Installation Guide:
Radio Repeat / Airhorn
(P/N# 01-0864480-05)
©2006 Whelen Engineering Company Inc.
Form No.14065B (043008)
Automotive: Sirens/Switches
For warranty information regarding this product, visit www.whelen.com/warranty
DANGER! Sirens produce extremely loud emergency warning tones! Exposure to these tones without proper and adequate hearing protection, could
cause ear damage and/or hearing loss! The Occupational Safety & Health Administration (www.osha.gov) provides information necessary to determine
safe exposure times in Occupational Noise Exposure Section 1910.95. Until you have determined the safe exposure times for your specific application,
operators and anyone else in the immediate vicinity should be required to wear an approved hearing protection device. Failure to follow this
recommendation could cause hearing loss!
• Proper installation of this product requires the installer to have a good understanding of automotive electronics, systems and procedures.
• Whelen Engineering requires the use of waterproof butt splices and/or connectors if that connector could be exposed to moisture.
• Any holes, either created or utilized by this product, should be made both air- and watertight using a sealant recommended by your vehicle
manufacturer.
• Failure to use specified installation parts and/or hardware will void the product warranty.
• If mounting this product requires drilling holes, the installer MUST be sure that no vehicle components or other vital parts could be damaged
by the drilling process. Check both sides of the mounting surface before drilling begins. Also de-burr the holes and remove any metal shards
or remnants. Install grommets into all wire passage holes.
• If this manual states that this product may be mounted with suction cups, magnets, tape or Velcro®, clean the mounting surface with a 50/50
mix of isopropyl alcohol and water and dry thoroughly.
• Do not install this product or route any wires in the deployment area of your air bag. Equipment mounted or located in the air bag deployment
area will damage or reduce the effectiveness of the air bag, or become a projectile that could cause serious personal injury or death. Refer to
your vehicle owner’s manual for the air bag deployment area. The User/Installer assumes full responsibility to determine proper mounting
location, based on providing ultimate safety to all passengers inside the vehicle.
• For this product to operate at optimum efficiency, a good electrical connection to chassis ground must be made. The recommended
procedure requires the product ground wire to be connected directly to the NEGATIVE (-)
battery post (this does not include products that use cigar power cords).
• If this product uses a remote device for activation or control, make sure that this device is
located in an area that allows both the vehicle and the device to be operated safely in any
driving condition.
• It is recommended that these instructions be stored in a safe place and referred to when
performing maintenance and/or reinstallation of this product.
• FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT
IN DAMAGE TO THE PRODUCT OR VEHICLE AND/OR SERIOUS INJURY TO YOU AND YOUR
PASSENGERS!
CAUTION
Loud siren noise can cause
hearing damage and/or loss.
Refer to OSHA Section 1910.95 prior
to putting ANY siren into service!
Wear
Protection!
ACTIVATION OF THIS
SIREN MAY DAMAGE
UNPROTECTED EARS!
Warnings to Installers
Whelen’s emergency vehicle warning devices must be properly mounted and wired in order to be effective and safe. Read and follow all of Whelen’s written
instructions when installing or using this device. Emergency vehicles are often operated under high speed stressful conditions which must be accounted for
when installing all emergency warning devices. Controls should be placed within convenient reach of the operator so that they can operate the system without
taking their eyes off the roadway. Emergency warning devices can require high electrical voltages and/or currents. Properly protect and use caution around
live electrical connections.Grounding or shorting of electrical connections can cause high current arcing, which can cause personal injury and/or vehicle
damage, including fire. Many electronic devices used in emergency vehicles can create or be affected by electromagnetic interference. Therefore, after
installation of any electronic device it is necessary to test all electronic equipment simultaneously to insure that they operate free of interference from other
components within the vehicle. Never power emergency warning equipment from the same circuit or share the same grounding circuit with radio
communication equipment. All devices should be mounted in accordance with the manufacturer’s instructions and securely fastened to vehicle elements of
sufficient strength to withstand the forces applied to the device. Driver and/or passenger air bags (SRS) will affect the way equipment should be mounted. This
device should be mounted by permanent installation and within the zones specified by the vehicle manufacturer, if any. Any device mounted in the deployment
area of an air bag will damage or reduce the effectiveness of the air bag and may damage or dislodge the device. Installer must be sure that this device, its
mounting hardware and electrical supply wiring does not interfere with the air bag or the SRS wiring or sensors. Mounting the unit inside the vehicle by a
method other than permanent installation is not recommended as unit may become dislodged during swerving; sudden braking or collision. Failure to follow
instructions can result in personal injury. Whelen assumes no liability for any loss resulting from the use of this warning device. PROPER INSTALLATION
COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF EMERGENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF
EMERGENCY PERSONNEL AND THE PUBLIC.
