Wiiboox LUCKYBOT E SCM User manual

WIIBOOX LUCKYBOT
E_SCM
Instruction Manual

1.Introduction of the module
2.How to use E_SCM
E_SCM is the Signal Converter Module for
E-axis. With the E_SCM, users would no
need to disassemble the motherboard of the
3d printer to connect the E-axis port when
installing LuckyBot.
The E_SCM contains four groups of jump
caps that allow the user to select the
appropriate jump caps for different printers.
E_ SCM contains four groups of jumping
caps (H1/ H2/ H3 /H4), and the jumping
method of each group is the same;
01

Take H3 as an example to explain the four
jumping methods:
Each group of jump caps contains four
connection modes of CM-A，B, C and D.
When the four groups of jump caps are used,
it's not allowed to have any two or more
groups of jump caps jumping to the same
connection.
a. E_SCM for Creality Ender-3 series
（Factory default settings);
CM-A CM-C CM-B CM-D
02
3.Several modes
Notes:

03
Thanks for your purchase. Please feel free to
contact us at [email protected] if you have
any problems during the installation process.
We're always here to help you.
Thank you for choosing WIIBOOX Products,
Best Regards!
b. E_SCM for GEEETECH A10 Pro;
