Whirlpool CERAN GJC3034RC04 User manual

COOKTOP PARTS
1
For Models: GJC3034RB04,GJC3034RP04,GJC3034RC04,GJC3034RS04
(Black) (Pure White) (Pure Biscuit) (Stainless)
03−08 Litho in U.S.A. (amd) Part No. W10200248 Rev. A
30" ELECTRIC
BUILT−IN CERAN
COOKTOP

COOKTOP PARTS
2
For Models: GJC3034RB04,GJC3034RP04,GJC3034RC04,GJC3034RS04
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10200248
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
8286066 Cooktop
8304571 Undercounter Oven
W10162165 Use & Care Guide
8286341 Wiring Diagram
Safer Cooking Tips
9762761 English
W10065852 French
2 Cooktop & Bracket
Assembly
W10140991 Black
8286955 White
W10171628 Biscuit
3 246119 Screw (8)
4 8285928 Bracket, Switch
Mounting
5 Element, Surface
8523698 1200W − RF
8285848 4300W − LF & LR
4453909 1200/2500W − RR
6 9759094 Spring,Locator (6)
7 Switch, Infinite
3191050 Use W/LR Burner
9759474 Use W/LF & RR
Burners
3191049 Use W/RF Burner
Burners
8 3183956 Seal, Switch
Cover (5)
9 3192439 Seal, Limiter (4)
10 Knob, Control (4)
8286043WH White
8286043BL Black
8286043BT Biscuit
11 4455917 Bracket, Mounting
12 8285862 Box, Burner
13 8286582 Spring Clip,
Bridge (3)
14 3196537 Screw
15 8285469 Seal, Switch
Shaft (5)
16 9762441 Switch, Rotary
Accusimer
17 3400093 Screw
18 Knob, Accusimer
8286044WH White
8286044BL Black
8286044BT Biscuit
19
W10180225 Control, Heat
Shield
20 9763517 Rail, Element(2)
3191839 Seal, Heat
21 9760762 Shield, Heat
8286426 Seal
3196160 Screw
22 Trim, Cooktop
(Stainless Only)
W10142238 Right
W10142237 Left

OPTIONAL PARTS
3
For Models: GJC3034RB04,GJC3034RP04,GJC3034RC04,GJC3034RS04
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10200248
Illus. Part
No. No. DESCRIPTION
8286642 Tape, Foam
FOLLOWING PARTS
NOT ILLUSTRATED
SPLICING WIRES−−25FT.
LENGTH
4456028 Wire, Jumper
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242827 Wire, Yellow
14 Ga. 150 C
ACCESSORY PARTS
WIRING HARNESS PARTS
8286409 Harness, Main
8286347 Harness, Light
8286413 Conduit
3400015 Screw
