1 386367 Panel, Rear Console
2 343641 Screw, 10-16 x 1/2
3 355326 Screw, 13-16 x 5/8
4 63790 Cap, End (L.H.)
5 358472 Stop, Push-In
6 64211 Screw, 8-18
7 696098 Wire, Jumper
8 63796 Cap, End (R.H.)
9 61806 Resistor, Timer
10 339392 Screen, Lint
11 Cover, Lint Screen
688150 White
689310 Almond
689313 Golden Harvest
695022 Toast
695023 Platinum
12 339229 Hinge, R.H.
339230 Hinge, L.H.
13 688983 Screw, 8-18 x 5/8
16 Top
695507 White
695508 Almond
695509 Golden Harvest
695510 Toast
695511 Platinum
18 386635 Control Knob, Temperature
21 696881 Timer & Resistor, 60 Hz.
30 358473 Nut, Push-In (2)
31 3388066 Harness, Wiring
39 660936 Switch, Push-To-Start
346364 (Alt.)
692021 (Alt.)
48 3387900 Timer Knob Assembly
53 386627 Bracket, Control
54 3387986 Panel, Control
62 688805 Clip
67 689559 Clip, Push-On (4)
72 690853 Wire, Ground
79 694720 Switch, Temperature
81 3387894 Knob, Push To Start
LITERATURE PARTS
LIT693849 Guide, Dryer
LIT3390215 Use & Care Guide
LIT3389444 Instructions, Installation
LIT693849 Guide, Dryer
LIT3390359 List, Service Parts
OPTIONAL PARTS NOT INCLUDED
PAINTS
PAINT,TOUCH UP (1/2 oz.)
72017 White
72107 Almond
72110 Golden Harvest
72112 Toast
72113 Platinum
PAINT PRESSURIZED SPRAY (13 oz.)
350930 White
350956 Almond
261890 Golden Harvest
285365 Toast
285366 Platinum
350938 Primer, Gray
350941 Leveler (Thinner)
PAINT,BULK (1 qt.)
799344 White (Uncut)
978883 Almond (Uncut)
261891 Golden Harvest (Uncut)
285367 Toast (Uncut)
285368 Platinum (Uncut)
Following May Be Purchased: DO-IT-YOURSELF-REPAIR-MANUALS
LITERATURE PARTS
LIT677813 Automatic Washer (Belt Drive)
LIT677818 Dryer
LIT677821 Compactor
LIT677967 Dishwasher
LIT677971 Ice Maker (In Refrigerator)
1 690236 Wire, Ground (Motor)
2 9416643 Screw, 10-16 x 1/2
5 690893 Cover, Terminal Block
6 694091 Screw
7 346368 Panel, Rear
10 347207 Switch, Door
11 98129 Screw, 6-20 x 1-3/8 (2)
12 295998 Lever, Door Switch
13 693994 Screw, Rear Panel Mounting
16 688222 Foot, Dryer (4)
18 Cabinet
690847 White
690848 Almond
690851 Golden Harvest
694874 Toast
694875 Platinum
19 98234 Clip, Ground
20 690363 Lock, Front Top (2)
21 Upper Front Panel Assembly
693197 White
693198 Almond
693201 Golden Harvest
695259 Toast
695260 Platinum
23 685203 Clip, Felt Pad
24 3389441 Catch, Door
28 348023 Hinge and Pin Assembly (2)
29 237823 Clip, Front Panel (2)
31 98997 Clip, Harness
33 696144 Strike, Door
35 695656 Door, Rear
36 Door Front
348205 White
689314 Almond
689319 Golden Harvest
695214 Toast
695215 Platinum
37 Handle, Door
686711 White
689308 Almond
689586 Golden Harvest
695283 Toast
695284 Platinum
38 349462 Seal & Bearing Assembly
40 279393 Terminal Block Kit For Terminal Block
41 690261 Block, Terminal
51 238088 Hinge, Top (2)
53 691366 Idler & Pulley Assembly
56 660996 Belt, Drive
57 348780 Base, Motor
58 172455 Bolt, 5/16-18 x 3/4
59 694871 Pulley, 60 Hz.
61 337351 Switch (Use W/695075 Motor)
349588 Switch (Use W/689788 Motor)
62 695075 Motor Assembly 60 Hz.
63 660658 Clamp, Motor
343481 (Alt.)
685441 (Alt.)
67 685763 Seal, Door
87 690989 Screw, 10-32 x 1/2 (External Ground)
88 693995 Screw, 10-16 x 1/2
89 688412 Clip, Retainer
90 279318 Terminal, Tinned & Brass (3) (Includes Illus. 40)
1 694283 Lint Chute Assembly
2 686770 Support Protector
3 98460 Nut, Push-In (2)
5 90767 Screw,8x3/8
6 3389946 Thermal, Cut-Off (Hi-Limit Thermostat Illus. No.15 Included)
8 3388703 Washer, Support
10 695499 Wheel, Blower
11 695081 Housing, Blower
12 337272 Clip
13 343641 Screw, 10-16 x 1/2
14 695547 Box, Heater
15 696397 Thermostat, High Limit 250~F (121.1~C) (60 Hz.)
17 660982 Element, Heater (For 240 Volt Installation)
693300 (Alt.)
696579 (Alt.)
693062 (Alt.)
696326 Element, Heater (For 208 Volt Installation)
21 279457 Wire Kit (For Heater Element Wiring Harness Repair)
22 694630 Seal, Blower
23 694511 Fuse, Thermal
24 660039 Thermostat, Operating (150~F)(65.6~C)
341146 (Alt.)
25 61894 Heater, Thermostat
26 695239 Screw, 8-18 x 3/8
27 695240 Screw, 8-18 x 1/2
41 690997 Ring, Tri
42 347364 Shaft, L.H.
43 339489 Shaft, R.H.
44 349241 Roller, Support
46 348197 Washer, Support
47 120377 Nut, 3/8-16
48 685775 Bulkhead
62 297936 Ring, Bearing
63 690372 Screw, 11-16 x 7/8
66 337449 Seal, Rear Drum
67 695584 Drum Assembly
68 342847 Baffle, Drum
69 348945 Bracket, Support
70 90296 Clip
73 339956 Seal
74 687128 Screw, 10-16 x 1/2
75 696302 Shield, Exhaust
