Whirlpool AC1888 User manual

AC0788
AC0988
AC1288
AC1888
AE0789
AE0989
AC0788N
AC1888N
AC0988N
AE0789N
AC1288N
AE0989N
AE1889 AE1889N
AE1289 AE1289N

Thank you for choosing Whirlpool air conditioner. Our design is based on the best efficiency and the lowest noise operation and itcan
keep the room comfortable. Please read this operating manual carefully before operating the unit and keep it for consultation.
CONTENTS 1
2
3
5
6
6
7
10
13
14
15
16
17
Function
Operating condition
Installation
Notes for installation
Part identification
Air direction adjustment
Air conditioner opperation
Operation tips
Caution
Care and maintenance
Trouble shooting guide
After service
Structure mechanism
and Installation
Operation procedureCare and maintenance
Remote control operation procedure

Function and working temperature range.
Introduction
Window type room air conditioners of Whirlpool can regulate the room temperature,dry
the room. It is convenient for your work,study and life. It can be widely used in residence,
shop, hotel, office, library and laboratory, and so on.
Cooling in summer
In hot summer, Air conditioner can cool down
room air by transferring heat out.
Without reducing room temp, air conditioner
can dehumidify and make room air dry and
comfortable.
Dehumidifying in rainy or
humid season
1

Operating Condition
COOL mode operation
Outdoor temperature should be in range of 21
to 52 , otherwise it is possible for air conditioner
to breakdown.
Room humidity should be lower than 90% .
Otherwise, it is possible for air conditioner to dew
at air conditioner surface and even drop water after
running for so much time. But this maybe normal.
Please operate air conditioner in the correct conditions as following.
DRY mode operation
Outdoor temperature should be in range of 21
otherwise it is possible for air conditioner to breakdown.
Power requirement
Water pipe
The ground must be connected.
Special socket must be used. Furthermore, the socket and wiring
must conform to the wiring regulations. And the earthing method
must be reliable.
In fixed circuit, there must be electricity leakage protection switch
of enough power capacity and air switch with enough space.
Earth wireTo ensure the reliable earthing, please do not connect earth wire to the following places:
to 52 ,
2

How to install:
Choose a location where there are no any obstacle surrounding
the unit.
Prepare the installation hole slightly bigger than unit size.
Choose the installation space according to the following diagram.
The distance of obstructions from window unit inside should be
upper 300mm, lower 1500mm, left 500mm, right 500mm,
front1500mm.
3

Horizontal line
Sunshade board
Wall
Wooden frame
Rubber plate
Support
Horizontal line
Drain water:
To get the maximum cooling efficiency, the air conditioner is designed to splash the condensation water on the
condenser coil.
If the splashing sound annoys you, you can provide an outside drain by using the following procedure, which
may however cause a small loss of performance.
1. Slide out the chassis from the cabinet.
2. Remove the rubber plug from the body base plate.
3. Install the drain pan to the corner of the cabinet with 2 screws.
4. Connect the drain hose to the outlet on the drain pan bottom.
5. Slide the chassis into its original place in the cabinet.
Installation procedure:
1) Remove the sticker from the front panel.
2) Put the unit into the installation hole.
When installing the unit, it should be slanted
down to the back to avoid the enlargement of
noise or vibration. (Slant between 6-10mm.)
(Shown at right figure.)
The installation place should be strong enough
to avoid the enlargement of noise or vibration.
3) Fill up sews in the cabinet with sponge or foam.
Installation assistance:
Use iron support
The installation hole should be strong enough to
support the air conditioner. If it cannot, iron sup-
port has to be used outdoors.
Iron support should be fixed on the building (Shown
at right figure.)
Use sunshade board
Air conditioner should avoid anything to be dropped
into it and avoid direct sunshine. If there is no cover
on it, you should contact the seller for installing
the sunshade board. When installing the sunshade
board, don’t let it block the air inlet at the side grille.
4

Notes for installation
Remove
Before removing air conditioner to the other place, you should
contact the seller firstly.
Then it must be done under the direction of the professional
technician. In addition, the charge of this must be paid.
Noise
Electric wiring
Install in a location where is firm enough to avoid the enlargement of noise
and vibration.
Don’t put anything in front of the outlet of outdoor unit to avoid increasing
noise.
Be sure that hot air ornoise will not inconvenience neighbors.
Please contact the seller as soon as there is strange noise during operation.
Please use the safety support.
Must connect with ground reliably.
The exclusive circuit must be used. But removable socket can’t be used because poor
contact of it can cause over heat or fire.
Don’t pull the power cord strongly.
In fixed circuit, there must be electricity leakage protection switch and leakage current
is less than 30mA.
Air switch (thermal-magnetic breaker) should be installed in the circuit and its capacityis
10A for 7K and 9K, 15A for 12K, 20A for 18K, .
The fixed wiring should be more than 4.0mm
2
in area.
Note:
Drain hose or tubing can be purchased locally to satisfy your particular needs.
An all-pole disconnection switch having a contact separation of at least 3mm in all poles
should be connected in fixed wiring
Connecting method between air conditioners and power cord and interconnecting method
of each individual element with one another should accord with wiring diagram on the unit.
The air conditioner should be installed in accordance with national wiring regulation.
5

