Williams ALLEGRO III IN-HOME PACK User manual

WILLIAMS ALLEGRO III IN-HOME PACK
ASSEMBLY INSTRUCTIONS
Congratulations! You have just purchased a state of the art digital piano that provides remarkable acoustic
sound and feel. We recommend that you read through this assembly manual carefully, so you can get the
most enjoyment from your new piano.
BOX CONTENTS
The Williams Allegro III In-Home Pack should contain the following:
Piano-style Sustain PedalAllegro III Digital Piano
Piano BenchWooden Stand
21523900 Williams Allegro III Pack manual.indd 121523900 Williams Allegro III Pack manual.indd 1 6/10/21 12:57 PM6/10/21 12:57 PM

WILLIAMSPIANOS.COM
Stand Assembly
Begin assembling the stand
by attaching the legs to the
crosspiece.
The overall view of the
assembly image is on the right.
ASSEMBLY INSTRUCTIONS
Stand Parts and Hardware
A. M6 Barrel Nuts (x4)
B. M6x40 Bolt Screws (x4)
C. Screw Caps (x8)
D. M5x25 Hand Bolts (x4)
E. Phillips head screwdriver
(Not included)
F. Extra hardware
(1) Crosspiece
(2) Left Leg (3) Right Leg
B
B
C
C
A
A
(2)
(1)
(3)
21523900 Williams Allegro III Pack manual.indd 221523900 Williams Allegro III Pack manual.indd 2 6/10/21 12:57 PM6/10/21 12:57 PM

WILLIAMSPIANOS.COM
ASSEMBLY INSTRUCTIONS
D
Screw holes
A
Attaching Legs to Crosspiece
Step 1
Put the barrel nut (A) into the crosspiece as
shown, making sure to align barrel nut threads
with screw hole.
B
A
Step 2
Tighten until the crosspiece is ush with the leg
brackets and the legs are rmly attached.
(Please make sure to properly fasten the bolt (B)
through the leg and into the barrel nut. To avoid any
cross threading use two screw drivers, one to hold
the barrel nut steady and one to screw the bolt into
the barrel nut.)
C
CC
C
Finishing Touches to Stand Assembly
Step 3
After attaching legs to the crosspiece, place screw
caps (C) over all of the 8 tightened bolt screws.
Attaching Piano to Stand
Final Step
Lift the piano onto its stand and align the holes in the
stand legs with the holes on bottom of the piano.
Insert the hand bolts (D) into each hole to attach the
piano to its stand as shown in the insert picture.
21523900 Williams Allegro III Pack manual.indd 321523900 Williams Allegro III Pack manual.indd 3 6/10/21 12:57 PM6/10/21 12:57 PM

ASSEMBLY INSTRUCTIONS
Bench Assembly
1. Insert part A into the side of the
bench leg, then drop a wooden
dowel (C) into the top of the legs.
The dowel will go through the hole
in part A to keep it from spinning.
2. Attach the washer, lock washer,
and nut (B) to bolt (A). Tighten
using the included wrench (D).
Repeat for the other three legs.
Final Step
1. Plug the included sustain pedal into the
“Sustain” jack on the back of the piano
2. Please refer to the included Allegro III
Reference Manual for operation of the rest
of the piano.
1206-21523900
Dowel Pin (x4)
C.
A. M8 Bolts (x4)
B1. Flat Washer (1.8+_0.2) (x4)
B3. M8 Nut (x4)
B2. Spring Washer (x4)
D. Wrench (x1)
