Whirlpool Duet Steam User manual

ELECTRONIC
ELECTRIC DRYER
Use & Care Guide
For assistance, installation and service call: 1-800-807-6777
or visit our website at... www.whirlpool.ca
SÉCHEUSE
ÉLECTRIQUE
ÉLECTRONIQUE
Guide d’utilisation et d’entretien
Pour assistance, installation ou service composez le
1-800-807-6777
ou visitez notre site Web à www.whirlpool.ca
Table of Contents/Table des matières ................. 2
W10155790B
®
®

2
TABLE OF CONTENTS
DRYER SAFETY..............................................................................3
INSTALLATION INSTRUCTIONS..................................................4
Tools and Parts ............................................................................4
Options.........................................................................................4
Location Requirements ...............................................................5
Electrical Requirements ...............................................................7
Venting Requirements..................................................................7
Plan Vent System.........................................................................8
Install Vent System.....................................................................10
Install Leveling Legs...................................................................10
Connect Vent..............................................................................10
Connect Inlet Hose.....................................................................10
Level Dryer .................................................................................11
Complete Installation .................................................................11
DRYER USE ..................................................................................12
Starting Your Dryer.....................................................................12
Stopping Your Dryer ..................................................................13
Pausing or Restarting.................................................................13
Control Locked...........................................................................14
Drying and Cycle Tips................................................................14
Status Lights ..............................................................................14
Cycles.........................................................................................15
Additional Features ....................................................................16
Changing Cycles, Options and Modifiers..................................17
Drying Rack Option....................................................................18
DRYER CARE ...............................................................................19
Cleaning the Dryer Location ......................................................19
Cleaning the Lint Screen............................................................19
Cleaning the Dryer Interior .........................................................19
Removing Accumulated Lint......................................................19
Water Inlet Hoses.......................................................................20
Vacation, Storage and Moving Care..........................................20
Changing the Drum Light...........................................................20
TROUBLESHOOTING ..................................................................21
ASSISTANCE OR SERVICE.........................................................23
ACCESSORIES .............................................................................23
WARRANTY ..................................................................................24
TABLE DES MATIÈRES
SÉCURITÉ DE LA SÉCHEUSE ....................................................25
INSTRUCTIONS D'INSTALLATION.............................................26
Outillage et pièces......................................................................26
Options .......................................................................................26
Exigences d'emplacement.........................................................27
Spécifications électriques ..........................................................29
Exigences concernant l'évacuation ...........................................30
Planification du système d’évacuation ......................................31
Installation du système d’évacuation.........................................32
Installation des pieds de nivellement.........................................33
Raccordement du conduit d’évacuation ...................................33
Raccordement des tuyaux d'alimentation.................................33
Mise à niveau de la sécheuse ....................................................34
Achever l’installation ..................................................................34
UTILISATION DE LA SÉCHEUSE................................................35
Mise en marche de la sécheuse ................................................35
Arrêt de la sécheuse...................................................................37
Pause ou remise en marche.......................................................37
Control Locked (verrouillage des commandes).........................37
Conseils pour le séchage et les programmes ...........................37
Témoins lumineux ......................................................................38
Programmes...............................................................................38
Caractéristiques supplémentaires .............................................40
Changement des programmes, options et modificateurs.........41
Option de grille de séchage .......................................................41
ENTRETIEN DE LA SÉCHEUSE.................................................42
Nettoyage de l'emplacement de la sécheuse ...........................42
Nettoyage du filtre à charpie......................................................43
Nettoyage de l’intérieur de la sécheuse.....................................43
Retrait de la charpie accumulée ................................................43
Tuyaux d'arrivée d'eau...............................................................43
Précautions à prendre avant les vacances,
un entreposage ou un déménagement......................................43
Changement de l’ampoule d’éclairage
du tambour.................................................................................44
DÉPANNAGE.................................................................................44
ASSISTANCE OU SERVICE.........................................................47
ACCESSOIRES .............................................................................47
GARANTIE.....................................................................................48

3
DRYER SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electric shock, or injury to persons when using the dryer, follow basic precautions,
including the following:
WARNING:
■ Read all instructions before using the dryer.
■ Do not place items exposed to cooking oils in your dryer.
Items contaminated with cooking oils may contribute to
a chemical reaction that could cause a load to catch fire.
■ Do not dry articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry-
cleaning solvents, or other flammable or explosive
substances as they give off vapors that could ignite or
explode.
■ Do not allow children to play on or in the dryer. Close
supervision of children is necessary when the dryer is
used near children.
■ Before the dryer is removed from service or discarded,
remove the door to the drying compartment.
■ Do not reach into the dryer if the drum is moving.
■ Do not repair or replace any part of the dryer or attempt
any servicing unless specifically recommended in this
Use and Care Guide or in published user-repair
instructions that you understand and have the skills to
carry out.
■ Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product.
■ Do not use heat to dry articles containing foam rubber or
similarly textured rubber-like materials.
■ Clean lint screen before or after each load.
■ Keep area around the exhaust opening and adjacent
surrounding areas free from the accumulation of lint, dust,
and dirt.
SAVE THESE INSTRUCTIONS
■ The interior of the dryer and exhaust vent should be
cleaned periodically by qualified service personnel.
■ Do not install or store the dryer where it will be exposed
to the weather.
■ Do not tamper with controls.
■ See installation instructions for grounding requirements.

4
INSTALLATION INSTRUCTIONS
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Parts supplied
Remove parts package from dryer drum. Check that all parts are
included.
NOTE: Do not use leveling legs supplied with dryer if installing on
a pedestal.
Parts needed
Check local codes. Check existing electrical supply and venting.
See “Electrical Requirements” and “Venting Requirements”
before purchasing parts.
■For close-clearance installations between 31.5" (80.01 cm)
and 37" (93.98 cm), see “Plan Vent System” section for
venting requirements.
Mobile home installations require metal exhaust system hardware
available for purchase from the dealer from whom you purchased
your dryer. For further information, please refer to the “Assistance
or Service” section.
Options
Pedestal
Are you placing the dryer on a pedestal? You have the option of
purchasing pedestals of different heights separately for this dryer.
You may select a 10" (25.4 cm) or 15.5" (39.4 cm) pedestal.
These pedestals will add to the total height of the dryer for a total
height of approximately 48" (121.9 cm) or 53.5" (135.9 cm),
respectively.
For a garage installation, you will need to place the 10" (25.4 cm)
pedestal at least 9" (22.9 cm) above the floor and the
15.5" (39.4 cm) pedestal at least 3.5" (8.9 cm) above the floor.
The pedestals are available in several colors.
To order, call the dealer from whom you purchased your dryer or
refer to the “Assistance or Service” section.
■Flat-blade screwdriver
■#2 Phillips screwdriver
■Adjustable wrench that
opens to 1" (2.54 cm) or
hex-head socket wrench
(for adjusting dryer feet)
■Level
■Vent clamps
■Caulking gun and
compound (for installing
new exhaust vent)
■Tin snips (new vent
installations)
■¼" nut driver or socket
wrench (recommended)
■Tape measure
A. Leveling legs (4)
B. “Y” connector
C. Short inlet hose
D. Inlet hose with right-angle connector
E. Rubber washer
ABCDE
37"
(93.98 cm)
A. 10" (25.4 cm) pedestal
B. 15.5" (39.4 cm) pedestal
Pedestal Height Color Part Number
10" (25.4 cm) White WHP1000SQ
10" (25.4 cm) Diamond Dust
(Silver) WHP1000SU
10" (25.4 cm) Black WHP1000SB
15.5" (39.4 cm) White WHP1500SQ
15.5" (39.4 cm) Diamond Dust
(Silver) WHP1500SU
15.5" (39.4 cm) Black WHP1500SB
15.5" (39.4 cm) New Aspen WHP1500SA
15.5" (39.4 cm) Tuscan Chestnut WHP1500SC
AB