PART IDENTIFICATION
Air filter
(behind the front intake grille)
Front intake grille Control panel cover Power cord
Front grille
Air inlet louver
Cabinet
Vertical airflow direction vane
(Airflow direction adjustment up and down).
The vertical airflow direction vane is controlled by
positioning the vane to discharge the air upwards,
downwards or straight out.
Air direction adjustment
Panel outlook picture, just for reference, please take the real unit as standard.
6

3 MINUTES WAITBEFORE RESTARTING
Mechanical only
AIR CONDITIONER OPERATION
7

8

AIR SWING
Note:
If remote controller is lost, please open the panel and operate it by hand.
1 Power button
Press this button to turn on the unit. Press this button again to turn off the unit.
2 Swing button
Press this button to start up the auto swing function.
3 Fan speed button
4 Temp/time button
Press ▲button to increase set temperature and press ▼button decrease set temperature. The
temperature adjusting range is 16-30℃. After pressing TIMER button, press ▲button and time can be
set in 1-hour increments. Press ▼button and time can be set in 1-hour decrements. The time adjusting
range is 0-24hours.
5 Signal receivers
6 Mode button
Press this button select operation mode: COOL, FAN.
9
And DRY mode can't be chosen by hand.
Electronic only (control panel)

＋、－ ｂｕｔｔｏｎ
ＦＡＮ ｂｕｔｔｏｎ
Ｐｒｅｓｓ ｔｈｉｓ ｂｕｔｔｏｎ，
ｔｈｅ ｆａｎ ｒｕｎ ｏｎｌｙ．
ON/OFF
FAN
SPEED
FAN
COOL
Ａｔ ｏｐｅｒａｔｉｎｇ，ｐｒｅｓｓ ＋ ｏｒ
－ｔｏ ｉｎｃｒｅａｓｅｓ ｔｈｅ ｔｉｍｅｒ．
Ｉｎｃｒｅａｓｅ １ ｈｏｕｒ ｂｙ
ｐｒｅｓｓｉｎｇ ＋ ｂｕｔｔｏｎ ｏｎｃｅ，
ａｎｄ ｄｅｃｒｅａｓｅ １ ｈｏｕｒ ｂｙ
ｐｒｅｓｓｉｎｇ － ｂｕｔｔｏｎ．
ＴＩＭＥＲ ＯＦＦ：ｗｈｅｎ ｔｈｅ ｕｎｉｔ ｉｓ ｔｕｒｎ ｏｎ，
ｐｒｅｓｓ ＴＩＭＥＲ ｂｕｔｔｏｎ ｔｏ ｅｎｔｅｒ ＂ｔｉｍｅｒ
ｏｆｆ＂ ｓｔａｔｅ，ｔｈｅｎ ｔｈｅ ｔｉｍｅｒ ｌａｍｐ ｆｌａｓｈ．
Ｐｒｅｓｓ ＋ ｏｒ － ｔｏ ｉｎｃｒｅａｓｅ ｏｒ ｄｅｃｒｅａｓｅ
ｔｈｅ ｔｉｍｅｒ．Ｐｒｅｓｓ ｔｈｅ ＴＩＭＥＲ ｂｕｔｔｏｎ
ｏｎｃｅ ｍｏｒｅ ｔｏ ｅｎｓｕｒｅ ｔｈｅ ｓｅｔｔｉｎｇ ｈｏｕｒｓ．
ＴＩＭＥＲ ＯＮ：ｗｈｅｎ ｔｈｅ ｕｎｉｔ ｉｓ ｔｕｒｎ ｏｆｆ，
ｐｒｅｓｓ ＴＩＭＥＲ ｂｕｔｔｏｎ ｔｏ ｅｎｔｅｒ ＂ｔｉｍｅｒ
ｏｎ＂ ｓｔａｔｅ，ｔｈｅｎ ｔｈｅ ｔｉｍｅｒ ｌａｍｐ ｆｌａｓｈ，
ｐｒｅｓｓ ＋ ｏｒ － ｔｏ ｉｎｃｒｅａｓｅ ｏｒ ｄｅｃｒｅａｓｅ
ｔｈｅ ｔｉｍｅｒ．Ｐｒｅｓｓ ｔｈｅ ＴＩＭＥＲ ｂｕｔｔｏｎ
ｏｎｃｅ ｍｏｒｅ ｔｏ ｅｎｓｕｒｅ ｔｈｅ ｓｅｔｔｉｎｇ ｈｏｕｒｓ．
Remote control operation procedure
Name and Function-Remote controller
Note:
Be sure that there are no obstructions between reciever and remote controller.
Don't drop or throw the remote controller.
Don't let any liquid in the remote controller and put the remote controller
directly under the sunlight or any place where is very hot.
DRY
TIMER
SWING
ＳＷＩＮＧ ｂｕｔｔｏｎ
Ｐｒｅｓｓ ｔｈｉｓ ｂｕｔｔｏｎ，ｔｈｅ
ｓｗｉｎｇ ｆｕｎｃｔｉｏｎ ｗｉｌｌ ｂｅ
ｏｐｅｎｅｄ．Ｒｅｐｒｅｓｓ ｉｔ ａｇａｉｎ，
ｔｈｅ ｓｗｉｎｇ ｆｕｎｃｔｉｏｎ ｗｉｌｌ
ｂｅ ｓｔｏｐｐｅｄ．
10

