Whelen Engineering Company Inner Edge XLP 01-0687417-1 Series User manual

Page 1
©2013 Whelen Engineering Company Inc.
Form No.14675E (040319)
Automotive: Lightbars
For warranty information regarding this product, visit www.whelen.com/warranty
• Proper installation of this product requires the installer to have a good understanding of automotive electronics, systems and procedures.
• Whelen Engineering requires the use of waterproof butt splices and/or connectors if that connector could be exposed to moisture.
• Any holes, either created or utilized by this product, should be made both air- and watertight using a sealant recommended by your vehicle
manufacturer.
• Failure to use specified installation parts and/or hardware will void the product warranty.
• If mounting this product requires drilling holes, the installer MUST be sure that no vehicle components or other vital parts could be damaged
by the drilling process. Check both sides of the mounting surface before drilling begins. Also de-burr the holes and remove any metal shards
or remnants. Install grommets into all wire passage holes.
• If this manual states that this product may be mounted with suction cups, magnets, tape or Velcro®, clean the mounting surface with a 50/50
mix of isopropyl alcohol and water and dry thoroughly.
• Do not install this product or route any wires in the deployment area of your air bag. Equipment mounted or located in the air bag deployment
area will damage or reduce the effectiveness of the air bag, or become a projectile that could cause serious personal injury or death. Refer to
your vehicle owner’s manual for the air bag deployment area. The User/Installer assumes full responsibility to determine proper mounting
location, based on providing ultimate safety to all passengers inside the vehicle.
• For this product to operate at optimum efficiency, a good electrical connection to chassis ground must be made. The recommended
procedure requires the product ground wire to be connected directly to the NEGATIVE (-) battery post (this does not include products that use
cigar power cords).
• If this product uses a remote device for activation or control, make sure that this device is located in an area that allows both the vehicle and
the device to be operated safely in any driving condition.
• Do not attempt to activate or control this device in a hazardous driving situation.
• This product contains either strobe light(s), halogen light(s), high-intensity LEDs or a combination of these lights. Do not stare directly into
these lights. Momentary blindness and/or eye damage could result.
• Use only soap and water to clean the outer lens. Use of other chemicals could result in premature lens cracking (crazing) and discoloration.
Lenses in this condition have significantly reduced effectiveness and should be replaced immediately. Inspect and operate this product
regularly to confirm its proper operation and mounting condition. Do not use a pressure washer to clean this product.
• It is recommended that these instructions be stored in a safe place and referred to when performing maintenance and/or reinstallation of this
product.
• FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE
AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS!
Warnings to Installers
Whelen’s emergency vehicle warning devices must be properly mounted and wired in order to be effective and safe. Read and follow all of Whelen’s written
instructions when installing or using this device. Emergency vehicles are often operated under high speed stressful conditions which must be accounted for
when installing all emergency warning devices. Controls should be placed within convenient reach of the operator so that they can operate the system without
taking their eyes off the roadway. Emergency warning devices can require high electrical voltages and/or currents. Properly protect and use caution around
live electrical connections.Grounding or shorting of electrical connections can cause high current arcing, which can cause personal injury and/or vehicle
damage, including fire. Many electronic devices used in emergency vehicles can create or be affected by electromagnetic interference. Therefore, after
installation of any electronic device it is necessary to test all electronic equipment simultaneously to insure that they operate free of interference from other
components within the vehicle. Never power emergency warning equipment from the same circuit or share the same grounding circuit with radio
communication equipment. All devices should be mounted in accordance with the manufacturer’s instructions and securely fastened to vehicle elements of
sufficient strength to withstand the forces applied to the device. Driver and/or passenger air bags (SRS) will affect the way equipment should be mounted. This
device should be mounted by permanent installation and within the zones specified by the vehicle manufacturer, if any. Any device mounted in the deployment
area of an air bag will damage or reduce the effectiveness of the air bag and may damage or dislodge the device. Installer must be sure that this device, its
mounting hardware and electrical supply wiring does not interfere with the air bag or the SRS wiring or sensors. Mounting the unit inside the vehicle by a
method other than permanent installation is not recommended as unit may become dislodged during swerving; sudden braking or collision. Failure to follow
instructions can result in personal injury. Whelen assumes no liability for any loss resulting from the use of this warning device. PROPER INSTALLATION
COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF EMERGENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF
EMERGENCY PERSONNEL AND THE PUBLIC.
