Whyte WPSU-SAP1 User manual

Smart Apartment PSU
INSTRUCTION MANUAL
WPSU-SAP1 | WPSU-SAP2
www.whytetechnologies.com
In the interest of connuous improvement,
all specicaons of products within this brochure are
subject to change without noce.

CONTENTS
Safety
Precauons
Guarantee
General Descripon
Product Descripon
Technical Descripon
Installaon Instrucons
Example Conguraon
Specicaons
3
3
3
4
5
6
6
8
11
2

SAFETY
The Whyte Smart Apartment Power Supplies are intended for indoor use only.
Do not install the Power Supply in damp, humid, hot, or dusty areas. Switch
o the source of AC power when making connecons to the Power Supply to
avoid damaging the unit.
PRECAUTIONS
To ensure trouble free operaon of your Whyte Smart Apartment PSU:
Do not remove the cover of the Power Supply or dissemble it, as this will
invalidate your guarantee. The female F-Type connectors on this unit were
designed for use with ‘100’ type coaxial cable with a centre core diameter
of 1mm2. When using larger diameter ‘125’ or ‘165’ coaxial cables, you must
ensure that suitable F connectors with reducing pins are used, otherwise
damage to the unit will occur which will invalidate the guarantee.
Do not over ghten the F connectors (nger ght only).
GUARANTEE
All Whyte products are guaranteed for a period of 4 years from the date of
purchase against defects. Within this period, Whyte Technologies will repair
or replace the faulty product. In the unlikely event, please return any faulty
products to your dealer.
The guarantee will be deemed void if the serial number on the product is
removed, damaged or illegible. The guarantee excludes defects caused by
incorrect use, accidental damage, disassembly, water/re/lightening damage
or lack of venlaon.
3

GENERAL DESCRIPTION
The WPSU-SAP1 and WPSU-SAP2 are the world’s rst Smart Apt PSU’s.
Customer support is reduced, and customer sasfacon is increased as the
IRS system will funcon correctly irrespecve of building occupancy or type
of Set-top box (if any) is used by the resident.
A Smart Apartment PSU should be ed in to every apartment irrespecve
of whether satellite services are required or not, to support terrestrial
receponal in all scerarios.
They are available in Single or Dual feed versions and are compable with
both legacy and dSCR Set-top boxes. When connected to a legacy STB,
voltage switching commands (13/18V) are relayed by the dynamic PSU.
In the absence of STB LNB voltage, the Smart Apartment PSU will provide
14V to maintain the IRS System funconality in circumstances when the
occupants require TERR services only.
The Smart Apartment PSU’s can be set back locally near the TV or ed
discretely in an electrical cupboard.
4

1. Transformer Housing
2. LED Power Indicator
3. STB TV Connector
4. Mulswitch Connector
5. AC In Power Cord
6. UK Mains Plug
7. Corner Brackets
PRODUCT DESCRIPTION
5
WPSU-SAP 2 model shown for illustrave purpose only
WPSU-SAP2
Smart Apartment PSU – Dual Channel
Multi-
Switch 2
STB
TV 2
Multi-
Switch 1
STB
TV 1
+DC +DC
34 4 3
7 1
7
2
7
2
7
6
5

TECHNICAL DESCRIPTION
The Whyte Smart Apartment PSU is an intelligent power supply that operates
in "follow me" mode when connected to any satellite Set-top box (Legacy
13/18V +22kHz, DiSEqC switching or dSCR modes are supported).
The perfect partner for the Whyte Smart Apartment PSU is the Whyte
WSCR504RP Remote Powered dSCR Mulswitch which is designed
specically for installaons where no landlords power is available.
Where the Set-top Box voltage is below 15.5V DC the Mulswitch supply
voltage will be 14V DC, if the Set-top Box voltage is more than 15.5V DC the
Mulswitch supply voltage will be 18V DC.
Where no Set-top voltage is present (0 Volts) the default Mulswitch supply
voltage is at 14V DC enabling its use as a 14V Masthead Power Supply that
can deliver up to 1.57A (22W).
INSTALLATION INSTRUCTIONS
Select a suitable locaon to install the Whyte Smart Apartment PSU. Do not
install the power supply in damp, humid, hot, or dusty areas. Using the screw
slots on the Corner Brackets, secure the power supply using the appropriate
xing screws and wall plugs to suit the relevant wall surface or cabinet.
All connecons should be made rst before applying AC power. F-Type
connectors should be rmly nger ghtened. The markers on the power
supply indicate how to connect the coax feeds. The feed from the Set-top
Box (STB) connects to the “STB TV” F-Type connector.
The feed to the Legacy/dSCR Mulswitch connects to the “Mulswitch”
F-Type connector. (# See diagram 1)
6

7
(Green)
LED Indicato
r
WPSU-SAP1
Multi-
Switch 1
STB
TV 1
WPSU-SAP1
Smart Apartment PSU – Single Channel
+DC
When AC is applied the LED(s) will be lit green indicang that the power
supply is acve.
POWER INDICATOR