Warnings to Users
Whelen’s emergency vehicle warning devices are intended to alert other operators and pedestrians to the presence and operation of emergency vehicles and
personnel. However, the use of this or any other Whelen emergency warning device does not guarantee that you will have the right-of-way or that other
drivers and pedestrians will properly heed an emergency warning signal. Never assume you have the right-of-way. It is your responsibility to proceed safely
before entering an intersection, driving against traffic, responding at a high rate of speed, or walking on or around traffic lanes. Emergency vehicle warning
devices should be tested on a daily basis to ensure that they operate properly. When in actual use, the operator must ensure that both visual and audible
warnings are not blocked by vehicle components (i.e.: open trunks or compartment doors), people, vehicles, or other obstructions. It is the user’s responsibility
to understand and obey all laws regarding emergency warning devices. The user should be familiar with all applicable laws and regulations prior to the use of
any emergency vehicle warning device. Whelen’s audible warning devices are designed to project sound in a forward direction away from the vehicle
occupants. However, because sustained periodic exposure to loud sounds can cause hearing loss, all audible warning devices should be installed and
operated in accordance with the standards established by the National Fire Protection Association.
Safety First
This document provides all the necessary information to allow your Whelen product to be properly and safely installed. Before beginning the installation and/or
operation of your new product, the installation technician and operator must read this manual completely. Important information is contained herein that could
prevent serious injury or damage.
WARNING: This product can expose you to chemicals including Methylene Chloride which is known to the State of California to cause cancer, and
Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
51 Winthrop Road
Chester, Connecticut 06412-0684
Phone: [phone]
Internet: www.whelen.com
Sales e-mail: [e-mail]
Customer Service e-mail: [email protected]
®
ENGINEERING COMPANY INC.

Page 2
RAD SPEAKERS
12
PWR
HF
T3
YELP
WAIL
MAN
PA
RAD
0
GRN YEL RED
PB9
PB8
PB7
PB6
PB5
PB4
HORN
MAN
123
Slide Switch Pos.
Mounting...
An aftermarket center console is recommended for the mounting location. This not only allows the driver to reach the controls easily, but also
keeps the unit safely out of the path of the vehicle’s SRS air bag. Follow the console manufacturer’s instructions for mounting information. If a
console mounting is not possible, a bail strap mounting kit for over or under dash mounting is included. The following steps will guide you through
the installation process.
Wiring...
WARNING! All customer supplied wires that connect to the positive terminal of the
battery must be sized to supply at least 125% of the maximum operating current
and FUSED at the battery to carry that load. DO NOT USE CIRCUIT BREAKERS
WITH THIS PRODUCT!
Power Wires (Heavy Gage Wires)
1. Extend the 2 heavy gage RED wires along the vehicle factory wire harness towards
the battery. It may be necessary to drill a hole in the firewall. If so, be absolutely sure
that there are no components that could be damaged by drilling. After the hole is
drilled, insert a grommet to protect the wires.
2. Install a 60 amp fuse block (user supplied) on the ends of each of these wires.
NOTE: Remove the fuse from the fuse block before connecting any wires to the battery!
3. Connect each fuse block wire to the POSITIVE (+) terminal on the battery. There must not be more than 2 feet of wire between the fuse
blocks and the battery. As the wire between the fuse and the battery is “unprotected”, do not allow this wire to come in contact with any other
wires!
Power Wires (Input Connector)
1. Insert the Siren Input Connector into its port.
2. Connect the 2 RED wires together and extend them toward the battery. Repeat for the 2 BLACK wires.
3. Install a 20 amp fuse block (user supplied) on the end of the RED wire from the siren connector.
NOTE: Remove fuse from fuse block before connecting any wires to the battery!
4. Connect the fuse block wire to the POSITIVE (+) terminal on the battery. There must not be more than
2 feet of wire between the fuse block and the battery. As the wire between the fuse and the battery is
“unprotected.” Do not allow this wire to come in contact with any other wires!