5
Stack Kit
Are you planning to stack your DUET®washer and dryer? To do
so, you will need to purchase a Stack Kit.
To order, call the dealer from whom you purchased your dryer or
refer to the “Assistance or Service” section. Ask for Part Number
8541503.
Door Reversal Kit
Are you planning to reverse the door swing direction on your
DUET® dryer? To do so, you will need to purchase a Door
Reversal Kit.
To order, call the dealer from whom you purchased your dryer or
refer to the “Assistance or Service” section. Ask for Part Number
8579666.
Backguard
If you are installing your DUET®washer and dryer and wish to
avoid having loose items fall behind your machines, you may
purchase a pair of washer/dryer backguards. These will reduce
the chance of items falling behind the machines during operation.
To order, call the dealer from whom you purchased your dryer or
refer to the “Assistance or Service” section. Ask for Part Number
8212452 (White).
Location Requirements
You will need
■A location that allows for proper exhaust installation. See
“Venting Requirements.”
■A separate 30-amp circuit.
■If you are using a power supply cord, a grounded electrical
outlet located within 2 ft (61 cm) of either side of the dryer.
See “Electrical Requirements.”
■A sturdy floor to support the total dryer weight of 200 lbs
(90.7 kg). The combined weight of a companion appliance
should also be considered.
■Cold water faucets located within 4 ft (1.2 m) of the dryer, and
water pressure of 20-100 psi (138-690 kPa). You may use the
cold water supply from your washer using the “Y” connector
provided.
■20-100 psi (138-690 kPa) for best performance.
■A level floor with a maximum slope of 1" (2.5 cm) under entire
dryer. If slope is greater than 1" (2.5 cm), install Extended
Dryer Feet Kit, Part Number 279810. Clothes may not tumble
properly and automatic sensor cycles may not operate
correctly if dryer is not level.
■For a garage installation, you will need to place the dryer at
least 18" (46 cm) above the floor. If using a pedestal, you will
need 18" (46 cm) to the bottom of the dryer.
Do not operate your dryer at temperatures below 45ºF (7ºC). At
lower temperatures, the dryer might not shut off at the end of an
automatic cycle. This can result in longer drying times.
The dryer must not be installed or stored in an area where it will
be exposed to water and/or weather.
Check code requirements. Some codes limit, or do not permit,
installation of the dryer in garages, closets, mobile homes or
sleeping quarters. Contact your local building inspector.
Installation clearances
The location must be large enough to allow the dryer door to
open fully.
Dryer Dimensions
*Most installations require a minimum 5" (12.7 cm) clearance
behind the dryer for the exhaust vent with elbow. See “Venting
Requirements.”
Installation spacing for recessed area or closet installation
The following spacing dimensions are recommended for this
dryer. This dryer has been tested for spacing of 0" (0 cm)
clearance on the sides and rear. Recommended spacing should
be considered for the following reasons:
■Additional spacing should be considered for ease of
installation and servicing.
■Additional clearances might be required for wall, door and
floor moldings.
■Additional spacing should be considered on all sides of the
dryer to reduce noise transfer.
■For closet installation, with a door, minimum ventilation
openings in the top and bottom of the door are required.
Louvered doors with equivalent ventilation openings are
acceptable.
■Companion appliance spacing should also be considered.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Place dryer at least 18 inches (46 cm) above the floor
for a garage installation.
Failure to do so can result in death, explosion, or fire.
38"
(96.52 cm )
*32 ⁹⁄₁₆"
(82.65 cm)
27"
(68.6 cm)
52 ⁹⁄₁₆"
(133.16 cm)

6
Custom undercounter installation - Dryer only
*Required spacing
Closet installation - Dryer only
*Required spacing
**For side or bottom venting, 2" (5.1 cm) spacing is allowed.
Recessed or closet installation - Dryer on pedestal
*Required spacing
**For side or bottom venting, 2" (5.1 cm) spacing is allowed.
Recommended installation spacing for cabinet
installation
■For cabinet installation, with a door, minimum ventilation
openings in the top of the cabinet are required.
*Required spacing
**For side or bottom venting, 2" (5.1 cm) spacing is allowed.
Recommended installation spacing for recessed or
closet installation, with stacked washer and dryer
The dimensions shown are for the recommended spacing.
*Required spacing
*Required spacing
**For venting out the side, 2" (5.1 cm) spacing is allowed.
A. Side view - closet or confined area
B. Closet door with vents
A. Recessed area
B. Side view - closet or confined area
0"
(0 cm)
1"*
(2.5 cm) 1"*
(2.5 cm)
38" min.
(96.52 cm)
27"
(68.6 cm)
AB
14" max.*
(35.6 cm)
18" min.*
(45.72 cm)
1"*
5"**
(12.7 cm)
(82.65 cm)
48 in.
2*
(310 cm
2
)
24 in.
2*
(155 cm
2
)
3"*
(7.6 cm)
3"*
(7.6 cm)
(2.5 cm) 32⁹⁄₁₆"
AB
1"
(2.5 cm)
1"
(2.5 cm)
1"*
(2.5 cm)
5"**
(12.7 cm)
27"
(68.6 cm)
(82.65 cm)
18" min.*
(45.72 cm)
14" max.*
(35.6 cm)
32⁹⁄₁₆"
7"* (17.8 cm)
9"*
(22.9 cm)
7"* (17.8 cm)
5"**
(12.7 cm) 32⁹⁄₁₆"
(82.65 cm) 27" (68.6 cm)
1"*
(2.5 cm) 1" 1"
(2.5 cm)
(2.5 cm)
48 in.
2
*
(310 cm
2
)
3"* (7.6 cm)
3"* (7.6 cm)
1"* (2.5 cm)
24 in.
2
*
(155 cm
2
)
6"* (15.2 cm)
76"
(193 cm)
27"
(68.6 cm)
5¹⁄₂"**
(14 cm)
1"
(2.5 cm)
1"
(2.5 cm)