Ｎａｍｅ ａｎｄ Ｆｕｎｃｔｉｏｎ－Ｒｅｍｏｔｅ ｃｏｎｔｒｏｌ
ＦＡＮ ＳＰＥＥＤ ｂｕｔｔｏｎ
Ｐｒｅｓｓ ｔｈｉｓ ｂｕｔｔｏｎ ｔｏ
ｃｈａｎｇｅ ｔｈｅ ｆａｎ ｓｐｅｅｄ
ｏｆ：
． ＬＯＷ ｓｐｅｅｄ
． ＨＩＧＨ ｓｐｅｅｄ
ON/OFF
FAN
SPEED
FAN
COOL
ＯＮ／ＯＦＦ ｂｕｔｔｏｎ
Ｐｒｅｓｓ ｔｈｉｓ ｂｕｔｔｏｎ ｔｏ ｔｕｒｎ
ｏｎ ｏｒ ｔｕｒｎ ｏｆｆ ｔｈｅ ｕｎｉｔ．
ＣＯＯＬ ｂｕｔｔｏｎ
Ｐｒｅｓｓ ｔｈｉｓ ｂｕｔｔｏｎ， ｔｈｅ
ｏｐｅｒａｔｉｏｎ ｍｏｄｅ ｉｓ ｃｏｏｌｉｎｇ
ＤＲＹ ｂｕｔｔｏｎ
Ｗｈｅｎ ｉｔ ｉｓ ｐｒｅｓｓｅｄ， ｔｈｅ
ｏｐｅｒａｔｉｏｎ ｍｏｄｅ ｉｓ ｄｒｙｉｎｇ
ＴＥＭＰ． ｂｕｔｔｏｎ
ＳＥＴ ＴＥＭＰ．ｉｎｃｒｅａｓｅｓ １ Ｃ ｂｙ
ｐｒｅｓｓｉｎｇ Ｃ ｂｕｔｔｏｎ ｏｎｃｅ，ａｎｄ
ｄｅｃｒｅａｓｅｓ １ Ｃ ｂｙ ｐｒｅｓｓｉｎｇ
Ｃ ｂｕｔｔｏｎ ｏｎｃｅ．
Ａｔ ｃｏｏｌ ｍｏｄｅ ｏｐｅｒａｔｉｏｎ，ＳＥＴ
ＴＥＭＰ．ｃａｎ ｂｅ ｓｅｌｅｃｔｅｄ ｆｒｏｍ
１６ Ｃ ｔｏ ３０ Ｃ．
Ａｔ ＤＲＹ ｍｏｄｅ ｏｐｅｒａｔｉｏｎ，ＳＥＴ
ＴＥＭＰ． ｃａｎ ｂｅ ｓｅｌｅｃｔｅｄ ｆｒｏｍ
１６ Ｃ ｔｏ ３０ Ｃ ．
DRY
TIMER
SWING
11

How to insert batteries
NOTE:
Don’t confuse the new
and worn or different
types of batteries.
Remove batteries when
the remote controller is
not in use for a
longtime.
The lifetime of the bat-
teries is about one year.
The remote controller
should be placed about
1m or more away from
the TV. or any other
electric appliances.
Bad batteries are for-
bidden.
2.Remove the cover from the
back of the remote control.
3.insert the two batteries (Two
AAA dry - cell batteries).
4.Re - attach the cover.
Remove the
cover.
Re - attach
the cover.
Insert the AAA batteries.
12
1.Remove the screw with screwdriver.
3
4
1
2
Remove the
screw

