Whirlpool AWM 5145/5 User manual

GB AWM 5145/5 PROGRAMME CHART
5019 301 10192
Whirlpool is a registered trademark of Whirlpool USA
Programme Care
Labels Type of wash/Notes
Max
Load
Detergent and additives Special options Max. Spin
speed
rpm
Programme
Selector
Softener Main
Wash Pre- wash Quick
Wash Rinse Hold Cold Wash
Kg
Cotton 95°
with prewash Heavily soiled, long wearing and temperature stable textiles in cotton and linen (bed linen, table linen, underwear, shirts etc.). 5.0 ❉Yes Yes —❉❉1400 1
Synthetics 60°
with prewash Heavily soiled blouses, shirts, overalls etc. made of polyester (Diolen, Trevira), polyamide (Perlon, Nylon) or blends with cotton. 2.5 ❉Yes Yes —❉❉800 1) 2
Delicates 40°
with prewash Heavily soiled curtains and delicate clothing, dresses skirts, shirts and blouses. 1.5 ❉Yes Yes —❉❉800 1) 3
Cotton 95° Slightly to normally soiled bed linen, table linen and underwear, towels, shirts etc. made of cotton and linen.
If you select “Quick Wash”, washing temperature is 60°. Normal 5.0
Quick Wash 3.0 ❉Yes — ❉❉❉1400 4
Cotton 60° Slightly soiled bed linen, table linen and underwear, towels, shirts etc. made of cotton and linen. 5.0 ❉Yes — ❉❉❉1400 5
Cotton 40° Slightly soiled bed linen, table linen and underwear, towels, shirts etc. made of cotton and linen. 4.5 ❉Yes — ❉❉❉1400 6
Slightly to normally soiled textiles made of cotton and/or synthetics. 3.0 ❉Yes — — ❉❉1400
Synthetics 40° Slightly soiled overalls and sports wear made of cotton, polyester, polyamide and blends with
cotton. 2.5 ❉Yes — ❉❉❉800 1) 7
Delicate 40° Curtains and delicate clothing, dresses skirts, shirts and blouses. 1.5 ❉Yes — —❉❉800 1) 8
Wool 40° Only woollens with a felt-free finish, labelled with the woolmark and identified as machine washable.
If you select “Rinse Hold” do not leave items to soak for too long. 1.0 ❉Yes — —❉❉800 1) 9
Silk 30° Textiles made of linen, silk, wool and viscose marked as “handwashable”.
If you select “Rinse Hold” do not leave items to soak for too long. No spinning. 1.0 ❉Yes — —❉❉ 02) 10
Rinse and spin —With this programme you can add starch and/or fabric softener.
The programme endswith an intensive spin cycle. 5.0 ❉———❉—1400 A
Fast spin —In this programme spinning is fast. Same as the spin cycle in the “Cotton” programme. 5.0 ——————
1400 B
Slow spin —In this programme spinning is slow. Same as the spin cycle in the “Wool” programme. 1.5 ——————
800 1) C
Drain —Drain only - no spinning. Alternative method of terminating programmethesynthetic,delicateand
wool programme and for premature removal of the laundry. ——————— — D
A. “On/Off” Button
B. “On/Off” Indication
❉: optional / Yes : dosing required
1) For improved garment care spin speed is restricted
to 800 rpm in this programme.
2) For improved garment care spin speed is null in this
programme.
During the selected washing programme the
programme selector knob moves by steps
clockwise through the phases prewash, main
wash, rinse and spin. Each step takes from some
seconds to several minutes.
B
A

