Whispbar K506W User manual

K506W
Fitting Kit
EN Fitting Instructions for Basic Carrier
PL Instrukcja systemu montażu
x 2 x 2 x 2 x 2
x 4
Revision No: 5D 1

Fitting Kit K506W
MAX kgs (lbs)
W/P WHD
Audi
A5 Sportback, 5dr Coupe 09-16 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
A5 Sportback, 5dr Coupe 09-16 ZA 75 kgs (165 lbs) 75 kgs (165 lbs)
A5 Sportback, 5dr Coupe 09-16 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
A5 Sportback, 5dr Coupe 09-17 AU 75 kgs (165 lbs) 75 kgs (165 lbs)
A5 Sportback, 5dr Coupe 10-17 CN 75 kgs (165 lbs) 75 kgs (165 lbs)
2

Fitting Kit K506W
X
A B C 1 2 3
A5 Sportback, 5dr Coupe 09-16 (NZ) -300mm 400mm - 895mm 870mm -
-11 -13/16ths" 15 3/4ths" - 35 1/4ths" 34 1/4ths" -
A5 Sportback, 5dr Coupe 09-16 (ZA) -300mm 400mm - 895mm 870mm -
-11 -13/16ths" 15 3/4ths" - 35 1/4ths" 34 1/4ths" -
A5 Sportback, 5dr Coupe 09-16 (EU) -300mm 400mm - 895mm 870mm -
-11 -13/16ths" 15 3/4ths" - 35 1/4ths" 34 1/4ths" -
A5 Sportback, 5dr Coupe 09-17 (AU) -300mm 400mm - 895mm 870mm -
-11 -13/16ths" 15 3/4ths" - 35 1/4ths" 34 1/4ths" -
A5 Sportback, 5dr Coupe 10-17 (CN) -300mm 400mm - 895mm 870mm -
-11 -13/16ths" 15 3/4ths" - 35 1/4ths" 34 1/4ths" -
3

Fitting Kit EN
K506W
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●This kit fits type A, B, C and D.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
NOTE: Clamp images in these instructions may
not be representative of the clamps in this kit
4

Fitting Kit EN
K506W
●Use keys to remove covers.
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
5

Fitting Kit EN
K506W
●Remove locking screw.
●Apply protective strip as shown.
Trim if required.
●Cut protective strip as shown.
6

Fitting Kit EN
K506W
●It is important to put the clamps in the
correct position on the vehicle.
●Letters refer to the part numbers stamped
on clamps.
●Clamp Part Number:
A = 688A
B = 689A
●Attach clamp to each leg. NOTE; clamps
may have labels showing their positions on
the vehicle (For example; "Front Right").
●Refit locking screw so that it goes through
the hole in the clamp. Do not begin to
tighten the locking screw.
7

Fitting Kit EN
K506W
●It is important to put the pads in the correct
position on the vehicle.
●Letters refer to the pad part numbers and
position.
●Pad Part Number:
A = 11-04-250
B = 11-04-251
●Fit rubber pads (supplied with fitting kit) to
foot. Pad may vary in shape to that shown.
●Make sure the pad fits into the holes
underneath the foot.
8

Fitting Kit EN
K506W
●Clamps onto anchor points under rubber
door frame mouldings
●The rubber seal must be peeled back from
the vehicle body to allow the clamp to be
inserted between the vehicle body and the
rubber seal.
Fitment
●Place crossbar on vehicle. Minimum
recommended spacing between the bars is
700mm (27 1/2") (unless otherwise stated).
●Please check the front of this manual for
information relating specifically to your
vehicle.
9

Fitting Kit EN
K506W
●Press adjusting screw to adjust the leg
positions on the crossbar.
●Tighten adjusting screw to 5 Nm (3.7 ft lb)
hand tight.
●Tighten locking screw on both legs evenly.
10

Fitting Kit EN
K506W
●Check crossbar is securely attached to the
vehicle.
●Use keys to fit and lock covers
CAUTION: Recheck all fasteners immediately after
a load is applied to the crossbars.
Regularly check screws are tight.
11

