover control too low
Excessive bass distortion at low volumes Subwoofer level set too high; LFE level set too high; Subwoofer incorrectly wired
Excessive or distorted bass at high levels System level set too high; Bass control set too high
Distortion / rattling at high levels System level too high; Objects too close or on top of speakers
Indistinct Sound; Poor localisation of eects.
Poor localisation of dialogue.
One or more loudspeakers is out of phase. Check all system connections and rectify.
(Read the manual for correct connection procedure)

9
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
Further Information
Care and Maintenance
If you play the speakers with the grilles o exercise
great care. NEVER touch drive units which are easily
damaged. The loudspeaker cabineys can be cleaned
with a damp cloth or with a spray furniture polish and
a soft cloth. Apply the spray sparingly to the cloth and
then polish the cabinet. Never apply spray directly to
the cabinet.
Guarantee & Service
In the unlikely event that your unit develops a fault
you should return it to the Wharfedale dealer using
the original packing to ensure safe shipping.
The terms of your guarantee may vary in dierent
countries but in all cases the guarantee excludes.
All damage caused through accident, misuse, wear
and tear, neglect, incorrect installation, adjustment or
repair by unauthorised personnel is not covered by
your warranty.
Wharfedale will not be liable for any consequential
damage, loss or injury, arising from or inconjunction
with this equipment.
Authorised Service Centres
UK
IAG UK LTD.
IAG House 13/14 Glebe Road, Huntingdon,
Cambridgeshire, PE29 7DL, England
Tel: [phone]
ASIA
IAG Group LTD.
Sanecore Industrial Park, Jiuwei, Xixiang, Shenzhen
China
Tel: [phone]
Additionally, Wharfedale retailers and global
distributors will be able to assist you on nding
authorised service centres worldwide. To nd your
Wharfedale distributor visit www.wharfedale.co.uk
Wharfedale has a policy of continuous product
development and reserves the right to change
specication without notice.
The name ‘Wharfedale’ is a registered trademark of
Wharfedale International Ltd. Wharfedale is a member
of the International Audio Group

10
USER INSTRUCTIONS: Crystal 4 Series USER INSTRUCTIONS: Crystal 4 Series
Specications
General description
Enclosure type
Transducer complement
Bass driver
Midrange driver
Treble driver
AV shield
Sensitivity (2.83V @ 1m)
Recommended amplier power
Peak SPL
Nominal impedance
Minimum impedance
Frequency response (+/-3dB)
Bass extension (-6dB)
Crossover frequency
Cabinet Volume (in litres)
Dimensions (mm)
Height (on plinth)
Width
Depth (with grille&terminal)
Carton size
Net weight
Gross weight
Finish
Crystal-4.1
Bookshelf Speaker
Bass Reex
2-way
100mm Woven Kevlar Cone
25mm Soft Dome
No
86dB
20-60W
95dB
8Ω Compatible
4.3Ω
75Hz - 20kHz
70Hz
3.4kHz
2.3L
194mm
141mm
(147+10)mm
382 x 225 x 280mm
2kg each
4.8kg/ctn
Black / Walnut / White
Crystal-4.2
Bookshelf Speaker
Bass Reex
2-way
125mm Woven Kevlar Cone
25mm Soft Dome
No
88dB
20-100W
96dB
8Ω Compatible
4.4Ω
60Hz - 20kHz
55Hz
2.6kHz
6.9L
265mm
180mm
(212+10)mm
475 x 300 x 385mm
4.2kg each
9.6kg/ctn
Black / Walnut / White
Crystal-4.3
Floorstanding Speaker
Bass Reex
3-way
165mm Polypropylene Cone
125mm Woven Kevlar Cone
25mm Soft Dome
No
88dB
25-120W
96dB
8Ω Compatible
3.7Ω
50Hz - 20kHz
45Hz
500Hz & 2kHz
7.5L&21L
(900+22)mm
205mm
(245+10)mm
1020 x 360 x 315mm
14.5kg each
16.2kg/ctn
Black / Walnut / White
Crystal-4.4
Floorstanding Speaker
Bass Reex
3-way
165mmPolypropylene Cone x2
125mm Woven Kevlar Cone
25mm Soft Dome
No
90dB
25-150W
102dB
8Ω Compatible
3.5Ω
40Hz - 20kHz
35Hz
460Hz & 2.7kHz
7.5L&23L
(950+22)mm
205mm
(245+10)mm
1070 x 360 x 315mm
15kg each
17kg/ctn
Black / Walnut / White
General description
Enclosure type
Transducer complement
Bass driver
Midrange driver
Treble driver
AV shield
Sensitivity (2.83V @ 1m)
Recommended amplier power
Peak SPL
Nominal impedance
Minimum impedance
Frequency response (+/-3dB)
Bass extension (-6dB)
Crossover frequency
Cabinet Volume (in litres)
Dimensions (mm)
Height (on plinth)
Width
Depth (with grille&terminal)
Carton size
Net weight
Gross weight
Finish
Crystal-4.C
Centre Speaker
Bass Reex
2-way
125mm Woven Kevlar Cone x2
25mm Soft Dome
Yes
89dB
25-100W
95dB
8Ω Compatible
4.2Ω
70Hz - 20kHz
65Hz
2.4kHz
8.2L
172mm
415mm
(192+10)mm
495 x 280 x 260mm
6.8kg each
8kg/ctn
Black / Walnut / White
Modle
Modle

IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
Tel: [phone] Fax: [phone] www.wharfedale.co.uk
IAG reserves the right to alter the design and specications without notice. All rights reserved IAG Group Ltd.
Wharfedale is a member of the International Audio Group. CODE: WH14-MNL006a
