WIATEC MicroGuard-USB User manual

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
General
ALL RIGHTS RESERVED.
NOPART OF THIS MANUAL MAY BE REPRODUCED, TRANSCRIBED, STORED IN A
RETRIEVAL SYSTEM, TRANSLATED INTO ANY LANGUAGE OR COMPUTER LANGUAGE OR
TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC, MECHANICAL,
PHOTOCOPYING, RECORDING OR OTHERWISE, WITHOUT THE PRIOR WRITTEN
PERMISSION OF THE COPYRIGHT OWNER.
THE COPYRIGHT OWNER GIVES NO WARRANTIES AND MAKES NO REPRESENTATIONS
ABOUT THE CONTENTS OF THIS MANUAL AND SPECIFICALLY DISCLAIMS ANY IMPLIED
WARRANTIES OR MERCHANTABILITY OR FITNESS FOR ANY PURPOSE.
THE COPYRIGHT OWNER RESERVES THE RIGHT TO REVISE THIS MANUAL AND TO MAKE
CHANGES FROM TIME TO TIME IN ITS CONTENTS WITHOUT NOTIFYING ANY PERSON OF
SUCH REVISIONS OR CHANGES.
Copyright: © WIATEC GMBH
Pictures: istockphoto.com, wiatec gmbh
14. January 2017
E-Mail: [e-mail]
Seite 2 Notification & Control by mobile phone

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
1. Introduction
The purpose of this manual is to provide general instructions for installation
of our MicroGuard-USB devices into cars equipped with parking heaters
and to explain parameter settings necessary for operation with different
heater manufacturers and models. Dedicated manuals for different heaters
are available in German language on our website:
http://microguard.de/downloads/anleitungen-microguard-usb
Please use those manuals for the individual connection of our device to a
particular heater model.
2. Scope of delivery
In the delivery you will find the following content:
•MicroGuard-USB (control device),
- special version with power conversion module +12V or
- a special version with modification for your specific connection
•Connectors with 15cm cable (will need individual extension)
•Option: external temperature sensor(s), if ordered
•Option: y-cable for several temperature sensors (if ordered)
For GSM remotes we offer only external temperature sensors.
3. General switching function
MicroGuard-USB is equipped with two output and two input lines which can
be used for heater switching and switch control (or alarm lines).
•Older heaters can be controlled using +12V signals (orange
output) or ground output (brown).
•Newer heaters use Bus signals (W-Bus, LIN, CAN). We offer a
special modul equipped with W-BUS signals. In other cases we
adopt the connection of our module to an existing control device
(like timer or wireless receiver).
http://www.microguard.de V1.0 Seite 3

Anleitung: MicroGuard – Der kleine Mobilfunkwächter
With MicroGuard-USB a temperature sensor can be used to feedback on
temperature inside the car.
4. External temperature sensor characteristics
Device: Dallas Semiconductor DS18B22:
•temperature range: -55°C bis +125°C
•Accuracy: +/- 0.5°C for -10°C < T < +85°C, +/- 2°C otherwise
•External sensors are water proof in a metal eclosure:
http://microguard.de/file_download/54/AnleitungTemperaturwaec
hter.pdf
5. Aufbau und Schnittstellen
Fig. 1 is showing MicroGuard-USB:
•Micro-USB: power supply connector, used only for some types of
GSM control configurations, mainly with remote senders
•Mini-USB: port for external T-sensors
•Ein-/Ausgänge: input and output lines, +12V power supply
•USB-Port: connection to Surfsticks (PORT1)
•LED: function indicator
Seite 4 Überwachung | Benachrichtigung | Steuerung per Handy

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
6. Connection to heaters controlled by +12V or ground
Use always a 5A fuse for power supply connections.
Never connect directly to car battery.
Wrong power connection will destroy the device!
http://www.microguard.de V1.0 Seite 5
Fig. 1: MicroGuard-USB Module
Ein-/Ausgänge
USB-Port
Signal-LED
Micro-USB Mini-USB
Signal-LED
35mm
60mm
22mm24mm
P RT1
P RT2

