Reset to factory settings
The device can be reset to the original factory settings by means of one of the following methods:
Method 1: Remove the device from the Z-Wave network;
Method 2: Six consecutive clicks on (B) button or on the external switch within 1 minute from system start-up;
Method 3: Set the parameter 61 to 0 –FACTORY RESET (see Configuration Parameters).
INFO: Please use methods 2 and 3 only in the event that the primary controller is missing or otherwise
inoperable.
INFO: If the device is reset when included in a network, the latter will notify its removal (Device Reset
Locally Notification).Conversely, if WiDom Energy Driven Switch receives a notification of removal of
another device from the network, this device will be removed from its associations.
Including the device into an existing Z-Wave network
WiDom Energy Driven Switch can be included into any Z-Wave network and operate with Z-Wave devices
from any other manufacturer. WiDom Energy Driven Switch, used as a constantly powered node, will act as
a signal repeater to increase the network reliability.
The device supports both the Network Wide Inclusion (which offers the opportunity of inclusion into a network
even if the device is not directly connected to the controller) and the Normal Inclusion mechanisms.
If the device is not included into a Z-Wave network, a single click on the (B) button or on the external switch
will launch the process of traditional inclusion. If the device inclusion procedure does not start within 2 seconds,
the Network Wide Inclusion network will be launched lasting a variable amount of time between 15-30 seconds.
INFO: Through the inclusion procedure, activated with a single click on the external switch2, the system
determines the type of external switch (see parameter No. 62).
Excluding the device from a Z-Wave network
Only a controller can remove a device from the network. WiDom Energy Driven Switch is compatible with all
Z-Wave certified controllers. After the exclusion procedure has been activated by the controller, the device can
be removed, putting it in Exclusion Mode by three consecutive clicks on the (B) button or on the external switch,
when available.
Associations
WiDom Energy Driven Switch can control other devices such as relays or dimmers. WiDom Energy Driven
Switch supports three association groups, each of which supports the association of up to 8 devices:
Basic Report, Device
Reset Locally
Notification, Meter
Report, Multilevel
Sensor: Power Report
Devices to receive
notifications on: status
changes; energy and
power levels; device local
reset
Devices controlled by the
Up Power event
Devices controlled by the
Down Power event
2Applicable only to version S.
