Whirlpool ACCESS AWM 8900-ROK User manual

SERVICE Whirlpool Europe
Customer Services
Model AWM 8900-ROK
Version 8570 082 74000 Page
Technical data 2 - 4
Spare part list 5 - 6
Exploded view 7 - 8
Wiring diagram 9
Circuit diagram 10
Program chart 11 - 17
Text/Legend 18 - 20
Family OMEGA
Access EU
9 kg
Service Manual
Washing machine
ACCESS
AWM 8900-ROK
AWM 8900-ROK
This documentation is only intended for qualified technicians who are aware of the respec-
tive safety regulations.
Date: 16.04.2007 Subject to modification
Document-No.: 4812 722 27545

SERVICE
16.04.2007 / Page 2 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Technical data
Dimensions
Height 96.5 cm
Width 68.6 cm
Depth 78.5 cm
Weight
Net 113 kg
Main connection
Voltage 230 V
Frequency 60 Hz
Power consumption 2.2 kW
Fuse rating 10 A
Drum
Volume 92 l
Wash spin 35/40 rpm
Ramp spin 100 rpm
Speed spinning max. 1200 rpm
Capacity of dry laundry
Capacity of dry laundry
Cotton/coloured laundry 9.0 kg
Synthetics 4.0 kg
Daily load 40˚C 4.0 kg
Quick Wash 30˚C 4.0 kg
Delicate 2.5 kg
Handwash 2.0 kg
Wool 2.0 kg
Big Items 2.5 kg
Gentle Spin 4.0 kg
Spin 9.0 kg
Rinse & Spin 9.0 kg
Pressostat for washing-machine
Level1
Switching point 55 ± 5 mmWc
Reset 35 ±5 mmWc
Overflow
Switching point 280 ±20 mmWc
Water column drum
(measured inside of the drum, rear position)
Level1
Switching point 39 - 50 mm
Overflow
Switching point 235 - 300 mm
Nominal current
Contacts:
11 - 12 ~3 mA 24 V DC
11 - 14 ~3 mA 24 V DC
11 - 16 ~3 mA 24 V DC
Contactsystem:
11 - 12 - 14 jump contacts
11 - 16 slow action contacts
Damping system no
Door lock
Nominal current:
contacts
4 - 5 16 A 230 V
6 - 7 16 A 230 V
8 - 9 0.1 A 230 V
Coil 1 - 2 and 2 - 3:
Nominal voltage 230 V
Frequency 45 - 65 Hz
Resistance 1 - 2 (lock) 133 Ω±10%
Resistance 2 - 3 (unlock) 140 Ω±10%
Locking time 40 ±10 ms
Unlocking time 1 s
(max.6 cyles)
Heating element
Kind of heating Tubular heating element
with NTC- Sensor
Nominal voltage 230 V
Nominal power 2050 W
Heat conductor
resistance R25 22 - 28 Ω
Resistance NTC:
0 ˚C 35.9 kΩ
30 ˚C 9.8 kΩ
40 ˚C 6.6 kΩ
50 ˚C 4.6 kΩ
60 ˚C 3.2 kΩ
70 ˚C 2.3 kΩ
95 ˚C 1.1 kΩ

