Sy S T E M SP E C i F i C AT i O N S
TR A N S M i T T E R , MO d E L PPA T36
Dimensions: 4.1” L x 2.8” W x 1.1” H (104 mm x 71 mm x 28 mm)
Weight: 2.9 oz (82 g), no batteries
Color: Black, shatter-resistant PC/ABS plastic
Battery Type: Two (2) AA 1.5 V non-rechargeable Alkaline batteries (BAT 001), 70 mA nominal current
drain, 30 hours approx. life or
Two (2) AA 1.5 V NiMH rechargeable batteries (BAT 026), 70 mA nominal current drain, 20
hours per charge approx., recharges in 14–16 hours, uses CHG 3502 or CHG 3512 Charger
Operating Freq’s: Selectable, 16 channels, 72.1 – 75.9 MHz* (channels 1-8 correspond with R35-8 receiver chan-
nels)
Stability: ± .005%, frequency synthesized, crystal reference, PLL
Modulation: Wide-band FM, 75 kHz pk, 75 µS pre-emphasis
RF Output: 80 mV/m at 3 m (max. allowed by FCC rules)
Freq Response: 200 Hz to 13 kHz, ± 3 dB at 1% max. THD
Signal-to-Noise Ratio: 65 dB (typical) transmitted
Transmit Antenna: Integral with microphone cord
Microphone: Electret type, 3.5 mm mono phone plug
External Controls: Momentary push button: push and hold 3 seconds for power On/Off, push and release for
microphone mute On/Off; Rotary sixteen channel switch (with internal channel lock switch)
Mic Input: 3.5 mm mono phone jack with electret mic bias, internal adjustable gain with 25 dB range
Aux Input: 2.5 mm stereo phone jack, internal adjustable gain with 60 dB range
Audio Compression: 1:1 or 2:1 ratio selected with internal slide switch
Compatible Receivers: PFM R31, PFM R32, PFM R33, PFM R36, PPA R35, PPA R35-8, PPA R1600
Approvals/Directives: FCC, Industry Canada, RoHS, WEEE
Warranty: 5 years, parts and labor (90 days on accessories)
Note: FCC regulations, section 15.21, requires the user to comply with the rules of transmitter opera-
tion. Any changes or modications made by the user not expressly approved for compliance
may result in the loss of all privileges and authority to operate the equipment
RE C E i v E R , MO d E L PPA R35
Dimensions: 4.1” L x 2.8” W x 1.1” H (104 mm x 71 mm x 28 mm)
Weight: 4.5 oz (127 g) w/ batteries
Color: Black
Battery Type: Two (2) AA non-rechargeable alkaline batteries (BAT 001), approx. 100 hours battery life or
Two (2) AA rechargeable NiMH batteries (BAT 026), 1400 mAh, approx 56 hours battery life
Current Consumption: Nominal 40 mA
Operating Freq.: Pre-tuned, adjustable, 72 MHz-76 MHz *
Intermediate Freq.: 75 kHz
FM Deviation: 75 kHz
De-Emphasis: 75 µS
LED Indicator Power: Green; Low Battery: Red
AFC Range: ± 120 kHz
Sensitivity: 2 µV at 12 dB Sinad with squelch defeated
Input Overload: 20 mV
Frequency Response: 100 Hz to 15 kHz, ± 3 dB
Signal-to-Noise Ratio: 65 dB at 10 µV
Receive Antenna: Integral with earphone/headphone cord
Audio Output: 35 mW, max. at 16 Ω
Output Connector: 3.5 mm mono phone jack
Earphone: Earbud-type with foam cushion, 3.5 mm plug, 32 Ω
Notes: The R35 Receiver can be eld tuned to any of 16 wideband
channels using the PLT 005 Tuning Tool.
Approvals: FCC, Industry Canada, RoHS, WEEE
Warranty: Five years, parts and labor. 90 days on cords, earphones,
headphones, batteries and other accessories
*DISCLAIMER: FCC RULES LIMIT USE OF THIS EQUIPMENT TO AUDITORY ASSISTANCE.
Note: Specications subject to change without notice.