7
Mobile home - Additional installation requirements
This dryer is suitable for mobile home installations. The
installation must conform to the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280
(formerly the Federal Standard for Mobile Home Construction
and Safety, Title 24, HUD Part 280) or Standard CAN/CSA-Z240
MH.
Mobile home installations require:
■Metal exhaust system hardware, which is available for
purchase from your dealer.
■Special provisions must be made in mobile homes to
introduce outside air into the dryer. The opening (such as a
nearby window) should be at least twice as large as the dryer
exhaust opening.
Electrical Requirements
It is your responsibility
■To contact a qualified electrical installer.
■To be sure that the electrical connection is adequate and in
conformance with the Canadian Electrical Code, C22.1-latest
edition and all local codes. A copy of the above codes
standard may be obtained from: Canadian Standards
Association, 178 Rexdale Blvd., Toronto, ON M9W 1R3
CANADA.
■To supply the required 4 wire, single phase, 120/240 volt,
60 Hz., AC only electrical supply on a separate 30-amp
circuit, fused on both sides of the line. A time-delay fuse or
circuit breaker is recommended. Connect to an individual
branch circuit.
■This dryer is equipped with a CSA International Certified
Power Cord intended to be plugged into a standard 14-30R
wall receptacle. The cord is 5 ft (1.52 m) in length. Be sure
wall receptacle is within reach of dryer’s final location.
4-wire receptacle 14-30R
If using a replacement power supply cord, it is recommended
that you use Power Supply Cord Replacement Part Number
9831317.
For further information, please reference the service
numbers located in the “Assistance or Service” section.
Venting Requirements
WARNING: To reduce the risk of fire, this dryer MUST BE
EXHAUSTED OUTDOORS.
IMPORTANT: Observe all governing codes and ordinances.
The dryer exhaust must not be connected into any gas vent,
chimney, wall, ceiling or a concealed space of a building.
If using an existing vent system
■Clean lint from the entire length of the system and make sure
exhaust hood is not plugged with lint.
■Replace any plastic or metal foil vent with rigid or flexible
heavy metal vent.
■Review Vent system chart. Modify existing vent system if
necessary to achieve the best drying performance.
WARNING
Electrical Shock Hazard
Plug into a grounded 4 prong outlet.
Failure to do so can result in death or electrical shock.
For a grounded, cord-connected dryer:
This dryer must be grounded. In the event of malfunction
or breakdown, grounding will reduce the risk of electric shock
by providing a path of least resistance for electric current. This
dryer is equipped with a cord having an equipment-grounding
conductor and a grounding plug. The plug must be plugged
into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
WARNING: Improper connection of the equipment-
grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service representative or
personnel if you are in doubt as to whether the dryer is
properly grounded. Do not modify the plug provided with the
dryer: if it will not fit the outlet, have a proper outlet installed
by a qualified electrician.
WARNING
Fire Hazard
Use a heavy metal vent.
Do not use a plastic vent.
Do not use a metal foil vent.
Failure to follow these instructions can result in death
or fire.

8
If this is a new vent system
Vent material
■Use a heavy metal vent. Do not use plastic or metal foil vent.
■4" (10.2 cm) heavy metal exhaust vent and clamps must be
used. DURASAFE™ venting products are recommended.
DURASAFE™ vent products can be purchased from your
dealer or by calling Whirlpool Parts and Accessories. For
more information, see the “Assistance or Service” section.
Rigid metal vent
■For best drying performance, rigid metal vents are
recommended.
■Rigid metal vent is recommended to avoid crushing and
kinking.
Flexible metal vent
■Flexible metal vents are acceptable only if accessible for
cleaning.
■Flexible metal vent must be fully extended and supported
when the dryer is in its final location.
■Remove excess flexible metal vent to avoid sagging and
kinking that may result in reduced airflow and poor
performance.
■Do not install flexible metal vent in enclosed walls, ceilings or
floors.
Elbows
45° elbows provide better airflow than 90° elbows.
Clamps
■Use clamps to seal all joints.
■Exhaust vent must not be connected or secured with screws
or other fastening devices that extend into the interior of the
duct. Do not use duct tape.
Exhaust
Recommended hood styles are shown here.
The angled hood style (shown here) is acceptable.
■An exhaust hood should cap the vent to keep rodents and
insects from entering the home.
■Exhaust hood must be at least 12" (30.5 cm) from the ground
or any object that may be in the path of the exhaust (such as
flowers, rocks or bushes, snow line, etc.).
■Do not use an exhaust hood with a magnetic latch.
Plan Vent System
Choose your exhaust installation type
Recommended exhaust installations
Typical installations vent the dryer from the rear of the dryer.
Other installations are possible.
4" (10.2 cm) heavy metal exhaust vent
Good Better
Clamp
4"
10.2 cm A. Louvered hood style
B. Box hood style
A. Dryer
B. Elbow
C. Wall
D. Exhaust hood
E. Clamps
F. Rigid metal or flexible metal vent
G. Vent length necessary to connect elbows
H. Exhaust outlet
4"
(10.2 cm)
4"
(10.2 cm)
B
A
4"
(10.2 cm)
2½"
(6.4 cm)
Improper venting can cause moisture and lint to collect
indoors, which may result in:
Moisture damage to woodwork, furniture, paint, wallpaper,
carpets, etc.
Housecleaning problems and health problems.
H
G
F
E
D
C
A
B

9
Optional exhaust installations
This dryer can be converted to exhaust out the right side, left
side, or through the bottom. Contact your local dealer to have the
dryer converted.
Alternate installations for close clearances
Venting systems come in many varieties. Select the type best for
your installation. Two close-clearance installations are shown.
Refer to the manufacturer’s instructions.
NOTE: The following kits for close clearance alternate
installations are available for purchase. To order, please see the
“Assistance or Service” section.
■Over-the-Top Installation:
Part Number 4396028
■Periscope Installation (For use with dryer vent to wall vent
mismatch):
Part Number 4396037 - 0" (0 cm) to 18" (45.72 cm) mismatch
Part Number 4396011 - 18" (45.72 cm) to 29" (73.66 cm)
mismatch
Part Number 4396014 - 29" (73.66 cm) to 50" (127 cm)
mismatch
Special provisions for mobile home installations
The exhaust vent must be securely fastened to a noncombustible
portion of the mobile home structure and must not terminate
beneath the mobile home. Terminate the exhaust vent outside.
Determine vent path
■Select the route that will provide the straightest and most
direct path outdoors.
■Plan the installation to use the fewest number of elbows and
turns.
■When using elbows or making turns, allow as much room as
possible.
■Bend vent gradually to avoid kinking.
■Use the fewest 90° turns possible.
Determine vent length and elbows needed for best
drying performance
■Use the following Vent system chart to determine type of vent
material and hood combinations acceptable to use.
NOTE: Do not use vent runs longer than those specified in
the Vent system chart. Exhaust systems longer than those
specified will:
■Shorten the life of the dryer.
■Reduce performance, resulting in longer drying times and
increased energy usage.
The Vent system chart provides venting requirements that will
help to achieve the best drying performance.
A. Standard rear offset exhaust installation
B. Left or right side exhaust installation
C. Bottom exhaust installation (not an option
with pedestal installations)
A. Over-the-top installation (also available with one
offset elbow)
B. Periscope installation
WARNING
Fire Hazard
Cover unused exhaust holes with one of the
following kits:
279818 (white)
279820 (black)
279925 (biscuit)
279969 (pewter)
280171 (diamond dust)
W10152954 (new aspen)
W10152955 (tuscan chestnut)
Contact your local dealer.
Failure to follow these instructions can result in death,
fire, electrical shock, or serious injury.
ABC
AB

