WiebeTech FSMR User manual

FSMR User Manual - 1 -
ne
Forensic Small Media Reader™
USER’S MANUAL
Revised August 27, 2007
Features
•This 3.5″adapter will fit into any standard floppy
disk bay for convenient access right in your
computer.
•Use FSMR to access multiple media types in o
unit. FSMR can read 5 different media types
(MMC/SD (MultiMedia Card/Secure Digital),
SmartMedia, CompactFlash and Sony Memory
Sticks).
•This unit has a unique self-regulating icon that
will change instantly depending on which media
type is being accessed.
•The LED indicator not only shows power status
but will also signal file transfer status.
Installation Instructions
1. Check the accessories with your FSMR. Please contact WiebeTech if any parts are missing or
damaged. The box should contain the following items:
Accessories Quantity
FSMR unit 1
Manual and Warranty Info (on CD)
2. Take a moment to familiarize yourself with the parts of the FSMR. This will help you to better
understand the remaining instructions.
Front View
Jum
p
ers
Molex Power Connection
IDE Connection Port
LED Indicato
r
SmartMedia Media PortMMC & SD Media Port
Memory Stick Media Port
Com
p
actFlash Media Port
Rear View

WiebeTech LLC
FSMR User Manual - 2 -
3. To use FSMR internally or externally plug in the IDE ribbon cable into
the IDE connection port. If you are installing FSMR inside a computer, the
other end of the ribbon cable will need to be plugged into an empty IDE slot on
the motherboard. If you are using FSMR externally, connect it to your
DriveDock as shown to the right. Connect the dock to your computer via USB.
Also, if there is a plastic jumper on the back of the FSMR, remove it.
4. For internal use mount FSMR in your computer. In an open 3.5″bay in your computer, install
FSMR as you would an internal floppy disk drive. A bracket will be needed to install into a 5.25″bay.
5. Your FSMR is ready to use. Now just insert one of any of the five media types that you need to
access.
Media Types Supported by FSMR
Media Name Maximum Capacity Support
Compact Type I/II Unlimited Capacity, 8MB to 8GB
IBM Microdrive 340MB and 1GB
Hitachi Microdrive 2GB, 4GB and 6GB
Magicstor CF+ Type II 2.2GB, 4GB and 6GB
Seagate ST1 Drive 5GB
Memory Stick PRO 256MB to 32GB (*4GB is highest
confirmed)
Memory Stick Classic 4MB to 256MB
Memory Stick MG 4MB to 128MB
Memory Stick DUO 4MB to 512MB
Memory Stick High Speed 4MB to 256MB
Memory Stick ROM 4MB to 128MB
SmartMedia 4MB to 128MB
SmartMedia ROM 4MB to 128MB
MultiMediaCard Unlimited Capacity, 4MB to 256MB
MMCPLUS Media 512MB to 2GB
RS-MulitMediaCard 64MB to 1GB
Secure Digital Card Unlimited Capacity, 8MB to 4GB
MiniSD Unlimited Capacity, 16MB to 256MB
xD Picture Card (through SM to xD adapter or
by using CF to xD adapter)
16MB to 1G

WiebeTech LLC
FSMR User Manual - 3 -
Usage with Windows Computers
Compatibility
The FSMR is compatible with Windows XP. No drivers are needed on this operating system.
Ejecting Volumes
To eject the flash media, click the green arrow icon on the task bar and ok the prompt to “Safely Remove”
the device. Windows will indicate when to remove the media from FSMR.
(Windows XP)
Technical Specifications
Product name/code: FSMR
Media Types Supported: MultiMediaCard, Secure Digital, SmartMedia, CompactFlash, 1.0-inch
MicroDrives, and Sony Memory Sticks
Operating System
Requirements: Windows 2K, XP, Server 2003
Operating Temperature: 50 – 85° Fahrenheit (10 – 30° Celsius)
Operating Humidity: 5% to 95%, noncondensing
Safety Certification: CE/FCC
Shipping Weights: 1 pound
Dimensions: (101.6 W x 134.62 L x 25.4 H)
Warranty:
2-year limited warranty. See warranty statement for details and limitations.
WiebeTech offers free phone support for 90 days after purchase (1-866-
744-8722). After 90 days, email support is available at
[email protected].
Forensic Small Media Reader is a trademark of WiebeTech LLC. Other marks are the property of their respective
owners.
© 2007 WiebeTech LLC. All rights reserved.
FCC Compliance Statement: “This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.”
Tested to comply
with FCC standards
FOR HOME OR OFFICE USE
In the event that you experience Radio Frequency Interference, you should take the following steps to resolve the problem:
1) Ensure that your unit is plugged into a grounded electrical outlet.
2) Use a data cable with RFI reducing ferrites on each end.
3) Use a power supply with an RFI reducing ferrite approximately 5 inches from the DC plug.
If you have any questions or problems, please contact [email protected] for technical support. If you are
interested in purchasing more WiebeTech products, check our website or contact [e-mail]. We
appreciate being able to serve you!
