Whirlpool SF315PEG User manual

TO THE INSTALLER: PLEASE LEAVE THIS INSTRUCTION
BOOK WITH THE UNIT.
TO THE CONSUMER: PLEASE READ AND KEEP THIS
BOOK FOR FUTURE REFERENCE.
4.65 Cubic Foot Oven
MODEL SF315PEG
8053372
Standard-Cleaning
Gas Range
A Note to You ............2
Range Safety .............3
Parts and Features....5
Using Your Range......6
Caring for Your
Range.......................20
Troubleshooting.......27
Requesting
Assistance or
Service .....................29
Index ........................31
Warranty...................32
1-800-253-1301
Call our Consumer Assistance Center
with questions or comments.

2
1-800-253-1301
Our Consumer Assistance Center number is toll free.
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
– Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone. Follow the gas
supplier’s instructions.
•If you cannot reach your gas supplier, call the fire department.
– Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
A NOTE TO YOU
Thank you for buying a WHIRLPOOL®appliance.
The Whirlpool Brand is committed to designing quality products that consistently perform for you to make your
life easier. To ensure that you enjoy years of trouble-free operation, we developed this Use and Care Guide.
It is full of valuable information about how to operate and maintain your appliance properly and safely. Please
read it carefully.
Also, please complete and mail the Product Registration Card provided with your appliance. The card helps us
notify you about any new information on your appliance.
Please record your model’s information.
Whenever you call to request service for your appliance,
you need to know your complete model number and
serial number. You can find this information on the
model and serial number label/plate (see diagram in
the “Parts and Features” section).
Please also record the purchase date of your appliance
and your dealer’s name, address, and telephone number.
Keep this book and the sales slip together in a safe place for future reference. It is important
for you to save your sales receipt showing the date of purchase. Proof of purchase will assure
you of in-warranty service.
Model Number
Serial Number
Purchase Date
Dealer Name
Dealer Address
Dealer Phone

3
RANGE SAFETY
continued on next page
You will be killed or seriously injured if you don’t
follow instructions.
You can be killed or seriously injured if you don’t
follow instructions.
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word “DANGER” or
“WARNING.” These words mean:
wDANGER
wWARNING
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
wWARNING
Tip Over Hazard
A child or adult can tip the range and be killed.
Connect anti-tip bracket to rear range foot.
Reconnect the anti-tip bracket, if the range is moved.
See the installation instructions for details.
Failure to follow these instructions can result in death or serious burns
to children and adults.
Making sure the anti-tip bracket is installed:
•Slide range forward.
•Look for the anti-tip bracket securely attached to floor.
•Slide range back so rear range foot is under anti-tip bracket.
Anti-Tip Bracket
Range Foot

4
RANGE SAFETY
– SAVE THESE INSTRUCTIONS –
WARNING: To reduce the risk of fire, electrical
shock, injury to persons, or damage when using the
range, follow basic precautions, including the
following:
•WARNING – TO REDUCE THE RISK OF
TIPPING OF THE RANGE, THE RANGE MUST
BE SECURED BY PROPERLY INSTALLED
ANTI-TIP DEVICES. TO CHECK IF THE DEVICES
ARE INSTALLED PROPERLY, SLIDE RANGE
FORWARD, LOOK FOR ANTI-TIP BRACKET
SECURELY ATTACHED TO FLOOR, AND SLIDE
RANGE BACK SO REAR RANGE FOOT IS
UNDER ANTI-TIP BRACKET.
•CAUTION – Do not store items of interest to
children in cabinets above a range or on the
backguard of a range – children climbing on the
range to reach items could be seriously injured.
•Proper Installation – The range, when installed,
must be electrically grounded in accordance with
local codes or, in the absence of local codes, with
the National Electrical Code, ANSI/NFPA 70. Be
sure the range is properly installed and grounded
by a qualified technician.
•This range is equipped with a three-prong
grounding plug for your protection against shock
hazard and should be plugged directly into a
properly grounded receptacle. Do not cut or
remove the grounding prong from this plug.
IMPORTANT SAFETY INSTRUCTIONS
•Disconnect the electrical supply before
servicing the appliance.
•Never Use the Range for Warming or Heating
the Room.
•Injuries may result from the misuse of appliance
doors or drawers such as stepping, leaning, or
sitting on the doors or drawers.
•Maintenance – Keep range area clear and free from
combustible materials, gasoline, and other
flammable vapors and liquids.
•Storage in or on the Range – Flammable
materials should not be stored in an oven or
near surface units.
•Top burner flame size should be adjusted so it
does not extend beyond the edge of the
cooking utensil.
For self-cleaning ranges –
•Before Self-Cleaning the Oven – Remove broiler
pan and other utensils. Wipe off all excessive
spillage before initiating the cleaning cycle.