10
Vent system chart
NOTE: Side and bottom exhaust installations have a 90º turn
inside the dryer. To determine maximum exhaust length, add one
90º turn to the chart.
Install Vent System
1. Install exhaust hood. Use caulking compound to seal exterior
wall opening around exhaust hood.
2. Connect vent to exhaust hood. Vent must fit inside exhaust
hood. Secure vent to exhaust hood with 4" (10.2 cm) clamp.
3. Run vent to dryer location. Use the straightest path possible.
See “Determine vent path” in “Plan Vent System.” Avoid 90º
turns. Use clamps to seal all joints. Do not use duct tape,
screws or other fastening devices that extend into the interior
of the vent to secure vent.
Install Leveling Legs
1. To protect the floor, use a large flat piece of cardboard from
the dryer carton. Place cardboard under the entire back edge
of the dryer.
2. Firmly grasp the body of the dryer (not the console panel).
Gently lay the dryer on the cardboard. See illustration.
3. Examine the leveling legs. Find the diamond marking.
4. Screw the legs into the leg holes by hand. Use a wrench to
finish turning the legs until the diamond marking is no longer
visible.
5. Place a carton corner post from dryer packaging under each
of the 2 dryer back corners. Stand the dryer up. Slide the
dryer on the corner posts until it is close to its final location.
Leave enough room to connect the exhaust vent.
Connect Vent
1. Using a 4" (10.2 cm) clamp, connect vent to exhaust outlet in
dryer. If connecting to existing vent, make sure the vent is
clean. The dryer vent must fit over the dryer exhaust outlet
and inside the exhaust hood. Check that the vent is secured
to exhaust hood with a 4" (10.2 cm) clamp.
2. Move dryer into its final location. Do not crush or kink vent.
3. (On gas models) Check that there are no kinks in the flexible
gas line.
4. Once the exhaust vent connection is made, remove the
corner posts and cardboard.
Connect Inlet Hose
The dryer must be connected to the cold water faucet using the
new inlet hoses. Do not use old hoses.
1. Turn cold water faucet off and remove washer inlet hose.
2. Remove old rubber washer from inlet hose and replace with
new rubber washer provided. If space permits, attach the
brass female end of the “Y” connector to the cold water
faucet.
NOTE: If “Y” connector can be attached directly to cold water
faucet, go to Step 6. If “Y” connector cannot be attached
directly to the cold water faucet, the short hose must be
used. Continue with Step 3.
3. Attach short hose to cold water faucet. Screw on coupling by
hand until it is seated on faucet.
4. Using pliers, tighten the couplings with an additional two-
thirds turn.
NOTE: Do not overtighten. Damage to the coupling can
result.
5. Attach “Y” connector to brass male end of small hose. Screw
on coupling by hand until it is seated on connector.
6. Attach straight end of long hose to “Y” connector.
7. Attach washer cold inlet hose to other end of “Y” connector.
Screw on coupling by hand until it is seated on connector.
Number of
90º turns
or elbows
Type of
vent Box or louvered
hoods
Angled
hoods
0 Rigid metal
Flexible metal 64 ft (20 m) 36 ft (11 m) 58 ft (17.7 m) 28 ft (8.5 m)
1 Rigid metal
Flexible metal 54 ft (16.5 m) 31 ft (9.4 m) 48 ft (14.6 m) 23 ft (7 m)
2 Rigid metal
Flexible metal 44 ft (13.4 m) 27 ft (8.2 m) 38 ft (11.6 m) 19 ft (5.8 m)
3 Rigid metal
Flexible metal 35 ft (10.7 m) 25 ft (7.6 m) 29 ft (8.8 m) 17 ft (5.2 m)
4 Rigid metal
Flexible metal 27 ft (8.2 m) 23 ft (7 m) 21 ft (6.4 m) 15 ft (4.6 m)
WARNING
Excessive Weight Hazard
Use two or more people to move and install dryer.
Failure to do so can result in back or other injury.

11
8. Using pliers, tighten the couplings with an additional two-
thirds turn.
NOTE: Do not overtighten. Damage to the coupling can
result.
9. Attach angled end of long hose to fill valve at bottom of dryer
back panel. Screw on coupling by hand until it is seated on fill
valve connector.
10. Using pliers, tighten the coupling with an additional two-
thirds turn.
NOTE: Do not overtighten. Damage to the coupling can
result.
11. Check that the water faucets are on.
12. Check for leaks around “Y” connector, faucet and hoses.
Level Dryer
Check the levelness of the dryer. Check levelness first side to
side, then front to back.
If the dryer is not level, prop up the dryer using a wood block.
Use a wrench to adjust the legs up or down and check again for
levelness.
Complete Installation
1. Check that all parts are now installed. If there is an extra part,
go back through the steps to see which step was skipped.
2. Check that you have all of your tools.
3. Dispose of/recycle all packaging materials.
4. Be sure the water faucets are on.
5. Check for leaks around “Y” connector, faucet and hoses.
6. Check the dryer’s final location. Be sure the vent is not
crushed or kinked.
7. Check that the dryer is level. See “Level Dryer.”
8. Plug into a grounded 4 prong outlet. Turn on power.
9. Remove the blue protective film on the console and any tape
remaining on the dryer.
10. Read “Dryer Use.”
11. Wipe the dryer drum interior thoroughly with a damp cloth to
remove any dust.
12. If you live in a hard water area, use of a water softener is
recommended to control the buildup of scale through the
water system in the dryer. Over time, the buildup of lime scale
may clog different parts of the water system, which will
reduce product performance. Excessive scale buildup may
lead to the need for certain part replacement or repair.
13. Select a Timed Dry heated cycle, and start the dryer. Do not
select the Air Only Temperature setting.
If the dryer will not start, check the following:
■Controls are set in a running or “On” position.
■Start button has been pushed firmly.
■Dryer is plugged into an outlet and/or electrical supply
is connected.
■Household fuse is intact and tight, or circuit breaker has
not tripped.
■Dryer door is closed.
This dryer automatically runs an installation diagnostic routine at
the start of its first cycle.
If you receive an L2 code, there may be a problem with your
home power supply keeping the dryer’s heater from turning
on. See “Troubleshooting.”
If you receive an AF code, your dryer vent may be crushed or
blocked. See “Troubleshooting.”
NOTE: You may notice a burning odor when the dryer is first
heated. This odor is common when the heating element is first
used. The odor will go away.
A. Inlet to cold water
A

