Wi-MM BP100-2-2-1 User manual

Wi‐MMBP100UsersManual(Page1)
TheWi‐MMBP100isacloudbasedactivitymonitorforbicyclists.Yougetonthebike,BP100knows
you’rethere,gathersyourdata,anduploadsittothecloudinrealtime.Youfocusonenjoyingyour
rideandthecyclingexperience,knowingallofthedataisthereforyou,allthetime.Nomorepost‐ride
downloadsoraddingandremovinghardwarefromyourbike.Theanti‐theftelementoftheBP100
systemhasthepotentialtoentirelychangethemindsetofhowoftenyouuseyourbikeorevenwhat
kindofbikeispurchased.

MounttheBP100tothebicycleatthewaterbottlesiteusingtheM5tamperresistantscrews
provided.

RegistertheBP100atwww.wi‐mm.comandinstallthemobilephoneapp.Themobileappisthe
primaryinterfaceforsettingandcontrollingtheBP100system.

TheBP100shouldbechargedbeforeuse.Chargingisthroughthemicro‐USBport.TheBP100canbe
connectedtoawallcharger,computer,orotherUSBstandardportwith+5Vpowerforcharging.The
secondlightfromthebottom(orange)willbesolidorangewhenthechargerispluggedin.Thelight
willturnoffwhentheunitisfullycharged.Ifthebatteryisfullydepleted,chargingtimecanbeupto4
hours.
















Manufacturer: Wi-MM Corp.
Model: BP100-2-2-1
FCC ID: 2ABUE-BP100-2-2-1
IC: 11915A-BP100221 Model BP100-2-2-1



Wi‐MMBP100UsersManual(Page2)
GPS(Yellow).
Blinkswhentheunitisawakeand
GPSisactive.
Lock(Red)
Whenthealarmisset(on)thislight
willblink
Battery(Orange)
Solidwhentheunitischarging
(connectedtoUSB)
OffwhenthebatterylevelisOK
Blinkingwhenthebatterylevelislow
Logging&Mapping(Green)
BlinkswhentheBP100isloggingand
mappingaride.
USBCharging
Port
SoftReset
Button
Manufacturer: Wi-MM Corp.
Model: BP100-2-2-1
FCC ID: 2ABUE-BP100-2-2-1
IC: 11915A-BP100221 Model BP100-2-2-1



Wi‐MMBP100UsersManual(Page3)

Operationisautomaticorsetusingthemobileapp.Theunitmustbe“awake”(i.e.yellowlight
flashing)toimmediatelyprocessnewcommands.Alternately,commandssuchassetalarm,orstart
loggingcanbeenteredwhentheunitis“asleep”,andthecommandwillbeprocessedthenexttime
theBP100wakesup.

LogintotheWi‐MMapponthemobilephonewiththeemailaddressandpasswordusedfor
registering.

Appfunctionforicons(lefttoright)are:

ID
ThisbuttonwillleadtothedisplayshowinginformationabouttheBP100andregistereduser.

Locate
Pressingthisbuttonwillshowthebikelocationonetimeonamap.

Log&Map
Pressingthisbuttonactivatescontinuousloggingandmapping.Thesystemmapstherideand
recordsspeed,elevation,batterycharge,andothercustombikesensordata.Thisinformationis
availablelocallyonthemobilephoneorremotelyinrealtimeastherideisunderway.After
completingtheride,loggingandmappingisstoppedbypressingthesameicon.Thedisplaywillzoom
outandmapmarkerswillindicatestart(green)andstop(red)points.Abluelinewillshowthepath
travelled.Ridedata,includinghistoryisavailableonthemobilephoneorthroughthewebinterface
accessedbyloggingintotheuseraccountatwww.wi‐mm.com.Additionalinformationsuchas
caloriesburnedandcarbonoffsetsareincludinginthewebinterface.Datacanalsobeuploadedto
thirdpartyappssuchasStrava.

Alarm:
Thealarmissetbypressingthelockicononthemobileapp.Thelockiconwillcloseandturnred.If
thebikeismoved,anaudiblealarmwillsoundandtheuserwillreceiveatextmessageandemail
indicatingsuspiciousactivity.Otherscanbeautomaticallyinformedofastolenbikebyoptinginto
severaloptionsavailableattheWi‐MMwebsiteregistrationportal.Thealarmfunctionisturnedoff
bypressingthesameicononce.Afterafewsecondsthelockwillopenandtheiconwillturnfromred
tooff(gray).


Manufacturer: Wi-MM Corp.
Model: BP100-2-2-1
FCC ID: 2ABUE-BP100-2-2-1
IC: 11915A-BP100221 Model BP100-2-2-1



Wi‐MMBP100UsersManual(Page4)

SoundAlarm:
Pressingtherightmostbuttonwiththespeakericonwillmanuallysoundthealarmonetimeand
displaythebikelocationonthemap.

Forbatterysavings,theBP100willshutdown(deepsleepmode)allnon‐essentialfunctionsifitisnot
movedforabout5minutes(default).TheBP100automaticallywakesupbysensingmotion.Thebike
mountedBP100isreadyforuseoncetheyellowGPSlightisflashingcontinuously.

Thealarmfunctionisstillactive,evenwhentheBP100isindeepsleep.Theusercanparkthebike,
setthealarm,andhavethesecurityofknowingthatthesystemwillautomaticallywakeupon
movement,soundthealarm,andprovidetextandemailnotificationsoftampering,weeksoreven
monthslater.

TheBP100canberesettofactoryinstalledfirmwarebyholdingtheresetbuttonforaboutfive
secondsandthenreleasing.Afteratwotonesound,alllightswillflashandthesystemwillrestart.

Therestartprocessmaytakeup30‐60secondsasthesystemconnectstothecellularnetworkand
acquirestheGPSsignal.TherestartprocessiscompletewhentheunitbeepsonceandtheGPSlight
(Yellow)beginstoflashcontinuously.
Manufacturer: Wi-MM Corp.
Model: BP100-2-2-1
FCC ID: 2ABUE-BP100-2-2-1
IC: 11915A-BP100221 Model BP100-2-2-1


Wi‐MMBP100UsersManual(Page5)
REGULATORY NOTICE
This equipment is designed and manufactured not to exceed the emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission of the U.S. Government and Industry Canada.
The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR
limit relevant for the application described in this manual is 1.6W/kg.
Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting
at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the equipment while operating can be well below the maximum
value. This is because the device is designed to operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the
power output.
Equipment Authorization has been granted to this model with the reported SAR level(s) evaluated as in
compliance with the FCC RF exposure guidelines. SAR information on this equipment is on file with the FCC and
can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on the FCC ID as
printed on the equipment.
This equipment has been tested to comply with FCC and IC radiation exposure limits set forth for an uncontrolled
environment when used for the documented intended purpose and when mounted and operated as shown in this
user manual. The equipment has been tested for a minimum distance of 30mm between the device and the
human body.
