Whirlpool AWE 9630 Operating and installation instructions

SERVICE Whirlpool EMEA
Customer Services AWE 9630
Service Information
Washing machine Toploader
AWE 9630
8530 963 38010
Last Modification: 10/02/10
Creation Date: 09/27/10
Spare Part List 2
Exploded View 5
Technical Data 7
Wiring Diagram 10
Circuit Diagram 12
Program Chart 14
Testprogram 26
Error Codes 27
Service Bulletin 4812 712 40354 33
Service Bulletin 4812 712 40358 35
Service Bulletin 4812 712 40317 37
Service Bulletin 4812 712 40348 38
Service Bulletin 4812 712 40313 40
Service Bulletin 4812 712 40315 41
This document is only intended for qualified technicans who are aware of the
respective safety regulations.
Subject to modifications
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 2 of 41
Spare Part List
Pos 12NC Description
002 0 4812 459 38057 Flap round GW
002 1 4812 459 38058 Hinge flap GW
004 0 4812 440 10727 Drip tray assy
010 0 4812 459 48219 Frame inner,soft open
010 1 4812 440 11663 Frame Top + nozzle box
011 0 4812 462 48054 Foot
012 7 4812 310 18497 Trolley kit front
012 8 4812 528 78075 Foot rear
021 0 4812 440 10742 Front panel GW
022 0 4812 440 10743 Side panel right GW
022 1 4812 440 10744 Side panel left GW
024 0 4801 111 04682 Rear panel
040 0 4812 417 19155 Hinge bolt lid GW
061 0 4801 111 04683 Counter weight
061 1 4812 466 88465 Counter weight right
081 4 4812 529 18043 Shock absorber
086 2 4812 401 18412 Stopper
086 4 4812 529 18045 Pin f. Shock absorber
086 5 4812 529 18052 Damper f. Shock absorber
100 1 4812 440 10745 Lid outer GW
100 3 4812 440 11824 Lid inner +hook+spring
100 5 4801 111 04684 Lid cpl.
110 4 4801 111 04685 Handle cpl.
130 0 4812 417 19156 Hook f. Lid GW
191 0 4801 101 00143 Door bellow
191 1 4812 492 98012 Strap f. Doorbellow
191 2 4812 466 88703 Seal
200 0 4801 111 04686 Tub
201 0 4801 111 04687 Cover for tub
220 0 4801 111 04688 Drum
221 1 4812 310 18843 Kit latch f.drum
223 0 4801 101 00104 Drum lifter low
290 0 4812 532 68078 Gasket
301 0 4801 111 04689 Control panel AWE 9630
321 3 4812 453 10906 Window FLD
331 0 4801 111 01462 Knob timer Core 08, metallic
331 2 4812 414 58307 Spring Knob timer
332 0 4812 410 29581 Button 4 options
333 0 4812 410 29582 Push button Reset/Drain
333 1 4812 410 29583 Button 2 option WP
333 2 4801 111 03029 Button window, left
333 3 4801 111 03031 Button window, middle
333 4 4801 111 03032 Button window, right
350 0 4801 111 04691 Control unit Motor
350 1 4812 239 58089 Module B4,FLD
400 0 4801 111 04692 Motor
421 0 4812 121 18285 Interf.filter
421 2 4812 404 38679 Holder RFI
430 0 4801 111 04693 Pump,draining
451 0 4812 259 28919 Heating element 2050W, 230V + NTC
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 3 of 41
Pos 12NC Description
490 0 4819 321 18136 Cable mains 2m SA
490 1 4812 321 28367 Strain relief
490 2 4801 111 04709 Ferrite core
521 0 4801 111 04694 Control unit DOMINO, programmed
521 1 4801 111 04695 Control unit DOMINO, Basic, CIM,F2-/hf
571 0 4812 281 28468 Valve magnet 1 inlet, 2 outlets
571 1 4812 281 18069 Cover for top frame
581 0 4812 271 28554 Pressostat
620 0 4812 239 58091 Module E3-opt. blue
630 0 4812 271 38366 Door lock 3 Pol
631 0 4812 271 38358 Switch MICRO
631 1 4812 404 38709 Holder Switch Aquastop
653 1 4812 134 18101 Light guide 4 opt. right
653 3 4812 134 18102 Light guide Start/Reset
653 4 4812 134 18103 Light guide prog. buttons
691 0 4812 282 19485 Sensor NTC
691 1 4801 111 04696 Sensor Drum up
701 0 4812 530 29256 Hose inlet 1.8 m (Eltek)
702 2 4812 530 29453 Hose valve-dispenser
707 0 4812 526 48244 Nozzle box cold cpl.