12
DRYER USE
Starting Your Dryer
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
This manual covers several different models. Your dryer may not
have all of the cycles and features described.
The following is a guide to starting your dryer. Please refer to
specific sections of this manual for more detailed information.
1. Clean lint screen before each load. See “Cleaning the Lint
Screen.”
2. Place laundry in dryer and shut door.
3. Press the POWER button then rotate the dial to select either
an Automatic or Manual Cycle. The preset settings and drying
time for the cycle chosen will be displayed.
NOTE: A default time is displayed when an Automatic Cycle
is selected. During the first few minutes of the drying process,
the cycle time may automatically vary from the default time
based on the size and fabric type of the load. Toward the end
of the drying process, the estimated time display will adjust
again, showing the final drying time.
To use an Automatic Cycle
NOTE: A light next to each feature will glow green when the
feature is selected or will glow amber when the feature is
selectable. The light will not glow when the selection is
unavailable with the cycle or option combinations selected.
■Press the POWER button.
■Rotate the dial to select an Automatic Cycle.
■Select DRYNESS LEVEL to adjust how dry you want the
load to be. As the cycle runs, the control senses the
dryness of the load and adjusts the time automatically for
the selected Dryness Level.
NOTE: Most loads may be dried using Normal, which is
shown in boldface type on your control panel. Normal is the
energy preferred dryness level and will use the least energy.
The default dryness setting is Normal when an Auto Dry
Cycle is selected. You can select a different dryness level,
depending on your load, by pressing DRYNESS LEVEL
and choosing More, Normal or Less. Selecting More,
Normal or Less automatically adjusts the dryness level at
which the dryer will shut off. Once a dryness level is set, it
cannot be changed without stopping the cycle.
The Dryness Level can be changed only with Automatic
Cycles.
NOTE: The More/Less Dry settings are not available on the
Sanitize cycle.
■Press the WRINKLE SHIELD™ feature button if this
option is desired.
■Press the CYCLE SIGNAL button to set end of cycle
signal volume to desired level.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Do not dry anything that has ever had anything
flammable on it (even after washing).
Failure to follow these instructions can result in death,
explosion, or fire.
WARNING
Fire Hazard
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on
it (including cooking oils).
Items containing foam, rubber, or plastic must be dried
on a clothesline or by using an Air Cycle.
Failure to follow these instructions can result in death
or fire.

13
■Press the DAMP DRY CYCLE SIGNAL button to set damp
dry signal volume to desired level.
■Press and hold START button until dryer starts (about
1 second).
Once an Automatic cycle has started, the WRINKLE
SHIELD™ feature and cycle signals can be adjusted. Press
the PAUSE/CANCEL key twice to clear the settings, allowing
you to select another cycle and Dryness Level.
NOTE: Time and Temperature are not adjustable for
Automatic Cycles. Pressing the DRY TIME or TEMPERATURE
buttons will cause a triple beep, indicating that the time
cannot be changed.
How Automatic Cycles Work
The AccelerCare™ function improves drying performance
with Auto Moisture Sensing Plus, which advances the cycle
as moisture is extracted from clothing. A thermistor
(electronic temperature sensor) and moisture sensing strips in
the dryer drum help measure the amount of moisture in the
clothes as they tumble. An electronic control determines the
load type to help save time, avoid overdrying, and increase
the accuracy of the end dryness level. After the first 5 minutes
of an automatic cycle, the estimated time display will adjust
based on the approximate load size, cycle, dryness level
selected and amount of moisture left in the clothes. When the
clothes have reached approximately 80% of the dryness level
selected, the estimated time display will adjust again,
showing the final drying time. The AccelerCare™ feature
takes the guesswork out of drying time and enhances fabric
care.
To use a Manual Cycle
NOTE: A light next to each feature will glow green when the
feature is selected or will glow amber when the feature is
selectable. The light will not glow when the selection is
unavailable with the cycle or option combinations selected.
■Press POWER.
■Rotate the dial to select a Manual Cycle.
■Press the DRY TIME up or down buttons until the desired
drying time is displayed. Press DRY TIME, and the time
will change by 1-minute intervals. Press and hold DRY
TIME, and the time will change by 5-minute intervals. The
initial time displayed is the actual drying time.
The Dry Time feature can be used only with Manual
Cycles and the Enhanced Touch Up Cycle.
■Press TEMPERATURE until the desired temperature
glows green.
Temperature settings can be changed only with Manual
Cycles.
■Press the WRINKLE SHIELD™ feature button if this
option is desired.
■Press the CYCLE SIGNAL button to set end of cycle
signal volume to desired level.
■Press and hold START button until dryer starts (about
1 second).
NOTE: Dryness Level is not adjustable for Manual, Steam or
Sanitize Cycles. Pressing the Dryness Level button will cause
the triple beep indicating that this option is not selectable.
While a Manual Cycle is running, you cannot change the
cycle until you clear the settings. You can change the settings
for Time, Temperature, the WRINKLE SHIELD™ feature and
the cycle signals. Press the PAUSE/CANCEL key twice to
clear the settings, allowing you to select another cycle.
To use a Steam Cycle
■Press the POWER button.
■Rotate the dial to select either the Enhanced Touch Up or
Quick Refresh cycles.
■Press the DRY TIME up or down buttons until the desired
drying time is displayed. Press DRY TIME, and the time
will change by 1-minute intervals. Press and hold DRY
TIME, and the time will change by 5-minute intervals. The
initial time displayed is the actual drying time.
NOTE: The More Time and Less Time buttons can be
used only with Manual Cycles and the Enhanced Touch
Up Cycle.
■Press TEMPERATURE until the desired temperature
glows green.
NOTE: During the Enhanced Touch Up Cycle, you can
change the settings for Time, Temperature, the WRINKLE
SHIELD™ feature and Cycle Signal. During the Quick Refresh
Cycle you can change the WRINKLE SHIELD™ feature and
the Cycle Signal. Press STOP twice to stop the dryer and
clear the settings. Select another cycle or option.
Stopping Your Dryer
To stop your dryer at any time
Press PAUSE/CANCEL twice or open the door.
Pausing or Restarting
To pause the dryer at any time
Open the door or press PAUSE/CANCEL once.
To restart the dryer
Close the door and press and hold START button until dryer
starts.
NOTE: Drying will continue from where the cycle was interrupted,
if you close the door and press Start within 5 minutes. If the cycle
is interrupted for more than 5 minutes, the dryer will shut off.
Select new cycle settings before restarting the dryer.