Warnings to Users
Whelen’s emergency vehicle warning devices are intended to alert other operators and pedestrians to the presence and operation of emergency vehicles and
personnel. However, the use of this or any other Whelen emergency warning device does not guarantee that you will have the right-of-way or that other
drivers and pedestrians will properly heed an emergency warning signal. Never assume you have the right-of-way. It is your responsibility to proceed safely
before entering an intersection, driving against traffic, responding at a high rate of speed, or walking on or around traffic lanes. Emergency vehicle warning
devices should be tested on a daily basis to ensure that they operate properly. When in actual use, the operator must ensure that both visual and audible
warnings are not blocked by vehicle components (i.e.: open trunks or compartment doors), people, vehicles, or other obstructions. It is the user’s responsibility
to understand and obey all laws regarding emergency warning devices. The user should be familiar with all applicable laws and regulations prior to the use of
any emergency vehicle warning device. Whelen’s audible warning devices are designed to project sound in a forward direction away from the vehicle
occupants. However, because sustained periodic exposure to loud sounds can cause hearing loss, all audible warning devices should be installed and
operated in accordance with the standards established by the National Fire Protection Association.
Safety First
This document provides all the necessary information to allow your Whelen product to be properly and safely installed. Before beginning the installation and/or
operation of your new product, the installation technician and operator must read this manual completely. Important information is contained herein that could
prevent serious injury or damage.
WARNING: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For
more information, visit www.whelen.com/regulatory.
Installation Guide:
Inner Edge® XLP LC Interior Lightbar
5-Light (w/Take-Down) 6-Light (w/o Take-Down)
51 Winthrop Road
Chester, Connecticut 06412-0684
Phone: [phone]
Internet: www.whelen.com
Sales e-mail: [e-mail]
Customer Service e-mail: [email protected]
®
ENGINEERING COMPANY INC.

Page 2
IMPORTANT! The lightbar should be a minimum of 16" from radio antennas!
Installation / Standard:
1. Loosen (do not remove) the three screws securing the passenger-side visor swivel
bracket to the vehicle.
2. Remove screws securing vehicles visor clip and remove clip and hardware.
3. Secure the bracket to the Inner Edge housing using hardware provided (Fig. 1).
4. Position the keyed opening of the mounting bracket directly under the location of the
visor clip removed in step 2 and remount the visor clip in its original location using the
original hardware (Fig. 1). Silverado & Tahoe require a spacer (Fig. 1).
5. Firmly tighten any hardware loosened in this procedure.
6. Repeat this procedure for the driver-side assembly.
7. When properly mounted, the rubber seal will be in full contact with the vehicle
windshield and roof. This is to prevent light output from entering the passenger
compartment. When this has been achieved, tighten mounting hardware firmly.
8. Route the lightbar cable down the A-pillar to your control head. Make all wiring
connections using the information in the wiring diagram.
The Tahoe and Silverado have a retainer
which holds the headliner to the visor
clip that must be replaced with
the supplied spacer.
PASSENGER
SIDE
Under visor
swivel bracket Under
visor clip
Fig. 1
HEADLINER
VISOR CLIP
side view
VISOR CLIP
side view
VISOR CLIP
side view
SPACER
Explorer bracket
shown for example
Mounting
Bracket
ROOFROOF
#8-32 x 3/8 Torx
Hd Screw (QTY 2)
R
U
BBER
S
EAL
Lightbar Side ViewLightbar Side View
WI
N
DS
H
IE
L
D
SPACER
HEADLINER
BRACKET
10 X 1" PHILLIPS
PAN HD SHEET
METAL SCREW
(type A) (QTY 1)
#8-32 x 3/8 TORX HD
SCREW (QTY 2)
VISOR
SWIVEL
BRACKET
VISOR CLIP BRACKET
Fig. 2
SHEET METAL
HEADLINER
VISOR CLIP MOUNTING
BRACKET
SHEET
METAL
ROOF
RUBBER SEAL
Lightbar
Side View
WI
N
DS
H
IE
L
D
Side View
2. Loosen (do not remove) the screws securing the passenger-side visor
swivel bracket to the vehicle.
