PARTNUMBER 8316532
COIN Sl IDE KI I
INSTAl ION
AND
VEND PRICE
CHANGE
INS I RUCTIONS
ESD MECHANICAL PRODUCTS
90 DAY WARRANTY
ESD warrants that the products it manufactures wtil be free from manufacturer's defects in materials and workmanship for aperiod of 90 DAYSfrom the
date of washer/dryer equipment i_Jrchase, In the event of a defect, it will be the manufacturer's option to repair or replace the defective part or componenL
The manufecturer retains the option to replace the defective part or component with a new or remanufactured pert or co,'P4)onenL
Warranty is recognized only upon receipt of a copy of the original equipment invoice, and a description of Hem(s) in question. ESD
reserves the rigid to inspect the product and determine reason for defecL
Cus_ who purchase ESD products do so with the knowledge that higher security products are available for an additional cost. Furthermore, a thief
with inganuthj and specialized tools may have the ability to force, pick or otherwise defeat any lock or lock box when given sufficient access. Customers
assume full re_bl&ly of protecting ESD products from attack or accept the risk of failing to de so. _ is not cmNmld _warfaMy.
Customer shall be responsible for paying return freight to ESO. Labor to replace parts is not incJndedin the warranty,
ESDDISCLAIMSANYWARRANTY,EXPRESSEDORIMPLIED,THATESDPRODUCT'SWILLWITHSTANDAWlGIVENATTACK.ESDASSUMESNOLIABIUTYFOR
ANYRESULTINGLOSSORDAMAGE.
ESD Technical Support
TOinitiate a warranty repair or replacement, the customer must secure a Return Goods Authorization number (RGA#) from ESD by calling
215-628-4)860

COIN SLIDE KIT (3954807) INSTALLATION INSTRUCTIONS
l
., i,"111 | ,, _, ,
\J
........C
C
ESD
MONEYBOX
KIT COMPONENTS:
WASHER EXTENSION
PART # 21053 DRYER EXTENSION PART # 21064
WASHER KIT CONSISTS OF
COIN SLIDE (V8-200)
MONEY BOX (72101-XD w/Key)
I BAG _NCLUDING:
MOUNTING BOLT #21749
EXTENSION #21053
SCREWS #10-32 PAN HEAD #50035
DECAL SHEET #72097
SERVICE DOOR LOCK (KEY & CAM INCLUDED) (0400ET_
DECAL
PART#72O97
DRYER KIT CONSISTS OF
COIN SLIDE (V8-200)
MONEY BOX (7210 I-XD)
IBAG INCLUDING:
MOUNTING BOLT #21749
EXTENSION #21064
2SCREWS #10-32 PAN HEAD #50035
#10-32 PAN HEAD SCREWS
(2) REQ'D
HI ,,,I ,i iii I HI I ,i Hi
WAVE WASHER #50045 LARGE LOCK NUT #50028
_ _ TUBULAR
i qL"-'Y-'K EY
LOCK, KEY & CAM !
COIN SLIDE MOUNTING BOLT
PART # 21749
LOCK #O400ET
I DECAL SHEET #72097 SMALL NUT #50014 LOCK WASHER #20529 #2052B-T
I SERVICE DOOR LOCK (KEY & CAM INCLUDED) (0400ET)
STEP h,._
COIN SLIDE EXTENSION V
ASSEMBLY
FIG. # I
WASHER COINSLIDE ASSEMBLY
FIG. #2
DRYER CO_NSLIDE ASSEMBLY
MOUNT WASHER EXTENSION #210S3 TO COIN SLIDE
FIG. # I
L_ EAD SCREWS
MOUNT DRYER EXTENSION #21064 TO COIN SLIDE
FIG. #2