PARTS AND FEATURES
5
Surface burner marker
(shows which burner
you are setting)
Right front
control knob
Right rear
control knob
Left front
control knob
(POWER™Burner)
Left rear
control knob
ON
Manual oven
light switch
(p. 26)
Electronic
oven control
(pp. 10-18)
Control panel
(pp. 5, 20)
Automatic oven
light switch
(p. 26)
Gasket
(p. 21)
Oven vent
(p. 18)
Surface burners
and grates
(pp. 6, 20, 22, 23)
Anti-tip bracket
(pp. 3, 19)
Door stop clip
(pp. 23-25)
Model and
serial number
plate
(behind left side
of broiler door)
Broiler door
(p. 16)
CONTROL PANEL

6
USING YOUR RANGE
USING THE SURFACE BURNERS
NOTE: Do not leave empty cookware, or cookware
which has boiled dry, on a hot surface burner. The
cookware could overheat, causing damage to the
cookware or cooking product.
Using POWER Burner
POWER Burner is an adjustable setting for the left
front burner which provides an ultra-high heat setting.
It can be used to rapidly bring liquid to a boil and to
cook large quantities of food.
Easy ways to save energy
•To help shorten your cooking time, use the least
amount of liquid possible.
•Preheat your pots and pans only when
recommended and for the shortest time possible.
•Start your food on a higher heat setting, then turn
the control to a lower setting to finish cooking.
wWARNING
Fire Hazard
Do not let the burner flame extend beyond
the edge of the pan.
Turn off all controls when not cooking.
Failure to follow these instructions can
result in death or fire.
RECOMMENDED USE
•To light the burner.
•To provide highest heat
setting.
•To start food cooking.
•To bring liquid to a boil.
•To hold a boil.
•To fry chicken or pancakes.
•For gravy, pudding, and icing.
•To cook large amounts of
vegetables.
•To keep food warm.
•To melt chocolate or butter.
•To simmer.
SETTING
LIGHT
POWER™Burner
(left front burner)
HIGH
Mid-range
(between HIGH
and LOW)
LOW
Burner heat settings
Use the following chart as a guide.
Using the control knobs
Your range comes with electric ignitors. Electric
ignitors automatically light the burners each time
you turn the control knobs to LIGHT.
•Place a filled pan on the burner grate before
turning on the surface burner. Do not operate a
burner for extended periods of time without
having cookware on the grate.
•Push in the control knob and turn it counter-
clockwise to the
LIGHT position. The
clicking sound is the
ignitor sparking. Make
sure the burner has lit.
•To stop the clicking
sound after the burner
lights, turn the control
knob to the cook setting
you want. You can set
the control knob
anywhere between HIGH and LOW.
NOTE: All four electric ignitors will click at the same
time. However, the burner with the control knob
turned to LIGHT is the one that will ignite.