Operation Tips
Operation for comfort and economy
Do not overcool the room
temperature, this is not good for
health and waste electricity.
Do not let sunshine enter the
room directly when the air con-
dition is in operation.
Keep blind or curtains closed,
Adjust the vertical and horizontal
airflow direction to ensure a uni-
form temperature in the room.
Make sure that the doors and windows
are shut tightly.Avoid opening doors
and windows as much as possible to
keep the cool air in the room.
Clean the air filter regularly.
Blackages in the air filter re-
duce dehumidifying effects.
Clean at least once every two
weeks.
Ventilate the room occasionally.
Since windows are kept closed, it
is a good idea to open them and
ventilate the room now and then.
13

Caution
Do not use the air conditioner
for other purposes such as dry-
ing clothes, preserving foods,
keeping animals, or cultivating
vegetables.
Do not block the air intake and
outlet vents.
This causes lowered perfor-
mance and irregular operation.
Do not insert sticks or other ob-
jects into these vents as it is dan-
gerous to touch the electric com-
ponents and the fan.
Select the most appropriate
temperature.
Take care to adjust the tempera-
ture to suit the conditions.
Rooms occupied by infants,the
elderly, or the sick should be kept
at an appropriate temperature.
Do not use heating apparatuses
in the air conditioner’s plastic
parts melt if exposed to exces-
sive heat.
Avoid exposing the body directly
to a continuous unidirectional air
flow for long periods.
This is not recommended for
health reason.
Always wait at least 3 minutes before switching the
air condition on again after you have switched it off
during cooling.
Always wait
at least 3 minutes
1) The plug must be accessible after the appliance is positioned.
2) Do not use this appliance in the laundry.
3) If the power cord is damaged, it must be replaced by the manufacture or its service agent in void of hazard.
Do not pull out the power cord.
Damage to the cord may result in
serious electrical shocks.
14

Care and maintenance
Always turn off the air conditioner and main power supply before cleaning to ensure safety.
Clean unit
1. Clean surface panel with a soft
and dry cloth, Which is soaked
warm water below 40 .
2. Do not use chemical solvent for cleaning.
3. Do not splash water directly to indoor
Air filter
The air filter behind the intake grille should be washed at least
every two weeks or as often as it needs cleaning.
How to clean the air filter:
1. To remove the faceplate to the left in 15mm, and pull it to
front and pull the air filter as show.
*Check earth wire
Vacuum cleaner
unit, in which there are micro-
computer and circuit plate,
they must not be touched by
water.
Is it broken
or loose?
*Check air inlet and outlet of outdoor unit.
Let the filter dry thoroughly before reinstalling it.
2. Vacuum the filter on the dusty side to remove light dust.
3. Wash the filter, cleaner side up under gently flowing water
to wash out accumulated dust and lint.
4. If the filter is very dirty, use a mild household detergent in
the wash water.
Air lock could result
in bad efficiency.
15

Trouble shooting guide
Fault phenomenon Trouble-shooting
Air conditioner dose not
operate at all.
* Is there a power failure?
* Is the plug out?
* Is power fuse or switch off ?
*
* Is air inlet or outlet locking?
* Is there any other heat source in room?
* Are air filters dirty very much?
* Is indoor fan speed set at LOW?
* Maybe the room is too hot when the unit is started,
please cool down the room after a period of time.
* At COOL mode operation, sometimes there is foggy
air flowing out of indoor unit, this is because the room
humid air has been cooling rapidly.
* The unit is normal while the indoor outlet is sending
out some odor, because the inlet air may be mixed
with the smell of furniture and smoke.
* For a noise that sounds like water flowing:
This is the sound of freon flowing inside the air con-
ditioner unit.
* For a noise that sounds like a shower:
This is the sound of the dehumidifying water being
processed inside the air conditioner unit.
* Condensation occurs when the airflow from the air
conditioner cools the warm room air.
* This is to protect the mechanism.
* Wait about three minutes and operation will begin.
Cool efficiency is not
good.
Foggy air
flows out.
The air conditioner opera-
tion is noisy.
It seems that condensation is leaking from air conditioner.
Air conditioner dose not operate for about 3 minutes when
restart.
Please check the following items before asking for repair,it saves your time and
money.
Whether the voltage is too high or too low?
16

*Operation starts or stops abnormally;
*Power fuse or switch often breaks;
*Carelessly splash water or something into air conditioner;
*Electrical lines are much hot or lines cover breaks;
*Other strange situations.
Immediately stop all operations and plug out, please contact your dealer
in the following situations.
After service
If your air conditioner has the questions of quality or anything else, please contact
the service center of Whirlpool.
17

Whirlpool Corporation
網站：http://www.whirlpool.com
66129912918