14
Control Locked
This feature allows you to lock your settings to avoid unintended
use of the dryer. You can also use the Control Locked feature to
avoid unintended cycle or option changes during dryer operation.
To enable the Control Locked feature when dryer is
running:
Press and hold the CONTROL LOCK/UNLOCK button for
3 seconds. The control is locked when a single beep is heard and
the Control Locked status light is on.
■When the dryer is off, it is not necessary to press the Control
On button before activating the Control Locked feature.
To unlock:
Press and hold the CONTROL LOCK/UNLOCK button for
3 seconds to turn this feature off.
NOTE: When the dryer is running and Control Locked is on, the
dryer can be stopped by pressing the Pause/Cancel button, but
cannot be restarted until the control is unlocked.
Drying and Cycle Tips
Select the correct cycle and dryness level or temperature for your
load. If an Automatic Cycle is running, the display shows the
estimated cycle time when your dryer is automatically sensing
the dryness level of your load. If a Manual Cycle is running, the
display shows the exact number of minutes remaining in the
cycle.
Cool Down tumbles the load without heat during the last few
minutes of all cycles. Cool Down makes the loads easier to
handle and reduces wrinkling. The length of the Cool Down
depends on the load size and dryness level.
Drying tips
■Follow care label directions when they are available.
■If desired, add a fabric softener sheet. Follow package
instructions.
■Remove the load from the dryer as soon as tumbling stops to
reduce wrinkling. This is especially important for permanent
press, knits and synthetic fabrics.
■Avoid drying heavy work clothes with lighter fabrics. This
could cause overdrying of lighter fabrics, leading to increased
shrinking or wrinkling.
■If you dry sheets in a mixed load or large items in the Bulky
Items cycle, rearrange the load when the signal sounds. This
will aid in the drying process.
Cycle tips
■Dry most loads using the preset cycle settings.
■Refer to the Automatic or Manual Preset Cycle Settings chart
(in the “Cycles” section) for a guide to drying various loads.
■Drying temperature and Dryness Level are preset when
you choose an Automatic Cycle. You can choose a
different dryness level, depending on your load by
pressing the DRYNESS LEVEL button to select MORE,
NORMAL or LESS.
■If you wish to adjust the cycle length of a Manual Cycle,
you must press the DRY TIME up or down buttons. Adjust
the temperature of a Manual Cycle by pressing
TEMPERATURE until the desired temperature is selected.
NOTE: You cannot choose a Dryness Level with Manual,
Steam or Sanitize Cycles.
Status Lights
You may follow the progress of your dryer with the drying Status
indicator lights.
WRINKLE SHIELD™ Feature
The WRINKLE SHIELD™ feature light glows during the WRINKLE
SHIELD™ feature (when selected).
Steam Feature
The Steam light glows when the dryer is dispensing water during
the Quick Refresh and Enhanced Touch Up cycles.
Wet
The Wet light will turn on when a wet item has been detected in
the dryer. The Wet light will remain on until:
■The damp dry point is reached in an Automatic Cycle.
■The dryer enters the cool down period in a Manual Cycle.
Damp
The Damp light indicates that the load has reached the damp dry
level. To be alerted when your load is approximately 80% dry, you
may use the Damp Dry Signal option. See “Damp Dry Signal” in
“Additional Features” section.
NOTE: The Damp light is not used with manual cycles.
Cool Down
The Cool Down light glows during the cool down part of the
cycle. Laundry is cooling down for ease in handling.
Done
The Done light illuminates when the drying cycle is finished. This
indicator stays on during the WRINKLE SHIELD™feature.
Indicator lights
Other indicator lights on the control panel show Cycle,
Temperature, Dryness Level, and cycle signal settings selected.
The time display will indicate the estimated or actual time
remaining in a cycle.

15
Cycles
Select the drying cycle that matches the type of load you are
drying. See Automatic Preset or Manual Preset Cycle Settings
chart.
Cycle Control knob
Automatic Cycles
Automatic Cycles allow you to match the cycle to the load you
are drying. See the following Automatic Preset Cycle Settings
chart. Each cycle dries certain fabrics at the recommended
temperature. A sensor detects the moisture in the load and
automatically adjusts the drying time for optimal drying.
Sanitize
Use this cycle for items such as towels, bedding, children’s
clothing or other items needing to be sanitized. This cycle is
designed to eliminate 99.9% of 3 common infectious bacteria.
This cycle should be run to completion to ensure sanitization. For
best results, do not interrupt cycle.
Heavy Duty
Use this cycle to get High heat for heavyweight mixed loads,
cotton towels or jeans.
Bulky Items
Use this cycle to get Medium heat for drying large items that
require very long drying times such as jackets, comforters and
pillows. Rearrange the load halfway through the dryer cycle. This
will aid in the drying process.
Normal
Use this cycle to get Medium heat for drying sturdy fabrics such
as work clothes and sheets.
Casual
Use this cycle to get Low heat for drying no-iron fabrics such as
sport shirts, casual business clothes and permanent press
blends.
Delicate
Use this cycle to get Low heat to gently dry items such as
washable knit fabrics.
Super Delicate
Use this cycle to get Extra-Low heat to gently dry items such as
lingerie.
Damp Dry
Use this cycle to dry items to a damp level using Low heat. Damp
dry items such as jeans (to avoid stiffness) or cotton clothing (to
make ironing easier). The temperature setting on this cycle
cannot be adjusted. Items will have different levels of dampness.
At the end of this cycle, clothes will be damp. To be alerted when
this cycle is complete, select the End of Cycle Signal.
Automatic Preset Cycle Settings
*Estimated Time with Dryness Level (Normal) setting. Time will
vary depending on load type and load size.
Manual Cycles
Use Manual Cycles to select a specific amount of drying time and
a drying temperature. When a Manual Cycle is selected, the
Estimated Time Remaining display shows the actual time
remaining in your cycle. You can change the actual time in the
cycle by pressing the DRY TIME up or down buttons.
Timed Dry
Use this cycle to complete drying if items are still damp after an
Automatic Cycle. Timed Dry is also useful for drying heavyweight
and bulky items such as bedspreads and work clothes.
Lightweight garments, such as exercise wear, can be dried using
Timed Dry on a Low temperature setting.
Quick Dry
Use this cycle for drying small loads or loads that need a short
drying time.
NSF Protocol P154
Sanitization Performance of
Residential Clothes Dryers
Automatic Cycles
Load Type Temperature Time* (Minutes)
SANITIZE
Towels, bedding,
children’s clothing
High 60
HEAVY DUTY
Heavyweight items, towels, jeans High 50
BULKY ITEMS
Jackets, comforters, pillows Medium 55
NORMAL
Corduroys, work clothes, sheets Medium 40
CASUAL
Permanent press, synthetics Low 35
DELICATE
Lingerie, blouses, washable
woolens
Low 30
SUPER DELICATE
Lingerie, blouses, washable
woolens
Extra Low 25
DAMP DRY
Clothes to come out suitable for
ironing
Low 20