Anleitung: MicroGuard – Der kleine Mobilfunkwächter
Fig. 2 shows a general scheme for potential connection of MicroGuard-USB
to external devices. You can use the orange line to control heaters by +12V
signals. You can use brown line to control heaters using ground signals or
convert ground to voltage-independent switch driving a relay.
Fig. 3 Shows usually used outputs and power supply lines used for GSM
controls for heaters. +12V battery voltage is vonnected to red line, ground
to black. Switched signal on orange (+12V) and brown (ground) are
available.
For individual connection schemes to divers heater models, please refer to
the schematics described in the dedicated German installation instruction.
If there are questions about the connection schemes, please contact our
support per mail: [email protected]
Seite 6 Überwachung | Benachrichtigung | Steuerung per Handy
Figure 2: General connection scheme for MicroGuard-USB
Ein-/Ausgänge
rot
orange
braun
grün
gelb
schwarz
Masse
Alarm Alarm
+12V
geschaltete Masse
+12V
geschaltete +12V
geschaltete Masse

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
7. General Initializing Procedure
MicroGuard-USB uses entries in the phone book of the SIM card to store
system parameters during initialization and later during operation. The
general init procedure is identical for all the modules, independently of the
connection type. Some parameters have to be adopted to the individual
heater / control device after initialization. Please refer to the chapters in the
German manuals for details.
Please go through these steps to initilize the system:
1. Validate that you can call out and send SMS using the SIM card.
Give yourself a call and send SMS to your phone number using
another mobile phone.
2. In the security options delete the need to enter a PIN when
starting the mobile phone. Validate this setting by switching the
mobile off an on again.
3. Delete all call forwarding using the GSM code ##002# with your
mobile.
4. Connect MicroGuard-USB with power supply. LED starts to flash
1x a second.
http://www.microguard.de V1.0 Seite 7
Figure 3: Available signals for heater control
Ein-/Ausgänge
rot
orange
braun
schwarz Masse
geschaltete Masse
+12V
geschaltete +12V

Anleitung: MicroGuard – Der kleine Mobilfunkwächter
5. Insert SIM into the USB UMTS-Stick and connect the stick to
MicroGuard-USB (PORT1!). After 20-30 seconds LED signal
changes and shows 2x fast flashing every second.
6. Make a call to the SIM in the stick using your mobile phone. This
mobile will be registered in the system as master control number.
The call will be terminated after 1-2 “rings”.
7. After call termination LED flashing changes to 3x long on, some
seconds off, 4x long on. In this time the parameters are being
written into the phone book of the SIM.
8. After approx. one minute, LED starts to flash 3x very quickly. If
you ordered a temperature sensor, plug in the sensor into the
Mini-USB port during this flashing procedure. Temperature
sensors have a unique ID which has to be registered in the
system during init procedure.
9. Sensor registration takes approx. 30 second. After that a call is
executed to the master control number (your mobile). Also,
confirmation SMS “System Init OK” is sent to the master number.
General Initialization completed.
Now it is time to adjust some system parameters to your heater or control
device connection. Below we describe parameter settings only for +12V
and GND controlled heaters. Other special settings might be required for
other connection types, please refer to German manuals or contact our
support: [email protected]
10.1 Parameters for heaters controlled by +12V
The duration of the +12V signal on the orange output (heating time) is
controlled by the parameter ORPULS. To be able to switch the orange line
by a simple call, please send an SMS with the content
SW=19 ORPULS=xxxx
from the master control number to MicroGuard-USB. Note that xxxx
determines the heater time in minutes (first two numbers), e.g:
Seite 8 Überwachung | Benachrichtigung | Steuerung per Handy

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
•Heating time of 30 minutes:
SMS command „SW=19 ORPULS=3000“
•Heating time of 15 minutes:
SMS command „SW=19 ORPULS=1500“
Test the switching function. You can check the parameters using SMS
command MGCONFIG.
10.2 Parameters for heaters controlled by Ground signal
The duration of the GND signal on the brown output (heating time) is
controlled by the parameter BRPULS. To be able to switch the brown line
by a simple call, please send an SMS with the content
SW=09 BRPULS=xxxx
from the master control number to MicroGuard-USB. Note that xxxx
determines the heater time in minutes (first two numbers), e.g:
•Heating time of 30 minutes:
SMS command „SW=09 BRPULS=3000“
•Heating time of 15 minutes:
SMS command „SW=09 BRPULS=1500“
Test the switching function. You can check the parameters using SMS
command MGCONFIG.
Note: To switch on both lines at the same time use SMS command
SW=29
http://www.microguard.de V1.0 Seite 9