7
USING YOUR RANGE
USING THE SURFACE BURNERS (CONT.)
In case of a prolonged power failure
You can manually light surface burners. Hold a lit
match near a burner and turn the control knob to
the LIGHT position. After the burner lights, turn the
control knob to the setting you want.
Home canning information
The large diameter of most water-bath or pressure
canners combined with high heat settings for long
periods of time can cause damage to the cooktop.
To protect your range:
•Center the canner over the surface burner. Do
not extend more than 1 inch outside the burner
area.
•Do not place your canner on two surface burners
at the same time.
•Start with hot water, cover with a lid and bring to
a boil; then reduce heat to maintain a boil or
required pressure levels in a pressure canner.
•
Refer to your canner manual for specific
instructions.
For up-to-date information on canning, contact your
local U.S. Government Agricultural Department
Extension Office or companies who manufacture
home canning products.
Using the right cookware makes a
big difference
•The pan should have a flat bottom, straight sides,
and a well-fitting lid.
•Choose medium to heavy gauge (thickness)
cookware.
•The pan material (metal or glass) affects how
quickly and evenly the pan heats.
•When using glass or ceramic cookware, check to
make sure it is suitable for use on surface burners.
•To avoid tipping, make sure pots and pans are
centered on the grates.
CHARACTERISTICS OF COOKWARE MATERIALS
The pan material affects how fast heat transfers from the surface cooking area through the pan material and how
evenly heat spreads over the pan bottom. Choose pans that provide the best cooking results.
Aluminum • Heats quickly and evenly.
• Use for all types of cooking.
• Medium or heavy thickness is best for most cooking.
• Used as a core or base in cookware to provide even heating.
Cast iron • Heats slowly and evenly.
• Good for browning and frying.
• Maintains heat for slow cooking.
• Can be coated with porcelain enamel.
Ceramic or
ceramic glass • Heats slowly and unevenly.
• Use on low to medium settings.
• Follow manufacturer’s instructions.
Copper • Heats very quickly and evenly.
• Used as a core or base in cookware to provide even heating.
Earthenware • Can be used for cooktop cooking if recommended by the
manufacturer.
• Use on low settings.
Porcelain enamel-on-steel or
enamel-on-cast iron • See cast iron and stainless steel.
Stainless steel • Heats quickly but unevenly.
•
A core or base of aluminum or copper on the cookware provides
even heating.
•Can be coated with porcelain enamel.

Positioning racks and pans
Place the oven racks where you need them before
turning on the oven.
•To move a rack, pull it out to the stop position,
raise the front edge and lift it out.
•Be sure the rack(s) is level.
•Use pot holders or oven mitts to protect your hands
if rack(s) must be moved while the oven is hot.
•For best performance, cook on one rack. Place
the rack so the top of the food will be centered in
the oven.
•When cooking with two racks, arrange the racks
on the 2nd and 4th rack guides. Two sheets of
cookies may be baked if sheets are switched at
approximately three quarters of the total bake time.
Increase baking time, if necessary.
•For best results allow 2 inches of space around
each pan and between pans and oven walls.
Extra oven rack position (roasting rack)
Use this rack position when roasting food too large
to be placed on the first
rack position.
For proper roasting,
follow these guidelines:
•To avoid spillage,
remove food before
pulling out the rack.
•Tilt the rack up at the
front before pulling it over
the door.
•Use an adequate amount of liquid in the pan (meat
juices or water) so your food does not get overdone.
8
USING YOUR RANGE
USING THE OVEN
USING ALUMINUM FOIL
Extra oven rack position
Where to place pans:
WHEN YOU HAVE
1 pan
2 pans
3 or 4 pans
PLACE
In center of the oven rack.
Side by side or slightly
staggered.
In opposite corners on
each oven rack. Stagger
pans so no pan is directly
over another.
NOTE: Do not line the oven bottom with foil or other
liners. It could affect the
oven surface as well as
the quality of your baking.
•Do not cover the entire
rack with aluminum foil.
It will reduce air circula-
tion and give you poor
cooking results.
•Use aluminum foil to catch spillovers from pies or
casseroles by placing foil on the oven rack below.
Foil should be turned up at edges and be at least 1
inch larger than dish.
•Place tent-shaped foil loosely over meat or poultry
to slow down surface browning for long term
roasting. Remove foil for the last 30 minutes.
•Use narrow strips of foil to shield piecrust edges if
browning too quickly.
Rack placement for specific foods:
FOOD
Frozen pies, large
roasts, turkeys, angel
food cakes
Bundt cakes, most
quick breads, yeast
breads, casseroles,
meats
Cookies, biscuits,
muffins, cakes,
nonfrozen pies
RACK POSITION
1st or 2nd rack
guide from bottom
2nd rack guide
from bottom
2nd or 3rd rack
guide from bottom
NOTE: For information on where to place your rack
when broiling, see “Broiling guidelines” later in this
section.