16
Manual Preset Cycle Settings
Air Only
Use Timed Dry/Air Only temperature setting for items that require
drying without heat such as rubber, plastic and heat-sensitive
fabrics. This chart shows examples of items that can be dried
using Air Only.
*Reset time to complete drying, if needed.
When using Air Only
■Check that coverings are securely stitched.
■Shake and fluff pillows by hand periodically during the cycle.
■Dry item completely. Foam rubber pillows are slow to dry.
NOTE: Automatic Cycles are not available when using the Air
Only setting.
Steam Cycles
In these cycles, a small amount of water is sprayed into the dryer
drum after several minutes of tumbling with heat. The STEAM
status light will come on while the water is sprayed into the drum.
The dryer will continue to tumble at High heat for the duration of
the cycle. The Steam cycles include Quick Refresh and
Enhanced Touch Up. The heat setting and cycle time are not
adjustable for the Quick Refresh cycle, but can be adjusted for
the Enhanced Touch Up cycle.
NOTE: Results may vary depending on fabric. 100% cotton
garments with wrinkle-free finish may yield better results than
those without.
Use of a fabric softener sheet is not recommended with steam
cycles as it may cause temporary staining on the clothes.
Quick Refresh
This cycle is best for smoothing out wrinkles and reducing odors
from loads consisting of one to four dry items of wrinkle-free
cotton, cotton-polyester blend, common knits and synthetic
garments.
Enhanced Touch Up
This cycle uses water and heat to help smooth out wrinkles from
items such as clothes packed in a suitcase or wrinkled from
being left in the dryer too long.
*Temperature and time are selectable only for the Enhanced
Touch Up Cycle.
NOTE: The Enhanced Touch Up cycle has a minimum dry time of
15 minutes and a maximum dry time of 40 minutes. Only the
Medium and High temperature settings can be used for the
Enhanced Touch Up cycle.
Additional Features
Drum Light
Select Drum Light to turn on the light inside the dryer drum.
During a cycle, if Drum Light is selected, the drum light turns on
and will remain on until DRUM LIGHT is pressed again, the door
is open and closed, or the door is left open for 20 minutes.
When the dryer is not running, the drum light will turn on when
DRUM LIGHT is pressed or the dryer door is opened, and it will
remain on until the dryer door has been open for 20 minutes, the
dryer door is closed or DRUM LIGHT is pressed again.
Press DRUM LIGHT at any time to turn the drum light ON or OFF.
WRINKLE SHIELD™ Feature
When you are unable to remove a load of clothes from the dryer
as soon as it stops, wrinkles can form. The WRINKLE SHIELD™
feature periodically tumbles, rearranges and fluffs the load to help
keep wrinkles from forming.
■Press the WRINKLE SHIELD™ feature to get up to
140 minutes of heat-free, periodic tumbling at the end of a
cycle.
■Stop at any time by pressing the WRINKLE SHIELD™ feature
or opening the dryer door.
■For the Casual Cycle, the WRINKLE SHIELD™ feature is
preset to “ON.” The other cycles will retain the WRINKLE
SHIELD™ feature setting. (For example, if you select the
WRINKLE SHIELD™ feature in the Normal cycle, the
WRINKLE SHIELD™ feature will be on the next time you
select the Normal cycle.)
NOTE: If you do not select the WRINKLE SHIELD™ feature, the
dryer stops after the cool down period.
Manual Cycles
Load Type Temperature Default Time (Minutes)
TIMED DRY
Heavyweight items, bulky
items, bedspreads, work
clothes
High 40
QUICK DRY
Small loads High 21
Type of Load Time*
(Minutes)
Foam rubber - pillows, padded bras, stuffed toys 20 - 30
Plastic - Shower curtains, tablecloths 20 - 30
Rubber-backed rugs 40 - 50
Olefin, polypropylene, sheer nylon 10 - 20
Steam Preset Cycle Settings
Timed Cycles
Load Type Default Temperature* Default Time (Minutes)*
QUICK REFRESH
Helps to smooth out
wrinkles and reduce odors
from loads consisting of
one to four dry items.
Medium 15
ENHANCED TOUCH UP
Helps to smooth out
wrinkles in loads left in the
dryer for an extended
period.
Medium 20

17
Damp Dry Signal
On some models, the Damp Dry Signal may be selected to alert
you that your clothes are approximately 80% dry. This is useful
when you want to remove lightweight items in a mixed load to
avoid overdrying or remove partially dry items that may need
ironing.
The DAMP DRY SIGNAL is useful when drying bedsheets/linens
in a mixed load. When the signal goes off, open the door to stop
the dryer, rearrange the load inside the dryer, close the door and
restart the dryer to finish the drying cycle. Rearranging the load
will aid in the drying process.
Press DAMP DRY SIGNAL until the desired volume (Loud, Soft or
Off) glows green.
NOTE: The Damp Dry Signal is available only with the Automatic
Cycles. The Damp Dry Signal is not a selectable option for the
Sanitize cycle.
Cycle Signal
The End of Cycle Signal produces an audible sound when the
drying cycle is finished. Promptly removing clothes at the end of
the cycle reduces wrinkling.
Press CYCLE SIGNAL until the desired volume (Loud, Soft or Off)
glows green.
NOTE: When the WRINKLE SHIELD™ feature is selected and the
End of Cycle Signal is on, an audible sound will be emitted every
5 minutes until the clothes are removed, or the WRINKLE
SHIELD™ feature is finished.
Button Sound
You can change the volume of the sound of the beeps. Press
BUTTON SOUND until the desired volume (Loud, Soft or Off)
glows green. The Power and Cancel buttons will still beep softly
even when the Button Sound volume is set to Off.
Changing Cycles, Options and Modifiers
You can change Auto Cycles, Timed Cycles, Modifiers and
Options anytime before pressing Start.
■Three short tones sound if an unavailable combination is
selected. The last selection will not be accepted.
Changing Cycles after pressing Start
1. Press PAUSE/CANCEL twice. This ends the current cycle.
2. Select the desired cycle and options.
3. Press and hold START. The dryer starts at the beginning of
the new cycle.
NOTE: If you do not press Start within 5 minutes of selecting the
cycle, the dryer automatically shuts off.
Changing Modifiers and Options after pressing Start
You can change a Modifier or Option anytime before the selected
Modifier or Option begins.
1. Press PAUSE/CANCEL once.
2. Select the new Modifier and/or Option.
3. Press and hold START to continue the cycle.
NOTE: If you happen to press Pause/Cancel twice, the program
clears and your dryer shuts down. Restart the selection process.
Changing the Preset Dryness Level Settings
If all your loads on all Auto Dry cycles are consistently not as dry
as you would like, you may change the preset Dryness Level
settings to increase the dryness. This change will affect all of your
Auto Dry cycles.
Your Dryness Level settings can be adjusted to adapt to different
installations, environmental conditions or personal preference.
There are 3 drying settings: 1 (factory preset dryness level),
2 (slightly dryer clothes, approximately 15% more drying time)
and 3 (much dryer clothes, approximately 30% more drying
time).
1. The Dryness Level settings cannot be changed while the
dryer is running.
2. Press and hold the Dryness Level button for 5 seconds. The
dryer will beep, and “CF” will be displayed for 1 second
followed by the current drying setting.
3. To select a new drying setting, press the Dryness Level key
again until the desired drying setting is shown.
NOTE: While cycling through the settings, the current setting
will not flash, but the other settings will flash.
4. Press START to save the drying setting.
5. The drying setting you selected will become your new preset
drying setting for all Auto Dry cycles.