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
8. External Switch Button
* ab Software-Version 1.43
MicroGuard-USB allows to cinfigure an exterlan button which can
switch the heater on and off when installed in the car. ig. 4
Shows a push button with integrated ON-indicator driven by the
signal on the orange output line. Note that the LED has to come
with a series resistor to be able to withstand +12V at the orange
line. Any other button without LED indicator can also be used
instead.
To be able to use the button function, some parameters must be
modified vs. factory settings, see Table below:
Seite 10 Notification & Control by mobile phone
Figure 4: Connection of an external ON/OFF push button
zum Taster
Ein-/Ausgänge
rot
orange
gelb
schwarz
Masse
+12V
Taster
+12V Ausgang

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
Phone Book
Enry
Factory
etting
M
Command
Function
MG SWITCH '09' SW=09
SW=19 Switching of brown line (GND) for LED indicator Switching of orange line (+12V) for LED indicator
SW=79 +12V signal for LED for WBUS modules
MG YON '1' YON=2 Push button function for yellow line IN
MG YACT '0' YACT=0 Active-low level for yellow line IN
Table 1: Parameter modifications for push button with icroGuard-USB
Examples:
•Push button wit +12V LED indicator, W-BUS module:
SW=79 YON=2 YACT=0
•Push button with +12V LED indicator, STD module:
SW=19 YON=2 YACT=0 (+12V orange line being switched)
SW=29 YON=2 YACT=0 (both lines being switched)
•Push button with GND LED indicator, STD module:
SW=09 YON=2 YACT=0 (GND brown line being switched)
SW=29 YON=2 YACT=0 (both lines being switched)
Please note: if both lines are being switched settings for heating time
should be equal for both liner (ORPULS and BRPULS). Otherwise there will
be a discrepancy between the real heating and button indication.
http://www.microguard.de V1.0 Seite 11

Anleitung: MicroGuard – Der kleine Mobilfunkwächter
9. Active Feedback of Switching*
* Software-Version 1.43 (2015) and later
MicroGuard-USB indicates the switching event by termination of the
incoming call. The number of “ring” signals is an indicator for the switchong
operation:
•Switching ON: 2 rings
•Switching O : 1 ring
MicroGuard-USB allows an active feedback about the switching operation
using available alarm lines. The feedback type can be set to call or/and SMS.
Table 2 summarizes the required parameters for the feedback function.
Phone Book
Enry
Factory
etting
M
Command
Function
MG AlarmOn1) '0' ARM Activation of the feedback function
MG SWITCH '0' SW=192)
SW=792) Use of +12V for switching (STD) Use of +12V for WBUS modules
MG AlCall '1' ALCALL=17 Feedback type set to call
MG AlSMS '0' ALSMS=17 Feedback type set to SMS
MG GACTHI '1' GACT=0
GACT=1
GACT=2
Feedback after switch-off
Feedback after switch-on
Feedback after switch-off and -on
Table 2: Configuration for active feedback
1) The feedback uses the alarm function of the module
2) +12V output line being used as signal for feedback and LED indicator
Example for SMS command setting SMS as feedback at on and off for a WBUS module
ARM SW=79 ALSMS=17 GACT=2
Seite 12 Überwachung | Benachrichtigung | Steuerung per Handy

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
http://www.microguard.de V1.0 Seite 13
Figure 5: Configuration of input and output lines for active feedback and a push button
zum Taster
Ein-/Ausgänge
rot
orange
grün
gelb
schwarz
Masse
+12V
Taster
+12V Ausgang

Anleitung: MicroGuard – Der kleine Mobilfunkwächter
11 GP Features
MicroGuard USB PORT2 is dedicated to additional accessories and
functions. One of those functions is GPS service, vehicle localization &
GPS-based alarm.
Fig. 6 shows a GPS receiver connected to PORT2. With this receiver,
following additional functionality is enabled:
1. Vehicle localization
2. 24h Timer
3. GPS fencing
4. GPS Home
Note that currently only limited GPS-receiver models are compatible with
MicroGuard-USB. You can find those compatible receivers in our shop:
http://www.wiatec.de/shop/index.php?cPath=35
No special init procedure is required for compatible GPS receivers.
Seite 14 Überwachung | Benachrichtigung | Steuerung per Handy
Figure 6: Anschluss von USB-Stick und GPS-Maus an MicroGuard-
USB
USB Surfstick*
GPS
Maus
Ein-/Ausgänge
GPS
Maus

