WiFi Solutions WS2419G-NF User manual

Model
WS2419G
-
N
F
Assembly Guide
Actual Test Chamber measurement
Parabolic Dish antenna with a grid reflector for minimum weight and wind resistance. This grid
dish represents the most signal gain and directivity in a economical priced antenna. (The next
step up is 2x weight, size and cost to obtain another 3dB of gain). This antenna provides an
amazing 19dBi rating (tested 18.77dBi lab at TruGain) with a very narrow pinpoint signal beam
just under 13 degrees wide.
This is the antenna which can provide many miles of signal propagation (provided proper height,
obstruction clearance, power and antenna on other end). This antenna has a grid made of plated
steel rods then electrostatic powder coated in a light gray finish. The feedhorn arm is a 12” long
support for the dipole/reflector assembly. Easy to mount on a suitable antenna mast, water pipe
or other support tube. Adjustable elevation angle is possible via the U-bolt mounting system.
SPECIFICATIONS:
Frequency Range
Gain
VSWR
Beamwidth, -3dB point
Beamwidth, -3dB point
Cable Length, Type
Connector
Mounting Bracket,
Wind Rating
Dimensions
Weight
Packed 1 Unit
2.40-2.49GHz
19dBi Rated, 18.77dBi Actual
1.2:1 average
Azimuth 12.7 degrees
Elevation 12.0 degrees
10" RG-8
N-type Female
U-Bolts from 1" - 2" mast
120 MPH
24" round grid
3.2 lbs. (4.8 Lbs boxed)
Box 24.5x24x4” Shipping box
FOR QUESTIONS:
CONTACT
US
:
WiFi Solutions
Phone: [phone]
Office Hrs: 9:00 am - 6:00 pm
EASTERN TIME.
E-mail: [e-mail]

B
G
C
D
E
Best Tools:
10mm Wrench, Socket and
Nutdriver. Phillips Screwdriver.
Alternate: Adjustable Wrench, Pliers.
What’s In The Box: Round Grid,
Feedhorn Box, Hardware Pack
Unpacking your parts and checking to
be complete. Hardware: 4 each bolt,
nut, flat washer, lock washer. 2 Ubolts
4 nuts, washers, lockwashers.
2 Clamps, Bracket, reflector.
A
F
A
-
Feedhorn
Arm
B
-
Feedhorn
C-L-bracket
D-Clamps E-hardware F-Reflector
G-U-Bolts w/nuts-washers
Place feed cable though center hole.
Be sure bracket wings and feed horn
are parallel to grid rods as shown.
Insert 2 bolts to hold arm.
Rear view of the 2 bolts before
bracket is added.
Add bracket as shown then install 2
flat washers, lock washers and nuts.
Hand tighten.
Add the other 2 bolts, washers,
lock washers and nuts. Shown
already installed. Tighten well.
Nuts and washers come pre-installed
on the U-Bolts. Remove them to
prepare for next step.
Push the U-bolts through the clamp
holes then through the matching
holes on the main bracket as shown.
Bracket shown ready to install on a
mast or pipe support. Extra holes
permit many mounting and angle
options.
Small screw on the feedhorn housing
arrives pre-installed.
Remove the screw using
your screwdriver.
Set the reflector in position as
shown and re-install the small screw.
Tighten snugly.
Feedhorn with reflector is complete.
Beware Of Power Lines! You Can Be
Killed If The Mast Or Antenna Comes
In Contact With High Voltage Lines!
Notice: Proper Aiming!
It is very high gain however a very narrow
beam. It must be precisely pointed to other
radio. All signals outside the beam are much
lower than a small rubber antenna due to
great signal rejection in all unwanted
directions.
