White-Westinghouse HQE6807SDER User manual

HQE6807SDER
User Manual
TABLE OF CONTENTS
www.white-westinghouse-intl.com
Important safety instructions .......................3
Description of your appliance .......................5
Installation .......................................7
Dimensions .......................................9
Using the appliance ..................................10
Care and cleaning .................................14
Troubleshooting ....................................15
Removing door handles .............................17
Electrolux Major Appliances International
10200 David Taylor Drive, Charlotte, NC 28262, USA Made in Thailand

2
BEFORE USING YOUR
APPLIANCE
Before you use the refrigerator, we recom-
mend that you read through the whole user
manual which provides the description of
the refrigerator and its functions. To avoid
the risks that are always present when you
use an electrical appliance, it is important
that the refrigerator is installed correctly
and that you read the safety instructions
carefully to avoid misuse and hazards.
For future reference, please store this
booklet in a safe place.
CONDITIONS OF USE
This appliance is intended to be used in
household and similar applications such as:
• Staff kitchen areas in shops, offices and
other working environments
• Farm houses
• By clients in hotels, motels and other
residential type environments
• Bed and breakfast type environments
• Catering and similar non-retail applica-
tions
BEFORE YOU CALL
Please ensure you read the instruction
manual fully before you call for service, or
a full service fee could be applicable.
RECORD MODEL AND NUMBER
HERE:
Model:
Serial No:
LEGEND:
WARNING
This symbol indicates information con-
cerning your personal safety.
CAUTION
This symbol indicates information on how
to avoid damaging the refrigerator.
IMPORTANT
This symbol indicates tips and information
about use of the refrigerator.

3
Please read the user manual carefully and
store in a handy place for later reference.
Pass the user manual on to possible new
owners of the refrigerator.
Read the following carefully to avoid dam-
age or injury.
This symbol indicates never to do
this
This symbol indicates always do
this
WARNING
• If pressurised aerosol containers bear
the word ‘flammable’ and/or a small
flame symbol, do not store them in-
side any refrigerator. If you do so you
may cause an explosion.
• When you dispose of refrigerators and
freezers, remove any doors. Children
can suffocate if they get trapped
inside.
• This refrigerator contains insulation
formed with flammable blowing gases.
Avoid safety hazards by carefully
disposing of this appliance.
• Don’t use a steam cleaner. If live
components come into contact with
condensing steam, they may short-
circuit or cause an electric shock.
WARNING
This appliance can be used by chil-
dren aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge if
they have been given supervision or
instruction concerning use of the ap-
pliance in a safe way and understand
the hazards involved. Children shall
not play with the appliance.
Cleaning and user maintenance shall
not be made by children with out
supervision.
WARNING
The appliance must be plugged into its
own dedicated 220-240V, 50Hz AC electri-
cal outlet.
Ensure that the electric outlet is properly
earthed to ground. Consult a qualified
electrician if you are unsure.
Do not use an extension cord or adapter
plug.
If the power cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
Unplug the appliance before cleaning and
before changing the light bulb to avoid
electric shock.
Never unplug the appliance by pulling on
the power cord. Always grip the plug firm-
ly, and pull straight out of the receptacle to
prevent damaging the power cord.
Choose a location that is not too cold - the
temperature should be above 10°C.
Do not store explosive substances such as
aerosol cans with a flammable propellant
in this appliance.
Put the appliance in a dry place, avoiding
areas of high moisture or humidity.
Don’t put the appliance in frosty or unpro-
tected areas, for example in a garage or
on a verandah.
Don’t put the appliance in direct sunlight.
Don’t put the appliance near stoves, fires
or heaters.
When transporting and installing the
refrigerator, care should be taken to ensure
that no parts of the refrigerating circuit are
damaged.
Do not damage the refrigerant circuit.
Keep ventilation openings in the appliance
enclosure or in the built-in structure clear
of obstruction.
When correctly installed, your appliance
should:
• have adequate clearance to the back and
sides for air circulation (refer to page 3).
• be aligned to the surrounding cupboards.
IMPORTANT SAFETY INSTRUCTIONS