8
REC 1
REC 3
Power
REC 2
REC 4
VL HL VH HHTERR
VL
V
HL
H
Sat A
VH
V
HH
H
Sat B
TERR Q
WB
TERR Gain
TERR
TM
WSCR504RP
4 Way dSCR Multiswitch
ON
DC 12V
OFF
WB
LNB
Q
0 dB
-10dB
-20dB
Frequency
Min/Max Input
Output (AGC)
Gain (AGC)
Trunk Loss Max
290 ~ 2340MHz
64 ~ 104dBμV
89dBμV
-5dB ~ +25dB
- 5dB
Consumption Min / Max @ 18V
Compatibility
LED Status
SAT dSCR / Legacy
Frequency
Min/Max Input
Max Output
Gain
Trunk Loss Max
87 ~ 790MHz
52 ~ 102dBμV
101dBμV
8dB ±2dB
- 5dB
0.1A / 0.28A
Sky UK- EN50607 - EN50494
Terrestrial
SCR Mode
Legacy Mode
Flashing Green
Solid Green
WSCR504RP
Remote Powered dSCR Mulswitch
STB
TV 1
WPSU-SAP1
Smart Apartment PSU – Single Channel
Multi-
Switch 1
+DC
WPSU-SAP1
SKY Q / Legacy STB
TERR TV
Apartment
Riser
RADIO
DC Block Terminators
Diagram 1
EXAMPLE CONFIGURATION
Typical Applicaon

Multi-
Switch2
STB
TV2
Multi-
Switch1
STB
TV1
WPSU-SAP2
SmartApartment PSU – Dual Channel
Multi-
Switch1
STB
TV1
WPSU-SAP1
SmartApartment PSU – Single Channel
REC1
REC3
Power
REC2
REC4
VL HL VH HHTERR
VL
V
HL
H
SatA
VH
V
HH
H
Sat B
TERR Q
WB
TERRGain
TERR
TM
WSCR504RP
4Way dSCR Multiswitch
ON
DC12V
OFF
WB
LNB
Q
0dB
-10dB
-20dB
Frequency
Min/MaxInput
Output(AGC)
Gain(AGC)
TrunkLoss Max
290 ~ 2340MHz
64~ 104dBμV
89dBμV
-5dB~ +25dB
-5dB
ConsumptionMin / Max @ 18V
Compatibility
LEDStatus
SATdSCR / Legacy
Frequency
Min/MaxInput
MaxOutput
Gain
TrunkLoss Max
87~ 790MHz
52~ 102dBμV
101dBμV
8dB±2dB
-5dB
0.1A/ 0.28A
SkyUK- EN50607 - EN50494
Terrestrial
SCRMode
LegacyMode
FlashingGreen
SolidGreen
REC1
REC3
Power
REC2
REC4
VL HL VH HHTERR
VL
V
HL
H
SatA
VH
V
HH
H
Sat B
TERR Q
WB
TERRGain
TERR
TM
WSCR504RP
4Way dSCR Multiswitch
ON
DC12V
OFF
WB
LNB
Q
0dB
-10dB
-20dB
Frequency
Min/MaxInput
Output(AGC)
Gain(AGC)
TrunkLoss Max
290 ~ 2340MHz
64~ 104dBμV
89dBμV
-5dB~ +25dB
-5dB
ConsumptionMin / Max @ 18V
Compatibility
LEDStatus
SATdSCR / Legacy
Frequency
Min/MaxInput
MaxOutput
Gain
TrunkLoss Max
87~ 790MHz
52~ 102dBμV
101dBμV
8dB±2dB
-5dB
0.1A/ 0.28A
SkyUK- EN50607 - EN50494
Terrestrial
SCRMode
LegacyMode
FlashingGreen
SolidGreen
RISER
APARTMENT 1
APARTMENT 2 SKY Q
SKY + HD
SKY HD
FREE SAT
TERR TV
WSCR504RP
WSCR504RP
WM508
WPSU-SAP2
WPSU-SAP1
+DC +DC
+DC
SKY+ HD
(SCR MODE)
SKY Q
FREE SAT
RADIO
TERR TV
9
EXAMPLE CONFIGURATION
Hybrid IRS - Powered from the Apartment