3. Slide the outside end of the mounting bracket under the visor swivel
bracket (Fig. 2). At the same time slip the rectangular hole in the other end
of the mounting bracket over the visor clip bracket. With the mounting
bracket in position re-tighten the visor swivel bracket hardware.
4. Using the screw hole in the mounting bracket as a guide, drill a pilot hole
into the sheet metal behind the headliner and secure other side of mounting
bracket using the supplied #10 X 1” PPHSMS.
5. Repeat this procedure for the driver-side assembly.
6. When properly mounted, the rubber seal will be in full contact with the
vehicle windshield and roof. This prevents light from entering the passenger
compartment. When this has been achieved, tighten all mounting hardware
firmly to maintain contact.
7. Route the lightbar cable down the A-pillar to your control head and make all
wiring connections using the information in the wiring diagram.
Wiring:
Wiring Diagram
To +12VDC
(fuse ea. @ 1A
WHT/GRN
BROWN
BLUE
ORANGE
WHT/BLK
WHT/ORG
BLK
RED
Scan-Lock
Low Power
Flash 1
CA Steady
Take-Downs
Flashing T-D
Ground (-)
+12VDC
All Fuses & Switches Customer Supplied
Fuse
(5 Amp)
Wire Color Function
Momentary Switch
SPST Switch
SPST Switch
SPST Switch
SPST Switch
SPST Switch
(+)
Battery
(-)
WARNING! All customer supplied wires that connect to the positive
terminal of the battery must be sized to supply at least 125% of the
maximum operating current and FUSED at the battery to carry that load.
DO NOT USE CIRCUIT BREAKERS WITH THIS PRODUCT!
Operation:
8-conductor cable. All functions listed here may not be present in all
lightbars.
WHT/GRN (Scan-Lock™) - The WHT/GRN wire allows you to choose from a
variety of flash patterns. A light must be activated to change the pattern.
TO CYCLE THROUGH ALL PATTERNS: To cycle forward apply +12 VDC to
the WHT/GRN wire for less than 1 second and release. To cycle backward
apply +12 VDC to the WHT/GRN wire for more than 1 second and release.
TO SET A PATTERN AS DEFAULT: When the pattern is displayed, allow it to
run for 6 seconds. The lighthead will now display this pattern when active.
TO RESET TO THE FACTORY DEFAULT PATTERN: Turn off power and
apply +12 VDC to the WHT/GRN wire while turning power on.
A normally open momentary switch is best suited for Scan-Lock
operation.
BLU (Flash 1) - Apply +12 VDC to the BLUE wire to activate the warning lights.
Fuse wire @ 1 Amp.
BRN (Hi/Low Power) - This feature places the lightbar in low power for night
time use. Fuse wire @ 1 Amp. A single pole / single throw switch can be used
to control Hi/Low power.
To activate Low power: Apply +12 VDC to the BRN wire. To restore regular
power: Remove the BRN wire from +12 VDC.
WHT/BLK (Take-Down) - Apply +12 VDC to the WHT/BLK wire to activate the
take-downs (5-light models only). Fuse this wire @ 1 Amp.
WHT/ORG (Flashing Take-Down) - Apply +12VDC to the WHT/ORG wire to
activate flashing take-down mode (5-light models only). Fuse this wire @ 1
Amp. Note: The WHT/BLK wire overrides this display.
ORG (California Steady) - Apply +12 VDC to the ORG wire to activate lights
using the California Steady pattern table (next page). Refer to the following
page for lighthead identification. Fuse wire @ 1 Amp. NOTE: Due to firmware
requirements, there are several ‘null’ patterns (no lighthead active) that
precede Pattern 1. Repeated Scan-Lock activations may be required
before Pattern 1 selection is achieved.