9
BAKEWARE CHOICES
Baking performance is affected by the type of bakeware used. Use the bakeware size recommended in the recipe.
BAKEWARE TYPE
Light colored aluminum • Light golden crusts
• Even browning • Use temperature and time recommended
in recipe.
Dark aluminum and other
bakeware with dark, dull,
and/or non-stick finish
• Brown, crisp crusts • May reduce baking temperature 25°F.
• Use suggested baking time.
• Use temperature and time recommended in recipe
for pies, breads, and casseroles.
• Place rack in center of oven.
Ovenproof glassware,
ceramic glass, or ceramic • Brown, crisp crusts • May reduce baking temperature 25°F.
Insulated cookie sheets or
baking pans • Little or no bottom browning • Place in the bottom third of oven. • May need to increase baking time.
Stainless steel • May need to increase baking time.
• Crisp crustsStoneware • Follow manufacturer's instructions.
• Light, golden crusts
• Uneven browning
BEST USED FOR GUIDELINES
USING YOUR RANGE

10
USING YOUR RANGE
THE ELECTRONIC OVEN CONTROL
Display/clock
•When you first plug in the range, “PF” will
appear on the display until you press any
command pad. If “PF” again appears on the
display, your electricity was off for a while.
•When you are using the oven, the display will
show preheat times and temperature settings.
•When you are not using the oven, the display will
show the time of day.
•When showing the time of day, the display will
show the hours and minutes.
•When you are using the minute timer, the display
will count down each minute.
•When setting a function, if you do not press
START/ENTER within 5 seconds, the Start?
indicator light will flash. If you do not press
START/ENTER within 5 minutes, the function
will be canceled.
Indicator lights
An indicator light to the left of the display lights up
when you are in a setting. An indicator light on the
display lights up when the oven is on.
Bake pad
(pp. 13, 15)
Using the control lock
The control lock lets you disable the control panel
command pads. The control lock comes in handy
when you want to prevent others from using
the oven.
NOTES:
•You can only use the control lock when the oven
is not in use or the control has not been set.
•Set the control lock when cleaning the control
panel to prevent yourself from accidentally turning
on the oven.
To lock the control panel:
Press and hold START/ENTER for 5 seconds.
You will hear a single tone and “Loc” will
appear on the temperature display for
5 seconds. “Loc” will then appear when-
ever a command pad is pressed.
To unlock the control panel:
Press and hold START/ENTER for 5 seconds.
You will hear a single tone and “Loc” will
disappear from the temperature display.
START
5 SEC
ENTER
START
5 SEC
ENTER
Temperature/
time pad
(pp. 11, 13,
15, 17)
Custom broil
pad
(p. 17)
Clock/timer pad
(pp. 11, 12)
Electronic
display
Start/enter pad
(pp. 10, 11, 12,
14, 15, 17)
Off/cancel pad
(pp. 12, 14, 17)
Indicator
lights
(see below)

11
SETTING THE CLOCK
USING YOUR RANGE
1. Press CLOCK.
2. Set the time.
Press the “up” (s) or “down” (t) pad(s) until
the correct time shows on the display.
3. Start the clock.
NOTES:
•To see the time of day when the clock time is
not on the display, press CLOCK.
•You must reset the clock if the power goes off
for more than 1 second.
USING THE ELECTRONIC MINUTE TIMER
The minute timer does not start or stop the oven.
It works like a kitchen timer. It can be set in hours
and minutes up to 12 hours, 59 minutes. The
minute timer will display minutes
and seconds for settings under 1 hour.
1. Press TIMER.
The timer indicator light will light up.
2. Set the interval to be timed.
Press the “up” (s) or “down” (t) pad(s) until
the correct time shows on the display.
CLOCK
PRESS YOU SEE
TIME
(example for 5:30)
START
5 SEC
ENTER
OR
CLOCK
PRESS YOU SEE
PRESS YOU SEE
TIMER
• • CANCEL
PRESS YOU SEE
TIME
(example for 10 minutes)
PRESS YOU SEE
continued on next page