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 3
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Technical data
Inlet valve cold fill
Water temperature max. 60 ˚C
Rated flow >1 bar 8 l/min
Pressure range 0.5 - 10 bar
Nominal voltage 220/240 V
Frequency 50 Hz
Starting voltage
<6 bar 160 V
6 - 10 bar 170 V
Nominal current 35 mA
Nominal power 6 VA
Nominal resistor (20 ˚C) 3.4 - 4.5 kΩ
Floater
Nominal current 5 V DC
Nominal power ~1 mA
Switch energy <15 cN
Drain pump (synchronous)
Nominal voltage 220 +10%, -15% V
Nominal current 0.46 A
Nominal consumption 50 W
Frequency 60 ±3Hz
Resistor (coil) 40.5 Ω±8%
Motor protection yes
Capacity (1.25m height) 31 ±2 l/min
Flowmeter
Nominal voltage 5 V
Nominal current:
nominal 1 mA
maximal 20 mA
Pressure area 0.5 - 10 bar
Line to be recognized 195 - 215 pulse/l
Frequency signal 3.25 - 36 Hz
Distribution actuator
Motor:
Nominal voltage 230 +10%, -15% V
Nominal current 13 mA
Nominal resistance (20 ˚C) 6.5 kΩ±10%
Contacts:
Nominal current 1 mA
Nominal voltage 24 V
Electronic complete
Basic 4619 702 17332
Programmed 4619 702 17401
Nominal voltage 220 V
Frequency 60 Hz
Detergent Dispenser 3 Chambers
Programmes 12
Cold fill yes
Flowmeter yes
Speed 1200 rpm
Ambient temperature up to 70 ˚C
Storage temperature up to 85 ˚C
Spin speed reduction
1200
1000
800
400
0
Program WH1
1. White cotton
2. Coloured cotton
3. Synthetics
4. Daily load 40˚
5. Quick wash 30 ˚C
6. Delicate
7. Wool
8. Handwash
9. Big Items
10. Gentle spin
11. Spin
12. Rinse & Spin
Output
Aquastop (activated) AQ2.2 - (Vcc) 24 V
Pump (on) DP2.1 - DP.2.2 230 V
Valve cold (on) VCH7.1 - VCH7.3 >170 V
Valve hot (on) VCH7.5 - VCH7.7 >170V
Heating (on) HE2.1 - HE2.2 230 V
Motor distributor (on) DI6.1- DI6.3 230 V
Pressostat PR6.4 - (Vcc) 24 V
- empty PR6.6 - (Vcc) 24 V
- full (L1) PR6.5 - (Vcc) 24 V

SERVICE
16.04.2007 / Page 4 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Technical data
Motor
Type CIM 2/55 - 132/
WH8
i = 1:13.4
Resistance contacts:
1 - 2 5.96 Ω ± 7%
1 - 3 5.96 Ω ± 7%
2 - 3 5.96 Ω ± 7%
4 - 5 115.4 Ω ± 7%
Radio interference supression
Nominal voltage 230 V
Nominal capacity 1 µF X1 + 2 x 4.7 nF Y
Nominal inductance 2 x 1.8 mH
Nominal resistance 470 kΩ
Motor control unit (MCU)
Supply L and N 230 V/50 Hz
Display module
Fac. code 4619 702 29891
Programs 12 buttons
Remaining time indication
Switch Start SST
Switch Time delay STD
Switch Pre wash SPW
Switch Temp. choose +/–
Switch Rinse intensive SRI
Switch Rinse stop SRS
Switch Spin speed reduction SSR
Switch Easy ironing SEI
Reset
Child lock