Installation / Caprice:
1. Secure the mounting bracket to the Inner Edge housing using the two #8 - 32 X 3/8
TORX HEAD SCREWS provided (Fig. 2).
PASSENGER SIDE (Top View)
PT-D P5 P4 P3 P2 P1
(or P6)
California Steady Pattern Table:
Active Lightheads
1. P1
2. P2
3. P3
4. P4
5. P5
6. P6 (6 Light models only)

Page 3
Installation 2013 Ford Fusion:
IMPORTANT AIR BAG WARNING! Do not install this product or route any
wires in the deployment area of your air bag. Equipment mounted or
located in the air bag deployment area will damage or reduce the
effectiveness of the air bag, or become a projectile that could cause
serious personal injury or death. Refer to your vehicle owners manual for
the air bag deployment area. The User/ Installer assumes full
responsibility to determine proper mounting location, based on providing
ultimate safety to all passengers.
IMPORTANT! The lightbar should be located a minimum of 16" from any
radio antennas!
Note: When routing the wires, it is important to choose a path that will
keep the wires away from excessive heat or any vehicle equipment that
could compromise the integrity of the wires (ex. trunk lids, door jams,
etc.)
Figures 1 thru 3 show the driver side of the interior of the vehicle, shown
looking up at the roof.
1. On the driver side visor swivel bracket, carefully pry the plastic cover off
the front of the bracket (Fig. 1). The lightbar mounting bracket will sit in
the space that the cover occupied. NOTE: Pry the cover off using two
flat blade screwdrivers on each side to avoid braking the cover. The
cover will not be used but should be saved in case you wish to
remove the lightbar in the future.
Available Flash Patterns:
1. ActionScan™
2. SignalAlert™ 75 Alternating
3. SignalAlert™ 75 Multi.
4. CometFlash® 75 Alternating
5. CometFlash® 75 Multi.
6. DoubleFlash 75 Alternating
7. DoubleFlash 75 Multi.
8. SingleFlash 75 Alternating
9. SingleFlash 75 Multi.
10.LongBurst™ 75 Alternating
11. LongBurst™ 75 Multi.
12.SingleFlash 60 Alternating
13. SingleFlash 60 Multi.
14.SingleFlash 90 Alternating
15. SingleFlash 90 Multi.
16.SingleFlash 120 Alternating
17.SingleFlash 120 Multi.
18.‘SingleFlash 240 Alternating
19. SingleFlash 240 Multi.
20.DoubleFlash 120 Alternating
21.DoubleFlash120 Multi.
22.ActionFlash™ 75 Alt.
23.ActionFlash™ 75 Multi.
24.ActionFlash™ 150 Alt.
25. ActionFlash™ 150 Multi.
26. MicroBurst™ Alternating
27.MicroBurst™ Multi.
28. PingPong™ Alternating
29.PingPong™ Multi.
30. FlimFlam Alternating
31.FlimFlam Multi.
32.ModuFlash™ Alternating
33.ModuFlash™ Multi
34.Cylon 1
35.Cylon 2
36.Cylon Chaser
37.Eyeballs Sync
38.Eyeballs In/Out
39.2 Eyeballs In/Out
40.Eyeballs Crazy
DRIVER SIDE DOOR
Pry plastic
cover off
VISOR SWIVEL
BRACKET
WINDSHIELD
Remove screw
and visor clip
VISOR
CLIP
MOUNTING CLIP
(remove)
V
I
S
O
R
Fig. 1
WINDSHIELD
2. Remove the swivel bracket mounting clip (located under the cover you
removed in step 1) and lift the swivel bracket assembly out. Install the
supplied fastex grommet into the hole in the roof sheet metal which the
clip snapped into. Reinsert the swivel bracket assembly (Figs. 1 & 2).
Install Faston grommet
into existing hole in roof
that clip snapped into.
Fig. 2
3. On the vehicle visor clip, remove the screw holding on the clip and
remove the clip. The supplied #8 X 1" sheet metal screw will replace the
screw you removed (Fig. 2).