5019 301 10192
Whirlpool is a registered trademark of Whirlpool USA
Prewash might increase programmme duration. Consumption values were measured in normalized conditions in
compliance with Standard IEC/EN 60 456.
Consumption data in the home may vary with respect to the values in the table in relation to the water supply pressure
and temperature, the load and the type of wash.
Add the detergent as described in the programme
table or in the chapter “Detergents and Additives”
in the booklet.
1. Open the tap.
2. Set the programme selector to the desired
programme.
3. Set the spin selector to the desired speed.
4. Special options can be selected.
5. Check that the door is well closed and turn on
the washing machine by pressing the “ON/
OFF” button. The indicator lights up, indicating
that the washing machine is on.
“Quick Wash” button
• For quick, economical washes.
• Ideal for minimum loads of lightly-soiled articles.
Note: reduce the detergents quantity.
“Rinse Hold” button
• The laundry remains in the last rinse water
without progressing to the final spin cycle to
avoid creasing and prevent colours from
changing.
• This option is particularly recommended for the
programme “Synthetics” or “Delicates”.
• This function is particularly useful if you want to
postpone spinning to a later time, or if you want
to drain only.
Terminate the “Rinse Hold” option:
• Press the “Rinse Hold” button again; the
programmewillterminateautomaticallywiththe
final spin cycle for the present wash programme.
• If you do not wish to spin the clothes, turn the
programme selector knob counterclockwise to
the “Drain” programme.
“Cold Wash” button
• With this option water is heated only up to 20°C.
CONSUMPTION DATA
Programme Load
(kg)
Water
(l)
Energy
(kWh)
Approx.
Programme
Duration
(hours:minutes)
Cotton 95° 5.0 54 1.90 2:05
Cotton 60° 5.0 49 0.95 2:25
Cotton 40° 4.5 49 0.60 2:10
Daily 40° 3.0 45 0.50 1:00
Synthetics 40° 2.5 55 0.60 1:25
Delicate 40° 1.5 60 0.60 0:50
Wool 40° 1.0 60 0.45 0:45
Silk 30° 1.0 45 0.30 0:45
ADD DETERGENTS,CLOSETHEDOORAND
SELECT THE PROGRAMME SELECT ANY DESIRED OPTION
To reselect a programme when a cycle has already
begun:
1. Switch off the appliance by pressing the
“ON/OFF” button.
2. Select the new programme.
3. Start the programme by pressing the “ON/
OFF” button.
1. At the end of the programme the programme
selector moves to the stop position.
2. To unload the machine wait for the door to
unlock (about 1 minute).
3. Switchofftheappliance,openthedoorandtake
out the laundry.
4. Close the tap and leave the door ajar to allow
the drum to dry out.
•WATER LEVEL
It may not be visible as the cycle is optimised
for a minimum water consumption without
compromising washing results.
•SPIN SPEED CONTROL
Spin speed may be reduced automatically or
may even be excluded in the case of small
loads with highly absorbent garments (e.g.
bathrobes, bathmat).
This control avoids cloth and machine damage
and excessive vibrations and consequent noise
produced by the machine due to load
unbalance: by selecting high spin speeds the
noise level increases.
•MOTOR NOISE
The running noises of the new, electronically-
controlled motor are not the same as the ones
you are used to from your old appliance. Don’t
be surprised - modern technology has a
modern sound.
•CLEANING THE FILTER
To ensure an impeccable function of the pump,
check the filter regular and clean it if necessary.
PROGRAMME CHANGE
PROGRAMME END
NOTES AND INDICATIONS FOR USE

5019 301 10192
Whirlpool is a registered trademark of Whirlpool USA
If you wish to connect
hot and cold water
supply (Fig.1):
1. Fix the red marked inlet hose at the hot
water tap and at the inlet valve with the red
filter on the rear side of machine.
2. Fix the other inlet hoseat the cold water tap
and at the inlet valve with the blue filter on
the rear side of the machine.
Make sure:
a) The connections are tightly fixed
b) Do not invert their position
(for example: cold fill into hot inlet valve and
viceversa).
If you wish to connect only the
cold fill follow the below
instruction (Fig.2):
1. You need a Y-piece connector. The
Y-piece connector can be ordered via our
Service Organization or purchased in a
specialized hydraulic component store.
2. Fix the Y-piece connector to the cold fill
tap.
3. Connect the two inlet valves present on
the rear part of the machine to the Y-piece
connector using the relative provider
hoses.
Make sure:
All connections are tightly fixed.
Fig.1 Fig.2
HOT / COLD FILL INSTRUCTION
Do not allow children to operate, crawl on, near or inside your
washer.
Note that during wash cycles, the surface temperature of the
porthole door may increase.
Close supervision of children is necessary when the appliance is
used near children.