4
WARNING
It is important to use you refrigera-
tor safely. This means you need to
supervise young children and inform
persons when they use it. You need
to make sure that young children do
not play with the refrigerator. Follow
the tips below:
Never let children play with the refrigera-
tor.
Never store fizzy drinks in the freezer
compartment.
Never try to repair the refrigerator yourself.
Never use electric heaters or dryers to de-
frost the freezer because you can receive
an electric shock.
Never use electrical appliances inside
the food storage compartments of the
refrigerator, unless they are of the type
recommended by the manufacturer.
Do not use mechanical devices or other
means to accelerate the defrosting process
other than those recommended by the
manufacturer.
WARNING
R600a refrigerant warning
This appliance contains flammable R600a
refrigerant.
Avoid safety hazards by carefully install-
ing, handling, servicing and disposing of
this appliance.
• Ensure that the tubing of the refrig-
erant circuit is not damaged during
transportation and installation.
• Leaking refrigerant may cause eye
injuries or ignite.
• The room for installing the appli-
ance must be at least 1m3 per 8g of
refrigerant. The amount of refrigerant
in the appliance can be found on the
rating plate inside the appliance.
• It is hazardous for anyone other than
an Authorised Service Person to ser-
vice this appliance.
IMPORTANT SAFETY INSTRUCTIONS

5
DESCRIPTION OF YOUR APPLIANCE
Four-door refrigerator
22 12 11 23 12 22
13
14
1
15
16
24
17
18
19
25
20
21
6
7
22
8
9
1
2
1
3
4
5
6
7
22
8
9
10
5
18
20
Partition
Lever
1Door bins (3 pcs)
2Adjustable glass shelf (2 pcs)
3Fixed glass shelf
4Bottle bin (left)
5Crisper
6Freezer drawer (small)
7Freezer drawer (large)
8Rollers (4 pcs)
9Adjustable feet (2 pcs)
10 Kickplate
11 Aluminium panel
12 Light
13 Dairy bin lid
14 Dairy bin
15 Egg tray
16 Egg pocket
17 Deli compartment
18 Bottle bin (right)
19 Crisper
20 Twist ice and serve (2 pcs)
21 Ice cube box
22 Magnetic door seals
23 Eco sign:
With the refrigerator door left open,
the lamp will slowly change its colour
from blue to orange. It shows that the
temperature in the refrigerator is rising
24 Deodorising unit
NOTE: Deodorising unit cannot remove
all of the odours thoroughly. Wrap the
food with strong odours.
25 Control panel

6
DESCRIPTION OF YOUR APPLIANCE
Control panel
Function
Select
1 7 8 9 2 3 5
6
410111213
1LCD display
2Freezer temperature setting
3Refrigerator temperature setting
4Function select button
5Setting selector
6Confirmation button
7Express freezing
8Timer
9Refrigerator temperature control
10 Freezer temperature control
11 Door alarm
12 Child lock
13 Holiday mode
Default setting
When power is turned on the display de-
faults to:
In the event of a power failure, the Timer
feature is cancelled and will need to be re-
entered if required.
NOTE: When no operation is made for 30
seconds, the display will automatically re-
turn to the initial content. The backlight will
become dark if there is no operation for 3
minutes. The backlight will turn off if there
is no operation for 6 minutes.
Defrosting
• The defrosting system is fully automatic
and energy efficient.
• The defrost water collects in the evapo-
rating pan, where it is evaporated by
the heat of the compressor.
• The evaporating pan does not require
cleaning or maintenance.