Re-install visor clip over bracket
using supplied #8 X 1" sheet metal screw
Install into Faston grommet using
supplied 1/4 X 1-1/4" PPHSMS
Install into Faston grommet using
supplied 1/4 X 1-1/4" PPHSMS
Install into Faston grommet using
supplied 1/4 X 1-1/4" PPHSMS
MOUNTING
BRACKET
Fig. 3
Fig. 4
When properly mounted, the rubber seal should be in full
contact with the vehicle windshield. The rear of the lightbar
should be in contact with the roof. This is to prevent light
from entering the passenger compartment. When this has
been achieved, tighten mounting hardware firmly to
maintain contact.
Mounting
Bracket
ROOF
#8-32 x 3/8 Torx Hd
Screw (QTY 2)
WI
N
DS
H
IE
L
D
RUBBER SEAL
Lightbar
Side View
Lightbar
Side View
Lightbar
Side View
Fig. 5
ROOF SHEET METAL
SCREW
GROMMET
HEADLINER
VISOR
SWIVEL
BRACKET
LT BAR BRACKET
MOUNTING TAB
4. Secure the mounting bracket to the lightbar and position the bracket
where it will mount on the vehicle (Figs. 3 & 4).
5. Secure the lightbar bracket to the swivel mount using the supplied 1/4 X
1-1/4” Phillips Pan Head Sheet Metal Screw. This screw will thread into
the fastex grommet you installed in step 2 and the bracket will sit where
the cover was (Fig. 5).
6. Line the rectangular hole in the other end of the lightbar bracket, up with
the visor clip and install the visor clip over the lightbar bracket using the
supplied #8 X 1” Sheet Metal Screw (Fig. 3).
7. Make sure all mounting hardware is tightened firmly and repeat procedure
for the passenger side of the vehicle.
Extend the cables and connect to power. Refer to the lightbar manual for wiring
and fusing information.

Page 4
2013 - TAHOE/SUBURBAN/ALL PICKUPS
11-26E645-007
07-287449-023
11-36E644-007
1
1
1
COVER, TOP PASS 12 CHEVY TAHOE INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS THOE INNER EDGE XLP BLACK
A
B
C
14-08228C-0604
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
D
BASE, HOUSING, PASS 12 TAHOE INNER EDGE XLP BLACK
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-B_ FINAL, INNER EDGE XLP, 5/6 LIGHT
2014 - TAHOE/SUBURBAN/ALL PICKUPS
11-26F642-007
07-287726-023
11-36F641-007
COVER, TOP PASS 14 CHEVY TAHOE INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS THOE INNER EDGE XLP BLACK
14-08228C-060
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
BASE, HOUSING, PASS 14 TAHOE INNER EDGE XLP BLACK
1
1
1
A
B
C
4D
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-D_ FINAL, INNER EDGE XLP, 5/6 LIGHT
2013 - CAPRICE PPV
A
B
C
D
E
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-9_
11-26E493-007
07-287419-023
11-36E494-007
COVER, TOP PASS 12 CAPRICE INNER EDGE XLP BLACK
BASE, HOUSING PASS 12 CAPRICE INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS CAPRICE INNER EDGE XLP BLACK
FINAL, INNER EDGE XLP, 5/6 LIGHT
14-08228C-06D
15-10141B-162
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
SCREW, 10 X 1" PPH SMS TYPE A SS BLACK OXIDE
1
1
1
2
1
PART NUMBER
01-0687417-A_
*