12
USING YOUR RANGE
3. Start the minute timer.
The minute timer will begin counting down
immediately after the timer is started.
When the time is up:
You will hear four 1-second tones.
NOTE: To display the time of day while the
minute timer is counting down, press CLOCK.
4. To clear the display, turn off the minute timer.
To cancel the minute timer during
the countdown:
USING THE ELECTRONIC MINUTE TIMER (CONT.)
START
5 SEC
ENTER
(display counts down)
YOU SEE
PRESS YOU SEE
PRESS YOU SEE
PRESS YOU SEE
(twice)
TIMER
• • CANCEL
TIMER
• • CANCEL
STARTING/CANCELING A FUNCTION
After setting a function for the first time, you
must press START/ENTER to start
the function.
OFF/CANCEL will cancel any function except for the
clock, minute timer, or control lock.
START
5 SEC
ENTER
OFF
CANCEL
(time of day)
(time of day)

IMPORTANT: Do not try to light the oven burner
during a power failure.
1. Place the racks where you need them. For
more information, see
“Positioning racks and
pans” in “Using the
Oven” earlier in this
section.
NOTE: Do not place
food directly on the
oven door or the oven
bottom.
2. Choose the bake setting.
The bake indicator light will light up.
3. Set the temperature (optional).
Do this step if you want to set a
temperature other than 350°F. Press ▲
to raise the temperature or ▼to lower the tem-
perature in 5°F amounts. You can set a tempera-
ture anywhere from 170˚F to 500˚F. Use these
pads until the desired temperature shows on the
display.
4. When roasting, put your food in the oven.
You do not have to
preheat the oven when
roasting, unless your
recipe recommends it.
ON
13
BAKING/ROASTING
Rear
Front
PRESS YOU SEE
BAKE
PRESS YOU SEE
(example for bake at 375°F)
Roasting meats and poultry
•For even cooking, place the meat on a rack in a
shallow pan. This keeps the meat out of the
drippings and allows the heat to circulate better.
•Use a meat thermometer for the most accurate
doneness. Insert it so the tip is in the center of
the largest muscle or thickest portion of the
meat or poultry. Make sure the thermometer is
not touching bone, fat, or the bottom of the pan.
USING YOUR RANGE
TIME
ON
continued on next page

6. When baking, put your food in the oven after
the preheat condi-
tioning time ends.
During baking/
roasting, the oven
burner will turn
on and off to keep the
oven temperature at
the setting.
7. After cooking, turn off the oven.
ON
14
USING YOUR RANGE
PRESS YOU SEE
OFF
CANCEL
(time of day or minute timer
countdown)
5. Press START/ENTER.
A preheat conditioning time counts down
the approximate preheat time after the oven
temperature has been set and START has been
pressed. The heat, bake, and on indicator lights
will light up. The oven control automatically sets
preheating times based on the oven
temperature you select:
•For 245°F and less, the preheating time is
4 minutes.
•For 250°F-445°F, the preheating time is
10 minutes.
•For above 450°F, the preheating time is
15 minutes.
The oven is preheated and ready to use when
you hear a 1-second tone, the countdown is
finished, and the set temperature is displayed.
The preheat and set temperatures may be
different at the end of the countdown. This is
normal.
NOTES:
•When the oven temperature is greater than
170°F, no preheat conditioning time will be
shown in the display.
•You can change the temperature setting any
time after pressing START/ENTER. You do not
have to press START/ENTER again.
START
5 SEC
ENTER
(example for set temperature
of 325°F)
PRESS YOU SEE
BAKING/ROASTING (CONT.)
•The preheat conditioning time will not change
if you reset the temperature before the count-
down time ends.
•If you are baking/roasting while the minute
timer is counting down, you can see the set
baking/roasting temperature for 5 seconds
by pressing BAKE.
Saving energy
•To avoid loss of heat, open the oven door as little
as possible.
•Use a timer to keep track of cooking time.
•Plan your meals for the most efficient use of the
oven by cooking more than one food at a time, or
baking while the oven is still hot after cooking a
meal.
YOU SEE
ON