707 1 4812 526 48049 Clamp f. nozzle box
712 4 4812 418 68302 Siphon f. softener
712 6 4812 418 68164 Clip soap dispenser
712 9 4812 418 68404 Soap dispenser
714 0 4812 360 78115 Container Aquastop
753 0 4812 418 68182 Chamber,air
754 0 4812 530 29267 Drainhose
754 1 4812 530 28832 Lock eco
754 2 4812 530 29352 Flange eco
756 0 4812 360 58365 Floater Aquastop
760 0 4812 480 58403 Filter
781 0 4819 530 29035 Hose draining
782 0 4812 530 29268 Hose Pressostat
783 3 4812 530 18001 Connection Part
786 0 4812 530 29506 Hose overflow-AQS
787 0 4812 530 29507 Hose air exhaust
787 2 4812 530 29463 Cover exhaust hose
794 0 4801 111 01551 Gasket airtrap
900 0 4819 401 18686 Clamp hose
900 2 4812 255 18304 Holder hose
900 3 4819 401 18529 Clamp hose
900 5 4819 400 18049 Cover
900 6 4812 400 18048 Pin
901 0 4819 401 18872 Clamp hose
910 0 4812 502 48347 Screw,selftap 3,5x14
910 1 4812 502 38151 Screw 4x14
910 2 4801 101 00801 Screw M8x18
910 4 4812 502 18423 Screw PT 7x15
910 6 4801 111 02619 Nut M8
910 7 4801 111 04284 Screw 8x40
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 4 of 41
Pos 12NC Description
910 8 4801 111 04697 Screw 8x28
910 9 4801 111 04698 Screw 8x23
911 0 4801 111 04699 Screw M8x22,5/DD
911 1 4801 111 04701 Washer 8.4x25x2
930 1 4812 492 48171 Torsions spring
930 2 4812 492 48086 Spring
941 0 4812 310 19144 Bearing kit ALL 1100
941 1 4812 520 28002 Bearing,ball 6203 2Z C3
941 2 4801 111 04702 Bearing
950 0 4801 111 04703 Shaft seal
953 0 4812 325 68001 Shaft seal
953 1 4812 520 28073 Ring counterface
953 2 4812 530 68017 O-Ring
965 0 4812 462 79974 Cap Transport blocking
993 0 4819 530 29028 U Curve for outlet hose
993 1 4801 111 01911 Clamp heatingelement
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 5 of 41
Exploded View
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 6 of 41
Exploded View
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 7 of 41
Technical Data
Dimensions + Weight
Product dimensions
Height ................................................................................................85cm
Width .................................................................................................40cm
Depth .................................................................................................60cm
Weight
net ....................................................................................................62 kg
Electrical base data
Voltage .......................................................................................... 230 V±10 %
Frequency ............................................................................................... 50 Hz
Fuse ......................................................................................................10 A
Power Consumption ...................................................................................~2.3kW
Drum data
Volume .....................................................................................................42 l
Wash speed .........................................................................................52 giri/min
Spinning
max. ...........................................................................................1200giri/min
Drum up sensor
........................................................................................................(SE -HallSensor)
Nominalvoltage ..................................................................................4.2 - 24 V DC
Pressostat
Level1 ...............................................................................................11-12/14
Overflow ................................................................................................11 - 16
Door lock
Kindofswitch .................................................................Interruttore con PTCdibimetallo
Nominalvoltage ............................................................................... 230 (90 - 264)V
Locking time ..............................................................................................≤5 s
Unlock time ............................................................................................≤180 s
Inlet valve
Nominalvoltage ............................................................................220 - 240 V / 50 Hz
Ratedflow .........................................(1.5-5bar) .........................................8l/min
Pressurerange .....................................................................................0.3-10bar
Nominalresistance .......................................(20°C) .......................................3.8 kΩ
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 8 of 41
Drain pump
Nominalvoltage ............................................................................220 - 240 V / 50 Hz
Total power ...............................................................................................25W
Resistor(coil) ............................................................................................224 Ω
Capacity ...........................................................................................19 ±2 l/min
Positionofdraining hose outlet .....................................................................0.9 -1.25m
Switch aquastop
Nominalvoltage ......................................................................................250 V AC
Heating element
Nominalvoltage ...........................................................................230 V + 10 %, -15 %
Total power .............................................................................................2050 W
Resistance(20°C) ........................................................................................25 Ω
Leakage current ...................................................................................... < 0.8 mA
NTC sensor
Resistance NTC
0 °C 35.9 kΩ
30 °C 9.8 kΩ
40 °C 6.6 kΩ
50 °C 4.6 kΩ
60 °C 3.2 kΩ
70 °C 2.3 kΩ
95 °C 1.1 kΩ
Motor
Resistancecontacts ...................................(25°C) ...................................15.5Ω±5 %
Control unit
Type ..................................................................................................DOMINO
Nominalvoltage ..................................................................................230 V / 50 Hz
Output control unit
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 9 of 41
Motore M7.6 - DSS3.2 >40 V
Acqua-stop AQ2.2 - DSS3.2 230 V
in fase di pompaggio AQ2.1 - DSS3.3 230 V
NTC non misurabile —
Pompa DP2.1 - DP2.2 230 V
Microritardatore porta DSS3.1 - DSS3.3 230 V
Pressostato E4 - E2 230 V
- vuoto PR2.1 - E2 230 V
- pieno PR2.2 - E2 230 V
Elettrovalvola (Rast 2.5) V2.1 - V2.2 >170 V
Opzioni non misurabile —
Motor control unit (MCU)
Type ............................................................................................... Direct Drive
Nominalvoltage ....................................................................................220 - 240 V
Frequency ...........................................................................................48 - 62 Hz
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 10 of 41
Wiring Diagram
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 11 of 41
Legend
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 12 of 41
Circuit Diagram
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 13 of 41
Legend
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 14 of 41
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 15 of 41
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 16 of 41
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 17 of 41
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 18 of 41
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 19 of 41
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8530 963 38010, 10/02/10
page 20 of 41
© Whirlpool EMEA www.scc-service.com