18
Drying Rack Option
The drying rack is useful for drying items you would not
necessarily want to tumble dry or that you would normally line dry
(for example, sweaters).
To order, call the dealer from whom you purchased your dryer or
refer to the “Assistance or Service” section. Ask for Part Number
W10143399.
To use the drying rack
Do not remove the lint screen.
1. Open dryer door.
2. Place drying rack inside dryer drum, positioning the back wire
on the ledge of the inner dryer back panel. Push down on
front edge of drying rack to secure over the lint screen.
3. Put the wet items on top of the drying rack. Leave space
between the items so air can reach all the surfaces.
NOTE: Do not allow items to hang over the edge of the drying
rack.
4. Close the door.
5. Select Timed Dry and desired temperature (see following
chart). Items containing foam, rubber, or plastic must be dried
on a clothesline or by using the Air Only temperature setting.
NOTE: Do not use automatic cycles with the drying rack.
6. You must select a time by pressing the DRY TIME up or down
buttons. Reset time as needed to complete drying. Refer to
the following table.
7. Press and hold START button (about 1 second).
NOTE: Check the lint screen and remove any lint accumulated
from items dried on the drying rack.
This chart shows examples of items that can be rack dried and
the suggested cycle, temperature setting and drying time. Actual
drying time will depend on the amount of moisture items hold.
*(Minutes) Reset time to complete drying, if needed.
NOTE: You must remove drying rack for normal tumbling.
A. Front edge
A. Dryer rack front edge
B. Dryer back panel
A
A
B
Rack Dry Setting Temp. Time*
Wool Sweaters
Block to shape and lay flat on
the drying rack.
Timed
Dry Low 60
Stuffed toys or pillows
Cotton or polyester fiber filled
Timed
Dry Low 60
Stuffed toys or pillows
Foam rubber filled
Timed
Dry Air Only
(no heat)
90
Sneakers or canvas shoes Timed
Dry Air Only
(no heat)
90

19
DRYER CARE
Cleaning the Dryer Location
Keep dryer area clear and free from items that would obstruct the
flow of combustion and ventilation air.
Cleaning the Lint Screen
Every load cleaning
The lint screen is located in the door opening of the dryer. The
control panel has an indicator light to remind you to clean the lint
screen before each load. A screen blocked by lint can increase
drying time.
To clean
1. Pull the lint screen straight up. Roll lint off the screen with
your fingers. Do not rinse or wash screen to remove lint. Wet
lint is hard to remove.
2. Push the lint screen firmly back into place.
IMPORTANT:
■Do not run the dryer with the lint screen loose, damaged,
blocked, or missing. Doing so can cause overheating and
damage to both the dryer and fabrics.
■If lint falls off the screen into the dryer during removal, check
the exhaust hood and remove the lint. See “Venting
Requirements.”
As needed cleaning
Laundry detergent and fabric softener residue can build up on the
lint screen. This buildup can cause longer drying times for your
clothes, or cause the dryer to stop before your load is completely
dry. The screen is probably clogged if lint falls off while the screen
is in the dryer.
Clean the lint screen with a nylon brush every 6 months, or more
frequently, if it becomes clogged due to a residue buildup.
To wash
1. Roll lint off the screen with your fingers.
2. Wet both sides of lint screen with hot water.
3. Wet a nylon brush with hot water and liquid detergent. Scrub
lint screen with the brush to remove residue buildup.
4. Rinse screen with hot water.
5. Thoroughly dry lint screen with a clean towel. Replace screen
in dryer.
Cleaning the Dryer Interior
To clean dryer drum
1. Make a paste with powdered laundry detergent and very
warm water.
2. Apply paste to a soft cloth.
OR
Apply a liquid, nonflammable household cleaner to the
stained area and rub with a soft cloth until all excess dye and
stains are removed.
3. Wipe drum thoroughly with a damp cloth.
4. Tumble a load of clean cloths or towels to dry drum.
NOTE: Garments that contain unstable dyes, such as denim blue
jeans or brightly colored cotton items, may discolor the dryer
interior. These stains are not harmful to your dryer and will not
stain future loads of clothes. Dry unstable dye items inside out to
avoid transfer of dye.
Removing Accumulated Lint
From Inside the Dryer Cabinet
Lint should be removed every 2 years, or more often, depending
on dryer usage. Cleaning should be done by a qualified person.
From the Exhaust Vent
Lint should be removed every 2 years, or more often, depending
on dryer usage.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Place dryer at least 18 inches (46 cm) above the floor
for a garage installation.
Failure to do so can result in death, explosion, or fire.

20
Water Inlet Hoses
Replace inlet hoses and hose screen after 5 years of use to
reduce the risk of hose failure. Periodically inspect and replace
inlet hoses if bulges, kinks, cuts, wear or leaks are found.
When replacing your inlet hoses, record the date of replacement.
Vacation, Storage and Moving Care
Install and store your dryer where it will not freeze. Because some
water may stay in the hoses, freezing can damage your dryer. If
storing or moving your dryer during freezing weather, winterize it.
Non-Use or Vacation Care
Operate your dryer only when you are at home. If you will be on
vacation or not using your dryer for an extended period of time,
you should:
1. Unplug dryer or disconnect power.
2. Clean lint screen. See “Cleaning the Lint Screen.”
3. Turn off the water supply to the dryer. This helps to avoid
unintended flooding (due to a water pressure surge) while you
are away.
To winterize dryer
1. Unplug dryer or disconnect power.
2. Shut off water faucet.
3. Disconnect water inlet hose from faucet and drain.
To use dryer again
1. Flush water pipes. Reconnect water inlet hose to faucet. Turn
on water faucet.
2. Plug in dryer or reconnect power.
Moving care
1. Unplug the power supply cord.
2. Shut off water faucet.
3. Disconnect the water inlet hose from faucet, then drain the
hose. Transport hose separately.
4. Make sure leveling legs are secure in dryer base.
5. Use masking tape to secure dryer door.
Reinstalling the dryer
Follow the “Installation Instructions” to locate, level and connect
the dryer.
Changing the Drum Light
The dryer light automatically turns on inside the dryer drum when
you open the door.
To change the drum light
1. Unplug dryer or disconnect power.
2. Open the dryer door. Locate the light bulb cover on the back
wall of the dryer. Remove the screw located in the lower right
corner of the cover. Remove the cover.
3. Turn bulb counterclockwise. Replace the bulb with a 10-watt
appliance bulb only. Replace the cover and secure with the
screw.
4. Plug in dryer or reconnect power.