7
INSTALLATION
1. To ensure adequate ventilation for your
refrigerator, it is recommended to pro-
vide space of 60mm on both sides and
at the back, and space of 90mm above
the refrigerator. Insufficient spacing will
decrease cooling efficiency, increase
energy consumption and may reduce
the life of the unit (see page 3).
2. Using the two front adjustable feet,
ensure that the refrigerator is posi-
tioned firmly and level on the floor.
3. Using the adjustable feet, raise the
front of the unit so it leans back slightly,
this will assist in door closing. Make
final adjustments to ensure that the
doors are correctly aligned.
4. Remove the 4 screws from the bottom
of the refrigerator and use these to fit
the kickplate (supplied inside the
refrigerator compartment).
5. Connect the power plug to a 240 volt
10 amp power point.
NOTES:
• Position your refrigerator so that the plug is
accessible.
• Keep your refrigerator out of direct sunlight.
Adjustable feet
When the left
door is raised
When the right
door is raised
Lower the foot
at right side* Lower the foot at left side*
*Until the adjustable foot on the
other side is slightly off ground.
Screw
(4 screws) Screw
Kickplate
• Do not place next to a heat generating
appliance.
• This refrigerator is designed for indoor use
only – do not place the unit on an unsealed
surface.
• To avoid vibration and misalignment of the
doors, the unit must be level. Place the unit
on a solid flat surface.
• Uneven floors eg. slate, tiles and floor-
boards, can cause the unit to sag over time
causing the doors to become misaligned.
• If the mains power is switched on when
the door is open, the door alarm will sound.
Close the door to stop the alarm.
When transporting
Wipe up water in the evaporating pan.
Before wiping up the water, wait more than
1 hour after pulling out the plug because
refrigeration cycle equipment is extremely
hot. (The evaporating pan is located at the
rear of the product.)
Evaporation pan
• Using the rollers, it is possible to move
back and forth. Carry the refrigerator by
holding the holding devices located on
the rear and bottom.
Before using your refrigerator
• Clean the inside parts with a cloth
soaked in warm water. If soapy water is
used, wipe it off thoroughly.

8
DIMENSIONS
817.5mm
200mm
12mm
50mm
40mm
890mm
441.5mm
m
1720mm
876.5mm
727.5mm
890mm
13mm
90°
685mm
1120mm
817.5mm
Recommended clearances
These are the recommended minimum
clearances.
102mm
90mm
60mm
60mm 60mm
Recommended
airspace
CABINET
DOORS
NOTE: Doors are designed to sit proud of
cabinetry (not flush). The clearances shown
above are the recommended minimum
clearances. For optimum product operation,
it is recommended that the clearance at the
rear should not exceed 75mm.
When positioned in a corner area, spac-
ing of at least 325mm on the sides will
allow the doors to open enough to enable
removal of the crisper bins and shelves.
325mm
Front face of
bench aligned
to front edge
of cabinet
Technical data
Refer to data label on the rear of the appli-
ance for details.

9
USING THE APPLIANCE
The refrigerator controls its temperature
automatically.
However, if needed, adjust the temperature
as follows.
Refrigerator compartment
1. Press the “Function select” button and
select the Refrigerator temperature set-
ting icon.
2. Press the button to select the
desired temperature. ( to increase,
to decrease)
3. Press the button to confirm.
Adjustable between 0° and 6°C in steps of
0.5°
IMPORTANT
For normal operation, the fridge tempera-
ture should be set to 3°C. Adjust higher
or lower to suit your needs.
Freezer compartment
1. Press the “Function select” button and
select the Freezer temperature setting
icon.
2. Press the button to select the
desired temperature ( to increase,
to decrease).
3. Press the button to confirm.
Adjustable between -13° and -21°C in
steps of 0.5°.
IMPORTANT
For normal operation, the freezer tem-
perature should be set to -18°C. Adjust
higher or lower to suit your needs.
Timer
The timer can be set for up to 99 minutes
and 30 seconds, in intervals of 30 seconds.
1. Press the “Function select” button and
select the Timer icon. The previous
timer entry is displayed.
2. Press the button to select the
time. ( to increase, to decrease).
Hold the button down to set the timer
more quickly.
3. Press the button to confirm. The
timer will start. The countdown will
begin. When the set time is reached,

10
USING THE APPLIANCE
the end tone will sound (for about 30
seconds).
To stop the end tone, press
To cancel the timer
Press the “Function select” button and
select the Timer icon.
Press the button.
Door alarm
An alarm will sound momentarily if a door
is left open for approximately 1 minute (60
seconds). If a door is left open for 3 min-
utes, the alarm will sound continuously.
To cancel operation
1. Press the “Function select” button and
select the Door Alarm icon.
2. Press the button to select “OFF”.
3. Press the button to confirm.
To start operation
1. Press the “Function select” button and
select the Door Alarm icon.
2. Press the button to select “ON”.
3. Press the button to confirm.
Child lock
The child lock can be turned on to prevent
children tampering with the controls.
1. Press the “Function select” button and
select the Child Lock icon.
2. Press the button to select “ON”.
3. Press the button to confirm.
To cancel operation
1. Press the “Function select” button con-
tinuously for 2 seconds or more.
2. Press the button to select “OFF”.
3. Press the button to confirm.
Express freezing
High-quality frozen foods can be made
using this feature. Convenient for home-
freezing of small food items.
1. Press the “Function select” button and

