Wilko WL14 User manual

WL14 multiposition TV
wall mount to 23" 15kg
assembly instructions
464426 rev00

Please Read
Retain all packaging in case the bracket needs to be returned.
Contents may vary from photography/ Illustrations.
You will not need all these parts, so expect there to be some left over depending upon the
specification of your TV.
This product is intended for indoor use only. Use of this product outdoors could lead to failure and
personal injury.
It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and
void of any services (eg gas, electricity, water etc).
Periodically check all nuts and bolts are tight.
Tools Recommended
Ø3mm (1/8")Ø8mm (5/16")
Boxed Parts
A
B
C
D
E
F
x4
x4
x4
x2
x2
x1
M4 x 12mm

Top
Step 1
Step 2
TV TV TV
A
B
A
B
C
Ax4
M4 x 12mm
Top
Bx4
Cx4
i
ii

Step 3 Solid Wall Fixing
Ex2
Dx2
Remove dust from hole
Ø8mm (5/16")
65mm (2 ")9/16

Step 3 Wood Stud Fixing
Ensure bracket is in the centre of the wood stud
Ø3mm (1/8")
Dx2
50mm (2")

Step 4

Shop online wilko.com
PROMISE
Shop with confidence. If not completely satisfied, simply return this product with the receipt,
within 28 days, and we’ll gladly exchange it or refund you. That’s a promise.
This does not affect your statutory rights.
Produced in China for Wilkinson, Roebuck Way, Manton Wood, Worksop,
Nottinghamshire, S80 3YY
Careline 0333 320 7024
All measurements are approximate. Images are for illustration only.
Step 5
Optional
Lock tilt
Cable Management
Fx1