QTY ITEM DESCRIPTION
E
A
C
B
D
F
2014 - IMPALA
FINAL, INNER EDGE XLP, 5/6 LIGHT
G
1
1
1
2
11-26G261-107
11-26G261-007
07-287946-123
07-287946-023
11-36G260-007
11-36G260-107
BASE, HOUSING, DRVR 2014 IMPALA INNER EDGE XLP BLK
COVER, TOP DRVR 2014 CHEVY IMPALA INNER EDGE XLP BLK
COVER, TOP PASS 2014 CHEVY IMPALA INNER EDGE XLP BLK
BRACKET, VISOR MT DRVR IMPALA INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS IMPALA INNER EDGE XLP BLACK
14-08228C-060 SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
BASE, HOUSING, PASS 2014 IMPALA INNER EDGE XLP BLK
PART NUMBER
01-0687417-G_
11-26J271-107
11-26J271-007
07-288558-123
07-288558-023
11-36J270-007
11-36J270-107
*
QTY ITEM
1
1
1
DESCRIPTION
BASE, HOUSING, DRVR SILVERADO 2019 INNER EDGE XLP BLK
COVER, TOP DRVR 19 SILVERADO LC INNER EDGE XLP BLK
COVER, TOP PASS 19 SILVERADO LC INNER EDGE XLP BLACK
BRACKET, VISOR MT DRV SILVERADO 2019 INNER EDGE XLP BLK
BRACKET, VISOR MT PAS SILVERADO 2019 INNER EDGE XLP BLK
E
A
C
B
D
F
2019 - SILVERADO 1500
FINAL, INNER EDGE XLP, 5/6 LIGHT
14-08228C-0602 SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
G
BASE, HOUSING, PASS SILVERADO 2019 INNER EDGE XLP BLK
PART NUMBER KEY
01-0687417-__
YEAR/MAKE
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G
H
=2013 TAURUS/INTERCEPTOR
2013 EXPLORER/SUV INTERCEPTOR=
2013 F150=
2013 F250-550=
=2013 EXPEDITION
2013 CHARGER=
2013 RAM 1500=
2013 DURANGO=
2013 CAPRICE PPV=
2014 IMPALA=
2013 TAHOE/SUBURBAN/ALL PICKUPS=
2013 FUSION=
2014 TAHOE/SUBURBAN/ALL PICKUPS=
2015 F150=
2018 EXPEDITION=
2019 SILVERADO 1500=
= 2020 EXPLORER/SUV INTERCEPTOR
VERSION: 1 = 5-Light (w/TD)
6-Light (w/oTD)2 =
A
C
B
2
3
7
3
2120
24
22 23
19
10
D
2
NOTE: There are Passenger and Driver specific
lightheads.NOTE:
NOTE: Mounting brackets and hardware not shown.
1514
18
16 17
13
continued on next page
2
3
ITEM PART NUMBER DESCRIPTION
QTY QTY
10
18
13
19
14
20
15
21
16
22
17
23
4
5
6
7
8
9
01-0687417-_1
FINAL ASSY, INNER EDGE XLP, LOW CURRENT 5 LT W/TD
14-08228C-06D
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
39-1M17672-08
HOUSING, PLUG 8 POS 18 AWG SL-156 W/ LOCKING RAMP
46-0743403-00
ASS'Y, CABLE 9/C 18 GA TPR 20' SL-156 SCKTS ONE END
26-0215001-06
TY WRAP, 6" BLACK - Not Shown
01-026E492-00 SUB ASSY, LC I/O INNER-EDGE XLP
46-076E495-00 ASSY, HARNESS PASSENGER INNER EDGE XLP
46-076E495-01
ASSY, HARNESS DRIVER INNER EDGE XLP
01-026E488-31 SUB ASSY, TAKE DOWN WHITE INNER-EDGE XLP (DRIVER)
01-026E488-10 SUB ASSY, WARNING AMB INNER-EDGE XLP (DRIVER)
01-026E488-20 SUB ASSY, WARNING BLU INNER-EDGE XLP (DRIVER)
01-026E488-30 SUB ASSY, WARNING WHT INNER-EDGE XLP (DRIVER)
01-026E488-40 SUB ASSY, WARNING GRN INNER-EDGE XLP (DRIVER)
01-026E488-50
SUB ASSY, WARNING RED INNER-EDGE XLP (DRIVER)
01-0687417-_2
FINAL ASSY, INNER EDGE XLP, LOW CURRENT 6 LT W/O TD
38-0546827-14
TRIM, SEAL HOUSING/WINDSHIELD 13.600" LENGTH INNER EDGE XLP
SCREW, 4-40 X 1/4 PPHMS 410SS BLACK PASSIVATE 14-040216-04H
01-026E488-12