Fitting Kit EN
K506W
●Clean the car roof and surfaces of the
product that will be in contact with the car
roof.
●Follow the fitting instructions for fitting the
product to your vehicle. Make sure all steps
are carried out in order.
●Set crossbars a minimum distance of
700mm (27 1/2") apart where no other
distance is specified in the fitting
instructions. This is especially important
when carrying long loads.
●Check unit is securely attached whenever
you refit it to the vehicle. If the unit feels
loose, refer to the fitting instructions and
readjust.
●Some glass/panoramic roofs and radio
antennae may not be able to be used when
the product is fitted.
●Do not modify this product.
●Refer to the maximum permitted load
capacity specified in the fitting instructions.
Do not exceed the vehicle manufacturers
roof load rating if it is lower than the
maximum load capacity specified in the
fitting instructions.
●Loads should not overhang the sides of the
product and be evenly distributed with the
lowest possible centre of gravity.
●Long loads should be secured with non-
elastic straps to the front and rear of the
vehicle.
●Objects with pointed ends (e.g. ski poles)
should be carried with the pointed ends to
the rear of the vehicle.
●Remove all loose or removable objects
from the load prior to loading.
●Make sure all loads are securely fastened
with non-elastic straps. Check regularly
during longer journeys.
●A loaded roof rack system can alter the
performance of your vehicle. Be especially
aware of the effects of side winds,
changing of direction, and braking
performance. Avoid rapid acceleration and
deceleration. Drive carefully.
●Note that the total height of the vehicle
increases when upright loads are carried.
●Products should be locked during transport
if they have locks fitted.
12

Fitting Kit EN
K506W
●Check and replace worn out or defective
parts.
●Keep the product clean and maintained.
●Never drive into a car wash with the roof
rack system fitted.
●Lubricate locks and adjusting screws at
regular intervals.
●Remove the products from the vehicle
when not in use. Make sure all loose parts
are stored safely.
●Yakima Products, Inc.
4101 Kruse Way,
Lake Oswego, OR 97035
USA
www.whispbar.com
www.whispbar.ca
●Yakima Europe Coöperatief U.A.
Archimedesbaan 25
3439 ME Nieuwegein
The Netherlands
[phone]
www.whispbar.eu
www.whispbar.co.uk
●Yakima Products, Inc.
4101 Kruse Way,
Lake Oswego, OR 97035
USA
www.whispbar.com
www.whispbar.ca
13

Fitting Kit PL
K506W
Pierwszy montaż
●Sprawdź zawartość opakowania i upewnij
się, czy zawiera wszystkie części
znajdujące się na liście. Jeśli nie,
skontaktuj się z odpowiednim sklepem.
●Kit pasuje do belek typu A, B, C oraz D.
●Instrukcja opisuje sposób montażu belek
typu A. Może być również stosowana do
belek typu B, C i D.
UWAGA: Zdjęcia łap mogą różnić się w zależności
od rodzaju kitu
14

Fitting Kit PL
K506W
●Odkręć osłony za pomocą klucza.
●Zdejmij osłony za pomocą klucza.
●Przyciśnij i usuń blokadę. Zamontuj stopy.
●Sprawdź czy oba końce belek mają taką
samą długość.
15

Fitting Kit PL
K506W
●Odręć śrubę zabezpieczającą.
●Nałożyć pasek ochronny, jak pokazano.
Zabezpiecz tśmą.
●Przytnij taśmę zabezpieczającą jak na
rysunku.
16

Fitting Kit PL
K506W
●Bardzo ważne jest aby umieścić łapy w
odpowiednich miejscach na dachu
samochodu
●Litery odnoszą się do oznakowań na
łapkach
●Numer łapy:
A = 688A
B = 689A
●Doczep łapki do kitu. Uwaga: Na łapkach
umieszczona jest informacja odnośnie ich
rozmieszczenia. ( Np. Prawy przód)
●Umieść śrubę w otworze łapki. Nie
dokręcaj śruby zbyt mocno.
17

Fitting Kit PL
K506W
●Bardzo ważne jest aby umieścić podkładek
w odpowiednich miejscach na dachu
samochodu
●Litery oznaczają podkładki oraz sposób ich
rozmieszczenia.
●Rozmieszczenie podkładek:
A = 11-04-250
B = 11-04-251
●Nałóż gumowe podkładki na stopę.
Podkładki mogą różnić się kształtem.
●Upewnij się, czy dobrałeś odpowiednią
podkładkę.
18

Fitting Kit PL
K506W
●Mocowanie w punktach fabrycznych pod
uszczelką drzwi
●Odsuń uszczelkę tak aby umieścić łapkę
między karoserią a gumą.
Montaż
●Umieść belki na dachu. Zalecana odległość
między belkami wynosi 700mm.
●Czytać na z przodu instrukcji znajdziesz
specyfikacje dla twojego samochodu.
19

Fitting Kit PL
K506W
●Dokręcając śrubę dopasuj stopę do belki.
●Dokręć z siłą 5 Nm / 3.7 ft lb.
●Dokręć śruby na każdej stopie.
20