10
EXAMPLE CONFIGURATION
Dual SAT IRS System - Powered from the Apartment
Multi
Sw1
STB
TV1
WPSU-SAP1
SmartApartment PSU – Single Channel
Multi
Sw2
STB
TV2
Multi
Sw1
STB
TV1
WPSU-SAP2
SmartApartment PSU – Dual Channel
REC1
REC3
Power
REC2
REC4
VL HL VH HHTERR
VL
V
HL
H
SatA
VH
V
HH
H
SatB
TERR Q
WB
TERRGain
TERR
TM
WSCR504RP
4Way dSCR Multiswitch
ON
DC12V
OFF
WB
LNB
Q
0dB
-10dB
-20dB
Frequency
Min/MaxInput
Output(AGC)
Gain(AGC)
TrunkLoss Max
290 ~ 2340MHz
64~ 104dBμV
89dBμV
-5dB~ +25dB
-5dB
ConsumptionMin / Max @ 18V
Compatibility
LEDStatus
SATdSCR / Legacy
Frequency
Min/MaxInput
MaxOutput
Gain
TrunkLoss Max
87~ 790MHz
52~ 102dBμV
101dBμV
8dB±2dB
-5dB
0.1A/ 0.28A
SkyUK- EN50607 - EN50494
Terrestrial
SCRMode
LegacyMode
FlashingGreen
SolidGreen
REC1
REC3
Power
REC2
REC4
VL HL VH HHTERR
VL
V
HL
H
SatA
VH
V
HH
H
SatB
TERR Q
WB
TERRGain
TERR
TM
WSCR504RP
4Way dSCR Multiswitch
ON
DC12V
OFF
WB
LNB
Q
0dB
-10dB
-20dB
Frequency
Min/MaxInput
Output(AGC)
Gain(AGC)
TrunkLoss Max
290 ~ 2340MHz
64~ 104dBμV
89dBμV
-5dB~ +25dB
-5dB
ConsumptionMin / Max @ 18V
Compatibility
LEDStatus
SATdSCR / Legacy
Frequency
Min/MaxInput
MaxOutput
Gain
TrunkLoss Max
87~ 790MHz
52~ 102dBμV
101dBμV
8dB±2dB
-5dB
0.1A/ 0.28A
SkyUK- EN50607 - EN50494
Terrestrial
SCRMode
LegacyMode
FlashingGreen
SolidGreen
RISER
APARTMENT 1
APARTMENT 2
TERR TV
WB
LNB
WB
LNB
SAT BSAT A
WSCR504RP
WSCR504RP
WPSU-SAP2
WPSU-SAP1
TERR TV
RADIO
DC Block
Terminators
SKY Q
SKY + HD
SKY HD
FREE SAT
SKY+ HD
(SCR MODE)
SKY Q
FREE SAT

11
SPECIFICATIONS:
WPSU-SAP1 | WPSU-SAP2
The EU Declaraon of Conformity can be viewed at www.whytetechnologies.com.
In the interest of connuous improvement, all specicaons of products are subject to change without noce.
4 Years Warranty
Comes in 1 Feed or 2 Feed versions
The World’s First Smart Apartment PSU
Compable with all Legacy and dSCR STB’s
Provides 22W Power @ 14/18V Per Channel
Can be installed as a set back Apartment PSU or in the Electrical Cupboard
MODEL WPSU-SAP1 WPSU-SAP2
Channels
AC Input Voltage
DC Input Voltage (STB Generated)
Output Voltage
Output Waage
Current Overload Protecon
Use as Masthead PSU
RF Frequency Pass
22kHz Control Tone Pass
RF Through Loss
RF Interfaces
Mains Lead (UK Mains Plug with 3A Fuse)
Dimensions L x W x H (mm)
Weight
Single Channel (Single feed)
100 - 240V AC 50/60Hz
13/18V DC
14/18V DC (Determined by STB Input)
22W
Yes (30W ±10%)
Compable
87 - 2340MHz
Legacy, DiSEqC, SKY UK, EN50607 & EN50494
<1dB
F-Type (Female 75Ω)
Figure of 8 C13 Cord 1m
116 x 120 x 43
234g
Dual Channel (Dual feed)
100 - 240V AC 50/60Hz
14V DC
18V DC Output
2 x 22W
Yes (30W ±10%)
Compable
87 - 2340MHz
Legacy, DiSEqC, SKY UK, EN50607 & EN50494
<1dB
F-Type (Female 75Ω)
Figure of 8 C13 Cord 1m
116 x 120 x 43
276g

Unit 1, Watermill Business Centre. Edison Road, Eneld. EN3 7XF
Tel: 0330 999 1980 | [email protected] | www.whytetechnologies.com
Copyright © Whyte Technologies. November 2022 - v1
This manual suits for next models
1
Table of contents
Popular Power Supply manuals by other brands

StarTech.com
StarTech.com ATX2POW450HS instruction manual

Hydromatic
Hydromatic A+ Installation and service manual

Horizont
Horizont ranger AN480 instruction manual

Furrion
Furrion Trekker 500 Installation and owner's manual

voss.pet
voss.pet Fenci M03 operating instructions

GW Instek
GW Instek PSW 30-36 user manual

Altronix
Altronix ALTV244 Installation guides

Wheelock
Wheelock POWERPATH series PS-12-24-8CP specification

TDK-Lambda
TDK-Lambda Genesys GENH Series user manual

Good Will Instrument
Good Will Instrument GPS-S Series user manual

Anton/Bauer
Anton/Bauer TITAN T2 owner's manual

Mountz
Mountz STC 30 Plus Operation instructions