SUB ASSY, WARNING AMB INNER-EDGE XLP (PASS)
01-026E488-22 SUB ASSY, WARNING BLU INNER-EDGE XLP (PASS)
01-026E488-32 SUB ASSY, WARNING WHT INNER-EDGE XLP (PASS)
01-026E488-42 SUB ASSY, WARNING GRN INNER-EDGE XLP (PASS)
01-026E488-52 SUB ASSY, WARNING RED INNER-EDGE XLP (PASS)
01-026E488-33 SUB ASSY, TAKE DOWN WHITE INNER-EDGE XLP (PASS)
24
4
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
14 14
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R

Page 5
2013 - TAURUS/INTERCEPTOR
11-36E485-007
07-287414-023
11-26E484-007
1
1
1
BASE, HOUSING PASS 12 TAURUS INNER EDGE XLP BLACK
COVER, TOP PASS 12 TAURUS INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS TAURUS INNER EDGE XLP BLACK
A
B
C
14-08228C-06D4
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
D
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-1_ FINAL, INNER EDGE XLP, 5/6 LIGHT
2013 - F250-550
A
B
C
D4
1
1
1
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
14-08228C-06D
BRACKET, VISOR MT PASS BLK F-250/350 INNER EDGE XLP
BASE, HOUSING PASS BLACK 13 F-250/350 INNER EDGE XLP
COVER, TOP PASS BLACK 2013 F-250/350 INNER EDGE XLP
11-36E848-007
07-287511-023
11-26E872-007
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-4_ INNER EDGE XLP, 5/6 LIGHT
2013 - F150
A
B
C
D
1
1
1
4
11-26E830-007
07-287501-023
11-36E829-007
COVER, TOP PASS BLACK 13 FORD F-150 INNER EDGE XLP
BASE, HOUSING PASS BLK 13 FORD F-150 INNER EDGE XLP
BRACKET, VISOR MT PASS BLK 13 FORD F-150 INNER EDGE XLP
14-08228C-06D
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
1
1
4
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-3_ FINAL, INNER EDGE XLP, 5/6 LIGHT
2013 - EXPLORER/SUV INTERCEPTOR
11-26E299-007
07-287371-023
11-36E300-007
1
1
1
COVER, TOP PASS BLACK 13 FORD SUV INNER EDGE XLP
BASE, HOUSING PASS BLACK 13 FORD SUV INNER EDGE XLP
BRACKET, VISOR MT PASS BLK 13 FORD SUV INNER EDGE XLP
A
B
C
14-08228C-06D4
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
D
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-2_ FINAL, INNER EDGE XLP, 5/6 LIGHT
2013 - FUSION
A
B
C
D
E
F
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-C_
11-26E890-007
07-287529-023
11-36E891-007
COVER, TOP PASS FORD FUSION DUO INNER EDGE XLP BLACK
BASE, HOUSING PASS 2013 FUSION INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS FUSION INNER EDGE XLP BLACK
21-12081205-3
SCREW GROMMET, FASTEX # 212-240602-040101
15-131416-202 SCREW, 1/4 X 1 1/4 PPHSMS SS TYPE A
15-081416-160 SCREW, 8 X 1 PPHSMS
FINAL, INNER EDGE XLP, 5/6 LIGHT
1
1
1
1
1
1
B
D
F
G
ITEM PART NUMBER DESCRIPTION
QTY
FINAL, INNER EDGE XLP, 5/6 LIGHT
1
1
1
2
01-0687417-5_
2013 - EXPEDITION
11-26G032-007
07-287846-023
11-36G031-007
COVER, TOP PASS '14 EXPEDITION INNER EDGE XLP BLACK
BASE, HOUSING PASS EXPEDITION INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS EXPEDITON INNER EDGE XLP BLK
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
14-08228C-06D
2013 - RAM 1500
A
B
C
D