DISCONNECT ELECTRICAL POWER BEFORE INSTALLATION
STEP 2:
•INSERT KEY INTO MONEY BOX -TURN KEYTO OPEN POSITION (UNLOCKED)
•INSTALL MONEY BOX IN METER CASE AS INDICATED BY ARROW FIG #3
-LOCK MONEY BOXTO SECURE
STEP 3:
•INSTALL COINSLIDEWITH EXTENSION tSEE FIG #l FORWASHER) (SEE FIG.#2 FOR DRYER)
STEP 4:
•SECURE COINSLIDEWITH MOUNTING BOLT (#21749) BY INSERTING THE MOUNTING BOLT THROUGH THE SERVICE DOOR OPENING ONTOP OF METER CASE.
GUIDING THROUGH MOUNTING BOLT GUIDEAND TIGHTEN TO SECURE COIN SLIDE_ USEA 5/16 SOCKETAND RATCHET (DO NOT OVER-TIGHTEN)
1
_ _.... I
i ill jll
MOUNTING WASHER INSTALLATION
MOUNTING BOLT GUIDE
MONEY BOX FIGURE #3
DRYER INSTALLATION
E
MONEY BOX
TIMER AREA
STEP 5:
• REMOVE 3/4 INCH NUT (LARGE #50028) FROM LOCK
• REMOVE 9/32 INCH NUT (SMALL #50014) FROM TAIL OF LOCK
•REMOVE LOCKWASHER (#20529) FROM TAIL OF LOCK
•DO NOT REMOVE (2) WAVE WASHERS (#50045) FROM TAtL OF LOCK
•INSERT LOCKTHROUGH SERVICE DOOR PANEL HOLE
• ATTACH 3/4 INCH NUT (LARGE #S0028),TIGHTEN TO SECURE TO PANEL
• FASTEN CAM (#21060) ONTO TAIL OF LOCK SECURING CAM WITH LOCK WASHERAND SMALL NUT. (OFFSET S_DE DOWN)

VERTICAL B PRICE CHANGE INSTRUCTIONS
STEP I :
STEP 2:
STEP 3:
STEP 4:
STEP 5:
STEP 6:
STEP 7:
UNHOOK RETURN SPRING (#22)
PUT COINS IN HANDLE, PUSH HANDLE (#2) IN UNTIL COINS DROPTHROUGH COINSLIDE
WHILE HOLDING HANDLE IN, LOOSEN SPRING BRACKET SCREW (#24)
REMOVE FUNCTIONAL INSERTS (#27) FROM CAVITY OF COINSLIDE HANDLE (SUGGESTION, STORE ALL INSERTS IN BULK FOR FUTURE USE)
RETIGHTEN SPRING BRACKET SCREW (#24)
FLIP COIN SLIDE UPSIDE DOWN, REMOVE THREE INSERT RETAINER PLATE SCREWS (#8) FROM UNDERSIDE
EXCHANGE BLANK INSERTSWITH FUNCTIONAL INSERTS
REVERSE INSTRUCTIONS TO RE-ASSEMBLE
ITEM PART # DESCRIPTION
I 21728 BODY
2 2 i727 HANDLE
321732 BRIDGE
I
4 20059 RATCHET
S 20065 RATCHET SPRING
6 20664 RETAINER SPRING
720736 RATCHET SCREW
INSERT RETAINER
8 21209 PiT SCREW
INSERT RETAINER
921738 PLATE
I0 21216 BLANK INSERT
i
!I 20709 BOTTOM PI.ATE
.... BoTToM PLATE
250034 SCREW
13 20710 PIVOT PIN
14 20181 LEVER
i5 20717 LEAF SPRING
_6 21210 RATCHET pLATE
17 21881 GATE
18 21866 GATE RETAINER
ITEM PART # DESCRIPTION
" __9 20185 L(_ATION
SCREW
20 50033 BRIDGE SCREW
BRIDGE iNSERT
21 20662 SCREW
22 21771 RETURN SPRING
EXTENSION
23 50035 SCREW
' SPRING B'RAC'KET
24 50032 SCREW
25 21860 SPRING BRACKET
26 21194 10_ INSERT
27 21193 2S€ INSERT
28 21281 SL00 iNSERT
$1,85 BRIDGE
29 217S8 INSERT
$200 BRID(_'E
30 21759 INSERT
31 21760 $2.75 BRIDGE
INSERT
$S,75 BRIDGE
32 2t765 INSERT
33 20732 .OIO SHIM
34 20733 ,015 SHIM
3S 20734 .020 SHIM
36 20735 .030 SHIM