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 5
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Spare part list
Model AWM 8900-ROK
Service No. 857008274000
Version 857008274000
Pos. No. 12NC Code Description
001 0 4812 440 11484 Cabinet Service Kit
002 0 4812 440 10966 Flap Filter
002 1 4812 440 98221 Protector
003 1 4812 464 48162 Crossbar rear
003 2 4812 464 48175 Crossbar table top
003 3 4812 464 48176 Crossbar transport
004 0 4812 440 11483 Drip tray assy
011 0 4812 462 18303 Adjust. foot
021 0 4812 440 10807 Front panel white
021 1 4812 440 98134 Shield Top right, light blue
021 2 4812 440 98135 Shield Base, light blue
021 3 4812 440 98136 Cover hinge
021 4 4812 440 98133 Shield Top left, light blue
021 5 4812 404 78466 Clip for Shield
021 6 4812 440 98154 Shield cpl.
024 0 4812 440 11437 Panel rear
025 0 4812 440 10789 Bracket control board
025 1 4812 440 11543 Water guide
030 0 4812 440 10792 Table top white porcelain
040 0 4812 417 19179 Hinge cpl.
040 1 4812 417 78091 Cover Hinge WH
050 0 4812 459 38064 Plinth white
061 0 4812 466 88705 Counter weight rear
061 1 4812 466 88706 Counter weight front
081 0 4812 466 48095 Shock absorber
086 0 4812 452 18994 Screw M8x20 A2F
086 1 4812 502 18399 Nut Push in M 8
110 1 4812 498 18366 Handle door cpl.
130 0 4812 417 28086 Plate door lock
131 0 4812 417 28087 Lock hook door
135 1 4812 498 18264 Pin door safety
135 2 4812 492 58044 Spring doof safety
135 3 4812 532 18068 Washer door safety
140 0 4812 450 78023 Door glass deep
143 0 4812 440 11197 Glassdoor frame silver + Protector blue
144 0 4812 440 10834 Frame glassdoor
144 1 4812 401 48585 Clamp door glass
144 2 4812 560 18068 Screw DIN 7500, CM 5x14
144 3 4812 502 48015 Screw 4,0x16-TORX
191 0 4812 466 68784 Door bellow grease resistant
191 0 4812 466 68785 Door bellow
191 1 4812 401 18657 Strap bellow, tub
191 2 4812 401 18621 Ring bellow front
200 1 4812 418 18448 Tub USA, Frontpart cpl.
200 2 4812 418 18449 Tub, half rear cpl.
200 4 4812 290 88054 Clamp for tub
220 0 4812 418 18525 Drum high cpl.
223 0 4812 418 48766 Drum lifter 1x
223 1 4812 418 48765 Drum lifter Set 3x
271 0 4812 358 18209 Belt J7
272 0 4812 528 58037 Pulley
272 1 4812 532 28944 Nut M16 f. pulley, drum
290 0 4812 532 68124 Gasket tub
301 0 4812 452 17957 Control panel + handle drawer
301 1 4812 452 12276 End cap left
Pos. No. 12NC Code Description
301 2 4812 452 12277 End cap right
303 0 4812 498 78637 Handle drawer 6.SENSE
321 0 4812 452 12273 Insert rear Knob
321 2 4812 452 14756 Filling piece door silver
321 3 4812 459 18237 Sticker WH-Logo
331 0 4812 412 59089 Knob timer EBL
332 1 4812 410 28963 Button Start Delay
332 2 4812 410 28967 Button assy +/-
332 3 4812 410 28965 Button assy Option 3x
332 4 4812 410 28964 Button assy Option 4x
333 0 4812 410 28966 Button Start
400 0 4812 361 58446 Motor 3-phases
421 0 4812 121 18178 Interf.filter
430 0 4812 360 18594 Pump cpl. 60Hz/220V
430 1 4812 466 68879 Damper rubber rear
430 2 4812 466 68758 Damper rubber front
451 0 4812 259 28871 Heating element 2050W, 230V
451 1 4812 401 18581 Fastener heating element EU
451 2 4812 560 18069 Screw MP 1951, M4x14 SS
480 0 4812 321 78261 Cable harness motor
480 1 4812 321 78259 Cable harness main + channel
480 2 4812 321 78262 Cable harness valve
490 0 4819 321 18136 Cable mains 2m SA
491 0 4812 321 28367 Strain relief
491 1 4812 502 38152 Screw 4.8x19
521 0 4812 214 58385 Cont.brd. Basic OMEGA,ACC. EU,9kg
521 0 4812 214 58496 Control board OMEGA, programmed
521 1 4812 214 79871 Control unit motor cpl.
571 0 4812 281 28429 Inlet valve single
581 0 4812 271 28582 Pressostat
582 1 4812 271 28522 Flowmeter
620 0 4812 276 28442 User board CUIO
630 0 4812 280 58041 Door lock
631 0 4812 360 58336 Floater Kit Access Europe
691 0 4812 259 28863 Sensor temper. NTC
701 0 4812 530 28781 Hose inlet 3.8 m (Eltek)
701 0 4819 530 28926 Hose inlet 2.5 m (Eltek)
702 2 4812 530 29264 Hose flowmeter
707 0 4812 526 48158 Nozzle distribution
707 1 4812 526 48228 Nozzle inlet cold
707 2 4812 630 58102 O-Ring 8,1 x 1,6 mm
708 0 4812 530 48626 Bend
711 0 4812 418 68349 Dispenser closed door rinse channel
712 0 4812 418 89012 Drawer detergent
713 0 4812 418 89013 Hook drawer
714 0 4812 418 79819 Container detergent
717 0 4812 323 18006 Actuator f. Distribution
717 3 4812 321 38026 Lever connection
717 4 4812 321 38027 Lever distribution
717 5 4812 528 38069 Cam actuator
717 6 4812 492 58045 Spring f. lever
717 7 4812 502 18623 Screw PT3,5x20-TORx20
718 0 4812 526 48132 Siphon
718 1 4812 418 88994 Separator set
753 0 4812 418 68292 Chamber,air