BASE, HOUSING PASS RAM 1500 INNER EDGE XLP BLACK
COVER, TOP PASS DODGE RAM 1500 INNER EDGE XLP BLACK
11-26E861-007
07-287518-023
11-36E862-007
BRACKET,VISOR MT PASS RAM 1500 INNER EDGE XLP BLACK
14-08228C-06D
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
1
1
1
4
E15-081416-160
SCREW, 8 X 1 PPHSMS
2
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-7_ FINAL, INNER EDGE XLP, 5/6 LIGHT
2013 - DURANGO
11-26F187-007
07-287616-023
11-36F186-007
COVER, TOP PASS DODGE DURANGO INNER EDGE XLP BLACK
BASE, HOUSING PASS 13 DURANGO INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS DURANGO INNER EDGE XLP BLACK
14-08228C-06D
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
1
1
1
A
B
C
4D
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-8_ FINAL, INNER EDGE XLP, 5/6 LIGHT
2013 - CHARGER
11-26E265-007
07-287356-023
11-36E264-007
1
1
1
COVER, TOP PASS 12 CHARGER INNER EDGE XLP BLACK
BASE, HOUSING PASS 12 CHARGER INNER EDGE XLP BLACK
BRACKET, VISOR MT PASS CHARGER INNER EDGE XLP BLACK
A
B
C
14-08228C-06D4
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
D
ITEM PART NUMBER DESCRIPTION
QTY
01-0687417-6_ INNER EDGE XLP, 5/6 LIGHT
PART NUMBER
01-0687417-E_
*
QTY ITEM DESCRIPTION
E
A
C
B
D
F
2015 - F150
FINAL, INNER EDGE XLP, 5/6 LIGHT
G
1
1
1
2
11-36G373-007
11-36G373-107
1
1
1
2
11-26G374-107
11-26G374-007
07-287988-123
07-287988-023
BASE, HOUSING DRIVER BLK 15 FORD F-150 INNER EDGE XLP
COVER, TOP DRIVER BLACK 15 FORD F-150 INNER EDGE XLP
COVER, TOP PASS BLACK 15 FORD F-150 INNER EDGE XLP
BASE, HOUSING PASS BLACK 15 FORD F-150 INNER EDGE XLP
BRACKET, VISOR MT DRVR BLK 15 FORD F-150 INNER EDGE XLP
BRACKET, VISOR MT PASS BLK 15 FORD F-150 INNER EDGE XLP
14-08228C-06D SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
PART NUMBER
01-0687417-F_
11-26J152-107
11-26J152-007
07-288533-123
07-288533-023
11-36J151-007
11-36J151-107
*
QTY ITEM
-
1
-
-
1
1
DESCRIPTION
BASE, HOUSING DRVR EXPEDITION INNER EDGE XLP BLACK
COVER, TOP DRVR '18 EXPEDITION LC INNER EDGE XLP BLACK
COVER, TOP PASS '18 EXPEDITION LC INNER EDGE XLP BLACK
BASE, HOUSING PASS EXPEDITION INNER EDGE XLP BLACK
BRACKET, VISOR MT DS EXPEDITION INNER EDGE XLP BLACK
BRACKET, VISOR MT PS EXPEDITION INNER EDGE XLP BLACK
E
A
C
B
D
F
2018 - EXPEDITION
FINAL, INNER EDGE XLP, 5/6 LIGHT
14-08228C-06D2
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE G
01-0687417-H_
11-26J429-107
11-26J429-007
07-288609-123
07-288609-023
11-36J428-007
11-36J428-107
BASE, HOUSING DRVR 2020 UTILITY INNER EDGE XLP BLACK
COVER, TOP DRVR 2020 UTILITY LC INNER EDGE XLP BLACK
COVER, TOP PASS 2020 UTILITY LC INNER EDGE XLP BLACK
BASE, HOUSING PASS 2020 UTILITY INNER EDGE XLP BLACK
BRACKET, VISOR MT DRVR 2020 UTILITY INNER EDGE XLP BLK
BRACKET, VISOR MT PASS 2020 UTILITY INNER EDGE XLP BLK
FINAL, INNER EDGE XLP, 5/6 LIGHT
14-08228C-06D
SCREW, 8-32 X 3/8" PAN TORX HD ROLOK SS BLACK OXIDE
PART NUMBER
*
QTY ITEM DESCRIPTION
E
A
C
B
D
F
2020 - EXPLORER/SUV INTERCEPTOR
G
1
1
1
2
1
1
1
2