5. Connect the BLACK wire to the factory chassis ground typically adjacent to the battery.
Speaker Wires (Yellow, Orange & Brown Wires)
NOTE: This section outlines a two-speaker installation. If a one-speaker installation is used, cut and cap the ORANGE wire, skip steps 3 & 4.
1. Extend the YELLOW, ORANGE and BROWN wires to the vehicle siren speakers and connect as follows.
2. SPEAKER 1 -YELLOW wire to the POSITIVE speaker connection and BROWN to the NEGATIVE speaker connection.
3. SPEAKER 2 - ORANGE wire to the POSITIVE speaker connection.
4. Splice a wire from the NEGATIVE speaker connection on SPEAKER 1 to the NEGATIVE speaker connection on SPEAKER 2.
Radio Rebroadcast (Blue Wire (Optional))
NOTE: Radio rebroadcast will NOT work with amplified remote speakers! If your remote speaker is amplified (contains a power amp circuit in the
speaker assembly), do not enable the radio rebroadcast feature.
1. Locate the two wires that connect the external speaker to the vehicle’s two-way radio.
2. Cut one of these wires and splice one of the BLUE wires into this circuit.
3. Cut the remaining speaker wire and splice the remaining BLUE wire into this circuit.
Backlight (White/Yellow wire):
Connect this wire to a +12VDC source that is activated with the vehicle’s ignition switch (see wiring diagram).
PIN
1
2
3
4
5
6
7
8
9
10
11
12
COLOR & GAGE
RED 14GA
BLACK 14GA
BLUE 18GA
RED 14GA
BLACK 14GA
BLUE 18GA
BROWN 16GA
ORANGE 16GA
VIOLET 18GA
GREY 18GA
WHITE 18GA
YELLOW 16GA
FUNCTION
+ BATTERY
GROUND
RADIO
+ BATTERY
GROUND
RADIO
SPEAKER COM
+SPEAKER #2
+SPEAKER #1
SIREN INPUT CONNECTOR
Not Used
Not Used
Not Used
REAR VIEW OF 295HFSA6
Fig. 1
Siren Input
Connector
Siren Input
Connector
(Rear View)
Fuse
3 Pin Connector
Heavy gage red
wires to positive
terminal of battery.
Fuse @ 60 amps.
1211
10
987
6
5
4
3
2
1
READ BEFORE INSTALLING!!!
Do not install this product or route any wires in the deployment
area of your air bag. Equipment mounted or located in
the air bag deployment area will damage or reduce the
effectiveness of the air bag or become a projectile that could
cause serious personal injury or death. Refer to your vehicle
owner's manual for the air bag deployment area.
The User/Installer assumes full responsibility to determine the
proper mounting location, based on providing ultimate safety
to all passengers inside the vehicle. Whelen Engineering Co.
assumes no liability or responsibility for determining individual
applications or exact installation location criteria.

Page 3
Terminal Operation...
The unit contains 15 screw terminals located in the upper rear panel of the housing. These terminals have been designed to activate components
that do not exceed specific load ratings (current draw). It is important that any components connected to these terminals do not exceed the
maximum current rating for that terminal. The terminals are rated as follows:
Terminal #’s Max. Load Fuse Designation
#1 20 Amps F1
#2 20 Amps F2
#3, #4 & #5* 20 Amps (Total) F3
#6 10 Amps F4
#7 10 Amps F5
#8 10 Amps F6
#9 10 Amps F7
#11** 10 Amps
#12 10 Amps F8/F8A
#14** 10 Amps
#15 10 Amps F9/F9A
* Terminals #3, #4 & #5 can not be individually activated.
** Terminals 11 & 14 are always on unless otherwise noted.
Dip Switches...
