Whirlwind Patent-Pending Recessed Wall Frames User manual

WFS8x8x1B 8" x 8" x 1" fits 8" x 8" x 4" surface-mounted electrical box
WFS8x8x2.5B 8" x 8" x 2.5" fits 8" x 8" x 6" surface-mounted electrical box
WFF8x8x1B 9" x 9" x 1" fits 8" x 8" x 4" recessed electrical box
WFF8x8x2.5B 9" x 9" x 2.5" fits 8" x 8" x 6" recessed electrical box
WFS12x12x1B 12" x 12" x 1" fits 12" x 12" x 4" surface-mounted electrical box
WFS12x12x2.5B 12" x 12" x 2.5" fits 12" x 12" x 6" surface-mounted electrical box
WFF12x12x1B 13" x 13" x 1" fits 12" x 12" x 4"recessed electrical box
WFF12x12x2.5B 13" x 13" x 2.5" fits 12" x 12" x 6" recessed electrical box
These two-piece wall frame assemblies recess exposed connectors, providing greater protection for them and
enhancing any installation. Whirlwind patent-pending Wall Frames are currently available to fit 8”x8” and 12”x12”
standard NEMA type 1 electrical backboxes. There are two standard recess depths (1” and 2.5”) and frames are
availableforbothflushmountandsurfacemountapplications.
Thesurfacemountversion(WFS___)mountingflangesarethesamedimensionsasthecorrespondingbackbox.
Theflush mountversion (WFF__ _)mounting flangesextend one-halfinchbeyondtheedgeofthebackboxonallfour
sidestoprovideavisuallyappealingtrimringeffecttothefinishedwall.
Framefinishisblackpowdercoat.(Customfinishesavailableuponrequest.)
Connectormountinginsertpanels(WFI__ _) attach to theframesandcanbe custom punched, engraved and loaded
byWhirlwindtoaccommodateanyinstallationrequirement. Standardfinishisblackanodizedaluminum.
OthersizesofrecessedWallFramesarealsoavailableuponrequest.
Whirlwind’s Patent-Pending Recessed Wall Frames
whirlwind · 99 Ling Road Rochester, NY 14612 · 800 733-9473 · http://www.whirlwindusa.com

A
C
B
ABC
Connector Insert Plates
WFI8x8B
fits 8x8 WFF and WFS
5.5"
usable area
6.5"
10.5"
9.5"
usable area
WFI12x12B
fits 12x12 WFF and WFS
Wall Frame Dimensions
4) SCR1032X1/2PPF screws included
to mount frame to backbox
SCR632X3/8FPU screws are supplied with
the WFI inserts for mounting.
WFS8x8x1
WFS8x8x2.5
WFF8x8x1
WFF8x8x2.5
WFS12x12x1
WFS12x12x2.5
WFF12x12x1
WFF12x12x2.5
8"
8"
9"
9"
12"
12"
13"
13"
6.75"
6.75"
6.75"
6.75"
10.75"
10.75"
10.75"
10.75"
1"
1"
1"
1"
2.5"
2.5"
2.5"
2.5"
whirlwind · 99 Ling Road Rochester, NY 14612 · 800 733-9473 · http://www.whirlwindusa.com
Made In USA