ON
ON
15
USING YOUR RANGE
Although your new oven is properly adjusted to
provide accurate temperatures, it may cook faster
or slower than your old oven.
If you are not satisfied with the baking/roasting
results, you can change the offset temperature by
following the steps below.
NOTE: DO NOT measure the oven temperature with
a thermometer. Opening the oven door will lower
the oven temperature and give you an incorrect
reading. Also, the thermometer temperature reading
will change as your oven cycles.
1. Press and hold BAKE for 5 seconds.
The display will show the current offset tempera-
ture, for example “00,” if you have not already
adjusted the temperature.
2. Set the new offset temperature.
Press ▲to raise the temperature or ▼to lower
the temperature in 10°F amounts. You can set
the temperature change to as low as -30°F or as
high as +30°F. A minus (-) sign will appear before
the number when decreasing the temperature
setting. The minus sign shows the oven will be
cooler by the displayed amount. There is no sign
in front of the number when increasing the
temperature setting.
3. Enter the adjustment.
NOTE: The oven control will stay adjusted even
after a power failure.
How to determine the amount of
adjustment needed
The chart at the right tells you how much to adjust
the offset temperature to get the cooking results
you want. You can figure out cooking results by the
amount of browning, moistness, and rising times for
baked foods.
ADJUSTING THE OVEN TEMPERATURE CONTROL
PRESS YOU SEE
BAKE
(factory setting of “00”)
PRESS YOU SEE
PRESS YOU SEE
START
5 SEC
ENTER
(time of day or minute timer
countdown)
TO COOK
FOOD ...
A little more
Moderately more
Much more
A little less
Moderately less
Much less
ADJUST BY
THIS NUMBER
OF DEGREES
(FAHRENHEIT)
+10
+20
+30
-10
-20
-30
TIME
(example when making
oven 10°F cooler)

16
USING YOUR RANGE
The broiler is located below the oven door. The
broiler pan and grid roll out for easy access.
Always broil with the broiler and oven doors
closed.
NOTES:
•Do not step on or apply weight to the broiler
door when it is open. This could damage the
door.
•Do not preheat the broiler before using it.
Completely close the broiler door during
broiling.
1. Open the broiler door and roll out the broiler
pan and grid.
2. Place the broiler pan and grid so grease can
drain down into the
lower part of the
broiler pan.
3. Before the broiler is turned on, place your food
on the broiler pan. Then
place the pan on the
broiler bottom (Position
0) or one of the two other
positions and roll the
broiler pan grid into the
broiler.
4. Close the broiler door.
Position 2
Position 0
Position 1
Broiler pan and grid
BROILING

17
BROILING (CONT.)
USING YOUR RANGE
5. Press CUSTOM BROIL.
The broil indicator light will light up.
6. Start the oven.
The on and heat indicator lights will light up.
NOTES:
•You can change the temperature setting any
time after pressing START/ENTER. To change
the setting, see “To custom broil at a lower
temperature” below.
•If you are broiling while the minute timer is
counting down, you can see the set broiling
temperature for 5 seconds by pressing
CUSTOM BROIL.
7. After broiling, turn off the oven.
To custom broil at a lower temperature:
•If food is cooking too fast, press the t
temp pad until “325°F” shows on the display.
•If you want food to broil slower from the start,
press CUSTOM BROIL and press the ttemp
pad so a temperature between 300°F and 525°F
shows on the display. Press START/ENTER.
Lower temperature settings let the broil burner
cycle and slow cooking results. The lower the
temperature, the slower the cooking.
NOTE: Thicker cuts and unevenly shaped pieces
of meat, fish, and poultry may cook better if you use
lower broiling temperatures.
CUSTOM
BROIL
PRESS YOU SEE
PRESS YOU SEE
START
5 SEC
ENTER
ON
ON
PRESS YOU SEE
OFF
CANCEL
TIME
ON
(example shows broil at 325°F)
TIME
START
5 SEC
ENTER
CUSTOM
BROIL
ON
(example shows broil at 400°F)
PRESS YOU SEE
PRESS YOU SEE
(time of day)
ON
continued on next page