SERVICE
16.04.2007 / Page 6 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Spare part list
Model AWM 8900-ROK
Service No. 857008274000
Version 857008274000
Pos. No. 12NC Code Description
754 0 4812 530 29414 Drainhose
754 1 4812 530 29445 Lock eco ball
754 4 4812 401 18623 Clamp 98,5 mm
760 0 4812 480 58317 Filter set pump
760 1 4812 466 88707 Gasket filter
781 0 4812 530 29376 Hose draining short
781 1 4812 530 29282 Hose connection outlet
782 0 4812 530 29196 Hose pressostat,with protector
783 4 4812 530 29413 Hose draining inner
785 0 4812 530 29303 Hose Draining
785 1 4812 462 79641 Stopper
787 0 4812 530 28813 Steam hose
787 1 4819 401 18174 Clamp hose 25-45 mm
787 5 4812 401 18624 Clamp 52,0 mm
794 2 4812 530 58164 Sealing
794 5 4812 530 58098 Gasket Airtrap
900 0 4812 255 18288 Holder Hose outlet
900 1 4812 255 18289 Holder Hose outlet, single
900 2 4812 401 18501 Clamp hose 19.2 mm
900 3 4812 401 18626 Clamp 32,7 mm
900 4 4812 401 18627 Clamp 40 mm
900 6 4812 255 18249 Holder drainhose inner
904 0 4812 462 79893 Threaded cap for dispenser
910 0 4812 502 48344 Screw
910 1 4812 502 18624 Screw 3.5x10-F A2F
910 2 4812 502 38352 Screw 4x10
910 4 4812 930 08022 Screw 4.2x13-F-H
910 5 4812 502 18382 Screw M8 X 35
910 6 4812 502 38355 Screw 4,2x16 T20
910 7 4812 502 18635 Screw 4.2x9.5
921 0 4812 011 18523 Ring circlip drive system
930 0 4812 492 38403 Spring,suspens. KD-Set (2x)
930 1 4812 492 38388 Silent bloc
941 0 4812 520 28183 Bearing,ball 6307
941 1 4812 520 28004 Bearing,ball 6206
952 1 4812 524 48014 Bushing f. shaft seal
953 0 4812 530 68029 Shaft seal
961 0 4812 268 18018 Distance sleeve upper
961 1 4812 268 18019 Distance sleeve lower
965 0 4812 466 68812 Cover
965 1 4812 262 78011 Threaded cap tub rear part
993 0 4819 530 29028 Bow
993 3 4812 395 58004 Tool

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 7
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Exploded view

SERVICE
16.04.2007 / Page 8 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Exploded view

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 9
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Wiring diagram

SERVICE
16.04.2007 / Page 10 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Circuit diagram

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 11
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Program chart

SERVICE
16.04.2007 / Page 12 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Program chart

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 13
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Program chart

SERVICE
16.04.2007 / Page 14 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Program chart

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 15
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Program chart

SERVICE
16.04.2007 / Page 16 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Program chart

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 17
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Program chart

SERVICE
16.04.2007 / Page 18 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Text/Legend

SERVICE Whirlpool Europe AWM 8900-ROK 16.04.2007 / Page 19
Customer Service 8570 082 74000 Doc. No: 4812 722 27545
Text/Legend

SERVICE
16.04.2007 / Page 20 AWM 8900-ROK Whirlpool Europe
Doc. No: 4812 722 27545 8570 082 74000 Customer Service
Text/Legend