In the default dip switch/fuse configuration the terminal outputs are enabled as follows:
Slide Switch Positions - Push-button Switches -
0 = Terminals OFF 4 = Terminal #6 ON
1 = Terminal #1 ON 5 = Terminal #7 ON
2 = Terminals #1 & 2 ON 6 = Terminal #8 ON
3 = Terminals #1, 2, 3, 4 & 5 ON 7 = Terminal #9 ON
8 = Terminal #12 ON / Terminal #11 OFF
9 = Terminal #15 ON / Terminal #14 OFF
See the “Custom Dip Switch Configurations” section for information on changing default
terminal control
Custom Dip Switch Configurations (Bank 1):
Slide Switch Functionality
In the default configuration the slide switch controls terminals 1 thru 5 (see the Term ina l
Specifications section for details). This configuration can be altered so that any
combination of these five terminals may be active or inactive in any of the 3 functioning
slide switch positions. The slide switch configurations are controlled by a dip switch bank
which is located on the top circuit board. Access is gained by removing 4 Torx-head
screws located at the 4 corners of the face plate. With these screws removed, slide the
chassis housing cover towards the rear of the unit. It is not necessary to slide this cover
more than a few inches, as the dip switch banks are located behind the control panel.
To help illustrate how to change default slide switch control, the following will outline how
configure the slide switch so that in position 2, only terminal 2 is enabled, while position 3
will only enable terminal 3.
SLIDE SWITCH POSITION 1 is controlled by dip switches 1, 2 & 3 on bank 1. Dip switch
1 (which controls Terminal 1) is in the on position, while dip switch 2 (which controls
Terminal 2) & dip switch 3 (which controls Terminals 3, 4 & 5) are in the off position. This
means that when the slide switch is in position 1, Terminal 1 alone becomes active.
SLIDE SWITCH POSITION 2 is controlled by dip switches 4, 5 & 6 on bank 1. Dip switch
4 (Terminal 1) is off, dip switch 5 (Terminal 2) is on and dip switch 6 (Terminals 3, 4 & 5) is
off. This means that when the slide switch is moved to position #2, Terminal 2 alone is
active, while Terminals 1, 3, 4 & 5 are inactive.
SLIDE SWITCH POSITION 3 is controlled by dip switches 7, 8 & 9 on bank 1. Dip switch
7 (Terminal 1) is off, dip switch 8 (Terminal 2) is off and dip switch 9 (Terminals 3, 4 & 5) is
on. This means that when the slide switch is moved to position 3, Terminals #3, 4 & 5 are
active, while Terminals 1 & 2 are inactive.
Enabling Siren Tones through Slide Switch Position #3: Slide switch position 3 can be configured to automatically activate siren tones, as
described in Rotary Switch Operations. If this is not desired, make sure that Dip Switch 1 on Bank 2 is in the OFF position. Please note that siren
activation through Slide Switch Position 3 is only available when the power switch is in the ON position.
DIP SWITCH
BANK #1
DIP SWITCH
BANK #2
SLIDE OUT
REMOVE
SCREWS
(Qty. 4)
Fig. 2
1
1
3
4
5
213
4
5
213
4
5
2
ON
OFF
SLIDE SWITCH
POSITION #1
Output
Terminals
Activated
SLIDE SWITCH
POSITION #2
SLIDE SWITCH
POSITION #3
Slide
Switch
23456789
DIP SWITCH CHART / DEFAULT POSITION
The side of the dip switch that is depressed is indicated as black.
1
1
3
4
5
213
4
5
213
4
5
2
ON
OFF
SLIDE SWITCH
POSITION #1
Output
Terminals
Activated
SLIDE SWITCH
POSITION #2
SLIDE SWITCH
POSITION #3
Slide
Switch
DIP SWITCH CHART (Modified for example)
The side of the dip switch that is depressed is indicated as black.
23456789

Page 4
Custom Dip Switch Configurations (Bank 2):
Push-button 9 (a momentary-type switch) has the ability to function in four different
modes. These modes are defined by the five-position dip switch (Bank 2).
Mode 1 (default) - In this configuration, the output is activated for as long as push-button 9
is depressed.
Mode 2 - In this configuration, when push-button 9 is pressed, the output is activated for a
period of 8 seconds.
Mode 3 - In this configuration, when push-button 9 is pressed, the output is activated.
When pressed again, the output is deactivated.
Mode 4 - In this configuration, when push-button 9 is pressed, the output is activated for a
period of 400 ms. After 400 ms, the output is deactivated for 400 ms. This cycle will
continue until push-button 9 is pressed again.
Custom Fuse Configurations:
Push-buttons 8 & 9 Functionality
Terminals #10 & 13 do not function as output terminals and are not used in the default configuration.
By changing the positions of specific fuses, these terminals can be configured to control auxiliary
circuits. These auxiliary circuits can not exceed 10 amps each.