11
USING THE APPLIANCE
select the Express freezing icon.
2. Press the button and select “ON”.
3. Press the button.
Express Freezing ends automatically in ap-
proximately 2 hours (the icon disappears).
To cancel operation: Select “OFF” in step 2.
NOTES:
• The time taken to freeze the item will de-
pend on the size, shape and type. For best
results, keep items as small as possible.
• Express Freezing may take a little longer if
the refrigerator is automatically defrosting.
• Avoid opening the door as much as pos-
sible during operation of this feature.
Holiday mode
Use this power saving feature when going
away for extended periods.
1. Press the “Function select” button and
select the Holiday mode icon.
2. Press the button and select “ON”.
3. Press the button.
The temperature inside the refrigerator
compartment will be adjusted to 10°C. The
temperature in the freezer is not changed.
To cancel operation
Select “OFF” in step 2.
Note: In Holiday Mode, the life of the food
in the refrigerator compartment may be
reduced to 1/2 or 1/3 of normal. Before
going away for extended periods of time,
we recommend removing all perishable
foods from the refrigerator, before setting
this feature.
Storing food
Refrigeration reduces the rate of food spoil-
age. To maximise the shelf life of perishable
food products, ensure that the food is of
the freshest possible quality. The following
is a general guide to help promote longer
food storage.
Fruit and vegetables
To minimise moisture loss, fruit and vegeta-
bles should be loosely enclosed in a plastic
material (e.g. wrap, bags) and placed in
the Vegetable crisper or the Chilled com-
partment. Those fruits and vegetables with
thick skins do not require wrapping.

12
USING THE APPLIANCE
Dairy products and eggs
• Most dairy products have a use by date
on the outer packaging which indicates
the recommended temperature and
expected life of the product.
• Eggs should be stored in the egg tray.
Meat, fish and poultry
• Place on a plate or dish and cover with
paper or plastic wrap.
• For larger cuts of meat, fish or poultry,
place to the rear of the shelves.
• Ensure all cooked food is wrapped se-
curely or placed in an airtight container.
NOTES:
• Evenly place the food on the shelves
to allow the cooling air to circulate ef-
ficiently.
• Hot foods should be cooled before
storing. Storing hot foods increases the
temperature in the unit and increases
the risk of food spoilage.
• Do not block the outlet and inlet of the
cool air circulating circuit with foods
or containers; otherwise the foods will
not be evenly cooled throughout the
refrigerator.
• Do not place food directly in front of
the cold air outlet. This may lead to the
food freezing.
For best freezing
• Food should be fresh.
• Freeze small quantities of food at a time
to freeze them quickly.
• Food should be properly stored in con-
tainers or freezer bags. Air should be
removed if possible and seal tightly.
• Evenly place the food in the freezer.
• Label bags or containers to keep an
inventory of frozen food.

13
CARE AND CLEANING
Care and cleaning
Some household cleaning chemicals can
cause cracks, splits or discolouration on the
inside surface of the refrigerator and door
liner. Only use diluted dishwashing liquid
and ensure that all plastic is wiped with
fresh water after cleaning.
Alkaline detergents may affect the alu-
minium parts of the door handle, causing it
to tarnish.
1. Remove the shelves and bins from the
cabinet and door. Wash them in warm
soapy water; rinse in clean water and
dry.
2. Clean the inside with a cloth soaked in
warm soapy water. Then use cold water
to wipe off the soapy water.
3. Wipe the exterior with a soft cloth each
time it is soiled.
4. Clean the magnetic door seal with a
toothbrush and warm soapy water.
5. Wipe the control panel with a dry cloth.
NOTES:
• Do not use hot water, household
cleaning powders, creams or spray-on
cleaning products or any other cleaning
products such as mineral turpentine,
methylated spirits, thinners, petrol etc.
These may damage your refrigerator
and may void any warranty.
• If undiluted detergent is used or soapy
water is not wiped off thoroughly,
cracking of plastic parts can result.
• Wipe any spills from the refrigerator
immediately, acid or alkaline in the
food can cause cracking and staining of
plastic parts.
• The glass shelves weigh approximately
3kg each. Hold firmly when removing
from cabinet or carrying.
• Wipe any spills from the control panel
immediately, liquid ingress can damage
the electronics.