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
11.1 Vehicle localization
The GPS receiver at PORT2 delivers current location of the vehicle every
10 seconds. This position can be requested any time using SMS
POSITION
MicroGuard-USB replies with the current location, e.g.:
https://www.google.de/maps/place/51.0754950,13.7478625
11.2 24h Timer
Beyond vehicle localization a GPS receiver delivers also a very accurate
satellite timer which can be used for timer functions. We have implemented
a 24h timer which allows to define the switching time of the heater to be set
in advance within 24h. You can send one SMS to the heater in the evening
to define when the heater will be switched on next morning (1 time only).
The SMS command is compatible with Eberspächer App EasyStart GSM
STARTxxyy
where xx is start time in hours and yy start time in minutes.
Example:
START0745
will start the heater next morning at 7:45 am.
11.3 Geo-Fencing
This feature generates a notification based on the last saved
position and the fact that the vehicle leaves the region of 300m
around this location. The notification can be defined to be a phone
call or text message with a text which can be individually set by
the user. This feature is being frequently used as theft alerts for
vehicles.
A summary of SMS commands for Geo- encing is given in Table
below.
http://www.microguard.de V1.0 Seite 15

Anleitung: MicroGuard – Der kleine Mobilfunkwächter
M Command Function
SETGEO Sets the current position as reference for GEO-fencing
GEONR=<Nr.> Changes the phone number to be alerted by GEOFENCE
(default is master control number)
GEOSMS Sets alert type to text message and turns on GEO-fencing
GEOCALL Sets alert type to phone call (default) and turns on fencing
GEOOFF Switches off GEO-fencing without changing the position
SETGEOSMS=<Text> Sets <Text> as content of the text message for GEO-fencing,
At the same time alert type is set to text message.
11.4 GP -Home
GPS-Home is the inverse function to GEO- encing. When the
vehicle enters a region 300m around a predefined location, an
alert is being generated. Also here the notification can be defined
to be a phone call or text message with a text which can be
individually set by the user.
A summary of SMS commands for Geo- encing is given in Table
below.
M Command Function
SETHOME Sets the current position as reference for GPS-Home
HOMENR=<Nr.> Changes the phone number to be alerted by GPS-Home
(default is master control number)
HOMESMS Sets alert type to text message and turns on GPS-Home
HOMECALL Sets alert type to phone call (default) and turns on GPS-Home
HOMEOFF Switches off GPS-Home without changing the position
SETHOMESMS=<Text> Sets <Text> as content of the text message for GPS-Home,
At the same time alert type is set to text message.
Seite 16 Überwachung | Benachrichtigung | Steuerung per Handy

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
12 Additional remarks
12.1 witching modes
•Using one of the connection schemes shown above heaters can
be switched on and off.
•Heating time is determined by the setting in MicroGuard-USB
(parameters ORPULS and BRPULS). A subsequent call/SMS
switched the heater on again.
•Another control device may be used without restrictions.
However, control devices will influence themselves. It is
recommended to use the same device fro switch off as for switch
on.
12.2 Using of mobile phones instead of U B ticks
Theoretically, a usage of compatible mobile phones instead of sticks is
possible. Due to the weakness of charging for STD mobile batteries,
reliable functions with mobile phone connected to MicroGuard-USB cannot
be guarneed at lower temperatures (below 5°C).
Please use USB Surf Sticks ONLY!
http://www.microguard.de V1.0 Seite 17

Anleitung: MicroGuard – Der kleine Mobilfunkwächter
13 Technical
Weight 30 g
Size L 60 x B 35 x H 24 mm
Supply voltage 7-15 V
Current
consumption 40mA (average)
Operating
Temperatures -20°C to 85°C
14 Certification
MicroGuard-USB fulfills following directives:
●89/336/EWG (EMV)
●73/23/EWG, extended by 93/68/EWG
●2002/95/EG (RoHS)
10. WEEE Directive 2002/96/EG
on waste electrical and electronic equipment
Disposing of this product correctly will help save valuable resources and
prevent any potential negative effects on human health and the
environment, which could otherwise arise from inappropriate waste
handling.
Please contact your local authority for further details of your nearest
designated collection point.
Seite 18 Überwachung | Benachrichtigung | Steuerung per Handy

MicroGuard-USB Instructions: GSM Remote for Parking Heaters
http://www.microguard.de V1.0 Seite 19