Moving Fuse #8 from its default position (F8) to its optional position (F8A) allows push-button 8 to
control an auxiliary circuit. Connect Power In from the aux. circuit to Terminal #10 and Load Out to
Terminal #12. Push-button 8 will now open and close this circuit.
Moving Fuse #9 from its default position (F9) to its optional position (F9A) allows push-button 9 to
control an auxiliary circuit. Connect Power In from the aux. circuit to Terminal #13 and Load Out to
Terminal #15. Push-button 9 will now open and close this circuit.
Backlighting
Backlighting for the six push-buttons may be controlled in one of two manners: In the default (as
shipped) mode, the 3-position connector controls the backlighting. The WHITE/YELLOW wire may be
connected to a 12VDC source that is activated with the vehicle’s ignition switch. For vehicles utilizing
a battery disconnect switch an internal jumper may be moved, allowing the backlighting to be
controlled by power applied to the number 10 AWG input wires, saving an additional connection.
Diagnostic Indicators
The unit has two diagnostic indicators on the front panel which are used to indicate fault conditions
with your siren system. The following table lists the type of fault and the indicators response. If the
indicator is on steady while a tone is in use, this implies that there is no fault with the associated
speaker output.
Fault Condition and Diagnostic Indicators Response
Over Voltage -
Speaker LED #1 will be in a DoubleFlash mode (2 quick flashes followed by a pause).
Under Voltage -
Speaker LED #2 will be in a DoubleFlash mode (2 quick flashes followed by a pause).
DIP SWITCH CHART / 5 POSITION / BANK 2
Dip Switches are shown below in their default (factory) setting.
The side of the dip switch that is depressed is indicated as black.
PANEL SWITCH 9
OPERATING MODE:
MOMENTARY
1 2 3 4 5
MODE 1
(DEFAULT)
MODE 2 MODE 3 MODE 4
PANEL SWITCH 9
OPERATING MODE:
8 SECOND ON TIMER
1 2 3 4 5
ON
OFF
PANEL SWITCH 9
OPERATING MODE:
LATCH ON LATCH OFF
1 2 3 4 5
ON
OFF
PANEL SWITCH 9
OPERATING MODE:
FLASHER (400MS ON & OFF)
1 2 3 4 5
ON
OFF
ON
OFF
AUX
ENABLE
Slide
Switch
NOT
USED
1
ON
OFF
2 3 4 5
Push Button
Switch #8 OFF
Push Button
Switch #8 ON
Fuse F8 moved
to F8A position
12
12
11
11
10
Power
In
Power
In
Load
Out
Load
Out
10
Push Button
Switch #9 ON
Fuse F9 moved
to F9A position
Push Button
Switch #9 OFF
15
15
14
14
Power
In
Power
In
Load
Out
Load
Out
13
13

Page 5
RAD
PAPA
MAN
PWRPWR
RAD
21
POWER SWITCH
This switch has two positions: Down (Off) &
Up (On). When this switch is Off, the unit will
not function. When the switch is On, the siren
is functional and may be activated at the
operator’s discretion.
ROTARY SWITCH
The Rotary Knob controls the Radio Repeat
and PA (Public Address) functions of the unit.
VOLUME KNOB
The Volume Knob controls the volume of
Public Address function. Volume is increased
by rotating the knob in a clockwise direction.
Rotating the volume knob in a counter-
clockwise direction decreases the volume
produced by these features.
RADIO REPEAT VOLUME
Before use, the Radio Repeat output volume
must be adjusted to satisfactory operating
levels. To adjust this level, a small, flat-blade
screwdriver is needed. Locate the Radio
Repeat adjustment port (potentiometer) to
the right of the Rotary Knob on the face of the
control head. Set the volume level of the
vehicle’s two-way radio to its normal operat-
ing volume. Turn the Rotory Knob on the con-
trol head to RAD to activate Radio Repeat.
Insert the screwdriver in the Radio Repeat
adjustment port and turn in clockwise direc-
tion to increase the sound level.
Control Head Component Identification:
MAN BUTTON
The Manual button is not used
HORN BUTTON
The HORN button is not used.