18
Broiling guidelines
Recommended pan positions are numbered from bottom (0) to top (2) (see “Broiler pan and grid” earlier in
this section). For best results, place food 3 inches or more from the broil burner. You should rotate the
broiler pan back to the front at the same time you turn the foods.
BROILING (CONT.)
MEAT
Steak, 1" thick
medium-rare
medium
well-done
Ground Meat Patties, 3⁄4" thick, well-done
Pork Chops, 1" thick
Ham Slice, 1⁄2" thick-precooked
Frankfurters
Chicken
bone-in pieces
boneless breasts
Fish, 1⁄2-3⁄4" thick fillets
SIDE 2
5-6
6-7
8-9
6-7
9-10
3-4
2-3
15-17
11-13
3-4
SIDE 1
10-12
12-14
16-17
11-13
19-21
6-8
5-6
15-
17
11-
PAN
POSITION
1
1
0
1
1
0
1
1
APPROXIMATE TIME
(MINUTES)
Times are guidelines only and may need to be adjusted to individual tastes.
Hot air and moisture escape from the oven through
a vent that is near the middle of the backguard.
The vent lets air circulate properly. Be careful not to
block the vent, or you will get poor baking/roasting
results.
NOTE: Never store plastics, paper, or other items
that could melt or burn near the oven vent, or any
of the surface burners.
THE OVEN VENT
USING YOUR RANGE
ONON
Oven vent

19
USING YOUR RANGE
Making sure the anti-tip bracket is installed:
•Slide range forward.
•Look for the anti-tip bracket securely attached to floor.
•Slide range back so rear range foot is under anti-tip bracket.
THE ANTI-TIP BRACKET
The range will not tip during normal use. However, the range can tip if you apply too much force or weight
to the open door without the anti-tip bracket fastened down properly.
wWARNING
Tip Over Hazard
A child or adult can tip the range and be killed.
Connect anti-tip bracket to rear range foot.
Reconnect the anti-tip bracket, if the range is moved.
See the installation instructions for details.
Failure to follow these instructions can result in death or serious burns
to children and adults.
Anti-Tip Bracket
Range Foot

20
CARING FOR YOUR RANGE
wWARNING
Explosion Hazard
Do not store flammable materials such as gasoline near this appliance.
Doing so can result in death, explosion, or fire.
CLEANING CHART
Before cleaning, always make sure all controls are off and the range is cool. Refer to instructions on all
cleaning products before using them to clean your range.
PART CLEANING METHOD SPECIAL INSTRUCTIONS
Control Knobs •Soap and water
•Dishwasher •DO NOT use steel wool or
abrasive cleaners.
•Pull knobs straight away from
control panel.
•Wash, rinse and dry with soft
cloth.
Control Panel •Soap and water •Wash, rinse and dry with soft
cloth.
Exterior Surfaces*
(excluding control panel and
oven door glass)
•Soap and water
•Mild liquid cleaner
•Spray glass cleaner
•DO NOT use abrasive or harsh
cleaners like chlorine bleach,
ammonia or oven cleaners.
•Wash, rinse and dry with soft
cloth.
•Spray glass cleaner •Apply spray cleaner to paper
towel; do not spray directly on
panel.
•Gently clean around the model
and serial plate, too much
scrubbing could remove the
numbers.
•Non-abrasive plastic scrubbing pad
Surface burner grates and caps*
•Light to moderate soil •Soap and water
•Non-abrasive plastic scrubbing pad •Clean as soon as they become
dirty.
•Wash, rinse and dry well.
•Repeat steps of cleaning process
(with items at left) as needed,
until soil is completely removed.
•Rinse thoroughly and dry.
•NOTE: Do not reassemble caps
on burners while wet.
•Non-abrasive plastic scrubbing pad
•Mild abrasive powdered cleanser
and water
•Heavy burned on soils
•Grates only (not caps).
•Dishwasher
•NOTE: To avoid product
damage, do not remove the
cooktop.
*When the cooktop is cool, remove all spills and clean. Food spills containing acids, such as vinegar and tomato,
may affect the finish.
