TOP AND CABINET PARTS
1
For Model: WFW8300SW0
(White)
4−06 Printed in U.S.A. (drd) Part No. 8181055
AUTOMATIC WASHER

TOP AND CABINET PARTS
2
For Model: WFW8300SW0
(White)
8181055
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8540910 Use & Care Guide
8540259 Tech Sheet
8540904 Energy Guide
8540913 Quick Start Guide
2 8540716 Top
3 8540548 Cabinet
4 8540572 Panel, Front
5 8540813 Toe Panel
6 389102 Foot, Leveling (4)
7 8540643 Bracket, Spring
8 3359452 Nut, Lock (4)
9 8518891 Rivet (2)
10 8540582 Panel, Rear
11 8540583 Brace, Transport
12 8540199 Bolt, Shipping (4)
13 Hose, Water Inlet
8571377 Blue Coupler
8571378 Red Coupler
14 8540752 Cord, Power
15 8540135 Motor Control Unit
16 8540557 Brace, Rear
17 8540093 Clamp, Tube
Transportation
18 8540011 Hose, Drain
19 8540607 Retainer,
Hose Outlet
20 8540977 Bumper (2)
21
W10015090 Screw, 8−18 x 5/8
22 8540230 Filter,
Interference
23 8540224 Switch, Pressure
24 8540294 Hose, Pressure
Switch
25 8540479 Screw, Grounding
26 8540268 Cover, Transport
27 8540021 U−Bend,
Drain Hose
28 8540210 Microswitch (2)
29 8540728 Sleeve,
Cord Support (2)
30 8540727 Screw, 3 x 8 mm
31 8540329 Screw
32 8540720 Brace, Top
(Includes Item 33)
33 8283273 Damper, Brace
34 2161302 Sleeve, Pressure
Switch Hose
35 8540947 Cable Tie
36 16123 Washer, Water
Inlet Hose (4)
1−1/16 x 5/8
37 8540290 Harness Channel,
Top Rear
38 8540288 Harness Channel,
Side Front
39 8540289 Harness Channel,
Side Rear
40 3390647 Screw, 8−18 x 1/2

DOOR AND LATCH PARTS
3
For Model: WFW8300SW0
(White)
8181055
Illus. Part
No. No. DESCRIPTION
1 8540952 Bellow
2 8540108 Clamp, Bellow
3 8540772 Lock, Door
4 8540725 Screw
5 8540221 Hook, Door
6 8540533 Trim Ring,
Outer Door
7 8540107 Clamp, Bellow
(Front)
8 8540115 Clamp, Support
9 8540114 Clamp, Glass (2)
10 8540513 Screw
11 8540588 Frame, Door
Front Assembly
12 8540428 Glass, Door
13 8540891 Door,
Back Support
14 8540416 Hinge, Door
15 8540284 Screw
16 8540282 Screw

CONTROL PANEL PARTS
4
For Model: WFW8300SW0
(White)
8181055
Illus. Part
No. No. DESCRIPTION
1 8574927 Panel, Control
2 8571944 Knob, Control
3 8571903 User Interface
4 8540558 Brace, Top Front
5 8540839 Channel, Water
6 8541000 Microcomputer,
Machine Control
7 3390647 Screw, 8−18 x 1/2
8 8540703 Harness, Wiring
(Main)
9 8540282 Screw
10
W10015090 Screw, 8−18 x 5/8

DISPENSER PARTS
5
For Model: WFW8300SW0
(White)
8181055
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8540751 Valve, Inlet
2 8540065 Hose, Valve
To Dispenser
3 370450 Clamp, Hose
4 8540282 Screw, Valve Mtg.
5 8540042 Nozzle, Inlet
6 8540393 Cam, Actuator
7 8540394 Lever, Water
Distribution
8 8540041 Actuator
9 8540282 Screw
10 8281276 Clamp, Hose
11 8540395 Connection, Lever
12 8540058 Dispenser
13 8540053 Nozzle,
Distribution
14 8540063 Hose, Dispenser
To Tub
15 8571947 Handle, Drawer
16 8529540 Medallion
17 8540402 Drawer,
Detergent
18 8540399 Cover,
Detergent Drawer
19 8540429 Siphon,
Bleach/Softener
20 8540400 Hook, Drawer

PUMP AND MOTOR PARTS
6
For Model: WFW8300SW0
(White)
8181055
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8540704 Harness, Motor
2 8540033 Cap, Right Foot
3 8540180 Air Trap
4 8540013 Ball
5 8540008 Clamp
6 8540012 Hose,
Tub to Pump
7 370448 Clamp
8 8540032 Damper, Rubber
(Left Foot)
9 356138 Clamp, Hose
10 8540024 Pump (Complete)
11 8540031 Damper, Rubber
(Right Foot)
12 8533964 Screw,
10−16 x 1.25 (2)
13 8540025 Seal, Filter Cap
14 8540996 Filter Assembly
(Includes Item 13)
15 8540133 Motor, Drive
16 8540134 Bolt, Motor

TUB AND BASKET PARTS
7
For Model: WFW8300SW0
(White)
8181055

TUB AND BASKET PARTS
8
For Model: WFW8300SW0
(White)
8181055
Illus. Part
No. No. DESCRIPTION
1 8533999 Nut, Pulley
2 8540088C Pulley
3 8540101 Belt, Drive
4 8540600 Counterweight,
Front Lower
5 8540737 Pipe, Ventilation
6 8540010 Clamp, Vent Hose
7 8540019 Hose, Exhaust
8 8540446 Tub, Rear
9 8540602 Counterweight,
Rear
10 8540090 Gasket, Tub
11 8540451 Basket, Complete
12 8540456 Baffle, Tub
14 8534084 Nut, Shock
Absorber Mounting
15 8540598 Counterweight,
Front Upper
16
W10010360 Spring,
Suspension
(Set Of 2)
17 8540292 Bolt,
Counterweight Mtg.
18 3363365 Clamp
19 8540015 Hose, Exhaust
20 8540092 Clamp, Tub
21 8540449 Tub, Front
(Includes Item 22)
22 8540072 Nut, Push−In
23 8540852 Shock Absorber
24 8540226 Negative
Thermistor Control
25 8540766 Seal, Rubber
26 8540382 Screw
27 8540457 Crosspiece Asm
28 8540940 Bracket, Shock
Absorber Mounting
29 8540841 Bolt, Shock Brkt.
30 8540842 Nut, Shock Brkt.

OPTIONAL PARTS (NOT INCLUDED)
9
For Model: WFW8300SW0
(White)
8181055
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350938 Primer, Gray
350930 White
PAINT, BULK (1 qt.)
799344 White (Uncut)
ACCESSORY PARTS
285863 Drain Extension