Page 6
NOTE: For access to circuit board S .ee Fig. 2 previous page
UPPER CIRCUIT BOARD: Fuse, Jumper and Dip Switch Identification
BACKLIGHT
ON POWER
DASHLIGHTS
3 PIN
STRIP
2 POSITION
JUMPER
F1 / 20 AMP
F2 / 20 AMP
F3 / 20 AMP
F4 / 10 AMP
F5 / 10 AMP
F6 / 10 AMP
F7 / 10 AMP
OR
F8A
10 AMP
F8
10 AMP
OR
F9A
10 AMP
F9
10 AMP
Fig. 3
GREEN
GREEN GREEN GREEN GREEN GREEN GREEN
GREEN
D26 D27 D28
D19 D20 D21 D22 D23 D24
FRONT
D29 D30 D31 D32 D33 D34
D25
RED
DIP SWITCH BANK 1
(9 POSITION)
JUMPER DETAIL
SIDE VIEW
TOP VIEW
DIP SWITCH BANK 2
(5 POSITION)
S1
S2
J4
YELLOW
10 AMP OUTPUT
10 AMP OUTPUT
BLACKOUT OUTPUT
BLACKOUT INPUT
BLACKOUT OUTPUT
BLACKOUT INPUT
10 AMP OUTPUT
10 AMP OUTPUT
10 AMP OUTPUT
10 AMP OUTPUT
20 AMP OUTPUT
20 AMP OUTPUT
20 AMP OUTPUT
10GA RED
BUTT SPLICES
10GA RED
60 AMP FUSE (QTY. 2)
BACK LIGHTING
(AUX ENABLE)
13
14
15
12
11
10
9
8
7
6
5
4
3
2
1
WIRING DIAGRAM
BLK
RED
WHT / YEL
OPEN
WHT / GRN
BLU
VIO
RED
RED
BLK
BLK
BLU
BRN
ORG
YEL
GRY
WHT
1
2
3
9
4
1
5
2
6
3
7
8
12
10
11
YEL
Speaker #2
(11 OHM)
Speaker #1
(11 OHM)
BLU
BLU
ORG
BRN
To Two-Way
Radio Speaker
20 AMP FUSE
(+)
Battery
(-)
SIREN CONNECTOR
Recomended Sizes for Customer Supplied Wires:
Switch Power
10 AWG.......................................................... 8 FT. MAX
8 AWG............................................................ 13 FT. MAX
6 AWG............................................................ 21 FT. MAX
Siren Power & Ground
12 AWG..........................................................18 FT. MAX
10 AWG..........................................................30 FT. MAX
Rotary Switch Operations:
RAD (Radio Repeat) - When the rotary knob is in the RAD position,
any signal that is received by the vehicle’s two-way radio will be
simultaneously broadcast over the vehicle’s loudspeaker (the unit
must be connected to the two-way radio as outlined in this manual).
When the rotary switch is in any other position, the siren is in a
standby state where no tones have been activated, but is waiting for
another action to be taken by the operator. These positions are the
best choice when public address is required.
Microphone
Whenever the unit is powered on, activating the microphone (pressing
the switch on the side of the mic.) will shut down any other siren
functions and enable public address operation regardless of the rotary
switch position or any other switch or input.
295HFSA6 Specifications
INPUT VOLTAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . 12.5 VDC ±20%
INPUT CURRENT @15 VDC @ 5.5 OHMS . . . . . . . .16 AMPS MAX.
INPUT FUSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 AMPS
SPEAKER IMPEDANCE. . . . . . . . . . . . . . . . . . . . . . 5.5 OHMS MIN.
OPERATING TEMPERATURE . . . . . . . . . . . . . . . -30° C. TO +60° C.
STORAGE TEMPERATURE . . . . . . . . . . . . . . . . . -40° C. TO +70° C.
HUMIDITY . . . . . . . . . . . . . . . . . . . . . . . . 99% (NON CONDENSING)
OUTPUT VOLTAGE @ 15 VDC @ 11 OHMS. . . . . . 32 V RMS MAX.
OUTPUT POWER @ 15 VDC @ 11 OHMS . . . . . 105 WATTS MAX.
OUTPUT POWER @ 15VDC @ 11 OHMS . . . . . . .185 WATTS MAX.
CAUTION
Loud siren noise can cause
hearing damage and/or loss.
Refer to OSHA Section 1910.95 prior
to putting ANY siren into service!
Wear
Protection!
ACTIVATION OF THIS
SIREN MAY DAMAGE
UNPROTECTED EARS!