14
TROUBLESHOOTING
CAUTION
Problem Solution
When your appliance is
not operating
Check that the power cord is plugged into the power outlet properly and
that the outlet is switched ‘ON’.
Try running another appliance from the power outlet. If no power is com-
ing from the outlet you may have blown a fuse or tripped a circuit of your
household power supply.
Try adjusting the temperature control to a slightly “colder” position.
It is normal for the freezer fan NOT to operate during the automatic de-
frost cycle, or for a short time after the refrigerator is switched on.
When there is refrigera-
tor noise
Modern refrigerators/freezers with increased storage capacity use high
speed compressors. These can provide a seemingly high level of sound
which is quite normal. Normal operational sounds include:
• Occasional gurgling, similar to water boiling.
• Air flow noise (air circulates because of a small fan).
• A popping noise heard during automatic defrost.
• A clicking noise heard just before the compressor starts (this is merely
the automatic switching action of the temperature control, turning the
compressor on or off).
Other strange sounds may mean that you need to check and take action.
For example, noises may mean that:
• The cabinet is not level.
• The floor is uneven or weak.
• Bottles are badly placed and rattling.
• There are vibrations from an object on top of or behind or beside the
refrigerator.
• The back of the refrigerator cabinet is touching the wall.
Remember it is quite normal for noise to
seem louder just after the refrigerator starts
operating.
If there are odours
inside the refrigerator
The interior may need cleaning.
Some foods produce odours.
Some containers and wrapping can cause odours.
Ask yourself if the odour started about the same time you started storing
something unusual.
If you think something may be wrong with
your refrigerator, you can carry out some
easy checks before calling for service. You
may locate the problem, sparing yourself
from inconvenience and saving time and
money.
CAUTION
The glass shelves weigh approxi-
mately 3kg each. Hold firmly when
removing from the cabinet or when
carrying.

15
If you still require service
If you have a problem, and the problem
persists after you have made the checks
mentioned above, contact your nearest
Electrolux approved Service Centre or the
dealer you bought the refrigerator from. Be
ready to quote the model number, which is
stated on the label inside the refrigerator
compartment.
When the compartment light is
blown
Contact the service agent approved by
Electrolux to request a replacement com-
partment light. The compartment light is
not to be removed other than by qualified
service personnel.
Switching off your refrigerator
If the refrigerator needs to be switched off
for an extended period, the following steps
should be taken to reduce the symptoms of
mould:
1. Remove all food.
2. Remove the power plug from the pow-
erpoint.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly for air circulation.
TROUBLESHOOTING
When the motor seems
to run more than
expected
Your new refrigerator provides you with large capacities in both the
refrigerator section and the separate freezer. It is normal for the motor to
operate frequently. However, to keep operation to a minimum, check the
following:
• Are doors kept open too long or too often?
• Are controls set too cold? See “Controlling temperature”.
• Have large amounts of warm food just recently been stored? Summer,
festive seasons and holidays usually mean a lot more work for your
refrigerator.
• If the day is hot or the room is very warm, the refrigerator will need to
run more than normal.
• The refrigerator will run more that normal just after you install it or
when it has been turned off for a long time.
If the temperature in
the refrigerator is too
warm
Check that the refrigerator has enough clearance at the sides, back and
top. Refer to the installation Instructions at the front of this booklet.
Refer to “Controlling temperature”.
You may have kept the door open too long or too frequently.
Food containers or packaging may be holding a door open.
If the temperature in
the refrigerator is too
cold
Refer to “Controlling temperature”.
Increase the temperature to avoid high energy consumption.
If heavy frosting occurs
in the freezer
Make sure you fully close the freezer and fridge doors. If the doors are
left partly open a heavy frost will coat the inside of the freezer. If a frost
develops, remove it. Take care to properly close the doors and the frost
will not reoccur.
If water droplets form
on the aluminium panel
This is normal as the panel is cooled from the rear, therefore indirectly
cooling the refrigerator compartment. It is normal for water droplets to
form on this panel under humid weather conditions.

16
000000000-RR-WWYYYY
REMOVING DOOR HANDLES
Removing door handles
If you need to remove the handles from
your door, please follow the instructions
below:
1. Simply tap handle from below being
sure not to scratch the handle.
2. Handle will unclip and can be pulled up
and out to remove.
